NETGEAR WNCE2001 - Ethernet to Wireless Adapter Gebrauchsanweisung

350 East Plumeria Drive

San Jose, CA 95134

USA

September 2010

202-10598-01

v1.0

Universal WiFi Internet

Adapter (WNCE2001)

User Manual

Universal WiFi Internet Adapter WNCE2001

No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated

into any language in any form or by any means without the written permission of NETGEAR, Inc.

Technical Support

Thank you for choosing NETGEAR. To register your product, get the latest product updates, or get support online,

visit us at http://support.netgear.com.

Phone (US & Canada only): 1-888-NETGEAR

Phone (Other Countries): See Support information card.

Trademarks

NETGEAR, the NETGEAR logo, ReadyNAS, ProSafe, Smart Wizard, Auto Uplink, X-RAID2, and NeoTV are

trademarks or registered trademarks of NETGEAR, Inc. Microsoft, Windows, Windows NT, and Vista are

registered trademarks of Microsoft Corporation. Other brand and product names are registered trademarks or

trademarks of their respective holders.

Statement of Conditions

To improve internal design, operational function, and/or reliability, NETGEAR reserves the right to make changes

to the products described in this document without notice. NETGEAR does not assume any liability that may occur

due to the use, or application of, the product(s) or circuit layout(s) described herein.

Contents |3

Table of Contents

Chapter 1 Getting Started

Hardware Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Top Panel with LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Power Connection Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Preparing to Change Your Internet Adapter Settings. . . . . . . . . . . . . . . . . . 6

Using the Smart Wizard to Change the Setup . . . . . . . . . . . . . . . . . . . . . . .8

Chapter 2 Advanced Settings

Device Status Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Show Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

DHCP Connection Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Managing Your Configuration Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Backing Up Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Restoring Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Erasing the Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Upgrading the Firmware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Advanced Wireless Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Using Push 'N' Connect (WPS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Chapter 3 Troubleshooting

Using the USB Power Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Connecting to http://www.mywifiext.net . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Connecting to Wireless Networks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Appendix A Factory Settings and Technical Specifications

Factory Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Technical Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Appendix B Related Documents

Appendix C Notification of Compliance

Chapter 1. Getting Started |4

1. Getting Started

Hardware Features

Top Panel with LEDs

Top Panel LED Activity

Power • Solid green: Unit is powered on and operating

normally.

• Solid or blinking amber: Unit is busy.

• Solid red:yy Power source does not provide enough

power.

• Off: Unit is not powered on.

LAN • On: The Ethernet cable is connected.

• Off: No Ethernet cable is connected.

WLAN • Green: The connection to the router is excellent.

• Amber: The connection to the router is good.

• Red: The connection to the router is poor.

• Off: No wireless connection.

Rear Panel

Ethernet port Power

Reset WPS

button

Figure 1. Rear panel

Chapter 1. Getting Started |5

Universal WiFi Internet Adapter WNCE2001

Power Connection Options

Depending on the cable that you received with your product, you might need a plug converter

to connect the Internet adapter to the power adapter. If it is needed, the plug converter is

included in the box.

Figure 2. Plug converter

You can power on your Internet adapter using either of these methods:

• Method 1: Connect the Internet adapter to an electrical outlet with the included power

adapter.

Figure 3. Power adapter

• Method 2: Connect the Internet adapter to a USB port on a nearby computer or device

with the USB power cable:

Figure 4. USB power cable

Make sure that the device where you connect the USB power cable is powered on. Some

USB ports on consumer electronic devices cannot provide the power that the Internet

adapter requires. In such cases, the power LED turns solid red and the Internet adapter

may reset itself or turn itself off. If this happens, try connecting the USB cable to a

different device, or use the Internet adapter power adapter instead.

6|Chapter 1. Getting Started

Universal WiFi Internet Adapter WNCE2001

Installation

The Universal WiFi Internet Adapter (WNCE2001) Installation Guide included in the package,

explains how to install your Internet adapter. The steps are summarized in this section.

1. You use a computer to set up the Internet adapter. During setup, make sure that your

computer is not connected to a router. You can restore the connection after the Internet

adapter installation is complete.

• Disconnect the Ethernet cable from your computer if you use it for a wired network

connection.

• If your computer is wirelessly connected to a network, stop your wireless connection.

2. Connect the Internet adapter.

• Use an Ethernet cable (included) to connect the Internet adapter to your computer.

• Use either the USB power cable or the power adapter to provide power to the Internet

adapter. (See Power Connection Options on page 5.)

3. Open your Internet browser. It automatically displays the setup page. Follow the instructions

on the setup page.

4. Disconnect the Ethernet and USB cables from your computer.

5. Connect the Internet adapter to your TV, Box, or Blu-ray player.

If your device doesn’t have a USB port, then use the power adapter cable that came with

your Internet adapter and plug it into an electrical outlet.

6. Congratulations! Your installation is complete. You can return your computer to its usual set

up and begin using the Internet adapter.

Preparing to Change Your Internet Adapter Settings

If you want to change the settings for the Internet adapter after installation, then you need to

connect it to a computer while you are making changes.

1. Connect your Internet adapter to a computer with an Ethernet cable.

2. Connect either the USB power cable or the power adapter cable that came in the product

package to the rear panel of your Internet adapter.

Chapter 1. Getting Started |7

Universal WiFi Internet Adapter WNCE2001

To supply power to your Internet adapter, use whichever method is more convenient for

you. See Power Connection Options on page 5.

Figure 5. Connecting the Internet adapter to a laptop

3. Launch an Internet browser such as Mozilla Firefox or Microsoft Internet Explorer. In the

address field, enter http://www.mywifiext.net.

Unless you changed the settings on the Firmware Upgrade screen (see Upgrading the

Firmware on page 15), the software automatically checks for new firmware at the

NETGEAR website. Then the following screen displays:

The Device Status screen shows what the current settings are for the Internet adapter. A

menu in the left pane allows you to view or change the settings.

8|Chapter 1. Getting Started

Universal WiFi Internet Adapter WNCE2001

Using the Smart Wizard to Change the Setup

The Smart Wizard helps you set up your Internet adapter. For information about advanced

configuration, see Chapter 2, Advanced Settings.

The Universal WiFi Internet Adapter (WNCE2001) Installation Guide included in the package,

explains how to install your Internet adapter. During installation, when you launch your

Internet browser, the Smart Wizard automatically displays.

After installation, to use the Smart Wizard again:

1. Connect the Internet adapter to a computer and go to http://www.mywifiext.net as

described in Preparing to Change Your Internet Adapter Settings on page 6.

2. From the menu on the left, select Setup Wizard. The following screen displays:

This is the same Smart Wizard that displays during installation as described in the

Installation Guide.

3. You can select a network from the list, or select the Manually input my wireless SSID radio

button. Click Continue. When you have chosen the network that you want to join, the next

wizard screen displays. Follow the onscreen prompts to connect to a wireless network:

4. When the Review Settings screen displays, click Finish. If you are done making changes,

disconnect your Internet adapter from your computer, and reconnect it to the device on

which you want to use it.

Chapter 2. Advanced Settings |9

2. Advanced Settings

To change advanced settings, connect the Internet adapter to your computer and use your

Internet browser to go to http://www.mywifiext.net as described in Preparing to Change Your

Internet Adapter Settings on page 6.

Device Status Screen

When you connect to http:/www.mywifiext.net, after the automatic firmware check, the

Device Status screen displays:

This screen shows the current settings and the status of your Internet adapter.

• You can click Show Statistics to see device performance statistics such as the number

of packets sent and number of packets received for each port. See Show Statistics on

page 11.

• Click DHCP Status to see information about your current DHCP connection. See DHCP

Connection Status on page 12.

• The following table describes the fields in the Device Status screen.

Table 1. Device Status Settings

Field Description

Device Status Hardware Version The hardware version of the Internet adapter.

Firmware Version The current firmware version of the Internet adapter.

If you upgrade the firmware, this field changes.

GUI Language Version The language version running on the Internet

adapter. If you upgrade the firmware, this field

changes.

Wireless Connection

Status

Wireless Connection The status of your wireless connection (connected or

disconnected).

Link Rate The actual transmission (Tx) and receive (Rx) link

rate in the current wireless connection

Name (SSID) Your Internet adapter is set up to connect to this

SSID, also called the wireless name.

Region The location of the Internet adapter.

Channel The wireless channel of the network.

Security Type The security setting for the wireless network.

LAN Port MAC Address The physical address of the Internet adapter, as

seen from the local area network (LAN).

IP Address The IP address of the Internet adapter. The default is

192.168.1.251.

DHCP Server Identifies the network DHCP server on the wireless

network.

IP Subnet Mask The IP subnet mask associated with the LAN IP

address of the Internet adapter. The default is

255.255.255.0.

Gateway IP Address The IP address of the wireless network gateway.

DNS Server The IP address of the Domain Name Server (DNS)

of the wireless network.

10 |Chapter 2. Advanced Settings

Universal WiFi Internet Adapter WNCE2001

Andere Handbücher für WNCE2001 - Ethernet to Wireless Adapter

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere NETGEAR Adapter Handbücher

NETGEAR

NETGEAR PL1000 Bedienungsanleitung

NETGEAR

NETGEAR AX741 - ProSafe Expansion Module Bedienungsanleitung

NETGEAR

NETGEAR WNA3100 - Wireless-N 300 USB Adapter Bedienungsanleitung

NETGEAR

NETGEAR WN511B - Next Wireless Pc Card Bedienungsanleitung

NETGEAR

NETGEAR WPN111 - RangeMax Wireless USB 2.0 Adapter Bedienungsanleitung

NETGEAR

NETGEAR POE101 Bedienungsanleitung

NETGEAR

NETGEAR XET1001 - Powerline Network Adapter Bedienungsanleitung

NETGEAR

NETGEAR XAV6501 Bedienungsanleitung

NETGEAR

NETGEAR XAV2001 - Powerline AV Ethernet Adapter Bedienungsanleitung

NETGEAR

NETGEAR WG111T - 108 Mbps Wireless USB 2.0 Adapter Bedienungsanleitung

NETGEAR

NETGEAR RangeMax WN511T Bedienungsanleitung

NETGEAR

NETGEAR HDX101 - Powerline HD EN Adapter Bridge Bedienungsanleitung

NETGEAR

NETGEAR PTV1000 - Push2TV - TV Adapter Bedienungsanleitung

NETGEAR

NETGEAR XAVB5501 Bedienungsanleitung

NETGEAR

NETGEAR HDX111 - Powerline HD Plus Ethernet Adapter Bedienungsanleitung

NETGEAR

NETGEAR WN511B - Next Wireless Pc Card Bedienungsanleitung

NETGEAR

NETGEAR XAV1301v1/XAVB1301v1 Bedienungsanleitung

NETGEAR

NETGEAR XAVT5601 Bedienungsanleitung

NETGEAR

NETGEAR Powerline PLP2000 Bedienungsanleitung

NETGEAR

NETGEAR MA311 - 802.11b Wireless PCI Adapter Bedienungsanleitung

NETGEAR

NETGEAR WAB501 - 802.11a/b Dual Band PC Card Bedienungsanleitung

NETGEAR

NETGEAR HDXB101-100NAS Technisches Datenblatt

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Bedienungsanleitung

NETGEAR

NETGEAR MA111v2 - 802.11b Wireless USB Adapter Bedienungsanleitung

Beliebte Adapter Handbücher anderer Marken

PCB Piezotronics

PCB Piezotronics 090B274 Bedienungsanleitung

Auvidea

Auvidea J20 Produkthandbuch

Gossen MetraWatt

Gossen MetraWatt AT3-III E Bedienungsanleitung

Akribis

Akribis ITF-21-BISS-MIT Bedienungsanleitung

Tenda

Tenda W54U Bedienungsanleitung

ROHO

ROHO AGILITY Bedienungsanleitung

PROLiNK

PROLiNK WN2001 Bedienungsanleitung

Hawking

Hawking HUF2 Bedienungsanleitung

Airlink101

Airlink101 AWLC4030 Bedienungsanleitung

Philips

Philips SWA4554S/10 Bedienungsanleitung

JVC

JVC TS-C9D2B Gebrauchsanweisung

D-Link

D-Link DWA-121 Bedienungsanleitung

Philips

Philips SWA2037 Bedienungsanleitung

Basalte

Basalte 0610-20 Bedienungsanleitung

Yealink

Yealink EHS40 Bedienungsanleitung

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Bedienungsanleitung

RCA

RCA AH57R Bedienungsanleitung

Koolatron

Koolatron AC16 Bedienungsanleitung
