TAKE CONTROL
The NXS amplifiers feature built-in digital signal processors (DSP). The DSPallows for
control and adjustment of sophisticated features previously found only in mid-to high
end dedicated pre-amplifier equipment. The DSP features are controlled and adjusted
withoneofthetwofollowingcomponents(soldseparately).
NXLIcomputerinterfaceandNXCSsoftware:
The NXLI is an control interface which allows
the amplifier's DSP to be controlled by a PC.
The NXLI provides a standard USB plug to
connecttoaPCandaRJ11socketforacable
connection to the Amplifier's DSP Netlink.
The NXLI is powered by the USB connection
eliminating the need for additional power
connections. This makes the NXLI portable
andsimpletoconnect.
Unliketraditionalamplifierinstallationswiththeadjustmentsmadeontheamplifierinthe
back of the car, the NXLI gives the flexibility to position a Laptop PC within the vehicle
while sitting in the listening position making the adjustments real-time. This allows for
idealcalibrationofthesystemincludingequalizationandtimedelay.
NXLCDCIn-DashController: TheNXLCDCisanoptionalin-dashcontroller
foruserswhodonotwanttouseaPCtosetup
and control their NXSAmplifiers. Shaped in a
convenient DIN size, the NXLCDC features a
4 line LCD Display, a function selecting scroll
wheel,4presetbuttonsanda'back'button.
ThisenablestheusertoselectandadjustdifferentamplifiersconnectedviaDSPNetlink
in the same car. Basic settings like EQ, Gain, Sub-woofer level and Crossover can be
selectedandadjusted.
The 4 presets on the NXLCDC can be programmed to recall up to 4 individual
configurationssavedtotheNXLCDC. Theusercaneasilytoggleconfigurationsbiased
toward'classical'vs'techno'musicforinstance.
There is also a Mini-USB PC computer input connection at the front of the controller.
This is to allow PCs with the NXCS software installed the convenience of connecting
and controlling the amps through the NXLCDC instead of having to run additional
cables.
NXLCRemoteLevelControl: TheNXLCis aremotelevelcontrolthat giveshands-
on-control over the amplifier(s) output level. The
NXLC operates through the amplifier’s DSP Netlink
connection and features an intelligent circuit
allowing you to select which amplifier and/or
channels you would like to control remotely.
Additionally, only one remote is needed to control
