Ogawa Tapping Footte Bedienungsanleitung

User Manual

OF 1728

使用手册

All information is correct at the time of print

User Manual

CONTENTS

Safety Instructions 03

Warranty Claims 05

Main Unit & Accessories 06

Controller Diagram 06

Product Operation Guide 07

Product Maintenance 08

Troubleshooting 09

Product Speciﬁcations 10

Safety Instructions

i. Usage environment

●Do not use the appliance in a wet condition or dusty environment as this may

result in malfunction or electric shock.

●Do not use the appliance in the bathroom.

●Do not use the appliance on the bed.

●Do not place or store the appliance where it can fall or be pulled into a tub or

sink. Place the appliance in a safe location.

●Do not sit on the appliance.

●Do not expose the appliance to a heater or direct sunlight.

ii. Health Precautions

If you are experiencing health complications or conditions as stated below, please

consult your doctor before use:

- Suffering from heart disease

- Pregnancy

- Any health concerns

iii. When the product should not be used

●If the use exceeds 15 minutes at one time.

●This unit should not be used by children or invalids without adult supervision.

●Do not use this product before sleep.

●If the fabric cover is torn.

●If water is accidentally spilled onto the appliance.

●If the user feels abnormal or severe pain during the massage.

●If the user detects any malfunction or other abnormal conditions during

operation.

●If there is lightning.

iv. Caution and warning

●Unplug the appliance from the outlet when not in use

●Do not use any attachments that are not recommended by OGAWA

●Do not operate this appliance if it has a damaged cord or plug. Please return

the unit to OGAWA Service Center for examination and repairs.

Safety Instructions

●Do not drop or insert any object into any opening.

●Handle heated surfaces carefully. The unattended use of the heated surfaces

by children or invalids may be dangerous.

●Do not lift or carry this appliance by the power cord or any cord.

●This appliance is designed only for personal use, and not for professional

purposes.

●Do not cover the appliance during operation.

●Do not crush the appliance and avoid any sharp folds.

v. Note

●To ensure safe and proper use of the appliance, do not operate it before

reading this user manual carefully first.

●The appliance is not intended for use by persons with reduced physical,

sensory or mental capabilities, or lack of experience and knowledge. They

need to be supervised and instructed about its usage by a person responsible

for their safety.

●Extensive usage could lead to excessive heating and a shorter product

lifespan. Should this occur, discontinue the use and allow the unit to cool

before operating again.

●For people under medication or with a medical condition, please consult your

doctor before use. Please do not use the product if you are not feeling well.

●If the appliance is used in a cold room, do not increase the room temperature

abruptly. It is advised that the temperature is gradually increased to a normal

level.

●If the appliance is stored in a cold place and being taken into a warm

environment, please wait one hour before use to get the optimum massaging

level.

●Do not remove the cover of the appliance. Mishandling the internal

components may result in malfunction or electric shock.

●Do not connect or disconnect the power plug from the electrical outlet with

wet hands.

●Do not use the appliance if the electrical outlet is loose.

The appliance has a heated surface. Persons insensitive to heat must be●

careful when using the appliance.

Warranty Claims

1. Warranty is not transferable.

2. This warranty is effective only if the product is purchased from OGAWA.

3. Proof of purchase (original receipt) is required for all warranty repairs.

4. All implied warranties, including but not limited to these implied warranties of fitness

and merchantability, are limited to the duration stated in the warranty policy.

5. Damage due to misuse, improper treatment and unauthorized modification and

repair are not covered by this warranty.

6. Warranty does not cover accessories and attachments which do not belong to the

massage unit.

7. Warranty is not effective to rental, business, commercial, institutional or other non-

residential users.

8. All services covered by this warranty must be approved by OGAWA and repaired by

authorized technicians only.

9. If replacement parts for defective materials are not available, OGAWA reserves the

right to make substitution in lieu of repair or replacement.

Safety Instuctions

The appliance is only to be used with the power supply provided.

This appliance can be used by children adged from 8 years and above and persons

with reduced physical, sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or instruction concerning use of the

appliance in a safe way and understand the hardzrds involved.

Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by children without supervision.

●

Main Unit & Accessories

Controller Diagram

Washable cloth

Console

Main Body

Wiring storage

Stand

1) POWER Button-Control supply of the appliance,

When button is press, the LED light will on.

2) Tapping Button-3 selection mode

Mode 1: green LED is on

Mode 2: blue LED is on

Mode 3: red LED is on

3) Heating Button-Press this button to activate heat

function, the red LED will on. Press again to stop

the function.

4) Intensity Button-Control the massage intensity of the appliance via 3 modes:

The green LED is weak, blue LED is middle, red LED is strong.

5) The Mode Function-

Mode 1: blue LED is on

Mode 2: green LED is on

Mode 3: red LED is on

6) Tapping speed controller- CW is to increase the speed. CCW is to decrese

the speed.

①

②

③④

⑤

⑥

Product Operation Guide

i. Preparation before use

1. Before using the appliance

●Check if there is any damage to the appliance.

●Check the appliance is placed in the proper position.

ii. Operation guide

1. Untie the cord and plug in the appliance into 220-240V 50/60Hz socket. the

buzzer will ring, the appliance will enter a standby state.

2. Operating method

●The appliance are in stand by mode, touch Power button, buzzer will sound,

decorative light will on, product enter to on mode, at the same time appliance

enter to 15 minute countdown.

Touch Mode button to activate Mode 1, Mode 2, Mode 3-close(at the same

time shut off tapping & heating) in a cycle. Each change, the buzzer will ring

and corresponding LED will turn on.

In auto mode, intensity is preset in week, green LED, tapping is in standby mode.

Mode 1: blue LED is on

Mode 2: green LED is on

Mode 3: red LED is on

Tapping button

1) Tapping function can be activate when Auto mode is off. The strength can be

adjust from tapping speed controller. Touch tapping button to activate tapping

function.

2) In auto mode,tapping button is white LED, tapping function can be on/off

independently, The strength can be adjust from tapping speed controller.

Heating function can be on/off independently by touching the heating button.

●

Mode 1: green LED is on

Mode 2: blue LED is on

Mode 3: red LED is on

When acivate, LED light will on and LED will off when function is off. The buzzer

will sound and corresponding LED will on.

●

Intensity button--Control the massage intensity of the appliance via 3 modes.

●

The green LED is weak, blue LED is middle, red LED is strong.●

white LED.

Product Maintenance

TO STORE

●Place the massager in this box or in a safe, dry and cool place. Avoid any contact

with sharp edges or pointed objects that might cut or puncture the surface.

●Please wind up and store the power cord under the appliance bottom frame. Do not

hang the unit by the power cord.

TO CLEAN

●Close the power button and unplug the unit before cleaning.

●Clean only with a soft, slightly damp sponge.

●The attachable cloth can be used to clean the appliance.

CAUTION

●Avoid using any corrosive detergent, such as Benzene or diluents to clean the

appliance.

●Take care of the LOGO area in order to avoid tearing the cloth via its edges.

MAINTENANCE

●Do not discard the protective film as much as possible in order to protect the metal

LOGO.

●Keep the appliance clean and store it away from wet conditions.

●If the appliance is not used for a long time, please use a dust cover (please buy it

by yourself) to cover the appliance, to avoid any dust on the product.

Operating Guide

When the appliance is on, it will enter into 15 minute countdown. Once reach 15 minute,

rall process will stop. Appliance turn into standby mode.

When the appliance is on standby mode, unplug the cord it will cut off the current.

●

Tapping speed controller●

Under activating tapping function, speed controller can be use

1) Turn button in CCW, tapping strength will decrease.

2) Turn button in CW, tapping strength will increase.

Troubleshooting

This massager is controlled by an integrated chip and is susceptible to power surges

from +10% to -15%. Due to this, the massager might display the following:

Conditions Solutions

Not operating 1. Check if the plug is connected properly.

2. Press the “POWER” button.

During operation, the appliance

is not operating

1. Check the plug is connected properly.

2. Press the “POWER” button again.

3. After the appliance has cooled down,

press the “ POWER” button again.
