One Forall 5 Bedienungsanleitung

WWW.ONEFORALL.COM 1

PICTURE OF ONE FOR A 5 REMOTE

INSTA ING THE BATTERIES

THE KEYPAD

SETTING UP THE ONE FOR A 5

(How to set up the ONE FOR ALL 5 to control your devices)

SEARCH METHOD

CODES

Televisions 18

Video Recorders 26

Satellite Receivers 28

Cable Converters 32

Video Accessory 32

Miscellaneous Audio 32

Amplifier 33

Amp. / Tuner 33

DVD 34

CODE B INK OUT

(To find out which code is currently programmed)

QUICK CODE REFERENCE

THE EARNING FEATURE

(How to copy functions from your original working

remote onto the ONE FOR ALL 5)

OPERATIONA RESET

EXTRA FEATURES

Mode re-assignment (Changing a device mode) 12

Volume Punch-Through 13

Macros (Sequence of commands) 14

Key Magic (How to program missing functions) 16

Colour and Brightness 17

TROUB E-SHOOTING

Table of Contents

Your ONE FOR ALL 5 can operate five devices:

TV : Television

VCR : Video Recorder

SAT : Satellite Receiver or Cable Converter

DVD : DVD Player

AMP : Amplifier / Tuner

Also, what makes the ONE FOR ALL 5 even more unique is the

"Learning" feature, which allows you to customise any of the special

functions of your original remote control onto the keypad of your

new ONE FOR ALL 5.

The following pages explain in simple steps how to customise

the ONE FOR ALL 5 to your devices.

You may need this guide again in the future, so please be sure

to keep it.

About Your ONE FOR A 5

English

2WWW.ONEFORALL.COM

12/13

WWW.ONEFORALL.COM 3

Installing the Batteries

Your ONE FOR ALL 5 requires 4 new “AAA/LR03” alkaline batteries.

1Push the battery door upwards and lift it up to remove it.

2Match the batteries to the (+) and (–) marks inside the battery case,

then insert the batteries.

3Replace the battery cover by pushing downwards and allowing

it to click back into position.

See picture of ONE FOR A 5 remote on page 2.

1Magic Key

The MAGIC key is used to set up your ONE FOR ALL 5.

2Power

The POWER key operates the same function it did on your original

remote control.

3Backlight Device Keys

The TV, VCR, SAT, DVD, and AMP keys select the home entertainment

device to be controlled. For example pressing the TV key allows

the remote to control the functions of your Television, after pressing

VCR you can operate your Video Cassette Recorder etc.

For more detailed information, please refer to the chart on page 6.

During operation of the ONE FOR ALL the red light (LED - Light Emitting

Diode) underneath a device key will light up (every time a key is pressed)

to indicate the device mode you are using.

4Number Keys (0-9, -/- -, AV)

The Number keys (0-9, -/--, AV) provide functions just like your

original remote, such as direct access channel selection. If your

original remote uses one/two digit input switching (-/-- symbol),

this function can be obtained by pressing the -/-- key. If your original

remote has an 10 key, this function can also be found under

the -/-- key. If your original remote has an 20 key, this function can also be

found under the AV key. In AMP mode the Number keys may provide

source (input) selection.

5AV Key

In TV mode you will obtain the AV / Input function. In VCR mode you will

obtain the “TV/VCR” function, if available on your original remote. In

DVD mode you will obtain the “TV/DVD” function, if available on your

original remote. In DVD mode you will obtain the “TV/SAT” or “TV/DTV”

function, if available on your original remote.

6Volume +/- Keys

These keys operate in the same way as the keys on your original remote.

The Keypad

Important notes:

-On the inside of the battery compartment door you will find

a label on which to write your Set-Up codes after your ONE FOR A 5

is set up for your device. Please write down your codes

for easy, future reference.

- Do not use rechargeable batteries.

- Upon changing the batteries, your set-up codes and advanced pro-

gramming will be retained.

4WWW.ONEFORALL.COM

7Mute Key

The Mute key operates the same function it did on your original remote

control.

8Menu Key

The MENU key controls the same function as it did on your original

remote.

9Channel +/- Keys

These keys operate in the same way as the keys on your original remote.

10 Directional Keys

If available on your original remote, these keys will allow you to navigate

through the menu mode of your device.

11 OK

The OK key will confirm your choice in menu operation.

12 Transport Keys (VCR / DVD)

These keys operate the transport functions (PLAY, FF, REW etc.) of your

device. To prevent accidental recording, the RECORD key mustbe pressed

twice to start recording.

13 Teletext Keys

After pressing the TV key, the transport keys (REW, PLAY, PAUSE, FF) are

used to operate the main Teletext functions. The symbols below the keys

are for Teletext. The text keys are used to access the Teletext functions of

your television. Of course, your television must have Teletext capability.

TEXT ON: Puts the television in the Teletext mode.

TEXT OFF: Switches the television back to regular viewing mode.

On some televisions, this may be done by pressing the TEXT ON key

several times.

HO D/STOP: Stops changing pages.

MIX: Shows teletext and regular television simultaneously.

You may also use this key for subtitling. On some televisions

this function is accessed by pressing the text key twice.

EXPAND: Shows the top half of the Teletext page in larger letters. By

pressing again, you can see the bottom half of the Teletext page enlar-

ged. To return to regular Teletext viewing, press the EXPAND key again,

or press the TEXT ON key, depending on your television.

INDEX: This key will give you access to the index function within the

text mode.

After pressing the TV key and accessing the text mode, the keys marked

red, green, yellow and blue, allow you to access the Fastext functions

of your television. If on your original remote control these keys are

used for Menu navigation, the ONE FOR A Fastext keys may

operate in the same way.

The Keypad

Important note: For a more detailed explanation of Teletext and Fastext, please

refer to the manual of your television. Remember, different televisions control

Teletext and Fastext features in different ways. Not all of the Teletext functions may

be available for your particular model.

WWW.ONEFORALL.COM 5

14 Additional Function Keys

Guide

In TV and/or SAT mode you will obtain the “Guide”

function, if available on your original remote.

In TV and/or SAT mode you may obtain the ‘Display”, “OSD” or

“info” function, if available on your original remote.

In SAT mode you will obtain the “help” function, if

available on your original remote.

Back

In TV, VCR and DVD mode you will obtain the “Menu Exit”

function, if available on your original remote. In SAT menu

mode you may use the “back” key to go to the previous menu

screen.

PPV

In SAT mode you will obtain the Pay Per View (PPV)

function, if available on your original remote.

Subt.

In TV, VCR, SAT and DVD mode you will obtain the “Subtitle”

function, if available on your original remote.

Radio

In SAT mode you will obtain the “Radio” function, if

available on your original remote.

Fav

In TV mode this key provides you the (16:9) wide screen view

function, if available on your original remote). In SAT mode

you will obtain the “Favorite” function, if available on your

original remote.

The Keypad

6WWW.ONEFORALL.COM

Example: To set up the ONE FOR A 5 for your Television:

1Find the code for your device in the Code list (page 18 –

38). Codes are listed by device type and brand name.

The most popular code is listed first. Make sure your

device is switched on (not on standby).

2 Press the TV key on the ONE FOR ALL 5 for the device you

wish to Set-Up.

3Press and hold down MAGIC until the ONE FOR A 5’s

TV key blinks twice (the red LED underneath the TV key will

blink once and then twice).

4Enter your four-digit device code using the number keys.

The device key will blink twice.

5Now, aim the ONE FOR ALL 5 at your device and press

POWER. If your device switches off, the ONE FOR A 5

is ready to operate your device.

6Turn your device back on and try all the remote’s functions to ensure they

are working properly. If the functions do not work properly, repeat steps

1-5 using another code listed under your brand.

7 If your device does not respond, follow steps 1 to 5 with each

code listed for your brand. If none of the codes listed for your

brand operate your device, or if your brand is not listed at all, try

the Search Method described on page 7.

Setting up the ONE FOR A 5

(How to set up the ONE FOR A 5 to control your devices)

- Some codes are quite similar. If your device does not respond or is not

functioning properly with one of the codes, try another code listed under your

brand.

- If your device’s original remote control does not have a POWER key, press PLAY

instead of POWER when setting up your device.

- Remember to press the corresponding device key before operating your device.

ONEFOR A



Acura

Admiral

Adyson

Agazi

AGB

Agef

Aiko

0009

0087,0093,0363,04

0217,0216

0264

0516

0087

0216,0009,0037,

0037,0274

0361,0208,0371

____

Devices can be found under the following keys:

To set up a second TV, VCR, SAT, DVD or AMP see page 12.

* DVBT codes (Digital Terrestrial / Free View) can be found in

the ”Satellite Receiver” section.

Video Recorder

Television

Satellite Receiver (also DVBT*) /

Cable Converter

Video Accessory

Amplifier

Amp. / Tuner

Miscellaneous Audio

DVD / DVD-R

WWW.ONEFORALL.COM 7

- Most TV’s do not switch on pressing the POWER key. Please try pressing a

“number” key or the “TV-text off” key to switch your TV back on.

- If you cannot control your Television properly, please continue the Search

Method, you may be using the wrong Code.

- To search for the code for another device follow the instructions above only

press the appropriate device key instead of TV during step 2.

- If the original remote control of your Video recorder or DVD player does not

have a POWER key, press PLAY instead of POWER during step 5.

Setting up the ONE FOR A 5

Search Method

--> If your device does not respond to the ONE FOR ALL 5 after you

have tried all the codes listed for your brand.

--> If your brand is not listed at all.

The Search Method allows you to scan through all the codes contained

in the memory of the ONE FOR ALL 5.

Example: To search for your TV code:

1Switch your television on (not on standby) and aim your ONE FOR ALL

at your TV.

2Press the TV key on your ONE FOR ALL 5.

3Press and hold down MAGIC until the ONE FOR A 5’s

TV key blinks twice (the red LED underneath the TV key

will blink once and then twice).

4Press 9 9 1. The TV key will blink twice.

5Next, press POWER.

6Aim the ONE FOR ALL 5 at your Television. Now press CH+ over

and over, until your Television turns off (every time you press

the CH+ key the ONE FOR ALL 5 will send out a POWER signal

from the next code contained in the memory). You may have

to press this key many times (up to 150 times) so please

be patient. If you skip past a code, you can go to the previous

code(s) by pressing the CH- key. Remember to keep pointing

the ONE FOR ALL 5 at your Television while pressing this key.

7As soon as your television turns off, press MAGIC to store the

code.

8WWW.ONEFORALL.COM

Once you have Set-Up your ONE FOR A 5, you can blink back your

SET-UP CODE for future reference.

Example: To blink out your Television code:

1Press TV once.

2Press and hold down MAGIC until the ONE FOR A 5’s

TV key blinks twice (the red LED underneath the TV key will

blink once and then twice).

3Press 9 9 0. The TV key will blink twice.

4For the first digit of your four-digit code, press 1and count

all the red blinks. If there are no blinks, the digit is "0".

5For the second digit, press 2and count all the red blinks.

If there are no blinks, the digit is "0".

6For the third digit, press 3and count all the red blinks.

If there are no blinks, the digit is "0".

7For the fourth digit, press 4and count all the red blinks.

If there are no blinks, the digit is "0". Now you have your

four-digit code.

Quick Code Reference

Write down the codes for your devices in the boxes below and in

the battery compartment for quick and easy reference.

Device Type Code

1._________________________

2._________________________

3._________________________

4._________________________

5._________________________

■ ■ ■ ■

Code Blink out

(To find out which code is currently programmed)

- To blink back the code for your other devices press the appropriat device key

during step 1.

WWW.ONEFORALL.COM 9

The ONE FOR ALL 5 comes with a complete library of pre-programmed

codes. After you have set up the ONE FOR ALL 5 for your device, you may

find that there are one or more keys that you had on your original remote,

which do not have a place on the ONE FOR ALL keypad.

As a convenience, the ONE FOR ALL 5 offers a special Learning feature that

allows you to copy any function from your original remote control onto the

keypad of the ONE FOR ALL 5.

Before you start:

- Make sure your original remote control is working correctly.

- Make sure neither your ONE FOR ALL, nor your original remote control is

pointing at your device.

• earning (Direct)

Example: To copy the “mono/stereo” function from your original TV

remote onto the ”Radio”key of your ONE FOR A 5.

1 Place both remote controls (the ONE FOR A 5 and your original) on

a flat surface. Make sure the ends which you normally point at your

device are facing each other. Keep the remotes at a distance of

2 to 5 cm.

2 Press and hold the MAGIC key until one of the device

keys will blink twice. The red LED underneath the

corresponding device key (depending on the device mode

that was selected) will blink once then twice.

3 Press 9 7 5 (the device key will blink twice).

4Press the device key (on the ONE FOR ALL remote) to select

the mode to which you want to copy the learned function

(Example: TV key).

5 Press the key (on the ONE FOR A remote) where you

want to place the learned function (Example: ”Radio” key).

The device key will flash rapidly.

6 Press and hold the key (on your original remote) that you

want to copy until the device key on the ONE FOR ALL blinks

twice (Example: “mono/stereo” key).

7If you want to copy other functions within the same mode, simply repeat

steps 5 and 6 pressing the next key you want to copy by learning.

8To exit the learning mode, press and hold MAGIC until

the device key blinks twice.

9Learning is mode specific. To access your learned function,

press the appropriate device key first.

The earning Feature

(How to copy functions from your original working remote

onto the ONE FOR A 5)

10 WWW.ONEFORALL.COM

The earning Feature

• Shifted earning

You can also learn a function on a key of the ONE FOR ALL without

sacrificing the original ONE FOR ALL function. A Shifted Learning function can

also be put on any key EXCEPT for the following: Device keys, MAGIC key,

Number keys. To install a Shifted Learning function, simply follow steps 1-8 on

the previous page. During step 5, press MAGIC once before you press the key

where you are placing the learned function.

To access the shifted function, press MAGIC and then the key you have

learned on.

Important notes:

- During steps 2 - 7 (page 9), you have approximately 10 seconds to conduct each

step. If there is a gap of more than 10 seconds between two steps, you will have

to start again from step number 2.

- If you learn a function on a key, the original ONE FOR ALL feature automatically

becomes shifted. You can press MAGIC then the key to access it (this excludes the

Channel and Volume keys).

- The Learning feature is mode specific. Therefore you can place one learned fea-

ture per mode on the same key.

- If a Shifted Learned function is placed on the Channel and Volume keys then

Colour/Brightness will be sacrificed.

- The ONE FOR ALL 5 can learn approximately 25 – 40 functions.

- You can replace a learned function by placing another learned function on top.

- Learning should not be done in direct sunlight or under incandescent lights.

- Make sure you are using new batteries before following the instructions above.

- Upon changing the batteries, your learned functions will be retained.

Andere One Forall Fernbedienung Handbücher

One Forall

One Forall KAMELEON 4 Bedienungsanleitung

One Forall

One Forall ONE FOR ALL URC3110 Bedienungsanleitung

One Forall

One Forall Xsight Touch Bedienungsanleitung

One Forall

One Forall Kameleon URC-9962 Bedienungsanleitung

One Forall

One Forall URC-4220 Bedienungsanleitung

One Forall

One Forall URC 1921 Bedienungsanleitung

One Forall

One Forall SMART STREAMER URC 7945 Bedienungsanleitung

One Forall

One Forall URC 8080 Bedienungsanleitung

One Forall

One Forall URC 7120 Bedienungsanleitung

One Forall

One Forall URC-7781 Bedienungsanleitung

One Forall

One Forall ONE FOR ALL PVR 6 Bedienungsanleitung

One Forall

One Forall ESSENCE Series Bedienungsanleitung

One Forall

One Forall Contour TV URC1210 Bedienungsanleitung

One Forall

One Forall URC-7110 Betriebsanleitung

One Forall

One Forall URC-9040 Bedienungsanleitung

One Forall

One Forall KAMELEON 3 Bedienungsanleitung

One Forall

One Forall XSight Bedienungsanleitung

One Forall

One Forall URC1281 Bedienungsanleitung

One Forall

One Forall KAMELEON 6 Bedienungsanleitung

One Forall

One Forall URC 7120 Bedienungsanleitung

One Forall

One Forall URC-6420 Administratorhandbuch

One Forall

One Forall URC-7800 Cinema 7+ Bedienungsanleitung

One Forall

One Forall URC-4640w Bedienungsanleitung

One Forall

One Forall URC-7110 Betriebsanleitung

Beliebte Fernbedienung Handbücher anderer Marken

Panasonic

Panasonic EUR7622KB0 Bedienungsanleitung

Bang & Olufsen

Bang & Olufsen Beo4 Bedienungsanleitung

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Bedienungsanleitung

Multiplex

Multiplex PROFI TX 9 Bedienungsanleitung

One Remote

One Remote RMB4 Bedienungsanleitung

FUTABA

FUTABA 9ZAP - PART2 Bedienungsanleitung

HR Matic

HR Matic HR MULTI 3 Bedienungsanleitung

Yamaha

Yamaha ACC-GNRST-30-20 Bedienungsanleitung

EisSound

EisSound KBSOUND Bedienungsanleitung

Marantz

Marantz RC101 Bedienungsanleitung

Conrad

Conrad FS20 TC6 Bedienungsanleitung

Anritsu

Anritsu MP1777A Bedienungsanleitung

Niles

Niles WVC100 Fehlerbehebungshandbuch

RCA

RCA RCU1300 Bedienungsanleitung

Bang & Olufsen

Bang & Olufsen BEO6 Bedienungsanleitung

GE 94901 Bedienungsanleitung

Onbon

Onbon YQ1-75 Bedienungsanleitung

FUTABA

FUTABA R7108SB Montageanleitung
