GD-1340
GD-1340
for MC760/MC770/MC780/ES7460/ES7470/ES7480/MPS3537/MPS4242
SET-UP GUIDE
Warnings Points
• Theunpackingandsetupprocedureshallbedonebyaqualiedservicetechnician.
• Besuretounplugthepowercableoftheequipmentbeforeinstallingandsettinguptheproduct.
• Disconnectthegroundwireafterunpluggingthepowercable.Inaddition,besuretoconnectthegroundwire
beforepluggingthepowercable.
Cautionary Points
• Installtheequipmentnearanoutlet.Besuretowirethepowercablesecurelysoastounplugiteasilyandnot
totripoverit.
• Accordingtotheequipmentmodel,theseillustrationsmaydiffer.
• Thecoversofthisequipmenthavebeendesignedsoasnottobeeasilyremoved.Therefore,whenusing
tools,besurenottoputyourfaceandhandsinthedirectioninwhichforcewillbeapplied;otherwisethiscould
resultininjury.Inaddition,payattentionnottodeformpartsbyusingtoomuchforce.
• Whenunpackingandsettinguptheproduct,besuretowearglovestoavoidinjury.
Accessories
A
B E
D
H
a
J
2 / 11
GD-1340
Setup
1. Take out the FAX unit and the accessories.
2. Take off the covers.
•ForJPD:3covers
•OtherthanJPD:2covers
3. Take off the cover.
*Youmustwearglovesforthisprocedure.
1) Remove[b]and[e].
•b:1
•e:1
2) Open[F].
3) Pushthelockingbuttontoopen[G].
F
G
b
e
3 / 11
GD-1340
4) Remove[b].
5) Remove[e].
6) Openthecoversintheorderof(A)and(B).
7) Close[G].
G
B
A
b
e
4 / 11
GD-1340
8) Releasethelatches(A)ofthecover.
•A:2
* Asshowninthegure,insertaathead
screwdriverintothegrooveandpushitin
thedirectionofthearrowtoreleasethe
latches.
When using tools, be sure not to put your
face and hands in the direction in which
force will be applied; otherwise this could
result in injury.
9) Releasethelatches(B)ofthecover.
•B:2
* Asshowninthegure,insertaathead
screwdriverintothegrooveandpushitin
thedirectionofthearrowtoreleasethe
latches.
When using tools, be sure not to put your
face and hands in the direction in which
force will be applied; otherwise this could
result in injury.
10)Releasethelatch(D)ofthecover.
•D:1
* Asshowninthegure,insertaathead
screwdriverintothegrooveandpushitin
thedirectionofthearrowtoreleasethe
latches.
When using tools, be sure not to put your
face and hands in the direction in which
force will be applied; otherwise this could
result in injury.
A
A
B
B
D
5 / 11
GD-1340
11)Closer[F].
12)Takeofftheuppersideofthecover,release
thelatch(E)andthentakeoffthecover.
•E:1place
4. Loosen the screws and take off the cover.
•Screws:15places
E
F
6 / 11
GD-1340
5. Connect the connectors of [D] and [B] to
the board.
6. Place [A] into the attaching position and
secure it with [a].
•a:4
When installing [A], be careful not to
catch the rear side cables.
7. Connect the cable of [A] to the board.
D
B
a
A
A
a
A
7 / 11
GD-1340
8. Connect the connectors of [D] and [B] to
[A].
9. Attach the cover and tighten the screws.
•Screws:15places
10. Insert its latch (E) and then the parts
indicated by the arrows as shown in the
figure.
Perform this operation with care to avoid
injury. In addition, be sure not to damage
the cover.
11. Insert the latches (A) and (B) of the cover.
•A:2places
•B:2places
E
A
B
A
B
A
B
D
A
8 / 11
GD-1340
12. Open [F].
13. Insert the latch (D) of the cover.
14. Close the covers in the order of (A) and (B).
15. Push the locking button to open [G].
16. Attach [b].
•b:1
G
b
BA
F
D
9 / 11
GD-1340
17. Attach [b] and [e].
•b:1
•e:1
18. Attach [e].
•e:1
19. Close in the order of [G] and [F].
20. Connect [E].
21. Connect the cable from the telephone.
G
F
E
b
e
e
10 / 11
GD-1340
22. Attach the label [H].
•H:1
23. Select the corresponding label [J]
according to the destination and applicable
model and attach it.
•J:1
24. The operation is now completed.
Setting Destination
1. Destination
(1)Plugthepowercable.
(2)TurnthepowerONbymeansofthemainpowerswitchwhilepressing[0]and[8]simultaneously.
(3)[9001]→[START]button
(4)Keyinthedestinationnumbershownbelowandthenpressthe[OK]button.
0:Japan
1:Asia/Chile/Peru/Argentina/SaudiArabia/Singapore/Malaysia
2:Australia/NewZealand 3:HongKong 4:U.S.A/Canada
5:Germany/Cyprus/Luxembourg/Ireland
6:England 7:Italy 8:Belgium
9:Holland 10:Finland 11:Spain
12:Austria 13:Switzerland 14:Sweden
15:Denmark 16:Norway 17:Portugal
18:France 19:Greece 20:Poland
21:Hungary 22:CzechRep. 23:Turkey
24:SouthAfrica 25:Taiwan 26:Russia
27:Brazil
(5)Shutdowntheequipmentbypressingthe[ON/OFF]buttonuntilasoundisaudible.
J
H
