INSTALLATION AND OPERATION MANUAL
Nordmann SPA Display
2591871-A EN 1903
Thank you for choosing Nordmann
Installation date (MM/DD/YYYY):
Commissioning date (MM/DD/YYYY):
Site:
Model:
Serial number:
Proprietary Notice
This document and the information disclosed herein are proprietary data of Nordmann Engineering AG. Neither
this document, nor the information contained herein shall be reproduced, used, or disclosed to others without the
written authorisation of Nordmann Engineering AG, except to the extent required for installation or maintenance
of recipient's equipment.
Liability Notice
Nordmann Engineering AG does not accept any liability due to incorrect installation or operation of the equipment
or due to the use of parts/components/equipment that are not authorised by Nordmann Engineering AG.
Copyright Notice
© Nordmann Engineering AG, All rights reserved.
Technical modications reserved.
3
Contents
1 Introduction 4
1.1 To the very beginning 4
1.2 Notes on the installation and operation manual 4
2 For your safety 6
3 Product Overview 8
4 Installation 9
4.1 Unpacking and checking the scope of delivery 9
4.2 Storing the unit 9
4.3 Notes on positioning the Nordmann SPA Displays 10
4.4 Mounting the Nordmann SPA Display 10
4.4.1 In-wall mounting 11
4.4.2 On-wall mounting 17
4.5 Connecting the Nordmann SPA Display to the Nordmann Omega or to the
Condair Delta SPA Control Box 23
5 CongurationandoperationoftheNordmannSPADisplay 27
5.1 CongurationoftheNordmannSPA Display 27
5.2 Operation of the Nordmann SPA Display 27
6 Troubleshooting 28
6.1 Fault indications / warning and fault list 28
6.2 Malfunctions during operation of the Nordmann SPA Display 28
7 Takingoutofservice/Disposal 29
7.1 Taking out of service 29
7.2 Disposal/Recycling 29
8 Technicaldata 30
9 Spareparts 31
4
1.1 Totheverybeginning
We thank you for having purchased the Nordmann SPA Display with touch-sensitive display.
The Nordmann SPA Display incorporates the latest technical advances and meets all recognized safety
standards. Nevertheless, improper use of the Nordmann SPA Display may result in danger to the user
or third parties and/or impairment of material assets.
To ensure a safe, proper, and economical operation of the Nordmann SPA Display, please observe and
comply with all information and safety instructions contained in the present installation and operation
manual.
If you have questions after reading this manual, please contact your Nordmann representative. They
will be glad to assist you.
1.2 Notesontheinstallationandoperationmanual
Limitation
The subject of this installation and operation manual is the external Nordmann SPA Display.
This installation and operation manual is restricted to the installation, commissioning, operation,
and trouble shooting of the Nordmann SPA Display and is meant for well trained personnel being
sufciently qualied for their respective work.
This installation and operation manual is supplemented by the installation manual and the operation
manual for the steam generator Nordmann Omega or the Condair Delta SPA Control Box, respectively.
Where necessary, appropriate cross-references are made to this publication in this installation and
operation manual.
Symbols used in this manual
CAUTION!
The catchword "CAUTION" designates notes in this installation and operation manual that, if neglected,
may cause damage and/or malfunction of the unit or other material assets.
WARNING!
The catchword "WARNING" used in conjunction with the general caution symbol designates safety
and danger notes in this installation and operation manual that, if neglected, may cause to injury to
persons.
DANGER!
The catchword "DANGER" used in conjunction with the general caution symbol designates safety and
danger notes in this installation and operation manual that, if neglected, may lead to severe injury
or even death of persons.
1 Introduction
5
Safekeeping
Please safeguard this installation and operation manual in a safe place, where it can be immediately
accessed. If the Nordmann Omega or the Condair Delta SPA Control Box with which the Nordmann SPA
Display is used changes hands, the documentation should be passed on to the new operator.
If the documentation gets mislaid, please contact your Nordmann representative.
Language versions
This installation and operation manual is available in various languages. Please contact your Nordmann
representative for information.
6
General
Every person working with the Nordmann SPA Display must have read and understood the present
installation and operation manual before carrying out any work.
Knowing and understanding the contents of the Installation and operation manual is a basic requirement
for protecting the personnel against any kind of danger, to prevent faulty operation, and to operate the
unit safely and correctly.
All ideograms, signs and markings applied to the Nordmann SPA Display must be observed and kept
in readable state.
Qualication of personnel
All actions described in the present Installation and operation manual (installation, operation, etc.) must
be carried out only by well trained and sufciently qualied personnel authorised by the owner.
For safety and warranty reasons any action beyond the scope of this manuals must be carried out only
by qualied technical personnel authorised by your Nordmann representative.
It is assumed that all persons working with the Nordmann SPA Display are familiar and comply with the
appropriate regulations on work safety and the prevention of accidents.
This unit may not be used by persons (including children) with reduced physical, sensory or mental
abilities or persons with lacking experience and/or knowledge, unless they are supervised by a person
responsible for their safety or they received instructions on how to operate the unit.
Children must be supervised to make sure that they do not play with unit.
Intended use
The Nordmann SPA Display is intended exclusively for the control of the steam generator Nord-
mann Omega and the Condair Delta SPA Control Box within the specied operating conditions
(see chapter8). Any other type of application without the express written consent of the manufacturer is
considered as not conforming with the intended purpose and may lead to the system becoming dangerous.
Operation of the equipment in the intended manner requires that all the information in these instruc-
tions are observed (in particular the safety instructions).
2 For your safety
7
Behavior in case of danger
If it is suspected that safe operation is no longer possible, then the Nordmann Omega or the Condair
Delta SPA Control Box, respectively should immediately be set out of operation, disconnected from
the mains and secured against accidental power-up (see Nordmann Omega or Condair Delta SPA
Control Box operation manual). This can be the case under the following circumstances:
– if the Nordmann SPA Display is damaged
– if the Nordmann SPA Display is no longer operating correctly
– if the connecting cable is damaged
All persons working with the Nordmann SPA Display must report any alterations to the unit that may
affect safety to the owner without delay.
Prohibited modications to the unit
No modications must be undertaken on the Nordmann SPA Display without the express written
consent of the manufacturer.
For the replacement of defective components use exclusively original accessories and spare parts
available from your Nordmann representative.
8
Nordmann SPA Display
in-wall mounted
Nordmann SPA Display
on-wall mounted
5
8
7
2a
1
4
5
78
1
4
2b
Fig. 1: Front view Fig. 2: Front view
6
3
2a
7
3
6
2b
7
8
Fig. 3: Back view Fig. 4: Back view
3 Product Overview
1 Touch-sensitive display
2a In-wall mounted housing
2b On-wall mounted housing
3 Connecting terminals (CAN BUS)
4 Decorative cover
5Magnets for the attachment of the decora-
tive cover
6 Magnetic centring frame with sealing
7 Cable entries
8 Shielding clamps
9
4 Installation
4.1 Unpackingandcheckingthescopeofdelivery
Unpacking the unit
Open the packing and check the delivery for completeness. Please contact your Nordmann represen-
tative in case something is lacking, they will be glad to send you the missing part without delay. The
standard delivery includes:
– Nordmann SPA Display in-wall mounted
– Nordmann SPA Display control PCB
– In-wall mounted housing with pre-mounted display mounting supports, fastening claws and
3 magnets
– Plastic bag containing mounting material
– Nordmann SPA Display on-wall mounted
– Nordmann SPA Display control PCB
– On-wall mounted housing
– Plastic bag containing mounting material
– Decoration cover with pre-mounted centring frame and sealing (if ordered)
Please check the equipment for damage. Please report any damage to your Nordmann representative
and to the carriers, as required.
Packaging
The original packaging of the Nordmann SPA Display was designed for optimum safety during transpor-
tation. Please preserve the original packing material in case you once have to return the unit for some
reason.
In case you wish to dispose of the packaging, observe the local regulations on waste disposal. Never
dispose of the packaging to the environment.
4.2 Storingtheunit
If the Nordmann SPA Display must be stored, store it in a protected area (best in the original packaging)
meeting the following requirements:
– room temperature: 1 ... 40 °C
– room humidity: 10 ... 80 %rh (non condensing)
10
4.3 NotesonpositioningtheNordmannSPADisplays
Please observe the following notes for the correct positioning of the Nordmann SPA Display(s):
– The Nordmann SPA Display(s) must not be installed in hazardous locations and in rooms where
water splashes may occur.
– Do not mount the Nordmann SPA Display(s) inside the steam bath cabin, sauna, bio sauna, etc..
– If possible mount the Nordmann SPA Display(s) at eye level.
– Do not mount the Nordmann SPA Display(s) in exposed places.
– Do not mount the Nordmann SPA Display(s) on vibrating components.
– Place the Nordmann SPA Display(s) in such a way, that the total length of 50 m of the CAN BUS
cables with which the Nordmann Omega or the Condair Delta SPA Control Box and the Nordmann
SPA Display(s) are interconnected is not exceeded.
4.4 MountingtheNordmannSPADisplay
CAUTION!
The electronic components of the Nordmann SPA Display are very sensitive to electrostatic discharge.
For all installation work on equipment appropriate measures must be taken to protect these components
against damage caused by electrostatic discharge (ESD protection).
Note: the Nordmann Omega or the Condair Delta SPA Control Box, respectively and the Nordmann SPA
Display(s) (up to a max. of 8 SPA Displays) are interconnected via a so-called CAN BUS. Use only a
shielded four-wire cable with a cross section of 0.34 mm2per wire to establish the CAN BUS con-
nections. The total length of the CAN BUS must not exceed 50 m.
