MODE ACTION L(press) R(press)
Engage/bypassloop2
Toggleloop1/loop2
MomentaryswitchviaSEND2
Favorite LatchviaOUTjack
Engage/bypassloop1
Masterbypass
MomentaryswitchviaSEND1
TaptempoviaSEND1 (TRScable)
RED
BLUE
GREEN
MODE ACTION L(Holdfor4s) R(Holdfor 4s)
NIL
turnon/offBJFbuffer for loop2
SEND2setstobeN.OorN.C
NIL
Turnon/offBJF buffer
Turnon/offBJF bufferforloop1
SEND1setstobeN.OorN.C
NIL
RED
BLUE
GREEN
PRESSBehaviorTable
HOLDBehavior Table
Dimensions................................................................118(L)x64(W)X50(H)mm
Weight........................................................................250g
Power Supply.............................................................DC9V(NegativeCenter)
CurrentDrain..............................................................max. 100mA
Max.Input Vp-p......................................................... 3V
Parameters
