NOMA 043-5221-2 Bedienungsanleitung

44” DC MOTOR TOWER FAN

Instruction Manual

model no. 043-5221-2

Toll-free: 1-866-827-4985

IMPORTANT: Please read this manual carefully

before running this tower fan and save it for reference.

Table of Contents

Model 043-5221-2

Voltage 120 V AC

Frequency 60 Hz

Watt 35 W

Coverage Area sq. ft. (m’)

Net Weight 4.2 kg

Dimension (L x W x H) 33 x 33 x 112 cm

Speciﬁcations 2

Assembly 3

Operation 3

LED Display 5

Cleaning and Maintenance 6

Safety 6

Warranty 8

Speciﬁcations

model no. 043-5221-2 | contact us: 1-866-827-4985

1. Plug into any AC 120 V, 60 Hz source, and ensure that the plug and the socket ﬁt well.

2. Operate the appliance by the control panel or remote.

Control panel

On/O Button

Speed Button

Style Button

Timer Button

Right to Left OSC Button

Up to Down OSC Button

Mode Button

23456

Remote

2 3

AssemblyOperation

Base Assembly

Operation

Press the button once, the fan will start at 3rd speed mode.

2. Speed Button

Fan speed adjust:

Press once to set 4th fan speed.

Press the second time to set 5th fan speed.

Press the third time to set 1st fan speed.

Press the fourth time to set 2nd fan speed.

Press the ﬁfth time return to 3rd fan speed.

3. Style Button: to select normal wind mode, natural wind mode or sleep wind mode.

NORMAL wind mode: unit operates in selected fan speed: 1, 2, 3, 4, or 5.

NATURAL wind mode: unit operates according to computerized intervals of

changing speeds.

SLEEP wind mode: unit operates according to computerized intervals of

changing speeds.

4. Timer Button

the TIMER button, the temperature will switch to display and ﬂash the default time.

The default time is 0.0 h. You can press the timer buttons continually to set the timer

The time will be set within 5 seconds once you ﬁnish pressing the button and the

time value set will display on the LED screen. When the time runs out, the fan will

5. Right to Left OSC Button

To activate the oscillation feature, press the button once.

Press again to cancel.

6. Up to Down OSC Button

There are three kinds of OSC angle adjustment: 45°, 75°, 90°.

Press once to set 45°.

Press the second time to set 75°.

Press the third time to set 90°.

Press the forth time to cancel OSC function.

model no. 043-5221-2 | contact us: 1-866-827-4985

Remote Battery

Battery Model: CR2032 DC3V.

WARNING

1. Keep batteries out of reach of children. Should a child swallow a battery,

consult a doctor immediately.

2. Do not recharge or dispose of battery in ﬁre.

3. Keep in a dry and cool place.

4. Insert battery in right direction.

Battery Disposal – please dispose of the used battery per municipal or provincial law.

LED Display

1. Fan Speed Indicator

2. Mode Indicator

3. Timer and Temperature

Indicator

7. Mode Button: select AUTO or normal mode.

Press it once, you can select AUTO mode and the sign “AUTO” will be on. At this

mode, the fan will select proper output automatically depending on the current room

temperature and the system set temperature (25°C). If room temperature is more

than 25°C, the motor will operate, if room temperature is less than 25°C, the motor

will stop automatically.

Press it again to select normal mode.

Operation

Cleaning and Maintenance

When using electrical appliances, basic precautions should always be followed to reduce

the risk of ﬁre, electric shock, and injury to persons, including the following:

1. Use this fan only as described in this manual. Other use not recommended as it may

cause ﬁre, electric shock or injury to persons.

2. This product is intended for household use ONLY and not for commercial, industrial

or outdoor use.

3. To protect against electric shock, do not place fan in window, immerse unit, plug or

cord in water or spray with liquids.

4. This appliance has a polarized plug (one blade is wider than the other). To reduce the

risk of electric shock, this plug is intended to ﬁt in a polarized outlet only one way. If

the plug does not ﬁt fully in the outlet, reverse the plug. If it still does not ﬁt, contact a

qualiﬁed electrician. DO NOT attempt to defeat this safety feature.

Safety

• Always turn o and unplug the fan before cleaning.

• Use only a soft, damp cloth to gently wipe the outer surfaces of the fan clean.

• To clean between the grilles, we recommend using a pipe cleaner, ﬂexible dust wand, vacuum

cleaner or compressed air to gently remove the dust.

• DO NOT immerse the fan in water and never allow water to drip into the motor housing.

• DO NOT use gasoline, paint thinner or other chemicals to clean the fan.

• For storage, you may leave the fan assembled and covered to protect it from dust. Store the fan

in a cool, dry, place

!WARNING: Do not attempt to open or repair the fan yourself. Doing so could void

the warranty and cause damage or personal injury.

model no. 043-5221-2 | contact us: 1-866-827-4985

Safety

READ AND SAVE THESE INSTRUCTIONS!

WARNING: Not suitable for use with solid-state controls.

5. Close supervision is necessary when any appliance is used by or near children.

6. Turn the fan OFF and unplug the fan from the outlet when not in use, when moving

the fan from one location to another and before cleaning.

7. To disconnect the fan, ﬁrst turn the unit OFF, grip the plug and pull it from the wall

outlet. Never pull the plug by the cord.

8. Do not operate the fan in the presence of explosive and/or ﬂammable fumes.

9. Do not place the fan or any parts near an open ﬂame, cooking or other heating

appliance.

10. Do not operate the fan with a damaged cord or plug, or if the product malfunctions,

is dropped or damaged in any manner.

11. Avoid contact with moving fan parts.

12. The use of attachments not recommended by the manufacturer may be hazardous.

13. Place the fan on a dry, level surface.

14. Do not hang or mount fan on a wall or ceiling.

15. Do not operate if the fan housing is damaged.

16. A loose ﬁt between the AC outlet (receptacle) and plug may cause overheating and

a distortion of the plug. Contact a qualiﬁed electrician to replace a loose or worn

outlet.

17. Do not operate any fan with a damaged cord or plug. Discard fan or return to an

authorized service facility for examination and/or repair.

18. Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or

Do not route cord under

furniture or appliances over.

This product carries a one (1) year warranty against defects in workmanship and

materials. Noma Canada agrees to replace a defective product,within the stated

warranty period,when returned to the place of purchase with proof of purchase.

This product is not guaranteed against wear or breakage due to misuse and/or

abuse.

Warranty

model no. 043-5221-2 | contact us: 1-866-827-4985

Made in China

Imported by

Noma Canada

Toronto, Canada M4S 2B8

VENTILATEUR-TOUR

À MOTEUR CC DE 44 PO

Guide d’utilisation

N° de modèle : 043-5221-2

Numéro sans frais : 1 866 827-4985

IMPORTANT : Veuillez lire attentivement le présent

guide avant d’utiliser ce ventilateur-tour et le

conserver aux ﬁns de consultation ultérieure.
