Nolan NSRX3C2MSX Bedienungsanleitung
P/N NSRX3C2MSX
USER GUIDE
WIRELESS MICROPHONE
BLUETOOTH
.
FCC ID:TNZNSRX3C2XXX
0678
Declaration of Conformity. We declare that product
NSRXRM3C2MSX conforms to the R&TTE Directive 1999/5/RC.
M
I
C
R
O
P
H
O
N
E
Please check the contents carefully and
contact your local dealer immediately if
anything is missing or damaged.
GETTING STARTED
Unpack the package carefully and confirm
that you have all of parts as shown below.
※
USB charging cableMicrophone
INTRODUCTION
The Bluetooth Wireless Microphone allows
capturing the source of audio wirelessly
and freely. Users can listen, capture or
record the audio/voice of subject with clarity
sound from Bluetooth wireless microphone.
Compatible stereo Bluetooth devices
must support the Bluetooth profile known
as A2DP, Headset/Handfree profiles.
CHARGING
Before using the microphone, you must
charge it for approximately 2 hours. After
fully charged, it can provide up to 5 hours of
playing time and 100 hours of standby time.
PRODUCT OVERVIEW
See image below. Please note some
models of microphone will differ slightly in
style, colour and the functionality may vary
according to their specifications.
Mic
Clipper On/Off
/Volume
Button
USB Charging
Connector
LED
Plug the USB charging cable into
microphone mini USB connector. Plug the
other side of the USB charging cable into a
powered USB connector.
When charging, the amber LED will be
lighted. When charging is completed, the
amber LED will be turn off.
or
TURN ON AND PARING
Microphone can work with 2 different types
of devices.
Type A: Audio receivers, speakers and
headsets
Type B: iPhones, iPads, android phones,
smartphones, tablets, PCs, laptop, Mac.
Those will indicate with different LED
lighting during pairing. Please ensure you
are using correct pairing type with your
devices and applications
Type A and Type B of pairing modes
supporting:
Type A pairing mode :blue LED flashes
along.
Type B pairing mode: blue and amber
LED flash alternatively.
then release the button. Microphone will be
turned on and inter current type A or B
pairing mode automatically. The type A and
B pairing mode has different LED indica-
tion, please ensure you are in suitable
pairing mode during the pairing.
Turn on your Microphone into pairing
mode
Press and hold the
ON/OFF button for
about 2 seconds, the
blue LED will solid light
for about 1 second,
When you press and hold the ON/OFF
button without released, the microphone
will switch between the type A and B mode
circularly with different LED indication.
When the microphone is into desired
pairing mode, release the button, the
microphone will keep this pairing mode for
using. If you like to change again, you can
repeat this operation for mode changing
between Type A and Type B.
Switch to desired Type A or Type B
mode
Power On
blue LED solid on
and then into type
A(or B) pairing mode
Switch Pairing Mode
blue and amber LED
solid on together and
then LEDS off
Switch Pairing Mode
blue and amber LED
solid on together and
then LEDS off
Power
Off
Power On
blue LED solid on
and then into type
B(or A) pairing mode
2. After the Microphone is in pairing mode,
initiate pairing feature on the audio
receiver. Refer to your audio receiver’s
User Guide.
3. The audio receiver should find the
Microphone and pair with it. When pairing is
completed and connected. The blue LED
on Microphone will begin to flash slowly.
1. Turn on the Microphone and into type A
pairing mode.
Important Note: Microphone supports
four sets of pin code: 0000, 1111, 1234,
and 8888. It covers the popular speakers,
receivers.
Type A: To pair with an A2DP enabled
Bluetooth audio receivers, speakers or
headsets
※
2. Initiate Bluetooth search feature and find
the device name “BTMIC”. If pin code
requested during pairing, please submit the
pin code 0000.
1. Turn on the Microphone and into type B
pairing mode.
Type B: To pair with iPhones, iPads,
tablets, android phones, smartphones,
laptop, Mac and PCs…etc
AT&T 10:08 AM
Settings
Bluetooth
BTMIC
Bluetooth
DEVICES
90%
TURN OFF
then the Microphone will turn off. Release
the ON/OFF button.
Press and hold the
ON/OFF button for
about 2 seconds, the
amber LED will stay on
for about 1 second and
In your laptop or pc, please ensure your
Bluetooth driver supported or included
headset/handfree profile. The most of
default Bluetooth drivers of Microsoft OS
such as Win7 does not come with
headset/handfree profile, you may need to
upgrade or install 3rd party driver such as
Microsoft, Broadcom's Widcom, Toshiba,
IVT...etc.
※
3. When pairing is completed and
connected, the blue LED will begin to flash.
