Nikon EDG 10x32 Bedienungsanleitung
3
4
Index
Precautions ........................................................... 4-6
Operation precautions .............................. 6-8
Composition ................................................. 9
Nomenclature ....................................... 10-11
Interpupillary adjustment ............................ 12
Focusing ring .............................................. 13
Diopter Adjustment ................................14-15
Adjusting the length of the eyecups ...... 16-17
Eyecaps ................................................ 18-19
Strap ..................................................... 20-21
Objective caps ........................................... 22
Specifications ............................................ 23
Thank you for purchasing the Nikon
binoculars.
Strictly observe the following
guidelines in order to use the
equipment properly and avoid
potentially dangerous accidents
1 Before using the product,
thoroughly read the “SAFETY
PRECAUTIONS” and the
instructions accompanying the
product on correct use.
2 Keep these instructions within
easy reach for reference.
3 Some of the “SAFETY
PRECAUTIONS”, “OPERATION
PRECAUTIONS” and
“OPERATION” described here
may not refer to the product you
purchased.
In order to protect you and third
parties from possible injury and/
or property damage or loss,
you are kindly requested to pay
close attention to all instructions,
warnings and cautions regarding
the use and care of this product.
Precautions
English
• Specifications and design are subject to change without notice.
• No reproduction in any form of this manual, in whole or in part
(except for brief quotation in critical articles or reviews), may be
made without written authorization from NIKON VISION CO.,
LTD.
5
Precautions
OPERATION PRECAUTIONS
The items contained in this section
alert you to the fact that any
improper use ignoring the contents
described herein may negatively
affect product performance and
functionality.
WARNING
This indication alerts you to the
fact that any improper use ignoring
the contents described herein can
result in potential death or serious
injury.
CAUTION
This indication alerts you to the
fact that any improper use ignoring
the contents described herein can
result in potential injury or may
cause only a material loss.
Never look at the sun directly while
using binoculars.
Doing so may seriously damage the
eyes. (Fig. 1)
CAUTION!
• Do not leave the binoculars in an
unstable place. They may fall and
cause injury.
• Do not look through the binoculars
while walking. You may walk into
something and get hurt. (Fig. 2)
• Do not swing the binoculars by their
straps. They may hit someone and
cause injury. (Fig. 3)
• The soft case, strap, and external
materials utilized on binoculars and
rubber eyecups may deteriorate
due to aging and stain clothes. To
prevent this, check their condition
before each use, and consult with
the shop where you bought them if
such deterioration is found.
WARNING!
Fig. 1
Fig. 2
Fig. 3
6
• If you use the rubber eyecups for a
long period of time, you may suffer
skin inflammation. If you develop
any symptoms, consult a doctor
immediately.
• Be careful not to pinch your finger
when adjusting interpupillary
distance or diopter. Be particularly
careful if you let small children use
the binoculars. (Fig. 4)
• Do not leave the polyethylene bag
used for packaging within small
children’s reach. Children may put it
on their mouths and suffocate.
(Fig. 5)
• Be careful that small children do
not inadvertently swallow the cap or
eyecup. If it does happen, consult a
doctor immediately.
• Do not disassemble the binoculars.
Repairs should only be performed by
a trained engineer.
(Fig. 6)
CAUTION!Fig. 4
Fig. 5
Fig. 6
OPERATION AND CONTROLS
1. Do not open the right and left
binocular tubes beyond their
limits. Also be careful not to
rotate the diopter ring, focusing
ring beyond their limits. (Fig. 7)
2. Avoid rain, water splashes,
sand and mud. (Fig. 8) With
waterproof binoculars, though
some rain or splashed water will
do no harm, wipe the water off as
soon as possible.
3. Always protect binoculars from
shock. If you cannot obtain a
normal image after dropping or
getting the binoculars wet, take
them immediately to the shop
where you purchased them.
(Fig. 9)
4. When exposed to sudden
temperature changes, water
condensation may occur on lens
surfaces. In this case, thoroughly
dry the binoculars at room
temperature.
Operation Precautions
7
Fig.7
Fig.9
Fig.8
STORAGE
5. Water condensation or mold may
occur on lens surfaces because
of high humidity. Therefore, store
the binoculars in a cool, dry place.
After use on a rainy day or at
night, thoroughly dry them at room
temperature, then store in a cool,
dry place.
6. For lengthy storage, keep
binoculars in a plastic bag or an
airtight container with a desiccant. If
this is not possible, store in a clean,
well-ventilated place, separate from
the case, as they are easily affected
by moisture. (Fig. 10)
7. Do not leave the binoculars in a car
on a hot or sunny day, or near heat
generating equipment. This may
damage or negatively affect them.
(Fig. 11)
Operation Precautions
Fig.10
Fig.11
8
MAINTENANCE & STORAGE
8. After having removed dust with a blower, clean the body surface using
a soft, clean cloth. After use at the seaside, lightly soak a soft, clean
cloth with water and wipe off salt that may be on the body surface.
Then wipe the body surface with a dry cloth. Do not use benzene,
thinner, or other organic agents. (Fig. 12)
9. When removing dust on the lens surface, use a soft oil-free brush.
10.When removing stains or smudges like fingerprints, from the lens
surfaces, wipe the lenses very gently with a soft clean cotton cloth or
quality oil-free lens tissue. Use a small quantity of pure alcohol (not
denatured) to wipe stubborn smudges. Do not use velvet cloth or
ordinary tissue, as it may scratch the lens surface. Once the cloth has
been used for cleaning the body, it should not be used again for the
lens surface. (Fig. 13)
11.Remove dust trapped in the focusing unit, diopter adjustment unit, or
other rotating parts with a soft brush.
(Fig. 14)
Fig.12
Fig.13
Fig.14
9
Binoculars (BT)
Strap x1 (SAY)
Eyepiece cap x1
(∅42; 7x: ECC, 8x: ECB, 10x: ECA)
(∅32: ECD)
Objective caps x2 (integral to binoculars)
(∅42: OBP, ∅32: OBQ)
Horn-shaped rubber eyecups and caps x2 each
Composition
(∅42; 7x: ACL, 8x: ACK, 10x: ACJ)
(∅32: ACP) (∅42: EBY, ∅32: ECK)
Case
(∅42: CCT, ∅32: CCW)
10
①
③
⑨
⑤
⑥
②②
⑧
⑦
③
④
Nomenclature
