ET4100CPp-TS
Transmitter of 4-port 10/100Mbps TX(PoE+) to 1-port Coax Ethernet Switch with PoC
1 V1.1
Thisquickstartguidedescribeshowtoinstallandusethe4‐port10/100MpstransmitterwithPoweroverEthernet
(PoE+).TheproductisdesignedforIPCCTVsystemupgrade.
Overview
TheET4100CPp‐TS(Transmitter)workswiththeET1100CPp‐R(Receiver)toprovideEthernetExtensionof4
channel10/100Base‐TXcopperEthernetto1‐portcoaxial.Themaximumcoaxialcabledistanceis800m.The
productsupportPoE+,hence,nopowerpointisrequiredforthetransmittersideandtheconnectedIPcameraif
thecamerasupportPoweroverEthernet(PoE+).
General
Toensuretroublefreetransportationandstorage,allOTSystemsproductsmustbethoroughlyinspected,tested
andproperlypackedbeforedelivery.Checktheproductuponreceiptforanyvisibledamagewhichmayhavebeen
causedduringshipment.
PackageContent
ET4100CPp‐TSx 1
QuickStartGuidex1
PhysicalDescription
FrontPanel
ET4100CPp-TS
Transmitter of 4-port 10/100Mbps TX(PoE+) to 1-port Coax Ethernet Switch with PoC
2 V1.1
Installation
There are two mounting holes in each side of the rear panel. Mount the product on wall with appropriate screws.
Then, push left or right, if the equipment fixed vertically, or push down, if equipment fixed horizontally, to make it
fixed tighter. Installation now is completed.
Setup
1. The EoC transmitter is a plug-and-play device. Connect an external AC to DC power adaptor (48VDC output) to
the power connector (2 pin terminal block) according to the polarity shown in the Power Connection section.
Then attach the plug into a standard AC outlet. The PWR LED will then be lit.
2. The Coax LINK LED will be lit (ON) when the transmitter is ready for data transfer.
3. Connect one end of the coaxial cable to the female BNC connector (COAX DATA) of ET4100CPp-TS and the
other end to the receiver (ET1100CPp-R). If the transmitter and receiver are properly connected and
communicated with each other, the ACT will be lit (ON).
4. Connect the Ethernet cable from the IP camera or similar equipment to the Ethernet port (10/100M). If the cable
is properly connected, the LINK/ACT LED at the RJ45 port with be lit. If there is data being transferred, the LED
will be blinking.
Interface
RJ‐45PinAssignment
Pin Si
g
nalName
1TP0+ Negative (VCC-)
2TP0‐ Negative (VCC-)
3TP1+ Positive (VCC+)
4TP2+
5TP2‐
6TP1‐ Positive (VCC+)
7TP3+
8TP3‐
PowerConnection：
Pin
Description ‐ +
PowerInput GND 48~57VDC
ET4100CPp-TS
Transmitter of 4-port 10/100Mbps TX(PoE+) to 1-port Coax Ethernet Switch with PoC
3 V1.1
CableConnection
InterfaceTypeSupportDescription CableType
RJ45
10Base‐TX
100Base‐TX
1000Base‐T
Category3orabovecable
Category5orabovecable
Category5orabovecable
BNC(Female) EthernetoverCoaxData RG‐59/Uorsimilar
2‐pinTerminalBlock Powerinput(48~57VDC) 2‐wire
LEDStatus
LEDs Colour State Indication
PWR Green
Steady Poweron
Off Poweroff
ACT Green
Flashing Datatransferwithinthecoaxialcable
Off Nodatatransferwithinthecoaxialcable
Coax
LINK Green
Steady Theconverterisreadyfordatatransfer
Off Theconverterisnotready
Ethernet
LINK/
ACT Green
Steady Ethernetconnectionof10/100Base‐TXisestablished
Flashing TransmittingorreceivingEthernetdata
Off Neither valid Ethernet connection established nor transmitting or
receivingEthernetdata
PoE Yellow
Steady Ethernetconnectionof10/100/1000Base‐Tisestablished
Off Neither valid Ethernet connection established nor transmitting or
receivingEthernetdata
ET4100CPp-TS
Transmitter of 4-port 10/100Mbps TX(PoE+) to 1-port Coax Ethernet Switch with PoC
4 V1.1
Dimensions(Unit:mm)
ET4100CPp-TS
Transmitter of 4-port 10/100Mbps TX(PoE+) to 1-port Coax Ethernet Switch with PoC
5 V1.1
FunctionalDescriptions
ConnectinguptoET1100CPp‐Randupto4xIPcameras
10/100MbpsFull‐duplexcommunication
SupportPoweroverCoaxial
SupportIEEE802.3af/atPoweroverEthernet
Datarateperportupto25Mbps(Uplink/Downlink).
Distance:800m(max.)overCoaxialcable(RG‐59/U)
External48~57VDCpowerinput
‐10oCto60oC(14oFto140oF)operatingtemperature
ManualEarthGreenmanualisavailableinourwebsite.www.ot‐systems.com
