USER MANUAL
HD-EO
High Definition Electrical to Optical Converter
Network Electronics ASA
Thorøya
N-3204 Sandefjord, Norway
Phone: +47 33 48 99 99
Fax: +47 33 48 99 98
e-mail: [email protected]
www.network-electronics.com
HD-EO Rev. B
DATE: 13 August 2002
Network Electronics ASA, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: +47 33 48 99 99 – Fax: +47 33 48 99 98
Technical specifications are subject to be changed without notice.
2
Revision history
The latest version is always available in pdf-format on our web-site:
http://www.network-electronics.com/
Current revision of this document is the uppermost in the table below.
Revision Replaces Date Change Description
BA13.08.02 Printing errors
A09.08.02 Preliminary version
HD-EO Rev. B
DATE: 13 August 2002
Network Electronics ASA, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: +47 33 48 99 99 – Fax: +47 33 48 99 98
Technical specifications are subject to be changed without notice.
3
Index
1. General......................................................................................................................................................4
2. Specifications............................................................................................................................................5
3. Format Configuration.............................................................................................................................7
4. Connector module....................................................................................................................................8
4.1 Mounting the connector module..........................................................................................................8
4.2 Terminal format support......................................................................................................................9
5. Module status...........................................................................................................................................9
5.1 GPI ALARM – Module Status Outputs..............................................................................................10
4.2 Front Panel - Status Monitoring........................................................................................................11
6. Laser safety precautions........................................................................................................................12
Declaration of conformity with CE..........................................................................................................13
General environmental requirements for Network flashlink®equipment...........................................13
HD-EO Rev. B
DATE: 13 August 2002
Network Electronics ASA, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: +47 33 48 99 99 – Fax: +47 33 48 99 98
Technical specifications are subject to be changed without notice.
4
1. General
The flashlink HD-EO is a multi bit-rate electrical to optical converter module providing high
performance media conversion for various signal formats from 19.4Mbps up to 1485Mbps. This state of
the art unit offers Fabry-Perot laser technology with long wavelength on single mode fiber. Unmatched
signal accuracy, even in critical applications with pathological signal patterns makes the HD-EO the first
choice for all optical transport demands.
The HD-EO can transport all HD and SD signal formats in addition to DVB-ASI and SMPTE 310. It can
also perform signal reclocking, which is selectable on application. The optical output comes with a
sophisticated 1310nm F-P laser covering the demands of short and medium haul applications. The open
system platform of Network Electronics flashlink system allows easy interoperability with third party
fiber optical systems.
The electrical input is equipped with a multi rate cable equaliser providing an equalisation of typically
100m of high quality coax cable at 1485Mbps. A distribution amplifier with 2 outputs reduces the need
for additional DA’s (for DVB-ASI only one can be used).
Figure 1 - HD-EO – HD-SDI Electrical to Optical Converter for 1310nm
HD-EO Rev. B
DATE: 13 August 2002
Network Electronics ASA, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: +47 33 48 99 99 – Fax: +47 33 48 99 98
Technical specifications are subject to be changed without notice.
5
2. Specifications
Optical Output
Transmission circuit fiber: Single Mode
Light source: F-P laser
Optical power: -7.5dBm or –3dBm @1310nm
0dBm @ 1550nm (DFB laser)
Optical centre wavelength: 1310nm or 1550nm
Max. wavelength drift: +/- 20nm @
temp. range: 0 to +50 °C
Jitter (UI=Unit Interval): 0.135 UI max. @ 270Mbps
0.2 UI max. @ 1485Mbps
Connector return loss: >40dB w/SM fiber
Maximum reflected power: 4%
Connector: SC/UPC
Electrical
Power: +5V DC / 3W Max.
Control: Control system for access to setup and module status
with BITE (Built-In Test Equipment)
Electrical Input
Data rate NRZ: 19.4 to 1485 Mbps
Equalisation: Automatic
Cable equaliser and reclocker can be bypassed to
support bitrates down to 2Mbps.
Impedance: 75 ohm
Return loss: >15dB @ 1485MHz
Signal level: nom. 800mV
Connector: BNC
Electrical Output
Number of outputs: 2
Connector: BNC
Impedance: 75 ohm
Return loss: >15dB @ 1485MHz
Jitter: max 0.2UI
Peak to peak signal level: 0.8V ±0.1V
Signal polarity: 1 non inverting,
1 inverting
HD-EO Rev. B
DATE: 13 August 2002
Network Electronics ASA, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: +47 33 48 99 99 – Fax: +47 33 48 99 98
Technical specifications are subject to be changed without notice.
6
Standards
Supported standards for electrical and optical ports:
SMPTE: SMPTE 292, SMPTE259M, SMPTE297,
SMPTE305M, SMPTE310,
DVB-ASI: EN50083-9
HD-EO available in 3 versions:
Part number Wavelength Laser type Output power
HD-EO-13T -7.5dBm
HD-EO-13T -3dBm
HD-EO-15T 0dBm
1310nm
1310nm
1550nm
F-P
F-P
DFB
-7.5dBm
-3dBm
0dBm
HD-EO Rev. B
DATE: 13 August 2002
Network Electronics ASA, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: +47 33 48 99 99 – Fax: +47 33 48 99 98
Technical specifications are subject to be changed without notice.
7
3. Format Configuration
The HD-EO can support a number of different broadcast formats. The correct configuration can either be
set with a DIP switch or with the GYDA Control System. The layout of HD-EO is shown in the drawing
below with the DIP switch to the upper left position.
Figure 2 - HD-EO-13T board layout.
DIP switch configuration must be set according to the table below:
Switch # Label Function DIP=ON Function DIP=OFF Comment
1D/B Not in use Not in use Always in broadcast mode
2E/O Not in use Not in use Always E to O mode
3RCL Reclocker ON Reclocker Bypass Reclocker mode
4EQ Cable equaliser ON Cable equaliser Bypass Equaliser mode
5ASI DVB-ASI Reclocker
support SDI 177Mbps Reclocker
support Select ASI or 177Mbps
support
6GBE Not in use Not in use
7622 Not in use Not in use
8OVR Override GYDA control
Config. with DIP switch GYDA control
Config. with GYDA Select configuration from
GYDA
All DIP switches are off when pointing towards the release handle.
All clock rates for HD-SDI, SDI and DVB-ASI are automatically configured by the module itself.
HD-EO Rev. B
DATE: 13 August 2002
Network Electronics ASA, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: +47 33 48 99 99 – Fax: +47 33 48 99 98
Technical specifications are subject to be changed without notice.
8
4. Connector module
The HD-EO has a dedicated connector module: SDI-C1 (Rev.1 or later). This module is mounted at the
rear of the sub-rack. The module is shown in figure 3.
Figure 3 - Overview of the SDI-C1 connector module
In typical use a HD-EO / HD-OE module at each end will be used. The electrical input signal is connected
to the DIGITAL INPUT BNC on the transmitting HD-EO, and the electrical output is connected to the
DIGITAL OUTPUT 1 or DIGITAL OUTPUT 2 BNC on the receiving HD-OE. The fiber cable is
connected to the OPTICAL ports on HD-EO and HD-OE. Please note that DIGITAL OUTPUT 2 has an
inverted signal, so formats like DVB-ASI can not use be used on this output.
4.1 Mounting the connector module.
The details of how the connector module is mounted, is found in the user manual for the sub-rack frame
FR-2RU-10-2.
This manual is also available from our web site: http://www.network-electronics.com/
HD-EO Rev. B
DATE: 13 August 2002
Network Electronics ASA, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: +47 33 48 99 99 – Fax: +47 33 48 99 98
Technical specifications are subject to be changed without notice.
9
4.2 Terminal format support
The different input and output ports on HD-EO can support a number of formats. The table below shows
which signal formats are supported on the selected terminals.
Terminal format support:
Terminal Function Supported Format Mode
DIGITAL
INPUT Electrical Input HD-SDI, SDI, DVB-ASI,
SMPTE310, Transparent* Input
DIGITAL
OUTPUT 1 Electrical Output – None inverted
Reclocked DA output HD-SDI, SDI, DVB-ASI,
SMPTE310, Transparent* Output
DIGITAL
OUTPUT 2 Electrical Output – Inverted
Reclocked DA output HD-SDI, SDI, Transparent* Output
OPTICAL Optical Output (Transmitter) HD-SDI, SDI, DVB-ASI,
SMPTE310, Transparent* Output
GPI ALARM Open Collector Alarms Wired alarms OC
Output
* HD-EO has a “Transparent mode”. In this mode all reclockers are switched off and no jitter attenuation
will be performed. This mode may be used for non-standard or unsupported bit rates over shorter
distances and up to 1 Gbps.
5. Module status
The status of the module can be monitored in three ways.
1. GYDA System Controller (optional).
2. GPI at the rear of the sub-rack.
3. LED’s at the front of the sub-rack.
Of these three, the GPI and the LED’s are mounted on the module itself, whereas the GYDA System
Controller is a separate module giving detailed information on the card status. The functions of the GPI
and the LED’s are described in sections 5.1 and 5.2. The GYDA controller is described in a separate user
manual.
HD-EO Rev. B
DATE: 13 August 2002
Network Electronics ASA, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: +47 33 48 99 99 – Fax: +47 33 48 99 98
Technical specifications are subject to be changed without notice.
10
5.1 GPI ALARM – Module Status Outputs
These outputs can be used for wiring up alarms for third party control systems. The GPI outputs are open
collector outputs, sinking to ground when an alarm is triggered. The GPI connector is shown in figure 4.
Electrical Maximums for GPI outputs
Max current: 100mA
Max voltage: 30V
MR-TR module GPI pinning:
Signal Name Pin # Mode
Status General error status for the module. Pin 1 Open Collector
Laser Fail Laser Fail Alarm Pin 2 Open Collector
LOS Los Of Signal Pin 3 Open Collector
LOCK Reclocker out of Lock Pin 4 Open Collector
Ground 0 volt pin Pin 8 0V.
Figure 4 - GPI Outlet
