Ortlieb SK 30 Leitfaden

Version 05.12.2018

Technical Documentation

SK-Tool Gripper

Tool Grippers for tool shanks with 7/24 taper

DIN 69871 /72 / ISO 7388/1+2 / ANSI B5.50 / MAS BT

Ortlieb Präzisionssysteme GmbH & Co. KG • Jurastr.11 • 73119 Zell unter Aichelberg • Germany

Tel.: +49 (0) 7164 79701-0 • Fax.: +49 (0) 7164 79701-51 • e-mail: info@ortlieb.net • www.ortlieb.net

Content:

General ..................................................................................................................................3

1.1

Introduction.....................................................................................................................3

1.2

Guarantee ......................................................................................................................4

1.3

Intended Use ..................................................................................................................5

1.4

Initial start-up..................................................................................................................5

1.5

Checklist for Installation..................................................................................................6

Product description ................................................................................................................8

2.1

Tool-Grip

SK.................................................................................................................9

2.2

Multi-Grip

SK ................................................................................................................9

2.3

Technical Data ...............................................................................................................9

Spare parts ..........................................................................................................................10

Mounting instructions ...........................................................................................................11

General Safety Instructions ..................................................................................................12

5.1

Troubleshooting............................................................................................................14

Assembly declaration ...........................................................................................................15

Shipping data .......................................................................................................................16

1. General

Ortlieb Präzisionssysteme GmbH & Co. KG • Jurastr.11 • 73119 Zell unter Aichelberg • Germany

Tel.: +49 (0) 7164 79701-0 • Fax.: +49 (0) 7164 79701-51 • e-mail: info@ortlieb.net • www.ortlieb.net

1 General

1.1 Introduction

This operation instruction will help you to operate your Ortlieb product safely and to avoid

accidents, possible dangers and risks.

Please read this operation instruction and the safety instructions carefully before initial start-up.

This documentation provides all information on operating and maintaining your Ortlieb product.

Ortlieb Präzisionssysteme GmbH & Co. KG assumes no liability for damages and interruptions

caused by disregarding several articles of this documentation.

Ortlieb Präzisionssysteme GmbH & Co. KG reserves the right to make any technical changes and

improvements to this product. No liability on literal mistakes.

For Start-up, operation and maintenance, the information in this manual must be supplemented by

the relevant national and international „safety and accident prevention regulations“. Compliance

with the safety regulations and statutes will prevent injury and damages to machinery and this

product.

1. General

Ortlieb Präzisionssysteme GmbH & Co. KG • Jurastr.11 • 73119 Zell unter Aichelberg • Germany

Tel.: +49 (0) 7164 79701-0 • Fax.: +49 (0) 7164 79701-51 • e-mail: info@ortlieb.net • www.ortlieb.net

1.2 Guarantee

Products of Ortlieb Präzisionssysteme GmbH & Co. KG are produced according to national and

international standards as well as company standards, supervised by a certified quality assurance.

For those products Ortlieb Präzisionssysteme GmbH & Co. KG assumes liability in the manner that

parts with material or production defects proven within 12 month after purchasing were repaired

free-of-charge, replaced by new ones or taken back to the charged price.

In the event of improper assembly and operation, use of non-original spare parts, unauthorized

modifications to our product we shall assume no liability for personal injury or damage to

machinery and our product.

We shall assume no liability for damage of any type resulting from the removal of safety devices.

We take the initial start-up of our products on appropriate and technically flawless machines by

qualified and continuous trained personal for granted.

1. General

Ortlieb Präzisionssysteme GmbH & Co. KG • Jurastr.11 • 73119 Zell unter Aichelberg • Germany

Tel.: +49 (0) 7164 79701-0 • Fax.: +49 (0) 7164 79701-51 • e-mail: info@ortlieb.net • www.ortlieb.net

1.3 Intended Use

Use the tool-grippers only for the intended use. Insufficiently clamped tools or work-pieces, failure

to comply „safety and accident prevention regulations“, and the use of work-pieces and our

products on machines that are not intended for this propose, can result in personal injury and

damages to the clamping devices. In this case, we shall assume no liability. Do not apply force

during assembly, disassembly and operation; this could damage the clamping device or the

machine.

1.4 Initial start-up

A function check is implicitly before initial operation of the tool-gripper. To ensure a safe and

precise operation of the tool-gripper during machining, a sufficient clamping force must be

provided. Check the clamping force.

See: Checklist for Installation p.6

The tool-gripper, especially the function surfaces must be clean and lubricated sufficiently. It is

strongly recommended to grease with suitable assembling grease.

Never exceed the axial and radial forces specified on the tool-gripper.

Check the clamping force regularly!

1. General

Ortlieb Präzisionssysteme GmbH & Co. KG • Jurastr.11 • 73119 Zell unter Aichelberg • Germany

Tel.: +49 (0) 7164 79701-0 • Fax.: +49 (0) 7164 79701-51 • e-mail: info@ortlieb.net • www.ortlieb.net

1.5 Checklist for Installation

1.) Tool –“Eject” max. 1.0 mm. The tool is only drawn in securely by the tool gripper in this

range. Ensure that the clamping reserve is min. 2 mm and max. 3 mm.

2.) Check the clamping force. The max. pull-in force, Fz max. , must not be exceeded.

3.) Tool clamping must not be one-sided. Guide the disc spring stack accurately.

4.) Spindle receiver must meet DIN 69871 /72 standard and Ortlieb installation dimensions.

Functional surfaces hardened min. 1mm deep to HRc 60

+2.

5.) Observe the control operation.

Insert the tool until it reaches the limit stop at the draw-bolt plane surface, then clamp it.

Clamping must not de done too soon, as otherwise the clamping segments are not

disengaged can properly and can be damaged.

6.) Tool change: Grip the tool – eject – unclamp - blow-out. Make sure that the tool and

spindle are clean. If chips are drawn in, clamping segments will sustain damage.

(One-sided overloading of the clamping segments).

7.) If one clamping segment breaks, the tool will nevertheless be clamped safely. However

the tool-gripper must be exchanged immediately as a complete unit.

8.) The tool-gripper is a part which is subject to wear. Under favourable operation conditions,

the complete tool-gripper must be exchanged every 1x10

load alternations. We do not

assume liability and guarantee on consequential damages in case only parts are

exchanged.

9.) Refer to the Mounting instructions p.11 for information about how to change the tool-

gripper! Before installing the tool-gripper, check the spindle for damage. Grease the

functional surfaces.

1. General

Ortlieb Präzisionssysteme GmbH & Co. KG • Jurastr.11 • 73119 Zell unter Aichelberg • Germany

Tel.: +49 (0) 7164 79701-0 • Fax.: +49 (0) 7164 79701-51 • e-mail: info@ortlieb.net • www.ortlieb.net

10.) For optimal drawing-in force, RPM

max.

and n

max.

, please refer to data on the installation

drawing.

11.) Tools must meet DIN 69871 /72 standards.

12.) Without an HSK tool insert, there is no operation of the spindle allowed. (Out-of-balance!)

13.) After every crash, the tool-gripper must always be exchanged completely.

14.) The clamping force transmitted to the tool shank by the tool-gripper may not be below the

incident machining forces and torques. It is also important that the functional surfaces and

the clamping system are greased regularly (Metaflux lubricant metal paste)

Based on experience, re-greasing should be done after every 200.000 load alternations

at the least in order to keep the clamping force as uniform as possible. Regular

measurement of the clamping force, either quarterly or semi-annual, will ensure the

required safety for the work process. (See p.12)

15.) Check the tightening of the draw-bolt and the drawbar regularly to ensure a proper

function of the tool-gripper.

A loose draw-bolt causes a loss of clamping force and ejects the tool far over the allowed

max. 1,0mm.

2. Product description

Ortlieb Präzisionssysteme GmbH & Co. KG • Jurastr.11 • 73119 Zell unter Aichelberg • Germany

Tel.: +49 (0) 7164 79701-0 • Fax.: +49 (0) 7164 79701-51 • e-mail: info@ortlieb.net • www.ortlieb.net

2 Product description

The Ortlieb tool-grippers for tool shanks with 7/24-taper are an approved serial product for

automatic tool changing. They are clamping tools with ISO taper (7/24) and pull studs acc.

DIN 69871/72. The six-piece clamping segment has an optimal load balancing. Therfore a higher

permitted clamping force is possible. And this at faster cyles.

Pos.

Item

1 clamping segment

2 draw-bolt

3 ring spring

4 rubber shim

5 pull stud

6 tool

7 spindle

Function:

Milling spindles on machine tools are usually fitted with conventional spring loaded tool clamping

systems. The tool-gripper operates on pulling force.

The six-piece clamping segment is pulled by the draw-bolt into the machine spindle. The clamping

segment catches the pull stud of the tool and pulls it into the spindle whereas the clamping

segments are backed radial by the spindle-bore.

To change the tool, the disk springs were compressed, usually by a hydraulic cylinder. The draw-

bolt is pushed by the drawbar to the front, releases the clamping segments and pushes the tool by

force out of the spindle taper. The ring spring provides the opening of the clamping segments

which release the tool for changing.

2. Product description

Ortlieb Präzisionssysteme GmbH & Co. KG • Jurastr.11 • 73119 Zell unter Aichelberg • Germany

Tel.: +49 (0) 7164 79701-0 • Fax.: +49 (0) 7164 79701-51 • e-mail: info@ortlieb.net • www.ortlieb.net

2.1 Tool-Grip

By its simple design and few components, this tool-gripper is mounted quickly, extreme

maintenance friendly and persistent. This tool-gripper clamps tool shanks with 7/24-taper and pull

studs acc. DIN 69871/72.

DIN 69871/72

2.2 Multi-Grip

The Multi-Grip tool-gripper clamp tool shanks with 7/24-taper and pull studs acc. DIN 69871/72 by

default. In the same spindle with the same measures, tool shanks with other pull studs can be

clamped by simply change the tool-gripper. The following standards are supported:

DIN 69871/72 ISO 7388/1+2 (A+B) ANSI B5.50 MAS BT JIS B6339-1992

On request:

- Reinforced design for higher clamping forces

- Design with air blast, coolant, minimal quantity lubrication delivery and additional sealings

2.3 Technical Data

Size Item

Installation

measure (EM)

Release

stroke Reserve Fsp max

SK 30 BSK 2557-03 71,3 5 2 9 kN

BSK 2557-02 71,3 6,5 2 5 kN

BSK 2557-11 71,3 4 2 9 kN

BSK 2557-16 71,3 4 2 9 kN

SK 40

BSK 2602

93,9

20 kN

BSK 2605 93,9 6 2 20 kN

BSK 2537-06 93,4 5,5 2 20 kN

BSK 2537 93,7 6 2 15 kN

SK 45

BSK 2425

112,2

25 kN

BSK 2425-02 112,2 8 2 25 kN

BSK 2543-04 112,2 6 2 25 kN

BSK 2543-03 112,2 6 2 25 kN

SK 50

BSK 2528

134,7

35 kN

BSK 2528-02 134,7 6 2 35 kN

BSK 2615-02 135,3 6 2 35 kN

BSK 2494 134,7 8 2 35 kN

SK 60

BSK 2604

201,3

60 kN

BSK 2604-12 201,3 9,5 3 60 kN

* Further technical data and installation measures on the installation drawing

3. Spare parts

Ortlieb Präzisionssysteme GmbH & Co. KG • Jurastr.11 • 73119 Zell unter Aichelberg • Germany

Tel.: +49 (0) 7164 79701-0 • Fax.: +49 (0) 7164 79701-51 • e-mail: info@ortlieb.net • www.ortlieb.net

3 Spare parts

Pos.

Item

1 clamping segment

2 draw-bolt

3 ring spring

4 rubber shim

5 pull stud

6 tool

7 spindle

Size

Item

Clamping segment

Draw

bolt

Ring spring

Rubber shim

SK 30

BSK 2557-03 BSK 2557/1 BSK 2557/203 OBN 7196/10 BSK 2358/4

BSK 2557-02 BSK 2557/202

BSK 2557-11 BSK 2557/101 BSK 2557/211 OBN 7169/12 BSK 2358/4

BSK 2557-16 BSK 2557/216

SK 40

BSK 2602-03 BSK 2415/1 BSK 2602/203 OBN 7169/11 BSK 2415/4

BSK 2605 BSK 2605/2

BSK 2537-06 BSK 2537/1 BSK 2537/206

BSK 2537 BSK 2537/2

SK 45

BSK 2425-01 BSK 2425/1 BSK 2425/201 OBN 7169/14 BSK 2415/4

BSK 2425-02 BSK 2425/202

BSK 2543-04 BSK 2543/1 BSK 2543/204

BSK 2543-03 BSK 2543/203

SK 50

BSK 2528 BSK 2416/1 BSK 2528/2 OBN 7169/12 BSK 2416/4

BSK 2528-02 BSK 2528/202

BSK 2615-02 BSK 2649/101 BSK 2615/202

BSK 2494 BSK 2494/1 BSK 2494/2

SK 60

BSK 2604 BSK 2604/1 BSK 2604/2 OBN 7169/13 BSK 2604/4

BSK 2604-12 BSK 2604/212

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Ortlieb Werkzeuge Handbücher

Ortlieb

Ortlieb Tool-Grip-HSK Leitfaden

Beliebte Werkzeuge Handbücher anderer Marken

Martor

Martor SECUNORM 175 Bedienungsanleitung

ERKCO

ERKCO 1000 Bedienungsanleitung

jbc

jbc N4473 Bedienungsanleitung

FEINMETALL

FEINMETALL FZWZ-SET-001 Bedienungsanleitung

Worx Professional

Worx Professional Sonicrafter WU676 Bedienungsanleitung

Gage Bilt

Gage Bilt GB713SH Bedienungsanleitung

Hilti

Hilti DX 9-ENP Bedienungsanleitung

norbar

norbar NORTRONIC 34399 Bedienungsanleitung

BGS technic

BGS technic 8578 Bedienungsanleitung

Makita

Makita DHR241 Bedienungsanleitung

Motor Guard

Motor Guard JMB-1250 Bedienungsanleitung

Power Adhesives

Power Adhesives 805-12 Bedienungsanleitung

Clemco

Clemco 24189 Bedienungsanleitung

VVG

VVG VNG 903 Series Bedienungsanleitung

Hilti

Hilti FX 3-A Bedienungsanleitung

Grizzly

Grizzly H6472 Bedienungsanleitung

axing

axing BWZ 5-02 Bedienungsanleitung

Dh-Robotics

Dh-Robotics RGI-100 Anleitung zur Verwendung
