Ocean Digital MA-80 Bedienungsanleitung

Internet Radio

User Manual

Please read this user manual carefully before using the receiver.

MA-80

Contents

LocationofControls ...................................1

Remotecontrol........................................2

Enter encryption code of the Wi-Fi router..................3

Connect the radio with your Wi-Fi Router . . ...............5



Ethernetconnection ...................................6

Startusinginternetradio ...............................6

MyFavorite.......................................6

Internet Radio .....................................7

Media Centre......................................8

AlarmSetting.....................................11

Snooze. . . . . .....................................12

Sleep Timer ......................................12

Configuration . . . . . . . .............................12

AddyourfavoriteURL.................................14

MusicStreamingfrommobiledevices ...................15

Helpful Tips..........................................16

Technical Specification. . . .............................17

Front

Back

Location of Controls

Tune / Select

Volume

12 13 14 15

Ethernet Line Out

16 1817 19 20

Top

3214

Local Right

FAV.+

Standby Menu

Left

Alarm / Sleep Timer

234561 7

8910

1. Standby

- Press to turn on the radio/standby

2-5. Individual favourite keys no. 1-4

Long press to preset; short

press to recall

6. FAV

- Recall list of favorite stations

7. Menu – Press to enter menu

8. Left

- Back to previous menu

- Left cursor

9. Alarm / Sleep Timer / Snooze

- Press briefly to set the Sleep Timer

- Long pressing to set Alarm

- When alarm sounds, press to stop

the alarm for 9 minutes

10. Local

- Quick access the local station in

your country

11. Right

- Right cursor

- Under Favorite list, press to enter

the edit menu

12. Speaker

13. Volume control

14. LCD display

- On Standby mode, rotate the

Tune/Select knob to adjust the

brightness level

15. Tune/ Select control

- Rotate to tune and push to select

16. Ethernet port

- plug in the LAN cable and the radio

will switch to Ethernet from Wi-Fi in

seconds

17. 3.5 mm Line out jack

18. Telescopic antenna for FM

19. 3.5 mm Earphone jack

20. DC jack 5V IN

Remote Control

1. Power: Standby on/off

2. Mute: Speaker on/off

3. 0-9: Input numbers for encryption code, recall favorite

stations, enter index number to select item from

the list.

Toggle the same numeric key gives you a choice

to input letters

4. : Return to Main Menu

5. Mode: Switch between Internet radio/FM Radio /

Media Centre

6. Alarm: Alarm Setting

7. : Preset the current playing station to Favorite

8. : Recall the favorite list

9. Local: Access radio stations in your local country

10. Last: Switch between the current listening station and

the last listened station

11. ↑: Cursor up

12. ↓: Cursor down

13. ←: Cursor left/Back

14. →: Cursor right

15. Info: Quick access the network and system information

16. Enter: Confirm selection

17. : Next (next item in the list: next station, next track)

18. : Previous (Previous item in the list: previous station,

previous track)

19. Volume +: Increase volume

20. Volume -: Decrease volume

21. Sleep: Sleep Timer setting



Mode

Alarm

Sleep

Enter

Info

Local

Last

Enter encryption code of the Wi-Fi router

Using remote control

When you want to enter the letters, numbers or symbols for the encryption code, using remote

control would be easy to complete the job.

Here is the definition of each key and press the same button to cycling through different letters

/ symbol available

After each entry, press the right key to input the next. When it is done, press Enter to confirm.

Key 1: 1 and different kind of symbols !@#$%^&*()_+[]{};:'”\|,./<>?

Key 2: 2ABCabc

Key 3: 3DEFdef

Key 4: 4GHIghi

Key 5: 5JKLjkl

Key 6: 6MNOmno

Key 7: 7PQRSpqrs

Key 8: 8TUVtuv

Key 9: 9WXYZwxyz

Key 0: 0

Using buttons on the radio

Use the Dial control to scroll through the letters or symbols, press right key to input the next

entry. Press the Dial knob when it is done.

Before you start

Please ensure the following is ready:

You have a broadband internet connection.

A wireless broadband router is connected to the internet successfully.

The radio supports Wireless B, G and N connection (Wireless N router can also be used with

the setting on B or G).

You know the Wired Equivalent Privacy (WEP) or Wi-Fi Protected Access (WPA) data

encryption code/password. You need to key in the correct code when the radio is connected

to the wireless router for network connection.

If you do not know the code/password, please contact the person /technician who set up the

router/network for you.

The radio can work via Wireless network connection (Wi-Fi connection)

Precautions

The radio should not be used in a high temperature or high humidity environment over

prolonged periods of time as this may damage the unit.

Keep the radio away from liquids as it may get damaged. Please switch off the radio

immediately if water or liquids is spilled into the radio. Consult with the shop you bought this

radio for any question.

Avoid using or storing the unit in dusty or sandy environment.

Do not open and repair the radio by yourself.

Use only the AC adaptor supplied with the radio.

Connecting a power supply with a different rating will cause permanent damage to the radio

and may be hazardous.

Clean only with dry cloth.

Connect the radio with your Wi-Fi Router

1. Use the AC adaptor supplied with the product, one end to the DC socket located at the rear

side of the radio and the other end to the wall socket outlet.

Caution: Use only the adaptor supplied with the radio. Connecting a power supply

with a different rating will cause permanent damage to the radio and may be

hazardous.

2. The radio will power on and display as follow. Choose <Yes> to start configuring network.

3. Select <Add/Remove AP> and <Add AP>:

4. It will start scanning the available AP (Access points /Wi-Fi routers) nearby. Choose to

connect your AP and enter the encryption code. Press 'Enter' to confirm.

Remark: The encryption codes are case sensitive to upper and lower case.

5. When the Wi-Fi connection is done, the display shows:

Connecting to Network

eeeeeee

Configure Network?

GGGGGcYes> No

Welcome

Add/Remove AP

AP:[ ]

Add AP

Remove AP

Association complete

When this symbol appears, the radio is

trying to connect to the Wi-Fi network

Skytune

< 1/6 >

01:42AM

If you try to select Skytune when the Wi-Fi

network is not connected, it will show the

message below:

Skytune not connected,

retry later

After the Wi-Fi network is connected,

you will see the Wi-Fi signal bar here.

1. fm Bay Smooth Jazz

H2 ch

< 18/11225 00:25

iRadio

Ethernet connection

If you want to connect the internet via Ethernet, simply plug in the Ethernet cable to the

Ethernet socket at the rear side of the radio, you will see the Ethernet icon starts blinking,

it’s now connecting to the network. Once the icon goes steady, it means the network is

connected.

Start using internet radio

Press <Menu> to return to the main menu or the key on the remote controller. You will

see the item list below:

<My Favorite>- To show the list of favorite stations which have been assigned to the presets.

There are up to 99 presets available.

<Internet Radio>- Start exploring the worldwide radio stations and music here

<Media Centre>- Music streams from the UPnP servers/ devices under the same Wi-Fi

network

<FM Radio> - Listen to FM

To seek the FM radio station, press the Left or Right button, the radio will seek the next

available station. If you want to fine tune the frequency, please the up / down button on the

remote control.

When listening to FM radio, you can press the <Tune/Select rotary knob> to mute the sound

or <Enter> on the remote control

<Alarm>- Setting of Alarms

<Sleep Timer>- You can set the timer to turn the radio standby after certain time elapsed

<Configuration>- More settings available for you to configure the radio as you desire

My Favorite

This is to show the list of your Favorite stations which have been assigned to the presets.

Preset a station

There are 4 individual preset buttons on the radio allows to access the top 4 favorite stations.

The radio can store up to 99 preset stations for each Internet radio and FM radio.

While you are playing a radio station, press the utton on the remote control or long press

My Favorite

Internet Radio

Media Centre

Alarm

Sleep Timer

Configuration

12:00AM

Connecting to Network...

!!!

the <FAV> key on the unit, you will see the icon appears as below. It means the station is

added to the Favorite list.

The new added station will always showing in the last item on the Favorite list.

You can store up to 99 presets

Recall a station

To recall the full list of your Favorite station, simply press the <FAV> button on the radio or use

the remote control button .

You can enter the Index number to quickly scroll to the radio station you want to listen.

e.g., on the remote control, press 2 8 and <Enter>, it will scroll to the station no. 28.

Edit your favorite list

On the Favorite list, choose the radio station you want to edit then press the right key on the

remote controller. It will enter the Edit menu with the following options:

Move down – To move down the ranking of a station

Move up – To move up the ranking of a station

Delete – To delete a particular station

Internet Radio

On the main menu, choose <Internet Radio> and you will find the options below:

Skytune

Select Skytune to start enjoying thousands of radio stations over the world. You can filter your

search by Region, Music genre and talks. The <Local Radio> let you access quickly the

stations available in your local area.

You can change the Local Radio area under Configuration> Local radio setup.

Instead of browsing the radio station list, you can access the desired station by performing

search and input the name of the station.

History

The radio will memorize the stations you have listened on the radio. It can memorize up to 99

stations.

If you have listened more than 99 stations, it will supersede the first station that you have

listened.

Skytune

History

Local Radio

Globe All

Globe By Genre

Globe By Region

1. fm Bay Smooth Jazz

128kbps, 44100 Hz, 2 ch

< 1/1 00:39

HISTORY

Preset icon

Media Centre

UPnP (Universal Plug and Play)

You can stream music from the Networked device which supports UPnP function to the radio to

play.

For instance, most of the latest computer laptop supports UPnP, and you can stream music

from Windows Media Player application on the computer and listen on your radio.

Please make sure your computer laptop is on the same Wi-Fi network as the Radio

before you start using this function

1. If your PC is running Microsoft Windows XP, then you can use Windows Media Player

11(WMP11) to act as your UPnP (Universal Plug and Play) media server. (For Windows 7 or

above, please download the correspond version of Windows Media Player). The latest

Windows Media Player may be downloaded from Microsoft’s website and install by following

the instructions detailed in its installation wizard.

2. Once installed, Windows Media Player will create a library from all the media files available

to it on your PC.

2.1 Windows XP / Windows Media 11

2.1.1 To add new media files to the library, select’ File > Add to Library…> Advanced

Options’, Click ‘Add’ and choose the files you wish to add and click’ OK’.

2.1.2 Now you need to connect your Internet radio to Windows Media Player 11 and

configure it to allow the radio to access your media library. In order to this, you will

need to do the following:

a. On the radio, go to the main menu and select <Media Centre> <UPnP>.

b. It will scan for all available UPnP servers. Note, this may take a few seconds for the radio

to complete its scan and before the scan has completed, the radio will display ‘[Empty]’.

The radio will continue to display ‘[Empty]’ if no UPnP servers and found.

c. After a successful scan. Select your UPnP server, by rotating the dial if there is more than

one UPnP server, and then press SELECT.

2.1.3 Your PC will now prompt you that a device has attempted to connect to your UPnP

server. In order to allow the radio to have access to the media files, you will need to

click the ‘Library’ tab from Windows Media Player 11 and select the <Media Sharing>

item to open the ‘Media Sharing’ window.

Selecting ‘Media Sharing…’ for Windows Media Player11:

Inhaltsverzeichnis

Andere Ocean Digital Radio Handbücher

Ocean Digital

Ocean Digital WR-300 Bedienungsanleitung

Ocean Digital

Ocean Digital WR-210CB Bedienungsanleitung

Ocean Digital

Ocean Digital WR-390 Bedienungsanleitung

Ocean Digital

Ocean Digital WR-210CB Bedienungsanleitung

Ocean Digital

Ocean Digital DBA-01C8 Bedienungsanleitung

Ocean Digital

Ocean Digital DK-821B Bedienungsanleitung

Ocean Digital

Ocean Digital WR-230SF Bedienungsanleitung

Ocean Digital

Ocean Digital WR-100F Bedienungsanleitung

Ocean Digital

Ocean Digital WR-280S Bedienungsanleitung

Ocean Digital

Ocean Digital DB-220B Bedienungsanleitung

Ocean Digital

Ocean Digital WR-210CB Bedienungsanleitung

Ocean Digital

Ocean Digital WR-238CD Bedienungsanleitung

Ocean Digital

Ocean Digital WR-828F Bedienungsanleitung

Ocean Digital

Ocean Digital WR-230S Bedienungsanleitung

Ocean Digital

Ocean Digital WR-23F Bedienungsanleitung

Ocean Digital

Ocean Digital DBA-03R Bedienungsanleitung

Ocean Digital

Ocean Digital WR-880N Bedienungsanleitung

Ocean Digital

Ocean Digital DK-70 Bedienungsanleitung

Ocean Digital

Ocean Digital DB-825C Bedienungsanleitung

Ocean Digital

Ocean Digital DK-336 Bedienungsanleitung

Ocean Digital

Ocean Digital WR-23D Bedienungsanleitung

Ocean Digital

Ocean Digital DK-23 Bedienungsanleitung

Ocean Digital

Ocean Digital DB-332 Bedienungsanleitung

Ocean Digital

Ocean Digital WR-336N Bedienungsanleitung

Beliebte Radio Handbücher anderer Marken

EisSound

EisSound KBSound iSelect Bedienungsanleitung

Midland

Midland 1001LWX Bedienungsanleitung

Konig

Konig HAV-SR41 Bedienungsanleitung

Roberts

Roberts exprssion Bedienungsanleitung

VDigi

VDigi DD3.0 Bedienungsanleitung

Radio Shack

Radio Shack 21-1863 Bedienungsanleitung

Roberts

Roberts Stream 207 Bedienungsanleitung

Sony

Sony Walkman SRF-M97 Bedienungsanleitung

Stanley

Stanley FatMax FMC770 Bedienungsanleitung

auna

auna DAB-Radio 10026947 Bedienungsanleitung

SOUNDMASTER

SOUNDMASTER UR190 Bedienungsanleitung

HYT

HYT TC-320 Bedienungsanleitung

auna multimedia

auna multimedia Yellowstone 10026851 Bedienungsanleitung

B-Tech

B-Tech GMRS-V2 Bedienungsanleitung

Weierwei

Weierwei VEV-V8 Bedienungsanleitung

SOUNDMASTER

SOUNDMASTER DAB750 Bedienungsanleitung

Telefunken

Telefunken TF-1505 Bedienungsanleitung

Makita

Makita LXRM03 Bedienungsanleitung
