OfficeSource EVH100BGG Bedienungsanleitung
OFFICE FURNITURE
MODEL NO. EVH100BGG/EVH100DBK
OFFICESOURCE.COM
Last Updated: 6/2022
ASSEMBLY INSTRUCTIONS
48" Height AdjustableReturn
D E
IMPORTANT NOTE:
Place all wooden parts on a cleanand smooth surface such as a rug or carpet to avoid the parts from being scratched
Check that you have all parts and hardware.
Remove all wrapping materials, including staples & packing straps before you start assemble.
Do not tighten all screws or bolts untill all completely assembled.
Keep all hardware parts out of reach of children.
Top support
Bracket 1 Pc
Hardware is packed with carton EVH100BGG
Hardware is packed with carton EVH100DBK
EVH100BGG
EVH100DBK
LEFT RETURN RIGHT RETURN
Allen Wrench
3mm-1pc
®
OFFICE FURNITURE
MODEL NO. EVH100BGG/EVH100DBK
OFFICESOURCE.COM
Last Updated: 6/2022
ASSEMBLY INSTRUCTIONS
®
1
N
OTE: The Return Desk can be installed as a Left Handed or Right Handed. Right Handed
is shown in the instructions. If Left Hand is desired, attach Modesty Panel (E) to other
side in Step 2.
P.2
48" Height AdjustableReturn
2Assemble Modesty Panel (B) toMetal Base (EVH100CBK) using Screws (3)
3
E
12
Assemble Metal Base (EVH100DBK)
using Screws (5)
Step 1st
Step 2nd
OFFICE FURNITURE
MODEL NO. EVH100BGG/EVH100DBK
OFFICESOURCE.COM
Last Updated: 6/2022
ASSEMBLY INSTRUCTIONS
®
P.3
3
Assemble Return (EVH100BGG) with Main Desk EVH400AGG
48" Height AdjustableReturn
15
15
5
2
EVH400AGG
EVH100CBK
7
8
Step 1st
Step 1st
Before assembling, please raise the top at the same time.
1
1
1
1
Step 2nd
OFFICE FURNITURE
MODEL NO. EVH100BGG/EVH100DBK
OFFICESOURCE.COM
Last Updated: 6/2022
ASSEMBLY INSTRUCTIONS
®
P.4
5
48" Height AdjustableReturn
EVH400AGG
EVH400AGG
RIGHT RETURN
LEFT RETURN
OFFICE FURNITURE
MODEL NO. EVH100BGG/EVH100DBK
OFFICESOURCE.COM
Last Updated: 6/2022
ASSEMBLY INSTRUCTIONS
®
P.5
48" Height AdjustableReturn
Hardware is packed with carton EVH100CBK
