Onkyo TX-8222 Bedienungsanleitung

TX-8222

SERVICE MANUAL

STEREO RECEIVER

Black and Silver models

MODEL TX-8222

Ref. No. 3945

062006

120V AC, 60Hz

230-240V AC, 50Hz

BMDD,BMDC

BMPP,SMPP,BMPA

RC-666S

SAFETY-RELATED COMPONENT

WARNING!!

COMPONENTS IDENTIFIED BY MARK ON THE

SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE

CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.

REPLACE THESE COMPONENTS WITH ONKYO

PARTS WHOSE PART NUMBERS APPEAR AS SHOWN

IN THIS MANUAL.

MAKE LEAKAGE-CURRENT OR RESISTANCE

MEASUREMENTS TO DETERMINE THAT EXPOSED

PARTS ARE ACCEPTABLY INSULATED FROM THE

SUPPLY CIRCUIT BEFORE RETURNING THE

APPLIANCE TO THE CUSTOMER.

TX-8222

SPECIFICATIONS

Amplifier Section

Tuner Section

General

Audio Inputs

Audio Outputs

Specifications and features are subject to change without

notice.

Rated Output Power (FTC) (North American)

All channels: 50 watts minimum continuous power

per channel, 8 ohm loads, 2 channels

driven from 20 Hz to 20 kHz, with a

maximum total harmonic distortion of

0.08 %

Rated Output Power (IEC) (European and Australian)

2 ch 70W at 4 ohms, 1 kHz, 2 ch driven

Maximum Output Power (JEITA) (Asian)

90W at 4 ohms, 1 kHz, 2 ch driven

Dynamic Power

North American: 135W + 135W (2 )

105W + 105W (4 )

70W + 70W (8 )

European and Australian:

110W + 110W (2 )

90W + 90W (4 )

55W + 55W (8 )

THD (Total Harmonic

Distortion) 0.08 % (Power Rated)/ 0.08 % (1 kHz,

1 W)

Damping Factor 60 (Front, 1 kHz, 8 )

Input Sensitivity and

Impedance 150 mV/ 50 k (LINE)

2.5 mV/ 50 k (PHONO MM)

Output Level and

Impedance 150 mV/ 2.2 k (REC OUT)

Frequency Response 10 Hz~100 kHz/ +1 dB~ 3 dB (CD)

Tone Control ±10 dB, 100 Hz (BASS)

±10 dB, 10 kHz (TREBLE)

Signal to Noise Ratio 100 dB (LINE, IHF-A)

80 dB (PHONO, IHF-A)

Speaker Impedance 4 16

Tuning Frequency

Range NorthAmerican: 87.5 MHz~107.9 MHz

Others: 87.5 MHz~ 108.0 MHz

Usable Sensitivity Stereo: 22.2 dBf (75 IHF)

Mono: 15.2 dBf (75 IHF)

Signal to Noise Ratio Stereo: 67 dB (IHF-A)

Mono: 73 dB (IHF-A)

THD Stereo: 0.5 % (1 kHz)

Mono: 0.3 % (1 kHz)

Frequency Response 30 Hz~ 15 kHz / ±1 dB

Stereo Separation 40 dB (1 kHz)

Tuning Frequency

Range NorthAmerican: 530 kHz~1710 kHz

Others: 522 kHz~ 1611 kHz

Usable Sensitivity 300 µV

Signal to Noise Ratio 40 dB

THD 0.7 %

Power Supply NorthAmerican: AC 120V, 60 Hz

European:AC 230-240V, 50 Hz

Others: AC 230-240V, 50Hz

Power Consumption NorthAmerican: 2.1A

European: 180W

Others: 180W

Standby Power

Consumption North American:0.2W

Others: 0.3W

Dimensions

(W H D) 435 150 332 mm

17-1/8" 5-7/8" 13-11/16"

Weight 7.5 kg

16.5 lbs.

Analog Inputs PHONO, CD,TAPE 1,TAPE 2, LINE 1,

LINE 2

Analog Outputs TAPE 1,TAPE 2

Speaker Outputs SPEAKERS A

SPEAKERS B

Phones 1

IR Input/Output 1/1

2. To initialize the unit

The TX-8222 contain a micro processor for signal processing

and control functions. In very rare situations, severe interference,

noise from an external source, or static electricity may cause it to lockup.

In the unlikely event that this happens, unplug the power cord from the

wall outlet, wait at least Þve seconds, and then plug it back in again.

3. Safety-check out

(U.S.A. model only)

After correcting the original service problem, perform the

following safety check before releasing the set to the customer.

Leakage Current Check

Measure leakage current to a known earth ground(water pipe,

conduit, etc.) by connecting a leakage current tester between

the earth ground and exposed metal parts of the appliance

(input/output terminals, screwheads,metal overlays, etc.).

Plug the power supply cord directly into a 120V AC 60 Hz outlet

and turn Standby switch on. Any current meausred must not

exceed 0.5mA.

1. Replacing the fuses

This symbol located near the fuses indicates that the

fuse used is fast operating type. For continued protection against

fire hazard, replace with same type fuse. For fuse rating refer to

the marking adjacent to the symbol.

Ce symbole indique que le fusible utlise est a rapide.

Pour une protection permanente, n'untiliser que fusibles de

meme type. Ce darnier est la qu le present symbol est

appse.

CIRCUIT NO. PART NO.

DESCRIPTION

Note: <D>:North American model only

<P>: European model only

<A>: Australian model only

To reset the TX-8222 to its f actor y defaults, turn it on and,

while holding down the VIDEO button, press the

ST ANDBY/ON button. When the reset is complete,

"Clear" appears on the display and the TX-8222 enter

Standby mode.

Memory backup

The TX-8222 use a batter y-less memory backup sys-

tem (C704) in order to retain r adio presets and other settings

when it's unplugged or in the case of a po wer failure.

Although no batteries are required, it must be plugged

into an AC outlet in order to charge the backup system.

Once it has been charged, the TX-8222 will retain the

settings for several weeks, although this depends on

the environment and will be shorter in humid climates.

F901 252326GR or 5A-UL/T-233 or

252258GR 5A-T/UL-ST2 <D>

F902 252075GR or 2.5A-SE-EAK or

252275GR 2.5A-SE-TL250V <P/A>

F903 252326GR or 5A-UL/T-233 or

252258GR 5A-T/UL-ST2 <D>

252075GR or 2.5A-SE-EAK or

252275GR 2.5A-SE-TL250V <P/A>

TX-8222

SERVICE PROCEDURES

TX-8222

EXPLODED VIEW

TX-8222

A212

x 3 pcs.

A003

x 5 pcs.

A003

x 2 pcs.

A003

x 10 pcs.

A203

x 2 pcs.

A009

x 2 pcs.

A811

x 2 pcs.

A003

x 2 pcs.

A003

x 2 pcs. A008

x 4 pcs.

E801

x 4 pcs.

A003

x 2 pcs.

A220

x 2 pcs.

A301

x 21 pcs.

A003

x 3 pcs.

A003

x 3 pcs.

A018

x 5 pcs.

A003

x 2 pcs.

A003

x 2 pcs.

A202

x 6 pcs.

Q521A

x 4 pcs.

A011

x 3 pcs.

A205

x 4 pcs.

A003

x 4 pcs.

A206

x 4 pcs.

A351

x 3 pcs.

A210

A350

A001

A607

A201

A002

P715

P704

P901

U023

U017

U012

U022

T901

U016

U015

U026

U05

U01

U02

U014

U013

A006

F901

D911

Q521

Q524

Q522

Q523

F903 A010

A014

A003

A302

A300

A023

A005

E801

A007

A352

A214

A355

F913

F914

F902

A028

P501B

A219

TX-8222

BLOCK DIAGRAM

SPA

SPBTHERM

PRO

-B1

+B1

DOWN

STB

DATA

TUNL

FLAC2

FLAC1

-VP

MUT

REMIN

FLDRST

FLDCS

FLDCLK

FLDSDO

+B3

-B3

TMUT

PLLCLK

PLLSDO

STEREO

RDSCLK

RDSDAT

POW

+5.6V

+5V_MPU

+5V_CPU

+12V

-12V

TU-L

TU-R

IRIN

IROUT

KEYINT0

KETINT1

KEYINT2

KEYINT3

LEDSTBY

FLAC1

FLAC2

+5.6V

Q525/6

Q581/582

PROTECT

TO POWER AMP

PRIMARY

THERMAL

SENSOR

Q6380

VOLTAGE REGULATOR

SPEAKERSPOWER AMP

PHONO

EQUALIZER

Q301

PHONO

REC

PLAY

TAPE-1

PLAY1

L1/

DVD

LINE1

DVD

TUNER

PLAY2

REC2

REC

PLAY

TAPE-2

LINE2

AUDIO IN / OUT

MOTOR

DRIVE

Q481

DISPLAY / CONTROL

CPU

VOLUME

MICROPROCESSOR

Q701

FL DRIVER

Q7502

FL DISPLAY

Q7501

PACK

FM/AM TUNER

TACT KEYS

To Audio Selector & Phono

Q302

PHONO

REC1

ANALOG

SWITCH

BASS

TREBLE Q591

RELAY

DRIVE

Q592

RELAY

DRIVE

POWER AMP

RL901

PRI RELAY

F903

OUTLET AC_CABLE

P501

SPEAKER-A

SPEAKER-B

RL591

SP-A RELAY

RL592

SP-B RELAY

P503

PHONES

C916

D911

Q921

Q922

D921

F901 <D>

F902 <P/A>

Q912

R641

Q491

MUTING

R393

BALANCE

D915~8

D920

T902

SUB

TRANS

C915

REMOTE

CONTROL

SENSOR

IRIN

IROUT

ST-BY

Q402

R409

Q401

R415

THERMAL

FUSE

T901

Q706

Q701

B C D E F G H

TX-8222

SCHEMATIC DIAGRAM 1 AUDIO SECTION

B C D E F G H

DATA

CLK

POFF2

TU_L

TU_R

SE1H

PROTECT

STB

VOL_UP

SP_A

SP_B

SP_A

SP_B

DIRECT

+12VA

DIRECT

VOL_DN

AMUT

5.6V

-12VA

VOL_DN

VOL_UP

STB

AMUT

DATA

MON-A

+12VS

MON-B

+12VR

CLK

+10S

S1GND

FLAC2

FLAC1

FLAC2

-VP

MTR+

MTR-

MTRG

TREBLE

BASS

OUT1

VREF

IN1

GND

MOTOR DRIVE

BALANCE

PHONO

EQUALIZER

SEL

STB

DATA

GND

T2 REC

T2 PLAY

VSS VDD

PHONO

T1 PLAY

DVD

V REC

V PLAY

TUNER

PHONO

-1

REC

TAPE

PLAY

-1

TAPE

-2

TAPE

REC

-2

PLAY

TAPE

T1 REC

P918

BUS

RLGND

+12V

-12V

TU_GND

TS_GND

SPEAKERS

L L

A B

IN2

OUT2

VCC

LINE-1/

DVD

RLGND

MPUGND

NAAF-8886

MPUGND

8200/56

[12V]

[-12V]

TO NADG-8876 (SCH.3)

MOTHER

TO NADG-8876 (SCH.3)

MOTHER

[12V]

[-12V]

ID+

ID-

2SC5197

2SA1940

[57.6V]

[-57.6V]

[1.2V]

[-1.2V]

[0.6V]

[-0.6V]

[0V]

[-0.6V]

[-55.8V]

[-22.8V]

[55.8V]

[56.3V]

[-55.7V]

[0.6V]

ID ADJ

-O

ID+

ID-

2SC5197

2SA1940

[57.6V]

[-57.6V]

[1.2V]

[-1.2V]

[0.6V]

[-0.6V]

[0V]

[-0.6V]

[-55.8V]

[-22.8V]

[55.8V]

[56.3V]

[-55.7V]

[0.6V]

ID ADJ

-O

VOLUME

NAAF-8888 NAPS-8887

THERMAL

FUSE

POWER TRANSFORMER

PRIMARY

TO NAPS-8880 (SCH.-4)

R413

100K

C424

223Z

R311

39K R313

100K

R314

100K

R417

R418

R575

220K

C342

223Z

R335

330

R336

330

R337 1M

R338 1M

R302

R349

22K

R435

220K

R301

C313

10/50

R304

56K

R303

56K

R305

220K

R306

220K

C307 100/10

R312

39K

C312

182J

Q301:B

NJM4558D-X

Q301:A

NJM4558D-X

C314

10/50

C345

223Z

R350

22K

C308

100/10

R318 1M

R317 1M

R316

330

R322

R321

R319

2.2K

R324

330 R326 1M

R325 1M

R323

330

R330 1M

R329 1M

R327

2.2K

R328

2.2K

R331

330

R332

330

R333 1M

R334

R407

3.3K

C311

182J

C301

471K

C302

471K

C309682J

C310

682J

R307

820

R308

820

R309

470K

R310

470K

R401

C421

223J

C422

223J

R419

3.3K

R420

3.3K

C403

47/25

C407

47/25

R404

220K

R405

22K

R406

22K

C392

101K

C391

101K

C404

47/25

R391

1K C416

220/16

C971

223Z

R951

(1/2W)

2.2

C928

100/50

C931

223Z

R491 47K

R492

47K

R436

2.2K

D952

1SS133

Q302

TC9273CNG-010

14 15

C423

223Z

R442 10

C401

47/25

R441 10

P916B

Q492

RN1241-A

Q592

DTC123JS

Q591

DTC123JS

R411

1.2K

R595

(1/2W)

C402

47/25

R402

R408

3.3K

C408

47/25

R392

R599

390(1W)

R598

390(1W)

Q402:A

NJM

2068L-D

Q491

RN12

41-A

Q401:B

NJM2068L-D

Q401:A

NJM2068L-D

R403

220K

P301

P302

D983

C591

103J

C592

103J

D591 D592

RL592

P501

R414

100K

R315

330

R320

2.2K

P915B

C341

223Z

R952 (1/2W)

2.2

J593

C433

103J

C434

103J

C412

47/25 R412

1.2K

C411

47/25

P914B

C343

223Z

R339

R340

R341 1M

R342 1M

P303

C953 4.7/50

D921

RL1N4003

GP104003E

D922

MTZJ33D

Q924

2SA965-Y

D954

MTZJ4.7B

Q493

KRA102M

D491

1SS133

C941

10/50

R953100K

J101

C925

334J

C919

330/35

C918

1000/35

C912

334J/50V

C911

334J/50V

C305

152J

C306

152J

C303

47/25

C304

47/25

C441

100/16

R924

560(1/2W)

C415

220/16

C527

47/63

C528

J102

C534

102J

C532

102J

C531

102J

C533

102J

C535

102J

C536

102J

E591

E592

D953

1SS133

C930

223Z

R932

330K

R934

100(1/2W)

R594

(1/2W)

2.2

R573

10K

R572

22K

C582

223Z

Q583

2SA970

R574

47K

R593

(1/2W)

2.2

R571

33K

Q581

2SC2240

Q582

2SC2240

C315

220/16

C316

220/16 R352

R351

R353

R354

C353

22/50

C354

22/50

JL913B

D571

MTZJ5.1B

C583

1/50

C317 101K(P/A)

C318101K(P/A)

C321

101K(P/A)

C322

101K(P/A)

C325

101K(P/A)

C326

101K(P/A)

C327

101K(P/A)

C328

101K(P/A)

C405

101K

C406

101K

C409

101K

(P/A)

C410

101K

(P/A)

C581

100/16

Q481

TA7291SG

RL591

6 1

R931

3.3K

(1/4W)

R933

22(1/2W)

Q922

79M12

O2I

C923

10/50

C922

33/50

C921

223Z

C920

223Z

C926

100/50

J903

JL716B

TO_NADIS-8887(SCH.2)

JL711B

TO NAETC-8882(SCH.-2)

JL613A

P705B

3 4

2P704B

3 4

C915

C916

C924

334J

D911

D10XB60H

R415

100K

R393

250K

3R409

100K

Q921

78M12

R919

1(1/2W)

D918

D3SBA20

D924

GP104003E

RL1N4003

D984

C982

222J

Q402:B

NJM2068L-D

D920

RL1N4003

GP104003E

C442

1/50

P701B

P702B

R501

470

R565

120K

C501

47/50

R507

R509

C519

104J

R519

R517

R521

(1/2W)

R577

120K

R563

100K

D511

1SS133

R561

270

C503

101K

R503

27K

Q507

2SA949Y

Q531

2SC1740S_S

R581

5.6K

R583

3.9K

R587

R589

3.3K

Q533

2SC1740S_S

R567

C509

10/50

R579

100

C511

NONE

Q503

2SC2240-BL

R531

18K

R525

(1/2W)

R527

(1/2W)

C521

10/50

Q513

2SA949Y

Q515

2SC2229-Y

R547

0.22(5W)

C515

101K

R515

1.5K

C505

220/25

C597

NONE

C523

020C

Q509

2SA949Y

R529

(1/2W)

C507

NONE

R569

R545

22K

L501

J691

NONE

R555

(1W)

8.2

C517

473J

P597A

NONE

P597B

NONE

C513

47/25

P511

R535

18K

C595

NONE

C529

NONE

R513

56K

R533

56K

R543

(1/2W)

220

R541

(1/2W)

2.2

R539

(1/2W)

2.2

R591

(1/4W)

2.2

Q501

2SC2240-BL

R505

Q529

2SC2458-GR

R549

3.3K

R585

820

Q519

2SA1930

Q517

2SC5171

Q521

Q523

R511

5.6K

Q505

2SC2240-GR

R523

(1/2W)

R553

47K

Q527

2SC2229-Y R551

33K

R502

470

R566

120K

C502

47/50

R508

R510

C520

104J

R520

R518

R522

(1/2W)

R578

120K

R564

100K

D512

1SS133

R562

270

C504

101K

R504

27K

Q508

2SA949Y

Q532

2SC1740S_S

R582

5.6K

R584

3.9K

R588

R590

3.3K

Q534

2SC1740S_S

R568

C510

10/50

R580

100

C512

NONE

Q504

2SC2240-BL

R532

18K

R526

(1/2W)

R528

(1/2W)

C522

10/50

Q514

2SA949Y

Q516

2SC2229-Y

R548

0.22(5W)

C516

101K

R516

1.5K

C506

220/25

C598

NONE

C524

020C

Q510

2SA949Y

R530

(1/2W)

C508

NONE

R570

R546

22K

L502

J692

NONE

R556

(1W)

8.2

C518

473J

P598A

NONE

P598B

NONE

C514

47/25

P512

R536

18K

C596

NONE

C530

NONE

R514

56K

R534

56K

R544

(1/2W)

220

R542

(1/2W)

2.2

R540

(1/2W)

2.2

R592

(1/4W)

2.2

Q502

2SC2240-BL

R506

Q530

2SC2458-GR

R550

3.3K

R586

820

Q520

2SA1930

Q518

2SC5171

Q522

Q524

R512

5.6K

Q506

2SC2240-GR

R524

(1/2W)

R554

47K

Q528

2SC2229-Y R552

33K

R644

8.2K

R643

8.2K

C648

223Z

P641

WS-CLAMP

P642

WS-CLAMP

JL613B

R641

4 7

12 52

11 6

R921

0.47(1/2W)

P915A

P916A

P914A

C991

104J

R922

0.47(1/2W)

J991

J992

C992

104J

R923

5.6(1/2W)

JL913A

T901

NPT-1544D(D)

NPT-1544P(P/A)

U02

U023

U022

Q401:A

47/63

1SS133

D924

NOTE: (D): North American model

(P): European model

(A): Australian model

8200/56

330

LINE-2

TX-8222

SCHEMATIC DIAGRAM 1-2

Power amplifier section

BCD

ID+

ID-

2SC5197

2SA1940

[57.6V]

[-57.6V]

[1.2V]

[-1.2V]

[0.6V]

[-0.6V]

[0V]

[-0.6V]

[-55.8V]

[-22.8V]

[55.8V]

[56.3V]

[-55.7V]

[0.6V]

ID ADJ

-O

ID+

ID-

2SC5197

2SA1940

[57.6V]

[-57.6V]

[1.2V]

[-1.2V]

[0.6V]

[-0.6V]

[0V]

[-0.6V]

[-55.8V]

[-22.8V]

[55.8V]

[56.3V]

[-55.7V]

[0.6V]

ID ADJ

-O

R501

470

R565

120K

C501

47/50

R507

R509

C519

104J

R519

R517

R521

(1/2W)

R577

120K

R563

100K

D511

1SS133

R561

270

C503

101K

R503

27K

Q507

2SA949Y

Q531

2SC1740S_S

R581

5.6K

R583

3.9K

R587

R589

3.3K

Q533

2SC1740S_S

R567

C509

10/50

R579

100

Q503

2SC2240-BL

R531

18K

R525

(1/2W)

R527

(1/2W)

C521

10/50

Q513

2SA949Y

Q515

2SC2229-Y

R547

0.22(5W)

C515

101K

R515

1.5K

C505

220/25

C523

020C

Q509

2SA949Y

R529

(1/2W)

R569

R545

22K

L501

R555

(1W)

8.2

C517

473J

C513

47/25

P511

R535

18K

R513

56K

R533

56K

R543

(1/2W)

220

R541

(1/2W)

2.2

R539

(1/2W)

2.2

R591

(1/4W)

2.2

Q501

2SC2240-BL

R505

Q529

2SC2458-GR

R549

3.3K

R585

820

Q519

2SA1930

Q517

2SC5171 Q521

Q523

R511

5.6K

Q505

2SC2240-GR

R523

(1/2W)

R553

47K

Q527

2SC2229-Y R551

33K

R502

470

R566

120K

C502

47/50

R508

R510

C520

104J

R520

R518

R522

(1/2W)

R578

120K

R564

100K

D512

1SS133

R562

270

C504

101K

R504

27K

Q508

2SA949Y

Q532

2SC1740S_S

R582

5.6K

R584

3.9K

R588

R590

3.3K

Q534

2SC1740S_S

R568

C510

10/50

R580

100

Q504

2SC2240-BL

R532

18K

R526

(1/2W)

R528

(1/2W)

C522

10/50

Q514

2SA949Y

Q516

2SC2229-Y

R548

0.22(5W)

C516

101K

R516

1.5K

C506

220/25

C524

020C

Q510

2SA949Y

R530

(1/2W)

R570

R546

22K

L502

R556

(1W)

8.2

C518

473J

C514

47/25

P512

R536

18K

R514

56K

R534

56K

R544

(1/2W)

220

R542

(1/2W)

2.2

R540

(1/2W)

2.2

R592

(1/4W)

2.2

Q502

2SC2240-BL

R506

Q530

2SC2458-GR

R550

3.3K

R586

820

Q520

2SA1930

Q518

2SC5171

Q522

Q524

R512

5.6K

Q506

2SC2240-GR

R524

(1/2W)

R554

47K

Q528

2SC2229-Y R552

33K

TX-8222

SCHEMATIC DIAGRAM 2 DISPLAY SECTION

B C D E F G H

FLDRST

FLDSDO

FLDCS

FLDCLK

IRIN

IROUT

MPUGND

+5VCPU

MPUGND

+5VDIS

REMIN

KEY0

KEY1

KEY2

KEY3

FLDCS

FLDSDO

FLDCLK

KEYINT0

KEYINT1

KEYINT2

KEYINT3

LEDSTBY

LEDPURE

FLDRST

MEMORY

FM MUTE

/MODE

STAND

BY/ON

TUNING

DOWN

TUNING

DISPLAY

SP-A

SP-B

PQR

MNO

JKL

GHI

DEF

ABC

DIRECT

TUNING

ENTER

CATE-

GORY

0/10 */

XM/

SIRIUS

FM/AM

TAPE-1

TAPE-2

VIDEO

DVD

TO NAAF-8886(SCH.-1)

NADIS-8877

YZ-

VWX

STU

PHONO

NAETC-8882

TO NADG-8876(SCH.-3)

FROM NAAF-8886(SCH.-1)

L852

022K

C858

101J

C856

104Z

R883

27K

R882 220

R881 220

R880 3.3K

R879 3.3K

C854 223Z

C853

223Z

C860 101J

C864

223Z

C863 101J

C862 101J

C861 101J

R884

100K

Q851

M66005-

0001AHP

SEG2

50 SEG1

51 SEG0

52 VCC2

53 DIG15/SEG39

54 DIG14/SEG38

55 DIG13/SEG37

56 DIG12/SEG36

57 DIG11

58 DIG10

59 DIG9

60 DIG8

61 DIG7

62 DIG6

63 DIG5

64 DIG4

1DIG03

2DIG02

3DIG01

4DIG00

5_RESET

6_CS

7SCK

8SDATA

9P1

10 P0

11 VCC1

12 XOUT

13 XIN

14 VSS

15 SEG35

16 SEG34

SEG33

SEG32

SEG31

SEG30

SEG29

SEG28

SEG27

SEG26

SEG25

SEG24

SEG23

SEG22

SEG21

SEG20

SEG19

SEG18

SEG17

SEG16

SEG15

SEG14

SEG13

SEG12

SEG11

SEG10

SEG9

SEG8

SEG7

SEG6

SEG5

SEG4

SEG3

R876

330

R855

330

R862

330

R869

330

R877

470

R856

470

R863

470

R870

470

R878

560

R857

560

R864

560

R871

560

R851

820

R858

820

R865

820

R872

820

R852

1.2K

R859

1.2K

R866

1.2K

R873

1.2K

R853

2.2K

R860

2.2K

R874

2.2K

C857

100/16

Q853

2SC2712-GR

S880

S881

S858

S857

S856

S864

S865

S866

S867

S875

S874

S873

S872

S882

S851

S859

S852

S868

S876

S877 S869 S861 S853

S860

R867

2.2K

JL716B

C866

100/16

R886 220

D851

MTZJ8.2B

C870

223Z C869

223Z

C868

223Z

C867

223Z

C865

33/50

R885 220

Q852

16-BT-128GNYK

1F21

2F22

5P35

6P34

7P33

8P32

9P31

10 P30

11 P29

12 P28

13 P27

14 P26

15 P25

16 P24

17 P23

18 P22

19 P21

20 P20

21 P19

22 P18

23 P17

24 P16

25 P15

26 P14

27 P13

28 P12

29 P11

30 P10

31 P9

32 P8

33 P7

34 P6

35 P5

36 P4

37 P3

38 P2

39 P1

40 16G

41 15G

42 14G

43 13G

44 12G

45 11G

46 10G

47 9G

48 8G

49 7G

50 6G

51 5G

52 4G

53 3G

54 2G

55 1G

58 F11

59 F12

D853

SLI-343URC-TE7

P715B

R891

2.2K

R887

100

C871

102J

R888

L857

470M

R854

3.9K

R861

3.9K

R875

3.9K

R889

12K

C873

100/16

U851

S862

S878

S879

S883

S863

R892

3.9K

D854

SIR-34ST3F

P503

PHONES

C876

104Z

C874

102J

C875

102J

L855

220M

L853

220M

L854

220M

P504

JL711A

U012

U017

TX-8222

SCHEMATIC DIAGRAM 3 MICROPROCESSOR SECTION

U01

BAND

INT1

INT2

INT3

SPRLB

CNVSS

FEPM

FCE

RESET

SYSOUT

LEDZONE2

LEDPURE

SPRLA

DIRECT

+5VCPU

MPUGND

+5VDIS

IROUT

IRIN

LEDZONE2

LEDPURE

MPUGND

FLDRST

KEY3

KEY2

KEY1

KEY0

REMIN

KEYINT3

KEYINT2

KEYINT1

KEYINT0

FLDCS

FLDCLK

FLDSDO

LEDSTBY

REMIN

IROUT

IRIN

+5VTU

SYSIN

MPUGND

RESET

FCLK

FBUSY

FRXD

FTXD

CNVSS

+5VMPU

APOWER

PLLSDA

TUNED

STEREO

RDSSIG

TUR

TUL

+9V_TU

PLLCLK

RDSDAT

MPUGND

+10S

PLLSDA

TUNED

SIRIUSTX

SIRIUSRX

+12VA

SRRST

+5VCPU

TUXMSELA

KEYINT0

LEDSTBY

RDSSIG

RDSDAT

PLLCLK

SYSIN

+5VMPU

SYSIN

KEY1

KEY2

KEY3

SEC1H

PROTECT

VOLH

VSWB

XMDACRST

XMCOMSEL

SELDAT

SELCLK

SELSTB

TUXMSELB

XMRST

XMSRTXD

FBUSY

FCLK

FRXD

AMUT

KEY0

VSWA

FTXD

XMSRRXD

VOLOUT1

VOLOUT2

APOWER

THERMAL

STEREO

FLDCLK

FLDSDO

FLDCS

FLDRST

KEYINT1

KEYINT2

KEYINT3

POFF

+12VS

RLGND

POFF

APOWER

-12VA

POFF2

SPRLA

SPRLB

SEC1H

+12VA

TS_GND

TU-GND

TU_L

TU_R

DIRECT

PROTECT

+12VR

MPUGND

RLGND

SELCLK

SELDAT

VSWA

VSWB

SELSTB

AMUT

VOLOUT2

VOLOUT1

5.6VM

+12VS

MPUGND

THERMAL

+5VTU

THERMAL

MPUGND

IRIN

NADG-8876

TO TUNER PACK

TO DISPLAY(SCH.-2)

IROUT

(VX)

(VR)

TO FLASH WRITER

NAETC-8878

TO NAAF-8886 (SCH.-1)

R61547K

R677

R676

R675

R662 0

R661 0

R660 0

R657

0R656

R650 0

R646 0

R642 0

R641 0

R640 0

R61647K

Q706

78M56

Q601

M30624FGPFP

P07/AN07/D7

P06/AN06/D6

P05/AN05/D5

84 P04/AN04/D4

85 P03/AN03/D3

86 P02/AN02/D2

87 P01/AN01/D1

88 P00/AN00/D0

89 P107/AN7/KI3

90 P106/AN6/KI2

91 P105/AN5/KI1

92 P104/AN4/KI0

93 P103/AN3

94 P102/AN2

95 P101/AN1

96 AVSS

97 P100/AN0

98 Vref

99 AVcc

100 P97/ADTRG/SIN4

P96/ANEX1/SOUT4

P95/ANEX0/CLK4

P94/DA1/TB4IN

P93/DA0/TB3IN

P92/TB2IN/SOUT3

6P91/TB1IN/SIN3

7P90/TB0IN/CLK3

8BYTE

9CNVSS

10 P87/XCIN

11 P86/XCOUT

12 RESET

13 XOUT

14 VSS

15 XIN

16 VCC1

17 P85/NMI

18 P84/INT2

19 P83/INT1

20 P82/INT0

21 P81/TA4IN/U

P80/TA4OUT/U

23 P77/TA3IN

P76/TA3OUT

P75/TA2IN/W

P74/TA2OUT/W

P73/CTS2/RTS2/TA1IN/V

P72/CLK2/TA1OUT/V

P71/RXD2/SCL2/TA0IN/TB5IN

P70/TXD2/SDA2/TA0OUT

P67/TXD1/SDA1

P66/RXD1/SCL1

P65/CLK1

P64/CTS1/RTS1/CTS0/CLKS1

P63/TXD0/SDA0

P62/RXD0/SCL0

P61/CLK0

P60/CTS0/RTS0

P57/RDY/CLKOUT

P56/ALE

P55/HOLD

P54/HLDA

P53/BCLK

P52/RD

P51/WRH/BHE

P50/WRL/WR

P47/CS3

P46/CS2

P45/CS1

P44/CS0

P43/A19

P42/A18

P41/A17

P40/A16

P37/A15

P36/A14

P35/A13

P34/A12

P33/A11

P32/A10

P31/A09

VCC2

P30/A8(/-/D7)

VSS

P27/AN27/A7(/D7/D6)

P26/AN26/A6(/D6/D5)

P25/AN25/A5(/D5/D4)

P24/AN24/A4(/D4/D3)

P23/AN23/A3(/D3/D2)

P22/AN22/A2(/D2/D1)

P21/AN21/A1(/D1/D0)

P20/AN20/A0(/D0/-)

P17/D15/INT5

P16/D14/INT4

P15/D13/INT3

P14/D12

P13/D11

P12/D10

P11/D9

P10/D8

P715A

R669 220

Q701

S-812C56

AUA-C3K

P708

R734

270(1W) (P/A)

R700

R704

10K

R702 10K

P707

P706

P705

P704A

L702

022K

L701

470M

C712

100/16

C709

100/16

C703

100/16

C702

100/16

C710

470/10

R699

220(P)

D704

R729 1M

R671 220

R670 220

R697

47K

R626 47

D702

1SS355

D713

R717

R715

R720*

R714

104Z

R850

10K

D707

1SS355

D706

1SS355

D705

1SS355

C729

104Z

C728

104Z

C719

104Z

R622220

R624

220

D604 UDZS5.1B

R710

10(1/2W)

C711 104Z

C701

104Z

R678

220K

R722

47K

R721

47K

C606

104Z

D603

1SS355

X601

6.000MHz

C716

101J

R709

100

C708

474K

R701

R667

47K

R666 220

C603

104Z

C602

104Z

D708

J702

J701

C718 100/16

C717

3.3/50

Q705

RN2402

Q703

RN1404

D703

D701

1SS355

C706

10/50

C704

DX-5R5L224

R705

2.2K

Q602

RN1404

R696

47K

R610 10K

R608

220

(P)

R612

47K

R613

R614 10K

R618

220

R619

220

R620

220

R621

220

R625

220

R629

10K

R630

10K

R639 47

R638 220

R637 47

R636 47

R635 47

R634 47

R633

R631

10K

R64447

R64547

R643

R647

10K

R648

10K

R649

10K

R651

10K

R652

10K

R653

10K

R654220

R655

220

R658

R664 220

R665 220

R674 10K

R673 10K

R672

10K

R679 47

R680 47

R681 47

R682 47

R683 47

R684 4.7K

R685 4.7K

R686 4.7K

R687 4.7K

R688 4.7K

R690 4.7K

R692 4.7K

R694 4.7K

R695 2.7K

R693 2.7K

R691 2.7K

R689 2.7K

C601 104Z

C604

101J

C605

101J

R663 47

C607 104Z

104Z

C611 104Z

C612 104Z

C613 102K

C614 102K

C615 102K

C616 102K

C617 102K

C618 102K

C619 102K

C620 102K

C621

104Z

C622104Z

R609 10K

R601

220

R602

220

C623

4.7/50

Q603

RN2402

D6021SS355

D601

1SS355

R733

10(1W)

JL911B

P702A

P701A

Q855

LM61CIZ

1G3

JL703A

JL703B

U08

1SS355

10K

R719*

56K33K

4.7K

R720

33K56K

33K

R719

(A)(P)(D)

C609

C610

10K

J701/J702:(P/A)

TO NAPS-8880 (SCH.-4)

560(1W) (D)

B C D E F G H

TX-8222

SCHEMATIC DIAGRAM 4

POWER SUPPLY SECTION

U015

MPUGND

POWER

+10S

POFF

RLGND

+12VS

AC-G

AC-H

NPT-1520JQD model

NPT-1519GQP/A model

T902

NAETC-8881

TO POWER TRANSFORMER T901

NAPS-8880

TO MAIN NADG-8876

(SCH.-3)

THERMAL FUSE

POWER TRANSFORMER

PRIMARY

TO NAPS-8881

C903

2200/35

T902

C906

4.7/50

R913

R914

100K

R909

100K

D912

1SS355

D901

1SS355

D902

1SS355

D903

1SS355

D905

1SS355

D906

1SS355

D909

1SS355

D991

1SS355

D992

1SS355

C991

104Z

C902

104Z

D904

1SS355

D913

1SS355

RL902

3 2

D908

1SS355 D914

UDZ5.1B

F902

2.5A-SE-EAK

(P/A)

J907

J918

Q912

KTC3199-GR

C912

103M/275

R915

150(1/2W)

F901

5A-UL/T-237(D)

JL911A

P991

P901A

P912A

P911A

F903

C904

100/35

J904

P910

AC_CABLE

P911B

P913B

P912B

ATTENTION

ET CALIBRATION COMME INDIQUE.

D'INCENDIE, REMPLACER UNIQUEMENT

PERMANENTE CONTRE LES RISQUES

AFIN D'ASSURER UNE PROTECTION

PAR UN FUSIBLE DE MEME TYPE

AGAINST FIRE HAZARD, REPLACE

FOR CONTINUED PROTECTION

AND RATING INDICATED.

ONLY WITH FUSE OF SAME TYPE

CAUTION

E LENT. POUR UNE PROTECTION PERMANENTE,N'UTILISER

CE SYMBOLE INDIQUE QUE LE FUSIBLE UTLISE EST

INDIQUE LA QU LE PRESENT SYMBOL EST APPOSE.

QUE DES FUSIBLES DE MEME TYPE. CE DARNIER EST

RATING REFER TO THE MARKING ADJACENT TO THE SYMBOL

FOR CONTINUED PROTECTION AGAINST FIRE

HAZARD,REPLACE WITH SAME TYPE FUSE. FOR FUSE

THIS SYMBOL LOCATED NEAR THE FUSE INDICATES

THAT THE FUSE USED IS SLOW OPERATING TYPE

J930

(MEASURED WITH

BY MARK ARE CRITICAL FOR SAFETY

IDENTIFIED

NOTE

THE COMPONENTS

REPLACE ONLY WITH PART NUMBER SPECIFIED.

.VOLTAGE VOLTMETER) IS DC VOLTAGE.(NO INPUT SIGNAL)

.ELECTROLYTIC CAPACITORS ( )ARE IN F/WV.

.ALL CAPACITORS ARE IN pF/50WV UNLESS OTHERWISE NOTED.

EX) 030-3pF 330-33pF 331-330pF 333-0.033uF

ALL RESISTORS ARE IN OHMS 1/4WATTS UNLESS OTHERWISE NOTED.

.THE THICK LINES ON PC BOARD ARE THE PRINTING SIDE OF THE PARTS.

EX) PRINTING SIDE

CIRCUIT IS SUBJECT TO CHANGE FOR IMPROVEMENT.

T901

NPT-1544D(D)

NPT-1544P(P/A)

U016

5A-UL/T-233(D)

2.5A-SE-EAK(P/A)

TO POWER TRANSFORMER

A model P model D model

(D): D model: North American model 120V 60Hz

(P): P model: European model 230~240V 50Hz

(A): A model: Australian model 230~240V 50Hz

B C D E F G H

Andere Handbücher für TX-8222

Inhaltsverzeichnis

Andere Onkyo Stereo-Receiver Handbücher

Onkyo

Onkyo TX-SR876 - AV Receiver Bedienungsanleitung

Onkyo

Onkyo TXNR905 - AV Network Receiver Gebrauchs- und Pflegehandbuch

Onkyo

Onkyo HT-R380 Bedienungsanleitung

Onkyo

Onkyo TX-SR3100 Bedienungsanleitung

Onkyo

Onkyo TX-8211 Bedienungsanleitung

Onkyo

Onkyo TX-NR929 Einrichtungshandbuch

Onkyo

Onkyo DV-BD606 - Blu-ray Single Disc Player Bedienungsanleitung

Onkyo

Onkyo TX-NR5007 - AV Network Receiver Bedienungsanleitung

Onkyo

Onkyo TX-RZ1100-B Installationsanleitung

Onkyo

Onkyo TX-NR727 Einrichtungshandbuch

Onkyo

Onkyo TX-RZ70 Bedienungsanleitung

Onkyo

Onkyo TX-NR595 Bedienungsanleitung

Onkyo

Onkyo TX-NR818B Bedienungsanleitung

Onkyo

Onkyo TX-8050 Bedienungsanleitung

Onkyo

Onkyo TX-RZ720 Bedienungsanleitung

Onkyo

Onkyo TX-8555 Bedienungsanleitung

Onkyo

Onkyo TX-NR676E Installationsanleitung

Onkyo

Onkyo TX-SR393DAB Bedienungsanleitung

Onkyo

Onkyo TX-SR803 Bedienungsanleitung

Onkyo

Onkyo TX-8130 Bedienungsanleitung

Onkyo

Onkyo TX-8030 Bedienungsanleitung

Onkyo

Onkyo TX-NR6050 Bedienungsanleitung

Onkyo

Onkyo TX-NR777 Installationsanleitung

Onkyo

Onkyo TX-NR801E Bedienungsanleitung

Beliebte Stereo-Receiver Handbücher anderer Marken

Marantz

Marantz CINEMA 70S Bedienungsanleitung

Kenwood

Kenwood KMDX92 Bedienungsanleitung

Yamaha

Yamaha RX-830 Bedienungsanleitung

Pioneer

Pioneer AVH-Z7250BT Bedienungsanleitung

Yamaha

Yamaha RX-750 Bedienungsanleitung

Denon

Denon AVR-1311 Bedienungsanleitung

Denon

Denon AVR-S760H Bedienungsanleitung

Denon

Denon AVR-X7200W Bedienungsanleitung

Pioneer

Pioneer SC-LX904 Handbuch

Sony

Sony XAV-1500 Bedienungsanleitung

Radio Shack

Radio Shack DX-399 Bedienungsanleitung

Sony

Sony STR-DE535 - Fm Stereo/fm-am Receiver Bedienungsanleitung

Pioneer

Pioneer SX-1000TA Bedienungsanleitung

Yamaha

Yamaha MusicCast TSR-5B3D Bedienungsanleitung

Sony

Sony STR-DE335 - Fm Stereo/fm-am Receiver Bedienungsanleitung

Sony

Sony STR-DG500 - Multi Channel Av Receiver Bedienungsanleitung

Panasonic

Panasonic AJSD955B - DVCPRO50 STUDIO DECK Bedienungsanleitung

Pioneer

Pioneer SX-838 Bedienungsanleitung
