Air/water heat pump

NIBE F2120

NIBE F2120 is an inverter-controlled air/water heat pump

which represent a real breakthrough when it comes to

efficiency. With a seasonal performance factor in excess

of 5.0* , the heat pump provides more than five times as

much heat per year as an electric heater with the same

energy consumption. NIBE F2120 provides optimized

savings since the heat pump automatically adapts to your

home’s output requirements all year round.

NIBE F2120 has a class leading working range and deliver a supply tem-

perature of up to 65°C. Even at outdoor temperatures of as low as -25°C,

it still provides a supply temperature of up to 63°C, while the noise level

stays low. NIBE F2120 has three-phase connection, which simplifies

electrical installation.

Thanks to smart technology, the product gives you control over your

energy consumption and will be a key part of your connected home. The

efficient control system automatically adjusts the indoor climate for high

comfort, and you do nature a favour at the same time.

•Breakthrough in efficiency with a seasonal performance factor

of over 5.0.*

•Class leading working range, supply temperature of up to 65°C,

and 63°C at an outdoor temperature of -25°C.

•Low noise level, even at full output.

*NIBE F2120 has a rating of SCOP > 5.0 (Average climate, Low temperature) and SCOP

4.3 (Colder climate, Low temperature) in accordance with European standard EN

14825:2013, i.e. the standard for determining the reference seasonal performance

factor, SCOP. Applies to F2120-16 and -20.

Installation method

F2120 – a part of your climate system where F2120 is inten-

ded to be combined with one of the indoor modules VVM or

the control modules SMO.

Together with an indoor module, F2120 creates a complete

heating/cooling and hot water unit. Our flexible indoor

modules provide efficient heating and high hot water per-

formance. VVM indoor modules are complete with a smart

and user-friendly control system, hot water heater, addition-

al heat, self-regulating circulation pump, etc.

The control modules, SMO, offer a flexible system solution

that can be easily customised. For systems with SMO, differ-

ent components such as water heaters, additional heat and

other accessories can be selected to suit the installation's

requirements. Up to eight F2120 can be connected to a

SMO 40.

There is a wide range of system solutions and accessories

for NIBE indoor modules and control modules.

2 NIBE F2120

This is how NIBE F2120 works

COMPATIBLE INDOOR MODULES (VVM) AND CONTROL MODULES (SMO)

SMO S40VVM S320

XXF2120-16

XF2120-20

SMO 40SMO 20VVM 500VVM 310

XXXXF2120-16

XXXF2120-20

INDOOR MODULES

VVM S320

Enamel, 3x400 V

Part no. 069 206

VVM S320

Stainless steel, 3x230 V

Part no. 069 201

VVM S320

Stainless steel, 3x400 V

Part no. 069 196

APH

VVM 310

Stainless steel, 3x400 V

With integrated EMK 310

Part no. 069 084

VVM 310

Stainless steel, 3x400 V

Part no. 069 430

VVM 500

Stainless steel, 3x400 V

Part no. 069 400

CONTROL MODULES

SMO S40

Control module

Part no. 067 654

SMO 20

LEK

Control module

Part no. 067 224

SMO 40

LEK

Control module

Part no. 067 225

NIBE F2120 3

Principle of operation

Principle of operation with hot water and a heating system.

The heating medium side and the domestic hot water side

must be fitted with the necessary safety equipment in ac-

cordance with the applicable regulations.

SYMBOL KEY

MeaningSymbol

Shut-off valve

Tapping valve

Non-return valve

Circulation pump

Expansion vessel

Filterball

Pressure gauge

Safety valve

Trim valve

Reversing valve/shunt

Control module

Air/water heat pump

Radiator system

Domestic hot water

Water heater

-EB101-QM1

XL1

XL2

-EB101-QM40

-EB101-QZ2

-EB101-FL10

-EB101-RM1

Heating medium connection, supply (from F2120)XL1

Heating medium connection, return (to F2120)XL2

4 NIBE F2120

Transport

F2120 must be transported and stored vertically.

Ensure that the heat pump cannot fall over during transport.

Check that the heat pump has not been damaged during

transport.

LIFT FROM THE STREET TO THE SET UP

LOCATION

If the surface allows, the easiest method is to use a pallet

truck to move the heat pump to the installation area.

The centre of gravity is offset to one side (see print on the

packaging).

LEK

C:a 180 kg

Approx. 180 kg

If the heat pump needs to be transported across soft ground,

such as a lawn, we recommend using a crane truck that can

lift it to the installation location. When the heat pump is lifted

with a crane, the packaging must be intact.

If a crane truck cannot be used, the heat pump can be

transported on an extended sack truck. The heat pump must

be taken hold of from its heaviest side and two people are

required to lift it.

LIFT FROM THE PALLET TO FINAL POSITIONING

Before lifting remove the packaging and the securing strap

to the pallet.

Place lifting straps around each machine foot. Lifting from

the pallet to the base requires four persons, one for each

lifting strap.

Installation and positioning

•Place F2120 outdoors on a solid level base that can take

the weight, preferably a concrete foundation. If concrete

slabs are used they must rest on asphalt or shingle.

•The lower edge of the evaporator must not be lower than

the level of the average local snow depth. The base should

be at least 70 mm tall.

•F2120 should not be positioned next to noise sensitive

walls, for example, next to a bedroom.

•Also ensure that the placement does not inconvenience

the neighbours.

•F2120 must not be placed so that recirculation of the

outdoor air is possible. Recirculation entails reduced power

and impaired efficiency.

•The evaporator must be sheltered from direct wind / ,

which negatively affects the defrosting function. Place

F2120 protected from wind / against the evaporator.

•Small amounts of condensation water, as well as melt

water from defrosting, may be produced. Condensation

water must be led off to a drain or equivalent.

•Care must be exercised so that the heat pump is not

scratched during installation.

LEK

F2120

min 300 mm

LEK

F2120

LEK

min

70 mm

Do not place F2120 directly on the lawn or other non solid

surface.

NIBE F2120 5

Good to know about NIBE F2120

If there is a risk of snow slip from roof, a protective roof or

cover must be erected to protect the heat pump, pipes and

wiring.

Installation area

The distance between F2120 and the house wall must be at least 350 mm, but not more than 500 mm in locations that are

exposed to the wind. The free space above F2120 must be at least 1,000 mm. The free space in front must be at least

1,000 mm for any future servicing.

350 mm

Fritt utrymme bakom

Fritt utrymme framför

dock 1000 mm för ev. framtida service

Min. avstånd

vid användning

av flera F2300

600 mm

1000 mm

400 mm

Minimalt

fritt utrymme

600mm

Minimalt

fritt utrymme

Minimum free

space Minimum free space

Minimum distance during use

of several F2120

600 mm

At least 1,000

Free space behind*

350 – 500 mm

400 mm

Free space in front for any future servicing

* The space behind must not exceed 500 mm in locations that are exposed to the wind.

6 NIBE F2120

Supplied components

Local differences in the enclosed kit may occur. See relevant

installer manual for more information.

F2120-16, F2120-20

Filterball (G1 1/4").

LEK

2 x flexible pipes (DN25, G1 1/4")

with 4 x gaskets.

NIBE F2120 7

Inspection of the installation

Current regulations require the heating installation to be

inspected before it is commissioned. The inspection must

be carried out by a suitably qualified person and must be

documented. The above applies to closed heating systems.

If the heat pump is replaced, the installation must be inspec-

ted again.

Condensation water trough

The condensate drain pan collects and leads away the con-

densation water.

It is important for the heat pump’s function that the con-

densation water is led away and that the outlet for the

condensation water pipe is positioned so as to prevent

damage to the building. Condensation run-off should be

checked regularly, especially during the autumn. Clean if

necessary.

Pipe with heating cable for draining the condensate drip

tray is not included. To ensure the function, the accessory

KVR 11 should be used.

•The condensation water (up to 50 litres/24 hrs) that col-

lects in the trough should be routed away by a pipe to an

appropriate drain, it is recommended that the shortest

outdoor stretch possible is used.

•The section of the pipe that can be affected by frost must

be heated by the heating cable to prevent freezing.

Pipe with heating cable for draining the condensation

water trough is not included.

To ensure the function, the accessory KVR 11 should be

used.

•Route the pipe downward from the heat pump.

•The outlet of the condensation water pipe must be at a

depth that is frost free or alternatively indoors (with reser-

vation for local ordinances and regulations).

•Use a water trap for installations where air circulation may

occur in the condensation water pipe.

•The insulation must seal against the bottom of the con-

densation water trough.

DRAINAGE OF CONDENSATION

Stone caisson

LEK

Frostfritt djup

F2120

Frost proof

depth

If the house has a cellar the stone caisson must be posi-

tioned so that condensation water does not affect the house.

Otherwise the stone caisson can be positioned directly under

the heat pump.

Drain indoors

Water seal

The condensation water is lead to an indoor drain (subject

to local rules and regulations).

When routing pipes indoors, condensation water pipes must

be insulated against condensation.

Route the pipe downward from the heat pump.

The condensation water pipe must have a water seal to

prevent air circulation in the pipe.

8 NIBE F2120

Installation

Gutter drainage

LEK

F2120

Frostfritt

djup

Frost free

depth

Water seal

Route the pipe downward from the heat pump.

The condensation water pipe must have a water seal to

prevent air circulation in the pipe.

If none of the recommended alternatives is used good lead

off of condensation water must be assured.

Pipe connections

Pipe installation must be carried out in accordance with

current norms and directives.

The pipe dimension should not be less than the recommen-

ded pipe diameter according to the table. However, each

system must be dimensioned individually to manage the

recommended system flows.

MINIMUM SYSTEM FLOWS

The installation must be dimensioned to manage at least

the minimum defrosting flow at 100% pump operation, see

table.

Minimum re-

commended

pipe dimen-

sion (mm)

Minimum re-

commended

pipe dimen-

sion (DN)

Minimum flow

duringdefrost-

ing

(100% pump

speed (l/s)

Air/water

heat pump

28250.38

F2120-16

(3x400V)

35320.48

F2120-20

(3x400V)

An undersized system can result in damage to the product

and lead to malfunctions.

F2120 can only operate up to a return temperature of about

55 °C and an outgoing temperature of about 65 °C from the

heat pump.

F2120 is not equipped with shut-off valves on the heating

medium side, rather these must be installed to facilitate any

future servicing. The return temperature is limited by the

return line sensor.

WATER VOLUMES

Depending on the size of your F2120, an available water

volume is required to prevent short operating times and to

enable defrosting. For the optimum operation of F2120, a

minimum available water volume of 10 litres multiplied by

the size number is recommended. E.g. F2120-12: 10 litres x

12 = 120 litres. This applies individually to heating and cooling

systems.

NIBE F2120 9

PIPE COUPLING, HEATING MEDIUM

You can find a list of compatible products in the section

"Compatible indoor modules (VVM) and control modules

(SMO)".

There is a difference between connection to a control

module compared with connection to an indoor module.

See the Installer Manual for the indoor module/control

module.

Vent the heat pump by the "heating medium supply" con-

nection (XL1) using the venting nipple on the enclosed flex-

ible hose.

Install as follows:

•expansion vessel

•pressure gauge

•safety valves

•drain valve

For draining the heat pump during prolonged power fail-

ures.

•non-return valve

Installations with only one heat pump: a non-return valve

is only required in those cases where the placement of

the products in relation to each other can cause self-cir-

culation.

Cascade installations: each heat pump must be fitted with

a non-return valve.

•charge pump

•shut-off valve

To facilitate any future servicing.

•enclosed filterball

Installed before connection "heating medium return" (the

lower connection) on the vacuum pump.

•reversing valve.

When connecting to the control module, and if the system

is to be able to work with both the climate system and the

hot water heater.

•trim valve

When connecting to control module and hot water heater.

Vent the heat pump by the "heating medium supply" con-

nection (XL1) using the venting nipple on the enclosed flex-

ible hose.

XL1

XL2

The image shows connection to the control module.

Charge pump

The charge pump (not included in the product) is powered

and controlled from the control module. It has a built-in frost

protection function and, for this reason, must not be

switched off when there is a risk of freezing.

At temperatures below +2 °C the charge pump runs period-

ically, to prevent the water from freezing in the charge cir-

cuit. The function also protects against excess temperatures

in the charge circuit.

Pressure drop, heating medium side

F2120

00,05 0,1 0,15 0,2 0,25 0,3 0,35 0,4 0,45 0,5 0,55 0,6 0,65 0,7 0,75 0,8 0,85 0,9

Tryckfall

[kPa]

Flöde [l/s]

Tryckfall F2120

Pressure drop

(kPa)

Flow

(l/s)

Pipe insulation

LEK

Heat insulation

All outdoor pipes must be insulated with at least 19 mm thick

pipe insulation.

Installation alternative

F2120 can be connected in several ways. The necessary

safety equipment must be installed in accordance with

current regulations for all installation options.

See nibe.eu for more detailed installation options.

10 NIBE F2120

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Nibe Wärmepumpe Handbücher

Nibe

Nibe F370 Bedienungsanleitung

Nibe

Nibe FIGHTER 1120 Bedienungsanleitung

Nibe

Nibe VVM S320 Bedienungsanleitung

Nibe

Nibe S1155PC Benutzerhandbuch

Nibe

Nibe FIGHTER 1240 Bedienungsanleitung

Nibe

Nibe F2040 Series Bedienungsanleitung

Nibe

Nibe Fighter 200P Bedienungsanleitung

Nibe

Nibe F1145 series Benutzerhandbuch

Nibe

Nibe F1255 Series Benutzerhandbuch

Nibe

Nibe F1245 Bedienungsanleitung

Nibe

Nibe F2120 Series Benutzerhandbuch

Nibe

Nibe F1245 Benutzerhandbuch

Nibe

Nibe F1145PC Bedienungsanleitung

Nibe

Nibe NIBE F1X26 Original Betriebsanleitung

Nibe

Nibe FIGHTER 1127 Bedienungsanleitung

Nibe

Nibe F2040 Series Bedienungsanleitung

Nibe

Nibe F1155 Series Bedienungsanleitung

Nibe

Nibe S1155 Originalbetriebsanleitung

Nibe

Nibe F730 Benutzerhandbuch

Nibe

Nibe ClimateMaster Tranquility 30 Digital Series Leitfaden

Nibe

Nibe S2125 Benutzerhandbuch

Nibe

Nibe F1126 Bedienungsanleitung

Nibe

Nibe AP-AW30 Bedienungsanleitung

Nibe

Nibe F1245 Bedienungsanleitung

Beliebte Wärmepumpe Handbücher anderer Marken

MICROWELL

MICROWELL HP 1000 GREEN Bedienungsanleitung

Sanyo

Sanyo SAP120FCH Bedienungsanleitung

Daikin

Daikin EHYHBH05AA Bedienungsanleitung

Panasonic

Panasonic WH-SDF03E3E5 Leitfaden

Bryant

Bryant 544B Bedienungsanleitung

Airxcel

Airxcel 45000 Series Handbuch

Mitsubishi Electric

Mitsubishi Electric PUZ-SWM60VAA Bedienungsanleitung

Dimplex

Dimplex LI 16I-TUR Benutzerhandbuch

Carrier

Carrier WSHP Open v3 Kurzanleitung zur Einrichtung

TGM

TGM CTV14CN018A Bedienungsanleitung

Carrier

Carrier 38MGQ Series Bedienungsanleitung

Kokido

Kokido K2O K880BX/EU Fehlerbehebungshandbuch

Viessmann

Viessmann VITOCAL 300-G PRO Type BW 2150 Kurzanleitung

Carrier

Carrier 48EZN Bedienungsanleitung

Viessmann

Viessmann KWT Vitocal 350-G Pro Series Betriebsanleitung

Ariston

Ariston NIMBUS Bedienungsanleitung

Weishaupt

Weishaupt WWP L 7 Benutzerhandbuch

GE Zoneline AZ85H09EAC Bedienungsanleitung
