Oracle SPARC T5-2 Bedienungsanleitung

This guide describes how to install and power on Oracle’s SPARC T5-2 server for the first time using the

preinstalled Oracle Solaris OS.

Before performing the procedures in this guide, review the following documents at the Oracle documentation

web site: http://www.oracle.com/goto/T5-2/docs

■SPARC T5-2 Server Product Notes - For any late-breaking issues that impact installation requirements.

■SPARC T5-2 Server Installation Guide - For more detailed installation information.

■SPARC T5-2 Server Safety and Compliance Manual - For safety and regulatory compliance information.

For additional safety information, refer to the Important Safety Information for Oracle’s Sun Hardware Systems,

which is in the shipping kit.

Shipment Inventory

1 Server

2 Cable management arm

3 Rackmounting kit

4 Antistatic wrist strap

5 RJ-45 to DB-9 crossover adapter

6 Printed documents

7 AC power cords (quantity 2)

SPARC T5-2 Server

Getting Started Guide

▼Install Optional Components

♦Before installing the server into the rack, install any optional components you plan to use with the server

that were not factory installed.

For instructions on installing optional components, refer to the documentation for each component and to

the SPARC T5-2 Server Service Manual.

▼Install the Server

For quick installation and configuration, follow these steps. For more detailed information, refer to the complete

online product documentation set.

Caution – Do not apply power until instructed to do so. – This system includes a service processor

(SP) that is used to configure and boot the host server. To properly configure the host server and view

SP messages, do not apply AC power to the server until you make the SP and host networking

connections, as described in this guide.

1. Place the server in its intended location.

For rackmounting and cable management arm instructions, refer to the SPARC T5-2 Server Installation Guide.

2. Connect a serial cable between the server’s SER MGT port and a terminal device.

This connection provides the initial communication with the SP. Set up the server to communicate using 9600

baud, 8 bit, no parity, 1 stop bit. For DTE-to-DTE communication, use the supplied RJ-45 crossover adapter

with a standard RJ-45 cable to set up a null modem configuration so that the transmit and receive signals are

crossed over.

3. (Optional) Connect an Ethernet cable between the server’s NET MGT port and the network to which

future connections to the SP and host will be made.

Configure the system for the first time through the SER MGT port. After the initial configuration, you can set

up communication between the SP and host through this Ethernet interface.

4. Connect an Ethernet cable between one of the server’s NET ports and the network to which the server

will communicate.

5. Connect the power cords to the power supplies and to separate power sources.

The server is equipped with two power supplies. Connect them to separate power sources (200 to 240 VAC)

to provide power redundancy. The system can operate with one power connection, but having only one

power source reduces the redundancy.

When the power cords are connected, the SP initializes and the power supply LEDs illuminate. After a few

minutes, the SP login prompt displays on the terminal device. At this time, the host is not initialized or

powered on.

6. At the terminal device, log in to the SP as root with a password of changeme.

After a brief delay, the Oracle Integrated Lights Out Manager (Oracle ILOM) prompt is displayed. For

optimal security, change the root password. For more information about administration tasks such as

changing passwords, adding accounts, and setting account privileges, refer to the SPARC T5 Series Servers

Administration Guide and the Oracle ILOM documentation at: http://www.oracle.com/goto/ILOM/docs

Note – By default, the SP is configured to use DHCP to obtain an IP address. If you plan to assign a static IP

address to the SP, refer to the SPARC T5-2 Server Installation Guide for instructions.

SUNSP00144FAC732F login: root

Password: changeme

. . .

7. Power on the server and redirect the host output to display on the serial terminal device.

The server initialization might take several minutes to complete.

To cancel the server initialization, press the #. (Hash+Dot) keys to return to the Oracle ILOM prompt. Then

type: stop /System

8. (Optional) You can execute other Oracle ILOM commands while the server initialization continues in the

background.

a. To display the Oracle ILOM prompt, press the #. (Hash+Dot) keys.

b. To see information about available Oracle ILOM commands, type: help

To see information about a specific command, type: help command-name

c. To return to displaying host output from the server initialization, type: start /HOST/console

9. When prompted, follow the onscreen instructions and type the configuration information for your system.

If you are not sure how to respond, accept the default and make changes later when the Oracle Solaris OS is

running. After you confirm the configuration information, the server reboots and displays the Oracle Solaris

10. Log in to the server.

You now can enter Oracle Solaris OS commands at the prompt. For more details, refer to the Oracle Solaris

11 or 10 OS man pages and documentation at:

http://www.oracle.com/goto/Solaris11/docs

http://www.oracle.com/goto/Solaris10/docs

Note – Consider using Oracle VM Server for SPARC. Oracle VM Server for SPARC is a preinstalled system

virtualization feature that provides a discrete logical grouping with its own operating system, resources, and

identity within a single computer system. You can run a variety of applications in different logical domains and

keep them independent for performance and security purposes.

▼Check for Latest OS Updates, Patches, and Firmware

Some server features are enabled only when certain versions of patches or firmware are installed. Install the

latest available versions for the best performance, security, and stability.

1. Review the SPARC T5-2 Server Product Notes.

See “Related Documentation” on page 5.

This document describes important product dependencies and late-breaking information.

-> start /System

Are you sure you want to start /System (y/n)? y

-> start /HOST/console

Are you sure you want to start /HOST/CONSOLE (y/n)? y

Serial console started.

. . .

2. Download the latest available versions from My Oracle Support at:

https://support.oracle.com

Related Documentation

Feedback

Provide feedback on this document at: http://www.oracle.com/goto/docfeedback

Access to Oracle Support

Oracle customers have access to electronic support through My Oracle Support. For information visit http://

www.oracle.com/pls/topic/lookup?ctx=acc&id=info or visit http://www.oracle.com/pls/topic/

lookup?ctx=acc&id=trs if you are hearing impaired.

Documentation Links

All Oracle products http://docs.oracle.com

SPARC T5-2 server http://www.oracle.com/goto/T5-2/docs

Oracle ILOM http://www.oracle.com/goto/ILOM/docs

Oracle Solaris 11 OS http://www.oracle.com/goto/Solaris11/docs

Oracle Solaris 10 OS http://www.oracle.com/goto/Solaris10/docs

Oracle VM for SPARC http://www.oracle.com/goto/VM-SPARC/docs

Part No.: E28859-02

Mfg No.: 7047746

February 2013
