PARAMETER SETTINGS
Under power o mode, to access or modify parameter settings , please long press and buttons simultaneously for ~8 seconds until
the MENU appear showing 01 which is menu 1. Each press of the button will go to the next MENU.
Menu Description Range Default
01 Temp. Offset -8°C ~ 8°C 0
02 Set Point Max. 5°C ~ 80°C 35°C
03 Set Point Min. 5°C ~ 80°C 5°C
04 Sensor Select
ROOM
FLOOR
ROOM + FLOOR
05 Frost Protection Temp. 5°C ~15°C 5°C
06 Surface Temp. Display Read Only
07 High Temp. Protection 20°C ~
80°C 32°C
11 Reset rE (Yes)
12 Key lock 0 - off, 1 - on 0
14 OWD function ON/OFF select 0 - off, 1 - on 0
15 OWD Detect Time Select 2 ~ 30 mins 15 mins
16 OWD Drop temp. select (within detect time) 2 / 3 / 4°C 2°C
17 OWD Delay time select (Return to previous working
status) 10 ~ 60 mins 30 mins
18 The temp. diff to exit high protection mode 1°C ~ 3°C 1°C
19 External sensor temp. offset -8°C ~ 8°C 0
20 Energy optimisation 1: electric radiator 3: ceiling heating
2: heating panel 4: oor heating 1
22 Software version
WIRING DIAGRAM
MOUNTING
SPECIFICATION
Operating voltage: 230V AC, 50/60 Hz
Capacity: 3600W/16A
Standby consumption: 0.5W
Display: LCD White backlight
External Sensor: NTC 10kΩ @ 25°C
IP protection rating: IP 30
Housing: White ABS to UL94-5 re standard
Temperature settings: 5°C–80°C, 0.5°C
Accuracy: ± 0.5°C
PRG options: 5+1+1, four cycles each day
Housing dimensions: 86 mm × 88 mm × 18 mm
Relay inst. dimensions: Ø 65 mm diameter, standard
KEY-LOCK FUNCTION
In order to avoid unauthorised access (hotels, public areas, child room) you can activate the key lock function from parameter settings page 12. To
unlock your device long press the and buttons for ~5 seconds.
Electrical box recessed
into the wall
(65x 55mm) horizontal
screw locations
3600W / 16A
(heating)
external
sensor
230V / AC
