Nokia Bluetooth Headset BH-217

9222327_enu1.fm Page 1 Wednesday, July 14, 2010 12:03 PM

9222327/Issue 11

9222327_enu1.fm Page 2 Wednesday, July 14, 2010 12:03 PM

ENGLISH

DECLARATION OF CONFORMITY

Hereby, NOKIA CORPORATION declares that

this BH-217 product is in compliance with

the essential requirements and other

relevant provisions of Directive 1999/5/EC. A

copy of the Declaration of Conformity can be

found at http://www.nokia.com/phones/

declaration_of_conformity/.

Bluetooth is a registered trademark of

Bluetooth SIG, Inc.

Introduction

With the Nokia Bluetooth Headset

BH-217, you can make and answer

calls hands-free with your compatible

Read this user guide carefully before

using the headset. Also, read the user

guide for the device that you connect

to the headset.

Warning: The connector of

the clip and car cradle may

contain a small amount of

nickel. Persons who are sensitive to

nickel may have symptoms from

prolonged skin contact with the

connector.

Bluetooth compatibility

The headset is compliant with the

Bluetooth Specification 2.1 + EDR

supporting the Headset Profile 1.1 and

Hands-Free Profile 1.5. Check with the

manufacturers of other devices to

determine their compatibility with

this device.

9222327_enu1.fm Page 3 Wednesday, July 14, 2010 12:03 PM

cellular phone.

ENGLISH

Get started

The headset contains the following

parts shown on the title page:

multifunction key (1), earloop (2),

indicator light (3), earpiece (4),

microphone (5), and charger

connector (6).

Before using the headset, you must

charge the battery and pair the

headset with a compatible device.

Compatible chargers

This device is intended for use when

supplied with power from the

following chargers: AC-3, AC-4, AC-5,

AC-8, DC-4 and DC-9. The exact

charger model number may vary

depending on the type of plug. The

plug variant is identified by one of the

following: E, X, AR, U, A, C, K, or B.

Charge the battery

1. Connect the charger to a wall

outlet.

2. Connect the charger cable to the

charger connector.

To charge the headset when it is in

the clip or car cradle, insert the

lower end of the headset into the

clip or car cradle (12), and connect

the charger cable to the charger

connector on the clip or cradle

(13).

The red indicator light is displayed

during charging. Charging the

battery fully may take up to 2

hours.

3. When the battery is fully charged,

the green indicator light is

displayed. Disconnect the charger

from the headset (or from the clip

9222327_enu1.fm Page 4 Wednesday, July 14, 2010 12:03 PM

ENGLISH

or car cradle), then from the wall

outlet.

The fully charged battery has power

for up to 5 hours of talk time. When

you keep the headset in the clip or car

cradle, the fully charged battery has

power for up to 3 months of standby

time. When you use the headset

without the clip or cradle, the standby

time is up to 100 hours.

To check the battery charge when the

headset is not connected to a charger,

press the multifunction key when the

headset is connected to a cellular

phone. If the indicator light is green,

the charge level is sufficient. If the

light is yellow, you may need to

recharge the battery soon. If the light

is red, recharge the battery.

When the battery charge is low, the

headset beeps every 5 minutes, the

red indicator light flashes, and if voice

prompts are activated, there is an

audible notification. If voice prompts

are activated, there is also an audible

notification when the battery is

completely discharged.

Switch the headset on

Remove the headset from the clip or

car cradle. If the headset is not in the

clip or cradle, press the multifunction

key. The headset beeps, and the green

indicator light flashes slowly while the

headset tries to connect to the last or

two last connected devices.

When the headset is connected to at

least one device and is ready for use,

the blue indicator light flashes slowly.

If the headset has not been paired

with a device, it automatically enters

pairing mode.

Switch the headset off

Place the headset into the clip or car

cradle, or press and hold the

multifunction key for about 5 seconds.

9222327_enu1.fm Page 5 Wednesday, July 14, 2010 12:03 PM

ENGLISH

The headset beeps, and the red

indicator light is briefly displayed.

If the headset is not connected to a

device within about 30 minutes, it

switches off automatically.

Pair and connect the headset

Before using the headset, you must

pair and connect it to a compatible

device.

You can pair the headset with up to

eight devices, but you can connect it

to a maximum of two devices at a

time.

To pair and connect the headset to a

device:

1. Make sure your cellular phone is

switched on and the headset is off.

2. If the headset has not been

previously paired with a device,

switch on the headset. The headset

enters pairing mode, and the blue

indicator light starts to flash

quickly.

If the headset has been previously

paired with a device, make sure the

headset is switched off and not

placed in the clip or car cradle, and

press and hold the multifunction

key for about 5 seconds until the

blue indicator light starts to flash

quickly.

3. Within about 3 minutes, activate

Bluetooth on your device, and set it

to search for Bluetooth devices. For

details, see the user guide of your

cellular phone.

4. Select the headset from the list of

found devices.

5. If necessary, enter the passcode

0000 to pair and connect the

headset to your device.

In some devices, you may need to

make the connection separately

after pairing.

9222327_enu1.fm Page 6 Wednesday, July 14, 2010 12:03 PM

ENGLISH

When the headset is connected to at

least one device and is ready for use,

the blue indicator light flashes slowly.

To manually connect the headset to

the last used device, press and hold

the multifunction key for about 2

seconds (when no other device is

connected), or make the connection in

the Bluetooth menu of the device.

You may be able to set your device so

that the headset connects to it

automatically. To activate this feature

in a Nokia device, change the paired

device settings in the Bluetooth menu.

Basic use

Change the earplug

The headset may be provided with

different sized earplugs. Select the

earplug that fits the best and is the

most comfortable for your ear.

To change the earplug, pull the

current earplug from the earpiece, and

push the new earplug into place (7).

Place the headset on the ear

To use the headset with the earloop,

attach the earloop to it (11). To detach

the earloop, gently pull it from the

headset.

You can rotate the earplug to keep the

headset securely in the ear (8). For

example, if you use the headset on the

right ear, you may need to rotate the

earplug to the right for the best fit. If

you wear an earring, make sure it is

not accidentally attached to the

earplug.

To place the headset on the ear, slide

the earloop behind your ear (9), and

gently push the earpiece against your

9222327_enu1.fm Page 7 Wednesday, July 14, 2010 12:03 PM

ENGLISH

ear. Point the headset towards your

mouth (10).

Store in the clip or car cradle

When you do not keep the headset on

your ear, store it in the clip or car

cradle. When the headset is in the clip

or cradle, it is switched off. When you

remove the headset from the clip or

cradle, the headset automatically

switches on.

To place the headset into the clip or

cradle, slide the headset into place

(14). To remove the headset, slide it

out.

Install the car cradle

When you install the cradle in a car,

make sure it does not interfere with or

hinder the steering or braking systems

or other systems used in the operation

of the vehicle (for example, airbags) or

disturb your field of vision while

driving. Check that the deployment of

the airbag is not blocked or impaired

in any way.

To install the car cradle, peel off the

protective sheet from the cradle, and

press the cradle against a flat surface

so that it stays firmly in place. Do not

install the cradle in a place where you

might come in contact with it in the

event of an accident or collision.

Use the car cradle

When you use the headset with the

cradle in a car, obey all local laws.

Always keep your hands free to

operate the vehicle while driving. Your

first consideration while driving

should be road safety. Only operate

the headset or car cradle if it is safe to

do so under all driving conditions.

Periodically check that the adhesive at

the bottom of the car cradle is firmly

attached, especially if the ambient

temperature changes a lot. It is

9222327_enu1.fm Page 8 Wednesday, July 14, 2010 12:03 PM

ENGLISH

recommended that you do not leave

the car cradle inside the vehicle in

direct sunlight or in excessive heat.

Adjust volume

The headset automatically adjusts the

volume according to ambient noise. To

manually adjust the volume, use the

volume controls of the connected

device.

The selected volume level is saved for

the device that is currently connected

to the headset.

Calls

To make a call, use your cellular phone

in the normal way when the headset is

connected to it.

To redial the number you last called (if

your cellular phone supports this

feature with the headset), when no

call is in progress, press the

multifunction key twice when the

headset is not in the clip or car cradle.

To activate voice dialing (if your

cellular phone supports this feature

with the headset), when no call is in

progress, press and hold the

multifunction key for about 2 seconds

when the headset is not in the clip or

cradle. Proceed as described in the

user guide of the cellular phone.

To answer a call, remove the headset

from the clip or cradle. If the headset

is not in the clip or cradle, press the

multifunction key. To reject a call,

press the multifunction key twice, or

place the headset into the clip or

cradle.

To end a call, place the headset into

the clip or cradle, or press the

multifunction key when the headset is

not in the clip or cradle.

To switch a call between the headset

and a compatible connected device,

press and hold the multifunction key

for about 2 seconds.

9222327_enu1.fm Page 9 Wednesday, July 14, 2010 12:03 PM

ENGLISH

Connect to two devices

The headset can be connected to two

devices at the same time.

Pair and connect to two devices

To pair the headset with two devices,

switch on the headset, activate

pairing mode, and pair it with the first

device. Switch off the headset,

activate pairing mode, and pair it with

the second device.

To connect the headset to the two

devices, switch the headset off and

back on.

Handle calls

If the headset can connect to two

devices at the same time and you use

redialing or voice dialing, the call is

made on the device that you last used

to make a call when the headset was

connected to it.

To answer a call on one connected

device and end the active call on the

other device, press the multifunction

key.

To answer a call on one connected

device and put the active call on hold

on the other device, press and hold the

multifunction key for about 2 seconds.

To end the active call on one

connected device and make the call

on hold active on the other device,

press the multifunction key.

To switch between the active call on

one device and the call on hold on the

other device, press and hold the

multifunction key for about 2 seconds.

Activate or deactivate voice

prompts

Make sure the headset is switched off

and not placed in the clip or car

cradle. Press and hold the

multifunction key for about 5 seconds,

9222327_enu1.fm Page 10 Wednesday, July 14, 2010 12:03 PM

Andere Handbücher für BH-217

Inhaltsverzeichnis

Sprachen:

Andere Nokia Headset Handbücher

Nokia

Nokia BH-804 - Headset - Over-the-ear Bedienungsanleitung

Nokia

Nokia BH-800 Bedienungsanleitung

Nokia

Nokia BH-101 Bedienungsanleitung

Nokia

Nokia BH-222 Bedienungsanleitung

Nokia

Nokia HS-76W Bedienungsanleitung

Nokia

Nokia HS-56W Bedienungsanleitung

Nokia

Nokia BH 213 - Headset - Over-the-ear Bedienungsanleitung

Nokia

Nokia HS 3W Bedienungsanleitung

Nokia

Nokia HS-12W Bedienungsanleitung

Nokia

Nokia DAB Bedienungsanleitung

Nokia

Nokia 02705Q5 Bedienungsanleitung

Nokia

Nokia WH-800 Bedienungsanleitung

Nokia

Nokia BH-302 Bedienungsanleitung

Nokia

Nokia HS-54W - Headset - Over-the-ear Bedienungsanleitung

Nokia

Nokia BH-303 - Headset - Over-the-ear Bedienungsanleitung

Nokia

Nokia BH 301 - Headset - Over-the-ear Bedienungsanleitung

Nokia

Nokia BH 300 - Headset - Over-the-ear Bedienungsanleitung

Nokia

Nokia BH-108 Bedienungsanleitung

Nokia

Nokia BH-602 Bedienungsanleitung

Nokia

Nokia BH 604 - Headset - Binaural Bedienungsanleitung

Nokia

Nokia BH 600 - Headset - Over-the-ear Bedienungsanleitung

Nokia

Nokia Reaction Bedienungsanleitung

Nokia

Nokia Hs-45 - And Ad-57 Xpressmusic Stereo Headset 5310 3.5mm... Bedienungsanleitung

Nokia

Nokia BH-108 Bedienungsanleitung

Beliebte Headset Handbücher anderer Marken

Sena

Sena SMH10 Bedienungsanleitung

IASUS

IASUS Stealth IA-NT4-BASIC-BT Bedienungsanleitung

Sennheiser

Sennheiser EPOS ADAPT 230 Bedienungsanleitung

Doro

Doro Flexus HS2005 Bedienungsanleitung

GE 98971 Bedienungsanleitung

Hama

Hama 00184070 Bedienungsanleitung

Plantronics

Plantronics Blackwire 3200 Series Bedienungsanleitung

Blue Tiger

Blue Tiger Advantage PLUS Bedienungsanleitung

Jawbone

Jawbone Icon Bedienungsanleitung

Jabra

Jabra FR 20 Bedienungsanleitung

Roxcore

Roxcore Flow A+ Bedienungsanleitung

Turtle Beach

Turtle Beach XP 510 Bedienungsanleitung

Philips

Philips SHB6101 Bedienungsanleitung

Jabra

Jabra PRO 9460 Duo Bedienungsanleitung

HyperX

HyperX HyperX Cloud Flight Bedienungsanleitung

Bose

Bose MIE2 Mobile Bedienungsanleitung

Jabra

Jabra Steel Bedienungsanleitung

HyperX

HyperX cloud ii Bedienungsanleitung
