OPERATING MANUAL

LA-BO

Applicator

Operating Manual LA-BO

02/2016 3Content

Content

General Notes & Safety Instructions -5

General notes -5

Validity and binding effect of this manual -5

Illustrations and descriptions -6

Safety instructions -7

Information and qualifications -7

Operational safety of the unit -8

Technical Data -10

Application Notes -10

Intended Purpose -10

System Requirements -10

Properties -11

Mode of Operation -11

Specifications -12

Mounting & Setting -13

Safety Instructions -13

Mounting on an ALX 92x -14

Requirements -14

Fitting the applicator -15

Adjusting the dispensing edge to the vacuum grid -16

Parameter settings on the ALX 92x -17

Mounting on an ALS 20x/256 -18

Requirements -18

Fitting the applicator -19

Adjusting the dispensing edge to the vacuum grid -21

Parameter settings on the ALS 20x/256 -22

Adjusting the labelling application height -25

Adjusting the LA-BO to the used label material -26

Adjusting the sliding bars in the vacuum grid -26

Adjusting the air nozzles in the vacuum grid -28

Adjusting the air stream support -29

Setting the dispensing position parameter -29

Initializing the applicator -29

Compressed air settings -30

Operating Manual LA-BO

02/2016 4Content

Operating Manual LA-BO

02/2016 | 00 5General Notes & Safety Instructions

General Notes & Safety Instructions

GENERAL NOTES

Validity and binding effect of this manual

Contents

The present manual refers exclusively to the LA-BO applicator. It is written for the purpose of en-

suring professional usage and calibration of the unit.

Prerequisites for the use and adjustment are the professional installation and configuration of the

unit. For any technical questions you may have that are not described in the user manual, see:

• The service manual.

• Request a service technician from one of our sales partners.

Our service technicians are available to assist you, particularly with configuring the unit as well as

in the case of malfunctions.

Technical status

10/2007

NOVEXX Solutions holds all rights to this manual and its appendixes. Reproduction, reprinting or

any other types of duplication, even of portions of this manual, may only be carried out with express

written consent. Third persons, in particular competitors, should not be given access to the infor-

mation in this manual.

Printed in Holland

Manufacturer

Novexx Solutions GmbH

Ohmstrasse 3

85386 Eching, Germany

Phone: +49-8165-925-0

Fax: +49-8165-3143

www.novexx.com 

NOVEXX Solutions reserves the right:

• To make modifications to construction parts, components and software, as well as to employ

comparable components in place of the parts specified, in keeping with technical advances.

• To modify information in this document.

No commitment will be made to expand these modifications to include any units delivered earlier.

Operating Manual LA-BO

02/2016 | 00 6General Notes & Safety Instructions

Illustrations and descriptions

Dangers and risk notes

Important directions that you must absolutely observe are particularly emphasized:

Figures

Texts are accompanied by figures where necessary.

Generally, the LA-BO unit shown is a right-handed version. The left-handed version is only shown

where it is necessary to differentiate between the two.

WARNING!

A warning refers to risks that can lead to serious injury or death! The warning contains safety

measures to protect the relevant persons.

Always follow the instructions.

Operating Manual LA-BO

02/2016 | 00 7General Notes & Safety Instructions

SAFETY INSTRUCTIONS

Information and qualifications

Follow the instructions

Keep the product information at hand

With respect to this manual:

• It should be kept at the location where the unit is installed and be available to the operator.

• It should always be legible.

• If the unit is sold, the manual should be made available to the new owner.

• The safety and warning notes affixed to the unit itself must be kept clean and legible. Missing

or damaged signs must be replaced.

Ensure the required qualifications are met

• Ensure that only trained and authorized personnel operate, configure and service the unit.

• Only allow qualified and well-trained expert personnel or service technicians to perform config-

urations.

• The responsibilities with regard to operation, configuration and maintenance should be clearly

defined and consistently maintained.

• In addition, personnel should also be instructed on a regular basis in matters of occupational

safety and environmental protection.

Qualification for operation

The instruction of personnel using the unit must ensure that:

• The operating personnel can use the unit on their own and safely.

• The operating personnel can remedy small operational disruptions on their own.

• At least two people must be instructed in the unit’s usage.

• Enough label material must be provided for testing and instructional purposes.

WARNING!

Safe and efficient operation of the LA-BO unit can only be guaranteed if you observe all neces-

sary information.

Product liability and warranty claims can only be asserted if the unit was operated in accordance

with the directions in the manual.

Before operating the unit, read the operating instructions and all other notes carefully.

Observe the additional safety and warning notes on the LA-BO unit.

Only permit competent people to operate and configure this unit.

When working with the LA-BO for a longer period, it is advisable to use hearing protection.

Operating Manual LA-BO

02/2016 | 00 8General Notes & Safety Instructions

Operational safety of the unit

Proper usage

Applicators of type LA-BO are additional units for NOVEXX Solutions print & apply systems or la-

bellers. The applicators take self-adhesive labels from the dispenser mechanism and stick these

onto moving or non-moving products. The company operating the unit must install it with suitable

equipment to protect operating personnel from danger; for example, the danger of hands or fingers

being crushed by reaching in between the product and the dispensing edge.

Protection against injuries by electrical current

Applicators of type LA-BO operate using low voltage 24 V DC supplied by NOVEXX Solutions

print & apply systems or labellers.

Protection against injuries by mechanical action

WARNING!

Improper usage of the unit can cause accidents, property damage and production downtime!

Only use the unit in accordance with the instructions specified in this manual.

Only configure the unit in accordance with this manual and with the required care.

Only use original accessories.

Do not make any modifications or alterations to the unit.

Repairs to the device may only be performed by authorised specialists who are aware of the

risks involved.

WARNING!

Never connect the LA-BO unit directly to mains voltage!

Only operate the unit once the housing has been reassembled properly.

Before cleaning, switch off the NOVEXX Solutions print & apply system or labeller and remo-

ve the power cable from the socket.

WARNING!

The unit is not protected against splashing water.

Keep the unit dry.

If liquids have penetrated the LA-BO unit, switch the NOVEXX Solutions print & apply system

or labellerprint & apply system or labeller off and disconnect or unplug it’s power cable immedi-

ately. Inform a service technician.

WARNING!

Risk of injury due to moving and rapidly rotating parts!

Long hair, loose jewellery, long sleeves and so on are not permissible when using the unit.

Sufficient protective clothing must be worn.

Keep moving parts free from obstructions even when the unit is not switched on, if there is a

chance the machine might be turned on.

Switch off the machine before making any mechanical settings.

Do not wear ties, loose clothing, jewellery, wrist watches or similar items on your person when

near the operating unit.

Operating Manual LA-BO

02/2016 | 00 9General Notes & Safety Instructions

Protection against injuries by chemicals

WARNING!

There is a low risk that you may get your hands crushed between the vacuum grid of the LA-BO

and the conveyed products!

Never reach between the product and the LA-BO edge while the unit is in operation or ready

for operation.

CAUTION!

Operating materials such as cleaning agents or the solvents in glues can be damaging

to health.

Always follow the instructions, use and safety regulations specified by the manu-

facturer!

Operating Manual LA-BO

02/2016 | 00 10 Technical Data

Technical Data

APPLICATION NOTES

Intended Purpose

Applicators of type LA-BO are additional units for print-and-apply or labelling heads that are listed

in the section Machine type on page 10. They take self-adhesive labels from the dispenser mech-

anism and stick these onto moving or non-moving products.

The LA-BO is mounted to the print-and-apply (ALX 92x) or labelling head (ALS 20x/256) by means

of an included base plate. The applicator is controlled by the optional Applicator Interface (AI) board

(mandatory for ALX and optional for ALS) or by the Internal Applicator Interface (ALS only). The

electrical connection to the LA-BO is done via a plug connector. The drive is provided by com-

pressed air.

Remark: The optional Applicator Interface (AI) board is not included with the LA-BO and has to be

ordered separately with the print-and-apply or labelling head.

The application process is triggered by means of a product sensor, which is also connected to the

AI-board.

Installation position

Permissible installation positions for the LA-BO are:

•Vertical, if application takes place from top to bottom (also referred to as “top labelling”: the

product is located below the applicator) or from bottom to top (also referred to as “bottom label-

ling”: the product is located above the applicator).

•Horizontal (also referred to as “side labelling”: the product is located next to the applicator)

System Requirements

Machine type

The LA-BO can be operated on the following machines:

By ordering the specified part number, you will receive a LA-BO applicator with installation material

and connection cables, suitable for installation on the device type listed at the beginning of the line.

The Applicator Interface (AI) board is not part of the delivery and has to be ordered separately.

Device Part number LA-BO Controller Notes

ALX 924/925/926 LH A8679 AI a / b / c

a) Use of the AI is mandatory for ALX.

b) The Applicator Interface (AI) is not contained in the scope of delivery and has to be ordered

separately with the ALX or ALS unit. A5032 : AI factory installed, A5207: AI Upgrade kit.

c) ALX 924/925/926 has to be equiped with standard dispensing edge.

ALX 924/925/926 RH A8680

ALS 204/206/256 LH A8677 AI or internal d / b/ e

d) Use of the AI is optional for the ALS. The Internal applicator interface of the ALS can be used

also, but limits the use of PLC signals.

e) ALS 20x/256/256 has to be equiped with L-shape fixed dispensing edge.

ALS 204/206/256 RH A8678

[Tab. 1] Print-and-Apply and labelling machines, to which the LA-BO can be applied (LH = lefthand, RH = righthand,

AI = Applicator Interface).

Operating Manual LA-BO

02/2016 | 00 11 Technical Data

Firmware

• Required version of the ALX 92X firmware: V3.30 or later.

• Required version of the ALS 20X/256 firmware: V1.17 or later.

The printer-dispenser must be equipped with an Application Interface (AI) board version V1.11 or

later.

Start signal

The start signal must be connected to the Product sensor input of the AI interface. When the Inter-

nal Applicator interface on the ALS is used, the startsignal must be connected to the M12-connector

“ Start” .

See service manual ALX 92x/ALS 20X/256/256, ‘Applicator Interface’ topic section, chapter ‘In-

terface signals’, ‘Product Sensor’. For using the M12 connector on ALS see Service manual ALS

20x/256 ‘ Connecting the sensors’.

Properties

LA-BO = Label Applicator – Blow On.

The applicator is driven by compressed air. The label is held to the aluminium grid on the bottom

side of the applicator by an inwards airflow created by a fan on the side of the applicator.

Mode of Operation

The fan in the LA-BO is continuously powered, creating a strong inwards airflow through the alu-

minium vacuum grid at the bottom side. While a label is dispensed, the small blow pipe is activated,

creating a small focused air stream to force the label against the aluminium grid. When the label is

fully dispensed, it is held onto the aluminium grid by the inwards airflow and is then stand-by to blow

off the label. When the application cycle is triggered by the product sensor, a high volume air pres-

sure is applied through the air nozzles built-in above the aluminium grid. The nozzles which are

not covered by the black sliding bars will now blow off the label towards the product at a high ve-

locity. After that, the next label can be dispensed on the grid.

Andere Handbücher für LA-BO

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Novexx Solutions Drucker Handbücher

Novexx Solutions

Novexx Solutions ALX 73 Series Bedienungsanleitung

Novexx Solutions

Novexx Solutions 64- series Bedienungsanleitung

Novexx Solutions

Novexx Solutions 64- series Bedienungsanleitung

Novexx Solutions

Novexx Solutions AP 5.4 Bedienungsanleitung

Novexx Solutions

Novexx Solutions ALS 30 Series Bedienungsanleitung

Novexx Solutions

Novexx Solutions LTSI Bedienungsanleitung

Novexx Solutions

Novexx Solutions 64- series Fehlerbehebungshandbuch

Novexx Solutions

Novexx Solutions LA-BO Bedienungsanleitung

Novexx Solutions

Novexx Solutions ALX 73 Series Bedienungsanleitung

Novexx Solutions

Novexx Solutions ALX 73 Series Bedienungsanleitung

Novexx Solutions

Novexx Solutions ALX 73 Series Bedienungsanleitung

Novexx Solutions

Novexx Solutions ALS 104 Bedienungsanleitung

Novexx Solutions

Novexx Solutions ALX 73 Series Bedienungsanleitung

Novexx Solutions

Novexx Solutions 64- series Bedienungsanleitung

Novexx Solutions

Novexx Solutions LA-SO Bedienungsanleitung

Novexx Solutions

Novexx Solutions 64- series Bedienungsanleitung

Novexx Solutions

Novexx Solutions XLP 504 Bedienungsanleitung

Novexx Solutions

Novexx Solutions ALX 92 Series Bedienungsanleitung

Novexx Solutions

Novexx Solutions ALX 73 Series Bedienungsanleitung

Novexx Solutions

Novexx Solutions AP 4.4 Bedienungsanleitung

Novexx Solutions

Novexx Solutions Label Maxx C Bedienungsanleitung

Novexx Solutions

Novexx Solutions AP 5.4 Bedienungsanleitung

Novexx Solutions

Novexx Solutions ALX 73 Series Bedienungsanleitung

Novexx Solutions

Novexx Solutions ALX 92 Series Bedienungsanleitung

Beliebte Drucker Handbücher anderer Marken

Lexmark

Lexmark 1400 Series Handbuch

Canon

Canon i70 Series Bedienungsanleitung

Evolis

Evolis Elypso Bedienungsanleitung

Kyocera

Kyocera FS-9530DN Bedienungsanleitung

Canon

Canon LASER SHOT LBP-1210 Bedienungsanleitung

Samsung

Samsung BIXOLON SRP-350plusF Bedienungsanleitung

Canon

Canon PIXMA PRO-1 Series Bedienungsanleitung

Canon

Canon PIXMA G3560 Einrichtungshandbuch

Dell

Dell Color Laser Printer 2130cn Bedienungsanleitung

Tektronix

Tektronix Phaser 840 Bedienungsanleitung

Epson

Epson ET-7750 Betriebsanleitung

Canon

Canon CLBR 460ps Bedienungsanleitung

Eltron

Eltron P210 Guide Bedienungsanleitung

Ricoh

Ricoh MD-P1 Bedienungsanleitung

Epson

Epson SC-F7100 series Bedienungsanleitung

Epson

Epson Stylus C40UX Bedienungsanleitung

Canon

Canon imagePASS-A2 Bedienungsanleitung

Canon

Canon S820D Bedienungsanleitung
