ORANGE CR6S Bedienungsanleitung

CR6S

Stereo Micro Crush

ENGLISH

CR6S

Stereo Micro Crush

ENGLISH

THANK YOU!

Thank you for choosing Orange. You are now a member of the

‘Legendary British Guitar Amplifier’ owners club!

Since 1968 when the company was founded, Orange has been a

pioneering force in the guitar amplification industry. Today, with

a team of the world’s finest amplifier engineers, Orange

continues to push back the boundaries of conventional amplifier

design.

Our commitment to craftsmanship and quality control has

allowed our amplifiers to stand the test of time, giving their owners as much pleasure now, as the day

they were bought. To maintain this level of excellence, each Orange amplifier is put through many

rigorous test procedures before leaving the factory.

This booklet contains valuable technical and safety information Please t ake the time to read this manual

as the information may enhance the sound and performance of your amplifier. We are confident that

you will be delighted with your new purchase and that it will provide you with many years of enjoyment.

CR6S

Stereo Micro Crush

ENGLISH

CONTENTS

CONTACT DETAILS...................................................................................................................................4

IMPORTANT SAFETY INFORMATION.......................................................................................................5

POWER .................................................................................................................................................... 8

FRONT PANEL FEATURES ........................................................................................................................9

REAR PANEL FEATURES.........................................................................................................................10

TROUBLESHOOTING.............................................................................................................................. 11

FREE EXTENDED WARRANTY OFFER .....................................................................................................12

CR6S

Stereo Micro Crush

ENGLISH

CONTACT DETAILS

Orange Amplification

OMEC House

108 Ripon Way

Borehamwood

Hertfordshire

WD6 2JA

ENGLAND

Tel: +44 20 8905 2828

Fax: +44 20 8905 2868

[email protected]

Orange USA

2065 Peachtree Industrial Ct.

Suite 208

Atlanta, GA 30341

USA

Tel: 1-404-303-8196

Fax: 1-404-303-7176

info@orangeusa.com

CR6S

Stereo Micro Crush

ENGLISH

IMPORTANT SAFETY INFORMATION

The lightning flash with arrowhead symbol, within an equilateral triangle, is

intended to alert the user to the presence of un-insulated ‘dangerous voltage’

within the product’s enclosure that may be of sufficient magnitude to constitute a

risk of electric shock to persons. Terminals labelled as

“Speaker Outputs” must be connected to a speaker cabinet of the designated

load rating using an un-shielded two conductor cable for speaker use at all times

during operation

The exclamation point within an equilateral triangle and "WARNING" are

intended to alert the user to the presence of important operating instructions.

Failure to heed the instructions will result in severe injury or death.

• Keep these instructions.

• Heed all warnings.

• Follow all instructions.

• Do not use this apparatus near liquid.

• Clean only with dry cloth.

CR6S

Stereo Micro Crush

ENGLISH

• Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus

(including amplifiers) that produce heat.

• Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has

two blades, one wider than the other. A grounding type plug has two blades and a third grounding

prong. The wide blade or the third prong is provided for your safety. If the provided plug does not fit

into your outlet, consult an electrician for replacement of the obsolete outlet.

• Servicing: Do not attempt to service this product yourself as opening or removing covers may

expose you to dangerous voltage or other hazards.

• Refer all servicing to qualified service personnel.

• Damage Requiring Service: Unplug this product from the wall outlet and refer servicing to

qualified service personnel under the following conditions: (a) When the power-supply cord or plug

is damaged; (b) If liquid has been spilled, or objects have fallen into the product; (c) If the product

has been exposed to rain or water; (d) If the product does not operate normally by following the

operating instructions. Adjust only those controls that are covered by the operating instructions.

Improper adjustment of other controls may result in damage and will often require extensive work

by a qualified technician to restore the product to its normal operation; (e) if the product has been

dropped or damaged in any way; (f) when the product exhibits a distinct change in performance -

this indicates a need for service.

• Replacement Parts: When replacement parts are required, be sure the service technician has

used replacement parts specified by the manufacturer or have the same characteristics as the

original part. Unauthorized substitutions may result in fire, electric shock, or other hazards.

CR6S

Stereo Micro Crush

ENGLISH

This Orange Amplifier conforms to UL Standard 60065 for Audio, Video and Similar Electronic

Apparatus - Safety Requirements;

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try and correct the

interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

Consult the dealer or an experienced radio/TV technician for help.

CR6S

Stereo Micro Crush

ENGLISH

POWER

ABOUT POWER

Since power consumption of this unit is fairly high, we recommend the use of an AC adapter

whenever possible. When powering the unit from a battery, use only an alkaline type.

AC ADAPTER OPERATION

Be sure to use only an AC adapter regulated 18V, 800mA and equipped with a

"centre minus" plug.

The use of an adapter other than the specified type may damage the unit and pose a

safety hazard.

The use of a non-regulated adapter could cause a low frequency hum in your

amplifier.

If the amplifier is not to be used for long time, disconnect the AC adapter from the

main socket.

BATTERY OPERATION

Use a generic 9V x 2 dry battery (6F22) (alkaline or manganese).

The Stereo Micro Crush cannot be used for recharging.

Pay close attention to the labelling of the battery to make sure you choose the correct

type.

If the Stereo Micro Crush is not to be used for an extended period of time, remove

the battery from the unit.

If batteries leakage has occurred, wipe the battery compartment and the battery

terminals carefully to remove all remnants of battery fluid.

While using the unit, the battery compartment cover should be closed.

9V x 2 battery compartment is on the bottom of the Unit.

To access pull on small tab labelled "OPEN". Replace with 2x new 9 V batteries.

CR6S

Stereo Micro Crush

ENGLISH

FRONT PANEL FEATURES

1. Input Jack Socket

Plug your instrument into this jack socket. A jack must be plugged into this socket for the

amplifier to ‘power up’. This is a battery saving feature.

2. Gain Control

This controls pre-gain level.

3. Tone Control

This controls the overall sound of the amplifier. Turning clockwise produces brighter tones.

4. Volume Control

This controls the output volume.

5. Aux In

Use this 1/8" stereo mini jack to connect the output of a CD or, MP3 player,Laptop,etc.,to the

amp (the jacks are internally summed to a mono signal).

6. Headphone Socket.

Connect headphones for silent practice.

CR6S

Stereo Micro Crush

ENGLISH

REAR PANEL FEATURES

1. Aux in/Stereo

Use this socket to connect your MP3 player or computer via 3.5mm jack

2. Line Out

Connect to external speakers or recording interface
