Thank You for purchasing this

Factory Service Manual on EBAY

from PCTECHINFO!

Click Here for more Factory Service

Manuals for other Computer and

Printer / Copier Manufacturers

from PCTECHINFO!

Page: 1

Service Guide ML390/391

Chapter 0 About This Manual

ML390/ML391

Dot Matrix Printers

Adobe Acrobat printable reference

copy of the OKIDATA Service Training Manual.

09/17/97

Note: This Adobe Acrobat version of the Okidata Service Training Manual was built with the

pictures rendered at 300 dpi, which is ideal for printing, but does not view on most

displays well.

Partner Exchange (BPX) for any updates to this material. (http://bpx.okidata.com)

Table of Contents Page

Service Guide ML390/391

0 About This Manual

Front Cover 1

Manual Copyright 2

1 Product Specifications

1.1 General Description - General Information 3

....1.1.02 Compatibility - Microline 390/391 vs. Microline

390/391-Plus 4

1.2 Product Specifications 5

1.3 Paper Specifications 6

1.4 Physical Specifications 7

1.5 Power Requirements 8

1.6 Environmental Requirements 9

1.7 Agency Approvals 10

1.8 Options 11

1.9 Consumables 12

1.10 Memory Specifications 13

1.11 Reliability Specifications 14

2 Principles of Operation

2.1 Printer Overview - General Information 15

....2.1.02 Compatibility - Microline 390/391 vs. Microline

390/391-Plus 16

2.2 Circuit Board Description 17

....Block Diagram (Microline 390/391) 18

....Block Diagram (Microline 390/391-Plus) 19

2.3 Electrical Operation - Initialization 20

....2.3.02 Interface Control 21

....2.3.03 Print Head Drive Circuit 22

....2.3.04 Spacing Operation 23

....2.3.05 Line Feed 24

....2.3.06 Alarm Circuits 25

2.4 Mechanical Principles Of Operation - Printhead 26

....2.4.02 Space Mechanism / Operation 27

........Head Gap Adjusting Mechanism 28

............Head Gap Adjusting Mechanism - Diagram 1 29

............Head Gap Adjusting Mechanism - Diagram 2 30

....2.4.03 Ribbon Drive Mechanism / Operation 31

....2.4.04 Paper Feed Mechanism 32

....2.4.05 Paper-End Detection Mechanism 33

....2.4.06 Semi-Automatic Sheet Feeder (SASF) Operation 34

....2.4.07 Release Lever Operation 35

3 Maintenance & Disassembly

3.1 Maintenance - General Information 36

Table of Contents Page

....3.1.02 Maintenance Tools 37

....3.1.03 Maintenance Precautions 38

3.2 Disassembly/Assembly Procedures 39

....3.2.01 Preliminary Items 40

....3.2.02 Separator Assembly 41

....3.2.03 Printhead Assembly 42

....3.2.04 Upper Cover Assembly 43

....3.2.05 Operator Panel Assembly 44

....3.2.06 Control Board - Revs A and B 45

........Control Board - Rev C 46

....3.2.07 IC Card (B) Panel 47

....3.2.08 Transformer - Revs A and B 48

........Transformer - Rev C 49

....3.2.09 Filter Assembly 50

....3.2.10 Power Supply Board - Revs A and B 51

........Power Supply Board - Rev C 52

....3.2.11 Power Interconnect Module / Cable Guide - Revs A

and B 53

........Power Interconnect Module / Cable Guide - Rev C 54

....3.2.12 Indicator Assembly (Bail Bar Assembly) 55

....3.2.13 Head Cable Access Cover and Connection Board

(SRBS) 56

....3.2.14 Ribbon Feed Gear Assembly 57

....3.2.15 Space Motor Assembly 58

....3.2.16 Carriage Frame Assembly 59

....3.2.17 Space Rack 60

....3.2.18 Guide Rail 61

....3.2.19 Platen Assembly 62

....3.2.20 Line Feed Motor and Gear - Line Feed Motor 63

........Line Feed Motor and Gear - Line Feed Motor Gear 64

....3.2.21 Line Feed Motor Interconnect Module 65

....3.2.22 Reset Spring, Change Gear, and Idler Gear 66

....3.2.23 Release Lever 67

....3.2.24 Paper Pressure Guide 68

....3.2.25 Pressure Roller Assembly 69

....3.2.26 Tractor Assembly 70

....3.2.27 Sensor Lever 71

....3.2.28 Paper End (B) Lever 72

....3.2.29 Main Chassis Assembly 73

3.3 Adjustments - General Information 74

....3.3.01 Printhead Gap Adjustment 75

3.4 Cleaning 76

3.5 Lubrication 77

4 Failure & Repair Analysis

Table of Contents Page

4.1 Overview - Introduction 78

....4.1.02 Compatibility - Microline 390/391 vs. Microline

390/391-Plus 79

4.2 Troubleshooting Updates 80

4.3 Reporting Problems 81

4.4 Troubleshooting Tips 82

4.5 Fault Alarms 83

4.6 Repair Analysis Procedures - Using The RAPS 84

....4.6.02 RAP Index 85

....4.6.03 Troubleshooting Cautions 86

........RAP 01: Operator Panel Lamps Do Not Light 87

........RAP 02: Abnormal Spacing 88

........RAP 03: Wrong or Missing Characters / Dots on Output 89

........RAP 04: Line Feed Problems 90

........RAP 05: Malfunction of Operator Panel Switch(es) 91

........RAP 06: Parallel Interface Does Not Receive Data 92

........RAP 07: Serial Interface Does Not Receive Data 93

4.7 Hexadecimal Dump 94

4.8 Resistance / Service Checks - Index To Charts 95

....4.8.02 Interconnect Diagrams - Microline 390/391 - Rev. A

and B 96

........Interconnect Diagrams - Microline 390/391 - Rev C 97

........Interconnect Diagrams - Microline 390/391 - Plus 98

....4.8.03 Printhead 99

....4.8.04 Space Motor 100

....4.8.05 Line Feed Motor 101

....4.8.06 Operator Panel Board 102

....4.8.07 Control Board 103

4.9 Printer Tests - General Information 104

....4.9.02 Rolling ASCII Print Test 105

....4.9.03 Font Sample Test 106

....4.9.04 Serial Interface Loopback Test 107

4.10 Menu Operation 108

4.11 Top Of Form 109

4.12 Paper Park 110

4.13 Forms Tear Off 111

A Board Diagrams

A.1 Board Reference Charts - General Information 112

....A.1.02 Compatibility - Microline 390/391 vs. Microline

390/391-Plus 113

A.2 Index To Charts - Microline 390/391: Rev A And B 114

....Index To Charts - Microline 390/391: Rev C 115

....Index To Charts - Microline 390/391 - Plus 116

....A.2.01 Control Board (SKRB) - Rev A and B 117

Table of Contents Page

....A.2.02 Control Board (SKRA) - Rev C and "Plus" Printers 118

....A.2.03 Power Supply (PAII) - Rev A and B 119

....A.2.04 Power Supply (SUII) - Rev C and "Plus" Printers 120

....A.2.05 Filter Assembly 121

....A.2.06 Operator Panel (LXSP) - Microline 390/391 122

....A.2.07 Operator Panel (LXSP-5) - Microline 390/391-Plus 123

....A.2.08 Interconnect Board (SRBS) 124

....A.2.09 RS232-C Serial Interface (LXHI) 125

B Illustrated Parts Listing

B.1 Illustrated Parts Listing - General Information 126

....B.1.02 Definitions of Terms 127

....B.1.03 Compatibility - Microline 390/391 vs. Microline

390/391-Plus 128

....B.1.04 Parts Ordering Information 129

B.2 Charts - Index 130

....B.2.01 Covers 131

....B.2.02 Electrical Components - Rev A and B 132

....B.2.03 Electrical Components - Rev C 133

....B.2.04 Printer Mechanism - Rev A and B (1 of 2) 134

....B.2.05 Printer Mechanism - Rev A and B (2 of 2) 135

....B.2.06 Printer Mechanism - Rev C (1 of 2) 136

....B.2.07 Printer Mechanism - Rev C (2 of 2) 137

....B.2.08 Operator Panel 138

....B.2.09 Carriage Assembly 139

....B.2.10 Tractor Assembly 140

....B.2.11 Options 141

....B.2.12 Consumables 142

....B.2.13 Packaging 143

....B.2.14 Documentation 144

Page: 2

Service Guide ML390/391

Chapter 0 About This Manual

This document may not be reproduced without written permission of the Okidata ® Technical Training

Group. Every effort has been made to ensure the accuracy of the information contained in this training

course. Okidata is not responsible for errors beyond our control.

First Edition April, 1994

Written and produced by the Okidata Technical Training Group

Please address any comments on this publication to:

Technical Training Group

Okidata

532 Fellowship Road

Mount Laurel, NJ 08054-3499

Fax Number: (609) 235-2600, ext. 7034

Okilink Login Name: Technical Training

OKIDATA is a registered trademark of Oki Electric Industry Company, Ltd.; marques deposee de Oki

Electric Industry Company, Ltd.; marca registrada, Oki Electric Industry Company, Ltd.

Microline is a registered trademark of Oki Electric Industry Company, Ltd.

Centronics is a registered trademark of Centronics Inc.

IBM is a registered trademark of International Business Machines, Inc.

Proprinter is a registered trademark of International Business Machines, Inc.

Partner Exchange (BPX) for any updates to this material. (http://bpx.okidata.com)

Page: 3

Service Guide ML390/391

Chapter 1 Product Specifications

1.1 GENERAL DESCRIPTION

1.1.01 General Information

The Microline 390, Microline 391, Microline 390-Plus, and 391-Plus are twenty-four pin, dot matrix printers.

These printers provide Epson LQ and IBM Proprinter emulations, which are selected through the Printer

Menu.

The major difference between the Microline 390/390-Plus and Microline 391/391-Plus is the width of each

printer. The Microline 390/390-Plus can handle 80 print columns (at 10 CPI). The Microline 391/391-Plus

can print up to 136 columns (at 10 CPI).

The standard interface is a Centronics parallel and an optional RS232-C serial interface can be installed.

The optional serial interface can transfer data at speeds up to 19.2K baud.

Both printers feature an enhanced operator panel which provides access to the following capabilities.

· Menu Selection

· Quiet Mode

· Printer Tests

· Paper Park

· Print Characteristics

· Standard Printer Controls

Partner Exchange (BPX) for any updates to this material. (http://bpx.okidata.com)

Page: 4

Service Guide ML390/391

Chapter 1 Product Specifications

1.1.02 Compatibility - Microline 390/391 vs. Microline 390/391-Plus

The differences between the Microline 390/391 and Microline 390/391-Plus printers are listed below.

Hardware Differences

· Operator Panel

· Operator Board

· Character Generator Programmable Read Only Memory (CGROM)

· Programmable Read Only Memory (PROM)

· Middle Cover

Operational Differences

· "Plus" printers have more resident fonts.

· In the "Plus" printers, data in the receive buffer is printed upon receipt, without having to wait for a line

terminator character (CR/LF or FF).

· In the "Plus" printers, the DC1/DC3 Acknowledge/Ignore, Receive Buffer Size, and RESET inhibit can be

controlled through the printers Menu.

Serial Number Revision Levels

Microline 390/391

Rev A units are original production units. An interconnect module connects the power supply board to the

main control board.

Rev B units are retrofitted to include a modified interconnect module, which prevents corrosion.

These units have a cable connection between the power supply board and the main control board. The

cable connection wire replaces the interconnect module.

Microline 390/391-Plus

Revision levels do NOT apply to the "Plus" printers.

NOTE:

Please refer to the parts lists for parts differentiation. Please be sure of the parts you need before ordering

to avoid confusion and incorrect parts orders.

Printer Serial Number Identification

There are three serial number revision levels for the printers. Hardware differences exist between levels.

To identify the revision level of a printer, record the serial number from the back of the printer. Refer to the

following to decode the serial number.

Example Printer Serial Number: 401A0154693

Date Code 401 (4 = year. 01 = month)

Revision A

Serial Number 0154693

Compatibility Chart

Item Okidata

P/N Purpos

e /

Functio

n of

Item

Printer

Serial

Number

Revision

Level

390/391A 390/391B 390/391C 390+ 391+

Main

Control

Board

SKRA

Board 5504540

1Main

Control

Board

Yes Yes No No No

SKRB

Board 5503870

2Main

Control

Board

Yes Yes Yes No No

SKRA-3

Board 5504540

3Main

Control

Board

Yes Yes Yes Yes Yes

Power

Supply

Board

PAII

Board 5503880

1Power

Supply

Board

Yes Yes No No No

SUII

Board 5504740

1Power

Supply

Board

Yes Yes Yes Yes Yes

Operator

Panel

Assembl

Andere Handbücher für MICROLINE Turbo ML390

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Oki Drucker Handbücher

Oki

Oki ML5721 Bedienungsanleitung

Oki

Oki C7350hdn Firmware-Update

Oki

Oki LP441b Bedienungsanleitung

Oki

Oki OKIPOS X400 Bedienungsanleitung

Oki

Oki C130n Bedienungsanleitung

Oki

Oki MPS710c Originalbetriebsanleitung

Oki

Oki ML390Turbo Bedienungsanleitung

Oki

Oki C942 Bedienungsanleitung

Oki

Oki B6250dn Montageanleitung

Oki

Oki ES1220n Bedienungsanleitung

Oki

Oki ES1624n MFP Bedienungsanleitung

Oki

Oki DP-5000 Metallic and Colour Desktop Printer Bedienungsanleitung

Oki

Oki LD670 Bedienungsanleitung

Oki

Oki MPS711c Bedienungsanleitung

Oki

Oki B 4600n Installationsanleitung

Oki

Oki OKIPOS 80 Plus III Bedienungsanleitung

Oki

Oki C 9650dn Bedienungsanleitung

Oki

Oki C830dn Bedienungs- und Wartungsanleitung

Oki

Oki ML280 Elite Bedienungsanleitung

Oki

Oki Microline 421N Bedienungsanleitung

Oki

Oki Microline 490 Bedienungsanleitung

Oki

Oki C3300n Bedienungsanleitung

Oki

Oki lp-1030-mf Bedienungsanleitung

Oki

Oki B4200 Bedienungsanleitung

Beliebte Drucker Handbücher anderer Marken

Lexmark

Lexmark 1400 Series Handbuch

Canon

Canon i70 Series Bedienungsanleitung

Evolis

Evolis Elypso Bedienungsanleitung

Kyocera

Kyocera FS-9530DN Bedienungsanleitung

Canon

Canon LASER SHOT LBP-1210 Bedienungsanleitung

Samsung

Samsung BIXOLON SRP-350plusF Bedienungsanleitung

Canon

Canon PIXMA PRO-1 Series Bedienungsanleitung

Canon

Canon PIXMA G3560 Einrichtungshandbuch

Dell

Dell Color Laser Printer 2130cn Bedienungsanleitung

Tektronix

Tektronix Phaser 840 Bedienungsanleitung

Epson

Epson ET-7750 Betriebsanleitung

Canon

Canon CLBR 460ps Bedienungsanleitung

Eltron

Eltron P210 Guide Bedienungsanleitung

Ricoh

Ricoh MD-P1 Bedienungsanleitung

Epson

Epson SC-F7100 series Bedienungsanleitung

Epson

Epson Stylus C40UX Bedienungsanleitung

Canon

Canon imagePASS-A2 Bedienungsanleitung

Canon

Canon S820D Bedienungsanleitung
