Novus NVC-VS10BD Bedienungsanleitung

USER`S MANUAL VER. 1.0

Contents

Preface

Safety instructions

Function description

Installation

Specifications

VANDAL DOME

B/W & COLOR CAMERA

NOVUS SECURITY Sp. z o.o.

359 Pulawska Str., 02-801 Warsaw, Poland

tel: +4822-546-0-500; fax: +4822-546-0-519

[email protected]; www.novuscctv.com

Vandal Dome B/W & Color Camera Manual, ver. 1.0

CONGRATULATIONS ON YOUR PURCHASE OF OUR

CAMERA

This product has been carefully inspected through rigid quality control

before shipment. With reasonable installation and operation, it will

provide years of reliable performance. Considering your investment, we

understand you would like to know the full performance capability about

the new product. Therefore, we need to recommend that you read the

installation and operation manual thoroughly before attempting to install

and operate the product.

IMPORTANT INFORMATION BEFORE INSTALLATION

Please read and observe all instructions and warnings contained in this

manual. Retain the original manual for the future reference. When

unpacking your new product, first please compare the received items with

your order list, second check for damaged items. If there is anything

missing or damage in evidence, please do not install or operate the

product. Contact your dealer for assistance immediately. Never try to

service this product by yourself. Opening the covers may expose you to

dangerous power voltage or other hazards. For your protection, take a

moment to complete the following product purchase information. The

serial number of this product may be found on the cover of the unit. The

serial number may be required by the factory when need service or

technical support.

Model NO.

Serial NO.

Purchase date

Vandal Dome B/W & Color Camera Manual, ver. 1.0

PREFACE

Design for this series CCD camera is based on professional video system

processing capability. Interior key components adopt Japanese advanced

charge coupled device (CCD) sensor and related peripheral IC. So the

CCD camera has better performance such as high sensitivity, sharpness,

premium fidelity and low noise. It also has auto electronic shutter,

backlight compensation and white balance function (for Color Cameras

only). Because power design uses switching regulator, its operating

current is only 200~250mA for DC12V model. Installation becomes more

simple and easier.

SAFETY INSTRUCTIONS

1. Never expose the unit to rain or moisture and avoid electric shock

hazard.

2. Any service or maintenance should be made by qualified service

personnel.

3. Storage temperature –30ºC~+80ºC.

4. All installation and service should be confirmed to local agents.

5. Do not open the cover; it may expose you to electric and other hazard.

6. Do not place anything on the unit which may spill or fall into the unit.

7. The equipment has been tested and passed the CE standard, which is

designed to provide reasonable protection against harmful interference

and be insusceptible to other radiating interference when operated in

commercial environment. Therefore the equipment can not also

generate and cause any interference to radio communication.

Vandal Dome B/W & Color Camera Manual, ver. 1.0

FUNCTION DESCRIPTION

Window for lens

1/3”

1/4"

Video out Power in

INSTALLATION

CCD Camera

Screw hole

1/3”

1/4"

Vandal Dome B/W & Color Camera Manual, ver. 1.0

Ceiling mounting type fixed

by screw (option)

1/4"

1/3”

Adjust lens focal length

Remove cover:

Press down spring hook turn right and remove cover.

After adjustment, replace it counterclockwise.

Vandal Dome B/W & Color Camera Manual, ver. 1.0

SPECIFICATIONS

A. Color Cameras

Model: NVC-

VS50CD

NVC-

VS55CD

NVC-

VH60CD

NVC-

VS45CD/IR

Pick-up Element 1/3” color CCD imager

Number of Pixels

(H) x (V) 537 x 597 795 x 596 537 x 597

Resolution > 380 TVL > 480 TVL > 380 TVL

Synchronizing

System internal

Video Output 1,0 Vpp, 75 Ohm, BNC

IR Projector N/A Yes

Min. Illumination 0,8 lx/F=1.2 1,2 lx/F=1.2 1,0 lx/F=1.2

0 lx/IR on

Electronic Shutter auto 1:50 to 1:100 000 s

S/N Ratio 48 dB (AGC off)

Gamma 0,45

White Balance auto / 2000°K ~ 8000°K

Back Light

Compensation auto

Standard Board

Lens

fixed focal:

f=3.6 mm varifocal auto iris: 4-9 mm fixed focal:

f=3.6 mm

Operating

Temperature –10°C ~ +50°C

Water Resistance IP66

Power Supply 12VDC / max. 250 mA

Dimensions 108 (D) x 75 (H) mm

Weight 640 g

Vandal Dome B/W & Color Camera Manual, ver. 1.0

B. B/W Cameras

Model: NVC-

VS10BD

NVC-

VS25BD NVC-VH35BD NVC-

VS15BD/IR

Pick-up Element 1/3” B/W CCD imager

Number of Pixels

(H) x (V) 537 x 597 795 x 596 537 x 597

Resolution > 420 TVL > 580 TVL > 420 TVL

Synchronizing

System internal

Video Output 1,0 Vpp, 75 Ohm, BNC

IR Projector N/A Yes

Min. Illumination 0,05 lx/F=1.2 0,08 lx/F=1.2 0,05 lx/F=1.2

0 lx/IR on

Electronic Shutter auto 1:50 to 1:100 000 s

S/N Ratio 48 dB (AGC off)

Gamma 0,45

Back Light

Compensation auto

Standard Board

Lens

fixed focal:

f=3.6 mm varifocal auto iris: 4-9 mm fixed focal:

f=3.6 mm

Operating

Temperature –10°C ~ +50°C

Water Resistance IP66

Power Supply 12VDC / max. 250 mA

Dimensions 108 (D) x 75 (H) mm

Weight 640 g

NOVUS SECURITY Sp. z o.o.
