WIRELESS CONNECTIVITY
FPV.JR Bluetooth
User Manual
Rev. 1.0 | August 2021.
Orqa FPV.JR Bluetooth User Manual, Rev.1.0 ©2021. Orqa Ltd.
PRODUCT DESCRIPTION
3
TECHNICAL SPECIFICATIONS & REQUIREMENTS
4
INSTALLATION STEPS
5
WARRANTY
6
2
Orqa FPV.JR Bluetooth User Manual, Rev.1.0
©2021. Orqa Ltd.
PRODUCT DESCRIPTION
Enable your radio controller based on JR Standard module bay with
Bluetooth connectivity for seamless wireless connectivity to your favourite
simulators on desktop and mobile devices.
Orqa FPV.JR Bluetooth is compatible with all radio controllers with the JR
module bay and desktop (Mac,PC, Linux) and mobile platforms (iOS,
Android, Huawie). Orqa FPV.JR Bluetooth module supports all major FPV
simulators. For the best experience download and install Orqa
FPV.Skydive simulator from Steam.
To download Orqa FPV.Skydive Mobile* use links bellow:
● iOS
● Android
● Huawei
*Orqa FPV.Skydive Mobile is in Open Beta version.
3
Orqa FPV.JR Bluetooth User Manual, Rev.1.0
©2021. Orqa Ltd.
TECHNICAL SPECIFICATIONS & REQUIREMENTS
Technical specifications:
● JR Standard Module
● JR Standard Pinout
● Bluetooth 5.0
● Reset button
● RGB Status LED
● Low Latency
Requirements:
● Orqa FPV.BT Module
● OpenTX based radio with GHST protocol support
● JR Standard Module bay on Radio Controller
● PC, Linux, Mac or iOS, Android or Huawei with a Bluetooth Module
4
Orqa FPV.JR Bluetooth User Manual, Rev.1.0
©2021. Orqa Ltd.
INSTALLATION STEPS
1. Update your controller with the latest version of OpenTX via this link;
2. After updating your OpenTX, set External RF mode to GHST and
turn off the controller;
3. Plug in FPV.BT in JR bay and turn on the controller again;
4. Go to your desktop or mobile device and search for "Orqa BT"
bluetooth device (1);
5. After pairing/connecting your desktop or mobile device with FPV.BT,
it should appear as a joystick or controller device;
6. If you wish to connect FPV.Bt with a new device, push the "reset"
button on FPV.Bt and wait for a green light.
5
Orqa FPV.JR Bluetooth User Manual, Rev.1.0
©2021. Orqa Ltd.
WARRANTY
WARNING!
Any damage done to the product caused by the attempt to open,
disassemble or modify it voids the warranty.
WARRANTY
2 Years
6
