AT8000

IN-WALL LOUDSPEAKER

• Tweeter and midrange can be pivoted

•Baffle-mounted bass, midrange and treble tone controls for

acoustical adjustments

8" 3-Way AT Advanced Technology

In-wall Loudspeaker

SPECIFICATIONS SHEET

IN-WALL LOUDSPEAKER

WOOFER TECHNOLOGY

■8" interlaced glass and carbon-fiber cone is extremely rigid to reduce breakup and lower distortion

even under high power

■Butyl rubber cone surround damps resonance and provides exceptional durability

■Sophisticated motor assembly including high BL magnet, extended pole piece, high temperature

aluminum voice coil former and machined top plate for deep bass response and clean bass tones

■Inverted dust cap for added rigidity and wide mid-bass dispersion

MIDRANGE TECHNOLOGY

■1-1/2" fluid-cooled tri-laminate Teteron hyperbolic dome midrange driver reproduces critical

midrange sounds with exceptional accuracy

■NDFE 35 neodymium, high BL magnet motor structures enable compact driver construction

TWEETER TECHNOLOGY

■1" Tri-laminate Teteron hyperbolic dome tweeter reproduces high frequencies and their harmonics

with crystal clear accuracy

■Tweeter is housed in a zero diffraction swiveling enclosure that allows installer to control dispersion

patterns for optimal response

AUDIOPHILE FEATURES

■Linkwitz-Riley filters with premium crossover components provides seamless driver integration

■Low diffraction, X-Matrix™ reinforced polycarbonate Baffle eliminates unwanted resonance

TONE CONTROLS

■4 increment (-2dB, Flat, +2dB, +4dB) bass, midrange and treble controls adjust from the front

baffle for fine tuning after installation

INSTALLATION

■100% rustproof MicroPerf™ aluminum grille conceals loudspeaker elements yet allows full

frequency sound through. Grille can be painted to match décor

■Moisture and UV resistant materials including all stainless steel and brass hardware stand up to

harsh environments

■Infrared sensor knockout provides a hidden remote control solution

■6mm low diffraction X-Matrix reinforced polycarbonate baffler resonance for improved

dynamic range

SPECIFICATIONS

■Impedance: 8 ohms (4 ohms minimum)

■Recommended amplifier power: 20W to 200W

■Frequency response: 30Hz-21kHz +/-3dB

■Sensitivity: 89dB for 2.83 pink noise, measured at 1 meter on axis

■Frame dimensions: 11" x 18-3/8"

■Hole cutout dimension: 9-3/4" x 17-1/4"

■Depth behind ceiling: 3-3/4" deep (based on 1/2" dry wall)

Warranty: Five-year limited

Shipping weight: 9 lbs.

AT8000

Stock Number

FG00741

8" In-Wall Loudspeaker

NILES AUDIO CORPORATION 12331 S.W. 130 Street, Miami, FL 33186 Tel: 800.289.4434 – www.nilesaudio.com NAAT8000PDF

IN-WALL LOUDSPEAKER

Details

HOME THEATER SPECIFIC MODELS

Deliver voice-matched cinema performance and are compatible with all AT High Definition models

MODULAR MOUNTING SYSTEM

Uses innovative mounting technique to simplify installation and ensure uniform contact with wall

BLACK BAFFLES

Deliver a seamless appearance after the speakers are installed and the grilles are in place

MICROPERF™ RUSTPROOF ALUMINUM GRILLES

Are acoustically transparent yet won’t rust or discolor

DEBRIS SCREENS

Block unwanted debris such as fiberglass insulation, sheetrock chips, or other foreign matter from coming in contact with the woofer cone

REQUIRES USE OF BRACKET KIT

Use AT8000 bracket kit - FG00746

REQUIRES USE OF FRAME AND GRILLE KIT

Use AT8000 frame and grille kit - FG00745

Technology

PIVOTING RATCHETING TWEETER AND MIDRANGE DRIVER

Enable installers to precisely adjust the angle of the tweeter and midrange driver up to 20° for optimum coverage

ADVANCED MATERIAL SCIENCE

Elevates performance of sub component parts like woofer cones, tweeter diaphragms and crossover components

SOPHISTICATED MOTOR AND MAGNETIC DESIGN

Including HIgh BL magnet, extended pole pieces, high temp aluminum voice coil former and machined top plates for deep bass response

IMPEDANCE MANAGEMENT

Selectable 4 ohm or 8 ohm impedance lets installers optimize the system design

ACOUSTIC FINE TUNING

Bass, midrange and treble controls optimize system sound for every acoustical environment

ANTI-RESONANT WAVE-BRACING TECHNOLOGY

Prevents transmission of woofer vibrations to the baffle and into the drywall for clear and dynamic bass response

NILES AUDIO CORPORATION 12331 S.W. 130 Street, Miami, FL 33186 Tel: 800.289.4434 – www.nilesaudio.com NAAT8000PDF
