OEM Tools ViperFlex 24424 Bedienungsanleitung
24424
Hose Reel and 50 Ft. x 3/8"Hose
OWNER’S MANUAL
Read this manual carefully before using this product.
This product is not intended for use by children.
Protect yourself and others by observing all safety information,
warnings and cautions. Failure to comply with instructions could
result in personal injury and/or damage to product or property.
1.
Please retain instructions for future reference!
®
GENERAL SAFETY
The product is designed for use on regulated compressed
air lines or on air compressors where the air pressure
does not exceed the maximum pressure limit of the hose.
Failure to follow this may result in personal injury and or
property damage.
Do not release hose rapidly. Retracting hose could cause
injury or property damage. Maintain control of hose as it
retracts.
INSTALLATION
1. Using the reel mounting bracket as a guide, drill 4 pilot
holes into wood wall studs or work bench.
2. Attach hose real, using the screws provided or bolts
and washers.
2.
Make sure that the mounting will
support up to 55 pounds
3. Connect air supply to 1/4” M X M NPT inlet fitting.
4. Connect desired quick connect or tool to the
1/4” M X M NPT outlet fitting.
OPERATION
1. To extend hose, pull hose to desired length. The hose
reel must be released to maintain its length. It may be
necessary to pull hose beyond desired length to keep
it from automatically retracting.
2. To retract, pull hose lightly then allow it to retract.
Hose will then automatically retract.
Do no release hose rapidly! Retracting hose could cause
injury or property damage. Maintain control of hose as it
retracts.
3.
4.
1. Self-laying system
2. Metal Handle
3. Safety Hook
4. Metal Mounting Bracket
5. Optional-position Lock
2.
1.
3.
4. 5.
SPECIFICATIONS
Hose Length: 50 Ft + 3 Ft
Working Pressure: 300 PSI
Burst Pressure: 900 PSI
Hose Material: Premium Hybrid Polymer
Air Inlet Thread Size: 1/4”
Hose End: 1/4” M X M NPT Brass Coupler
PACKING INFORMATION
MEAS: 40 x 22 x 33cm
G W/N W: 6.5 / 5.5kgs
5.
ViperFlex®is a registered trademark
of GreatNeck Saw Manufacturing
6.
One Year Limited Warranty:
For one year from the date of purchase of this OEM®
product you find any defect in material or workmanship,
through normal usage and not including standard wear,
either return it to the place of purchase, or send it to
OEM® for repair or replacement at our discretion. In
order to obtain this service send your tool and proof of
purchase, transportation pre-paid, to OEM® Q.A. Dept,
3580 E. Raines Rd. #3, Memphis, TN 38118. This warran-
ty gives you specific legal rights, and you may also have
other rights, which vary from state to state.
Please see our website for full warranty information.
OEM® Company, Mineola, NY 11501
Made In China
www.oem-tools.com
7.
TM
24424
Hose Reel and 50 Ft. x 3/8"Hose
OWNER’S MANUAL
