ORANGE MICRO TERROR Bedienungsanleitung

MICRO TERROR

ENGLISH

MICRO TERROR

ENGLISH

THANK YOU!

Thank you for choosing Orange. You are now a member of the

‘Legendary British Guitar Amplifier’ owners club!

Since 1968 when the company was founded, Orange has been a

pioneering force in the guitar amplification industry. Today, with

a team of the world’s finest amplifier engineers, Orange

continues to push back the boundaries of conventional tube

amplifier design.

Our commitment to craftsmanship and quality control has

allowed our amplifiers to stand the test of time, giving their owners as much pleasure now, as the day

they were bought. To maintain this level of excellence, each Orange amplifier is put through many

rigorous test procedures before leaving the factory.

The warmth, tonal quality and rich harmonics generated by a valve ampl ifier cannot be reproduced by

‘artificial’ means. Many guitarists have reached the same conclusion: neither the transistor nor

microchip is a suitable alternative to valve technology.

This booklet contains valuable technical and safety information Please take the time to read this manual

as the information may enhance the sound and performance of your amplifier. We are confident that

you will be delighted with your new purchase and that it will provide you with many years of enjoyment.

MICRO TERROR

ENGLISH

CONTENTS

CONTENTS............................................................................................................................................... 3

CONTACT DETAILS...................................................................................................................................4

IMPORTANT SAFETY INFORMATION.......................................................................................................5

USING YOUR AMPLIFIER ......................................................................................................................... 8

VALVES AND FUSES CAN FAIL AT ANY TIME! .......................................................................................... 9

FREE EXTENDED WARRANTY OFFER ....................................................................................................... 9

MICRO TERROR

ENGLISH

CONTACT DETAILS

Orange Amplification

OMEC House

108 Ripon Way

Borehamwood

Hertfordshire

WD6 2JA

ENGLAND

Tel: +44 20 8905 2828

Fax: +44 20 8905 2868

[email protected]

Orange USA

2065 Peachtree Industrial Ct.

Suite 208

Atlanta, GA 30341

USA

Tel: 1-404-303-8196

Fax: 1-404-303-7176

info@orangeusa.com

MICRO TERROR

ENGLISH

IMPORTANT SAFETY INFORMATION

The lightning flash with arrowhead symbol, within an equilateral triangle, is

intended to alert the user to the presence of un-insulated ‘dangerous voltage’

within the product’s enclosure that may be of sufficient magnitude to constitute a

risk of electric shock to persons. Terminals labelled as

“Speaker Outputs” must be connected to a speaker cabinet of the designated

load rating using an un-shielded two conductor cable for speaker use at all times

during operation

The exclamation point within an equilateral triangle and "WARNING" are

intended to alert the user to the presence of important operating instructions.

Failure to heed the instructions will result in severe injury or death.

• Keep these instructions.

• Heed all warnings.

• Follow all instructions.

• Do not use this apparatus near liquid.

• Clean only with dry cloth.

MICRO TERROR

ENGLISH

• Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus

(including amplifiers) that produce heat.

• Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has

two blades, one wider than the other. A grounding type plug has two blades and a third grounding

prong. The wide blade or the third prong is provided for your safety. If the provided plug does not fit

into your outlet, consult an electrician for replacement of the obsolete outlet.

• Servicing: Do not attempt to service this product yourself as opening or removing covers may

expose you to dangerous voltage or other hazards.

• Refer all servicing to qualified service personnel.

• Damage Requiring Service: Unplug this product from the wall outlet and refer servicing to

qualified service personnel under the following conditions: (a) When the power-supply cord or plug

is damaged; (b) If liquid has been spilled, or objects have fallen into the product; (c) If the product

has been exposed to rain or water; (d) If the product does not operate normally by following the

operating instructions. Adjust only those controls that are covered by the operating instructions.

Improper adjustment of other controls may result in damage and will often require extensive work

by a qualified technician to restore the product to its normal operation; (e) if the product has been

dropped or damaged in any way; (f) when the product exhibits a distinct change in performance -

this indicates a need for service.

• Replacement Parts: When replacement parts are required, be sure the service technician has

used replacement parts specified by the manufacturer or have the same characteristics as the

original part. Unauthorized substitutions may result in fire, electric shock, or other hazards.

MICRO TERROR

ENGLISH

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

MICRO TERROR

ENGLISH

USING YOUR AMPLIFIER

1. SPEAKER OUTPUT

Connect the amplifier to a speaker cabinet of the correct impedance.

2. Make sure that the ON/OFF switch is in the ON position for a minute or two before use. This

will warm up the pre-amp valve ready for use.

3. VOLUME CONTROL

The volume control adjusts the overall output of the amplifier.

4. TONE CONTROL

The tone control adjusts the overall tone of the amplifier from dark to bright.

5. GAIN CONTROL

The gain control adjusts the input gain of the amplifier.

6. PRE-AMP VALVE

The Micro Terror uses 1 x 12AX7 (ECC83) in the pre-amp.

7. PHONES INPUT

This allows headphones to be connected to the Micro Terror and disables speaker outputs

enabling silent practise.

8. AUX IN

Connect an MP3 Player (or similar audio playback device) to the Micro Terror for jamming.

MICRO TERROR

ENGLISH

VALVES AND FUSES CAN FAIL AT ANY TIME!

From time to time preamp valves may fail. We suggest that any servicing must be carried out by a

qualified engineer.

For more information on maintenance and for accessories and spares, please visit

www.orangeamps.com

FREE EXTENDED WARRANTY OFFER

Orange amplifiers are under warranty for one year subject to consumer protection laws in the

country of purchase and distributor’s terms and conditions, an additional year can be added by

registering.

Valves and speakers supplied with an Orange amp or purchased separately at our online store are

covered for 90 days from the date of purchase.

The warranty status of any Orange product is subject to its being used for its intended purpose in

suitable conditions. As the manufacturer we reserve the right to refuse to warranty any Orange

product which has been misused in any way whatsoever.
