Oriental motor DRS Series Bedienungsanleitung

HL-14006-3

Compact Linear Actuators

DRS Series

DC Power Supply Input Driver

OPERATING MANUAL

Thank you for purchasing an Oriental Motor product.

This operating manual describes product handling procedures and safety precautions.

• Please read it thoroughly to ensure safe operation.

• Always keep the manual where it is readily available.

−2−

Table of contents

1Introduction .................................. 3

2Safety precautions ....................... 6

3Precautions for use......................9

4Preparation..................................11

4.1 Checking the product................11

4.2 How to identify the product

model........................................12

4.3 Combinations of actuators and

drivers.......................................13

4.4 Names and functions of parts...14

5Installation.................................. 15

5.1 Location for installation.............15

5.2 Installing the driver....................15

5.3 Installing and wiring in compliance

with EMC Directive....................17

6Connection................................. 20

6.1 Connection example.................20

6.2 Connecting the power supply....23

6.3 Connecting the actuator............24

6.4 Connecting the electromagnetic

brake type.................................24

6.5 Connecting the power supply for

the electromagnetic brake.........25

6.6 Connecting the control

input/output...............................26

6.7 About controll input/output........28

6.8 Timing chart ..............................37

7Setting.........................................38

7.1 Resolution ................................ 38

7.2 Pulse input modes.................... 39

7.3 Operating current ..................... 40

7.4 Speed-filter............................... 41

7.5 Operation data.......................... 42

8Protective functions.....................47

8.1 Descriptions of protective

functions and numbers of LED

blinks........................................ 47

8.2 How to clear a protective

function..................................... 48

9Inspection....................................49

10 Troubleshooting and remedial

actions ........................................50

11 Options (sold separately)............53

1 Introduction

−3−

1 Introduction

 Composition and contents of this operating manual

This manual describes the DC power supply input driver used with the DRS series.

Read the following operating manuals regarding the DRS series and follow the

instructions.

• DRS Series Actuators OPERATING MANUAL

Explains the installation of the actuator and a load.

• DRS Series DC Power Supply Input Driver OPERATING MANUAL

(this manual)

Explains the checking the product, combinations of actuators and drivers,

installation, connection, I/O, setting and troubleshooting of the driver.

 Before use

Only qualified personnel should work with the product. Use the product correctly

after thoroughly reading 2 “Safety precautions” on p.6.

The product described in this manual has been designed and manufactured for use in

general industrial machinery, and must not be used for any other purpose. Oriental

Motor Co., Ltd. is not responsible for any damage caused through failure to observe

this warning.

 Overview of the product

The compact linear actuator DRS series is a unit product consisting of a newly

designed linear-drive actuator combining a stepping motor ( ) with built-in

rotor position sensor and a ball screw, and a high-performance microstep driver.

The DRS series models incorporating are not subject to missteps, even

when the load changes suddenly. The speed and amount of traveling are constantly

monitored during operation, so that when an overload is about to cause the motor to

misstep, any delay in response is corrected and operation continues at maximum

thrust force.

 Standards and CE Marking

This product is recognized by UL and certified by CSA, and bears the CE Marking

(EMC Directive) in compliance with the EN Standards.

Applicable Standards Certification

Body Standards

File No. CE Marking

Actuator

Driver UL 60950-1

CSA C22.2 No.60950-1 UL E208200 EMC Directive

∗ Approval conditions for UL 60950-1: Class III equipment, SELV circuit, Pollution degree 2

∗ For unit models, Oriental Motor declares conformance with the EMC Directive individually.

1 Introduction

−4−

• For Low Voltage Directive

This product is not subject to the EC’s Low Voltage Directive because its input

power supply voltage is 24 VDC. However, the user is advised to perform the

following steps when conducting product installation and connection.

• This product is designed for use within machinery, so it should be installed within

an enclosure.

• For the driver, use a power supply with reinforced insulation on its primary and

secondary sides.

• For EMC Directive

This product has received EMC measures under the conditions specified in

“Example of DC power supply input specification installation and wiring” on p.19.

Be sure to conduct EMC measures with the product assembled in your equipment by

referring to 5.3 “Installing and wiring in compliance with EMC Directive” on p.17.

Hazardous substances

The products do not contain the substances exceeding the restriction values of

Main features

• Low speed operation at low vibration levels

The DRS series achieves smooth, low speed operation with extremely low vibration,

thanks to its micro-stepping drive, which enables stepping in very small angles.

• Built-in alarm function

Whenever a load greatly exceeding the actuator rating is encountered, or when the

actuator’s screw shaft is constrained during operation, the driver outputs a warning

alarm.

In a vertical-travel application, the electromagnetic brake may be triggered upon the

detection of this alarm to prevent a moving section and the work from falling.

• Preset speed-filter

The filter time constant that determines actuator response can be set in 16

increments.

• Preset operating current

The level of motor current during operation can be set between 6 and 100%

(maximum) in 16 increments.

• Preset resolution

The actuator resolution levels can be set in four increments.

RoHS Directive (2011/65/EU).

1 Introduction

−5−

 System configuration

Controllers with pulse output functions are needed to operate the DRS series.

Driver

Actuator

DRS series

DC power

supply input

+LS sensor

LS sensor

Pulse output

and control

input/output

Driver cable

(sold separately)

Control input/output

Control

input/output Extension cable

(sold separately)

Controller

(programmable

controller and

others)

Positioning

controller

ex: EMP series

(sold seperately)

• As for the power supply to the driver, use a DC power supply with reinforced

insulation on both the primary and secondary sides.

• If using an electromagnetic brake type, provide a 24 VDC power supply for the

electromagnetic brake separately from the control power supply. When an

extension cable is used, provide lead wires for the electromagnetic brake.

• If the EMP series is to perform the return to mechanical home operation, you need

a home detection sensor.

2 Safety precautions

−6−

2 Safety precautions

The precautions described below are intended to prevent danger or injury to the user

and other personnel through safe, correct use of the product. Use the product only

after carefully reading and fully understanding these instructions.

Warning

Handling the product without observing the instructions that

accompany a “Warning” symbol may result in serious injury or

death.

Caution

Handling the product without observing the instructions that

accompany a “Caution” symbol may result in injury or property

damage.

Note

The items under this heading contain important handling

instructions that the user should observe to ensure safe use of

the product.

Warning

General

• Do not use the product in explosive or corrosive environments, in the presence of

flammable gases, locations subjected to splashing water, or near combustibles.

Doing so may result in fire or injury.

• Assign qualified personnel the task of installing, wiring, operating/controlling,

inspecting and troubleshooting the product. Failure to do so may result in fire,

injury or damage to equipment.

• For a vertical application, use the electromagnetic brake type and provide an

additional safety-brake mechanism to hold the load in position. The actuator loses

holding torque when the power is shut off, allowing the moving parts to fall and

possibly cause injury or damage to equipment.

• Do not use the actuator’s built-in electromagnetic brake mechanism for stopping

or for safety purposes. Using it for purposes other than holding the moving parts

and actuator in position may cause injury or damage to equipment.

• When the driver’s protective function is triggered, the actuator will stop and lose

its holding torque, possibly causing injury or damage to equipment.

• When the driver’s protective function is triggered, first remove the cause and then

clear the protective function. Continuing the operation without removing the

cause of the problem may cause malfunction of the actuator, leading to injury or

damage to equipment.

Installation

• Install the driver in an enclosure in order to prevent injury.

2 Safety precautions

−7−

Connection

• Keep the driver’s power supply input voltage within the specified range to avoid

fire.

• For the driver’s power supply use a DC power supply with reinforced insulation

on its primary and secondary sides. Failure to do so may result in electric shock.

• Connect the cables securely according to the wiring diagram in order to prevent

fire or electric shock.

• Do not forcibly bend, pull or pinch the cable. Doing so may result in fire.

Operation

• Turn off the driver power in the event of a power failure, otherwise the actuator

may suddenly start when the power is restored and may cause injury or damage to

equipment.

• Do not turn the C.OFF (All windings off) input to ON while the actuator is

operating. The actuator will stop and lose its holding ability, which may result in

injury or damage to equipment.

Repair, disassembly and modification

• Do not disassemble or modify the driver. This may cause injury. Refer all such

internal inspections and repairs to the branch or sales office from which you

purchased the product.

Caution

General

• Do not use the driver beyond its specifications, or injury or damage to equipment

may result.

• Keep your fingers and objects out of the openings in the driver, or fire or injury

may result.

• Do not touch the driver during operation or immediately after stopping. The

surface is hot and may cause a skin burn(s).

Installation

• Keep the area around the driver free of combustible materials in order to prevent

fire or a skin burn(s).

• To prevent the risk of damage to equipment, leave nothing around the driver that

would obstruct ventilation.

Operation

• Use the actuator and driver only in the specified combination. An incorrect

combination may cause a fire.

• Provide an emergency stop device or emergency stop circuit external to the

equipment so that the entire equipment will operate safely in the event of a system

failure or malfunction. Failure to do so may result in injury.

2 Safety precautions

−8−

• Before supplying power to the driver, turn all control inputs to the driver to OFF.

Otherwise, the actuator may start suddenly and cause injury or damage to

equipment.

• To prevent bodily injury, do not touch the screw shaft of the actuator during

operation.

• Before moving the screw shaft directly (as in the case of manual positioning),

confirm that the driver C.OFF (All windings off) input is ON to prevent injury.

• For the control input/output power supply, use a power supply with reinforced

insulation provided on the primary side, and provide it separately from the power

supply for the electromagnetic brake. Failure to do so may result in electric shock.

• Immediately when trouble has occurred, stop running and turn off the driver

power. Failure to do so may result in fire or injury.

Disposal

• To dispose of the driver, disassemble it into parts and components as much as

possible and dispose of individual parts/components as industrial waste.

3 Precautions for use

−9−

3 Precautions for use

This section covers limitations and requirements the user should consider when

using the DRS series driver.

• Conduct the insulation resistance measurement or withstand voltage

test separately on the actuator and the driver

Conducting the insulation resistance measurement or withstand voltage test with the

actuator and driver connected may result in injury or damage to the product.

• Acceleration (acceleration/deceleration rate)

The acceleration (acceleration/deceleration rate) when the actuator is started or

stopped must be within the specified range, irrespective of the loaded mass.

Operating at an acceleration (acceleration/deceleration rate) beyond the specified

range, an alarm will be output. Refer to p.42 for details.

• Operating speed

The operating speed of the actuator must be within the specified range, including

during acceleration. Refer to p.43 for details.

• Do not let the screw shaft hit the stroke end or load

Do not let the screw shaft hit the stroke end or equipment during operation, since

such an impact may damage the actuator. Should the screw shaft hit the stroke end

or equipment, return the potentiometer for adjusting the current setting switch

[SW1] to the factory set value and then retract the shaft by operating it in the reverse

direction at the starting speed. Refer to p.40, 43 for details.

• Use the electromagnetic brake type for an application involving

up/down travel.

When the actuator is used in an application involving up/down travel, such as a lifter,

use an electromagnetic brake type to hold the load in position. To hold the load in

position, apply the electromagnetic brake only after the actuator has stopped. Do not

use the brake to bring the moving actuator to a halt. Repeated braking for such a

purpose will wear the brake hub excessively, causing its holding ability to drop.

Since the electromagnetic brake is of the non-excitation type, it can also be used to

hold the load in position upon the occurrence of a power failure. However, this is not

a secure means of holding the load. Do not use the electromagnetic brake as a safety

brake.

When the driver-protection function is triggered, the actuator stops as the current is

turned off. The user must set a controller sequence that will cut off the power to the

electromagnetic brake and hold the load in position upon detecting an OFF state of

ALARM output.

3 Precautions for use

−10−

• Connecting an electromagnetic brake

If using an electromagnetic brake type, provide a 24 VDC power supply for the

electromagnetic brake separately from the control power supply.

When connecting the electromagnetic brake leads to DC power supply, observe the

correct polarity. Be sure to connect the supplied varistor (nonpolarized) to protect

the switch contacts and prevent noise.

• Preventing electrical noise

Refer to 5.3 “Installing and wiring in compliance with EMC Directive” on p.17 for

measures with regard to noise.

Andere Handbücher für DRS Series

Inhaltsverzeichnis

Andere Oriental motor Controller Handbücher

Oriental motor

Oriental motor CRD514-KD Betriebsanleitung

Oriental motor

Oriental motor DSC Series Bedienungsanleitung

Oriental motor

Oriental motor alphaSTEP ARL Series Handbuch

Oriental motor

Oriental motor DSC Series Bedienungsanleitung

Oriental motor

Oriental motor EZS Series Bedienungsanleitung

Oriental motor

Oriental motor CM10 Series Bedienungsanleitung

Oriental motor

Oriental motor MSC-1 Bedienungsanleitung

Oriental motor

Oriental motor EMP400 Series Bedienungsanleitung

Oriental motor

Oriental motor CRD5103P-RS4 Bedienungsanleitung

Oriental motor

Oriental motor DRL Series Bedienungsanleitung

Oriental motor

Oriental motor DR Series Bedienungsanleitung

Oriental motor

Oriental motor Astep AZ Series Bedienungsanleitung

Oriental motor

Oriental motor EZ limo EZHS Series Bedienungsanleitung

Oriental motor

Oriental motor DRS Series Bedienungsanleitung

Oriental motor

Oriental motor CRK Series Bedienungsanleitung

Oriental motor

Oriental motor DSC Series Bedienungsanleitung

Oriental motor

Oriental motor FSP200-1 Gebrauchsanweisung

Oriental motor

Oriental motor DRL Series Bedienungs- und Wartungshandbuch

Oriental motor

Oriental motor TM Series Bedienungsanleitung

Oriental motor

Oriental motor aSTEP AZ Series Bedienungsanleitung

Oriental motor

Oriental motor NX Series Bedienungsanleitung

Oriental motor

Oriental motor ASTEP AZ Series Bedienungsanleitung

Oriental motor

Oriental motor BXII Series Bedienungsanleitung

Oriental motor

Oriental motor DH Series Bedienungsanleitung

Beliebte Controller Handbücher anderer Marken

Digiplex

Digiplex DGP-848 Betriebsanleitung

YASKAWA

YASKAWA SGM series Bedienungsanleitung

Sinope

Sinope Calypso RM3500ZB Bedienungsanleitung

Isimet

Isimet DLA Series Style 2 Installationshandbuch

LSIS

LSIS sv-ip5a Bedienungsanleitung

Rockwell Automation

Rockwell Automation 1769-L31 Bedienungsanleitung

Airflow

Airflow Uno hab Bedienungsanleitung

ABB

ABB ACS580-01 drives Bedienungsanleitung

Panasonic

Panasonic GM1 Series Bedienungsanleitung

Emerson

Emerson SW93 Bedienungsanleitung

AutoAqua

AutoAqua Smart ATO micro SATO-120P Bedienungsanleitung

Panasonic

Panasonic FP? Positioning Unit RTEX Bedienungsanleitung

Samson

Samson Type 5824 Service-Handbuch

Alpha IP

Alpha IP MIOB 21001 Bedienungsanleitung

Siemens

Siemens OpenAir GMA 1 Series Bedienungsanleitung

Surecom

Surecom SR-629 Bedienungsanleitung

Fishman

Fishman TriplePlay Bedienungsanleitung

Regulus

Regulus SRS1 T Bedienungsanleitung
