User guide

Eppu_en1.fm Page 1 Thursday, January 8, 2004 3:48 PM

DECLARATION OF CONFORMITY

We, NOKIA CORPORATION declare under our sole responsibility that the product DTX-3 is in

conformity with the provisions of the following Council Directive: 1999/5/EC. A copy of the

Declaration of Conformity can be found from

http://www.nokia.com/phones/declaration_of_conformity/.

Reproduction, transfer, distribution or storage of part or all of the contents in this document

in any form without the prior written permission of Nokia is prohibited.

Nokia and Nokia Connecting People are registered trademarks of Nokia Corporation. Other

product and company names mentioned herein may be trademarks or tradenames of their

respective owners.

Nokia operates a policy of continuous development. Nokia reserves the right to make

changes and improvements to any of the products described in this document without prior

notice.

Under no circumstances shall Nokia be responsible for any loss of data or income or any

special, incidental, consequential or indirect damages howsoever caused.

The contents of this document are provided “as is”. Except as required by applicable law, no

warranties of any kind, either expressed or implied, including, but not limited to, the implied

warranties of merchantability and fitness for a particular purpose, are made in relation to

the accuracy, reliability or contents of this document. Nokia reserves the right to revise this

document or withdraw it at any time without prior notice.

The availability of particular products may vary by region. Please check with the Nokia

dealer nearest to you.

Issue 2

Eppu_en1.fm Page 2 Thursday, January 8, 2004 3:48 PM

For your safety

1. For your safety

Read these simple guidelines. Breaking the rules may be dangerous or illegal. Further detailed

information is given in this guide.

INTERFERENCE

All wireless equipment may get interference which could affect performance.

DO NOT USE IN HOSPITALS

Follow any regulations and rules. Do not install the Nokia 32 terminal near medical equipment.

DO NOT USE IN AIRCRAFT

Wireless devices can cause interference in aircraft.

DO NOT USE NEAR FUEL OR CHEMICALS

Do not install the Nokia 32 terminal at a refuelling point. Do not install near fuel or chemicals.

DO NOT USE NEAR BLASTING

Do not install the Nokia 32 terminal where blasting is in progress. Observe restrictions, and follow

any regulations and rules.

QUALIFIED SERVICE

Only qualified service personnel must repair equipment.

INSTALLATION

Follow the installation instructions. Use only approved accessories.

ACCESSORIES AND BATTERIES

Use only approved accessories and batteries. Do not connect incompatible products.

CONNECTING TO OTHER DEVICES

When connecting to any other device, read its user guide for detailed safety instructions. Do not

connect incompatible products.

Eppu_en1.fm Page 3 Thursday, January 8, 2004 3:48 PM

WATER-RESISTANCE

Your terminal is not water-resistant. Keep

it dry.

MAKE BACKUP COPIES

Remember to make backup copies of all

important data.

EMERGENCY CALLS

This terminal, like all wireless equipment,

operates using radio signals, wireless and

landline networks as well as user-

programmed functions which cannot

guarantee connection in all conditions.

Therefore, you should never rely solely upon any

wireless equipment for essential communications

(e.g. medical emergencies.)

If a call is on, put down the handset to exit the

call. Wait for the dial tone and enter the

emergency number. Give your location. Do not

end the call until told to do so.

Eppu_en1.fm Page 4 Thursday, January 8, 2004 3:48 PM

For your safety

Contents

Introduction.............................. 7

Network services .............................. 9

Installation conditions .................. 10

Setting up the Nokia 32

terminal ..................................11

PBX installation .....................14

Connecting the Nokia 32 terminal to a

PBX trunk line.................................. 15

Connecting the Nokia 32 terminal to a

PBX extension line ......................... 17

Connecting the Nokia 32

terminal to a fax machine ....22

Sending faxes ..................................23

Receiving faxes ...............................23

Configuration .................................. 23

Light indicators ......................25

Tone indicators ......................28

Configuration ........................ 29

Basic settings .................................. 29

Advanced settings ......................... 30

Features ................................. 32

Supplementary services ................ 32

Nokia 32 terminal’s

accessories ............................. 37

Troubleshooting .................... 38

First things to check ..................... 38

Dial tone is not heard ................... 38

Noise is heard during a call ........ 39

Reception is poor ........................... 39

Entering PIN code does not

succeed ............................................. 39

Nokia 32 terminal cannot be reached in

extension mode .............................. 40

Technical specifications ....... 41

Eppu_en1.fm Page 5 Thursday, January 8, 2004 3:48 PM

Care and maintenance.......... 44

Important safety information 46

Eppu_en1.fm Page 6 Thursday, January 8, 2004 3:48 PM

Introduction

2. Introduction

The Nokia 32 PBX Connectivity Terminal is a device for various voice and data

communication services. The Nokia 32 terminal operates in the GSM 900 and

GSM 1800 networks.

The Nokia 32 terminal connects a company telephone switch (PBX; Private Branch

Exchange) to a GSM network. This allows the company to bypass the fixed

telephone network when calling GSM numbers. The Nokia 32 terminal works also

as a backup in cases when the fixed telephone line is down.

The Nokia 32 terminal provides telecommunication services in premises where

landline connection is not available. Phone calls and faxes are routed via the GSM

network, and the Nokia 32 terminal works as a substitute for a fixed telephone

line.

With the Nokia 32 terminal it is possible to make data calls using a compatible PC.

The Nokia 32 terminal works as a GSM modem, allowing the user to browse the

Internet and send PC faxes, for example. The Nokia 32 terminal also supports

connection for an analog fax machine. Connecting a fax machine to the trunk

connector of the terminal enables using fax machines in the GSM environment.

Installing and using the Nokia 32 terminal is easy. For making calls with a normal

landline telephone, just insert the SIM card, connect the handset to the Nokia 32

terminal, connect the power supply, and start making calls. In most cases of PBX

installations, some configuration of the PBX is needed for proper routing of the

telephone calls.

Eppu_en1.fm Page 7 Thursday, January 8, 2004 3:48 PM

The Nokia 32 terminal supports different kinds of network features, such as GSM

supplementary services, High Speed Circuit Switched Data, and GPRS. For

information about various GSM network services, contact your network service

provider.

For more information and downloadable files, contact www.nokia.com.

The Nokia 32 terminal incorporates:

• GSM terminal (1)

• PBX application module (2)

• PBX extension connector (3)

• trunk connector (4)

• RS-232 data connector (5)

• power supply connector (6)

Eppu_en1.fm Page 8 Thursday, January 8, 2004 3:48 PM

Introduction

The sales package contains:

• user guide (1)

• GSM terminal (2)

• PBX application module (3)

• power supply with a wall rack, AC

and DC cables (4)

• mounting screws (5)

■Network services

The cellular device described in this

user guide is designed to be used as an end-user terminal on the GSM 900 and

GSM 1800 networks and on the GSM 900/1800 dual band network. A number of

features included in this guide are called network services. These are special

services that you arrange through your wireless service provider. For information

on different network services in GSM networks, please consult your network

service provider. Before you can use any of these network services, you must

subscribe to them through your network service provider and obtain instructions

for their use from your service provider.

Note: Dual band functionality is a network-dependent feature. Check

with your local service provider if you can subscribe to and use dual band

functionality.

Eppu_en1.fm Page 9 Thursday, January 8, 2004 3:48 PM

Note: For availability, rates, and information on using SIM services,

contact your SIM card vendor, e.g. network operator, service provider, or

other vendor.

■Installation conditions

Do not install the Nokia 32 terminal very close to a metal ceiling. This can be done

under some circumstances, however, if an external antenna is used.

The environmental temperature should range between -10ºC and +55ºC and the

humidity between 20% and 75%.

Caution: In order to comply with RF exposure requirements, install the

Nokia 32 terminal so that a minimum distance of 20 cm can be

maintained between the antenna and all persons. If you use an external

antenna, install the antenna so that a minimum distance of 20 cm can be

maintained between the antenna and all persons, with antenna gain not

exceeding 3 dBi.

Eppu_en1.fm Page 10 Thursday, January 8, 2004 3:48 PM
