Ocean Digital WR-330D Bedienungsanleitung

WR-330D

Wooden Internet with DAB Radio

User Manual

Please read this user manual carefully before using the receiver

Important Safety Instructions...........................................1

Battery Instructions.........................................................2

Location of Controls.........................................................3

Remote Control................................................................4

Switching the radio on......................................................5

Connecting to your WiFi Network.....................................6

Internet Radio..................................................................7

Bluetooth ........................................................................9

Media Center..................................................................10

FM Radio........................................................................11

DAB Radio......................................................................12

Information Center.........................................................13

Configuration.................................................................14

Trouble Shooting............................................................18

Technical Specification..................................................20

Contents

Warning: To prevent ﬁre or shock hazard, do not expose the unit to rain or

moisture.

To avoid electrical shock, do not dismantle. Refer all servicing to qualiﬁed service

personnel.

1. Please read all of the instructions carefully and retain for future reference.

2. When using electrical appliances, basic safety precautions should always be

followed.

3. This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction concerning

use of the appliance by a person responsible for their safety.

4. This product is not a toy! Children should be supervised to ensure that they do not

play with the appliance.

5. Any repairs must be done by qualiﬁed service personnel. There are no user-

serviceable parts inside. Do not attempt to repair by yourself.

6. Keep the unit away from sharp edges that could cause damage.

7. Keep the unit free from dust and away from heat sources, direct sunlight,

humidity, water or other liquids.

8. Use only with the provided adaptor.

9. Do not operate the product with a damaged adaptor cord or plug, or if the product

malfunctions, or is dropped or damaged in any manner.

10. If the adaptor cord is damaged, it must be replaced by the manufacturer, its

service agent or similarly qualiﬁed persons in order to avoid hazard.

11. When removing the adaptor plug from the wall outlet, always pull directly on the

plug; never pull on the cord.

12. Do not immerse the unit in water or other liquids.

13. Do not operate the unit if it has been exposed to water, moisture or any other

liquid in order to prevent electric shock, explosion and/or injury to yourself and

damage to the unit.

14. Do not use the unit for anything other than its intended use.

15. Do not store the unit in direct sunlight or in high humidity conditions.

16. Do not insert foreign objects into any opening on the unit.

17. Unplug the adaptor after the unit has been used, before it is cleaned and whilst

being repaired.

18. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

19. Keep the unit away from ﬂammable materials.

- 01 -

Important Safety Instructions

Battery Instructions

1. Replace with batteries of the same or equivalent type as recommended.

2. Ensure correct polarity when inserting batteries.

3. Do not expose batteries to excessive heat sources such as ﬁre and direct

sunlight.

4. Remove any batteries from the remote control when it is not being used for a long

period of time to avoid leakage.

5. Keep batteries out of reach of children.

6. Rechargeable batteries should only be charged under adult supervision.

7. Do not throw in ﬁre, crush, puncture, dismantle or otherwise damage the

batteries.

8. Do not expose batteries to heat or ﬁre as they may explode.

9. Do not dispose of batteries in your household waste. Contact your local council

for information on disposal or recycling.

- 02 -

1. Power

On/Standby mode

2. Mode

Press to change the radio mode

(Switch between Internet radio /

DAB radio / FM radio/ Media Center

[UPnP] / Bluetooth)

3. Preset

Press and hold to enter favourite

list

Press brieﬂy to recall the favourite

list

4. Left

Back to previous menu / left cursor

5. Right

Right cursor / Enter edit menu

under Favourite list

6. Menu

Access main menu

7. Up / Down / Enter

Rotate to scroll up or down on the

main menu / Push to conﬁrm or

select menu options / Push to stop

or resume playback of radio

channel

8. Volume dial

Rotate to adjust the volume level

9. TFT 2.4” color screen

10. Speaker

11. DC IN jack

12. Antenna

- 03 -

Location of Controls

2 1 7458

Remote Control

1. : Standby button

2. : Mute

3. 0-9: Favorite station key / input letters and

numbers for WiFi Encryption code

4. :Dim the display

5. : Favorite button, adding station to your

favorite list

6. ▲ : Cursor up

7. ▼ : Cursor down

8. ◄ : Cursor left / back to previous menu

9. ► : Cursor right

10. OK : confirm button

11. : Alarm button

12. : Sleep Timer

13. Vol+ : Volume up

14. Vol- : Volume down

15. : Main Menu

16. Mode: Switch between Internet Radio, DAB

Radio, FM Radio, Media Center (UPnP)

and Bluetooth

17. EQ : Equalizer

18. : Previous song (for UPnP / Bluetooth)

19. : Play/pause (for UPnP / Bluetooth)

20. : Next song (for UPnP / Bluetooth)

- 04 -

The remote control uses 2 x 'AAA' batteries(batteries not included). Open the

battery compartment and insert the batteries ensuring correct polarities.

Connect the mains adaptor to the radio unit - one end to the DC IN on the radio and

the other end to the AC mains wall socket.

Caution: Use only the mains adaptor supplied with the radio. Connecting a

power supply with a different rating will cause permanent damage to the radio

and may be hazardous.

The radio will power up and display Welcome:

Select the language for the radio menu:

It will ask to set the <Check Network when Power on>, it is suggested to choose

<Yes>. The radio will always check the available WiFi network automatically.

- 05 -

Switching the radio on

Connecting to your WiFi Network

Now you can adjust the network conﬁguration setting. Choose <Yes> to start

searching for available WiFi networks. If your router has Wi-Fi Protected Setup

(WPS) function, you can select <Yes(WPS)> to proceed.

After the search is done, it will display a list of the available WiFi networks.

Choose your network from the list; enter the password if the network is set with

encryption code. If your network does not require any password to access, the WiFi

will be connected automatically.

Note: The encryption code would have been set up by the person who set up

and conﬁgured your network.

Follow the steps below to enter the password of your WiFi network:

- Rotate the [Up/Down/Enter] dial to browse through the characters

- Press the [Right] button to skip to the next entry

- When it is done, push the [Up/Down/Enter] dial to conﬁrm.

The radio will start connecting to the network.

When the WiFi is connected successfully, it will pop to the main menu and you are

ready to access available internet radio stations.

08:58

Internet Radio

- 06 -

Choose <Internet Radio> from the menu to see several listed options.

To start listening to available radio stations, select <Radio Station/Music>. You

can ﬁnd your favourite station by Genre or Location.

My Favorite

This is to show the list of your Favorite stations which have been added to the list.

To preset a station:

When your favourite station is playing and you want to add it to favourite list, press

and hold the [Preset] button and <Add to My Favorite> menu will display. The

preset number will be assigned automatically to the next available number. Push

the [Up/Down/Enter] dial to conﬁrm. The playing station will be added to the preset

list.

The presets will be stored in ascending order. You can store up to 250 presets.

Note: Presets 1 to 5 are for your favourite channels. The ﬁrst time you add a

preset station, Preset 6 will be recommended. To add a channel to preset 1-5,

simply scroll up to the desired preset.

You can edit your favorite list anytime with the options below:

Delete – To delete the selected station

Shift up- To shift the selected station by one level up on the ranking

Shift down – To shift the selected station by one level down on the ranking

Rename – To rename the selected station

Play – press and play the selected station

Navigate to <My Favourite> on the menu or press the [Preset] button, choose the

radio station that you want to make the above changes. Then press the [Right]

button to enter the edit menu.

Push [Up/Down/Enter] dial to conﬁrm

The symbol on the top row means

station is added to favourite list

- 07 -

Internet Radio

To recall a preset station:

Press the [Preset] button brieﬂy and choose your desired station.

Local Radio

Select this option to quickly access the radio stations located in your country.

History

The radio will memorise the last 10 listened stations.

Service

Search Stations

You can ﬁnd your desired radio station by inputting the name of the radio or just a

few characters to ﬁlter the list.

Add New Radio Station

If you want to add the station and you have the audio stream URL, you can add it

through the MediaYou website as follows, or you can contact MediaYou if the station

cannot be located.

http://www.mediayou.net/

Please refer to the “Manage My mediaU” under Conﬁguration section below for

more details.

When a radio station is playing, press the [Right] button and it will display the

station logo (if any). Continue to press the [Right] button to view the radio

information.

- 08 -

Internet Radio

Station
