OwnElement SwaySingle Bedienungsanleitung
In the box
●Please read the manual thoroughly before you begin the
installation.
●This product contains high-pressure gas springs. Do not put
into re or expose to high temperatures.
●Under no circumstances does the manufacturer accept
warranty claims or liability claims for damages caused by
improper use or handling of the desk.
●Do not open or modify any of the components. Doing so may
cause damage or personal injury and oids any warranty
claims.
●Only mount onto desktops that could bear the weight of the
mount and monitors.
●This product contains small parts, keep away from children.
Cautions
Instruction Manual
Sway Single
STEP 1: Installing the base STEP 2: Installing the arm
STEP 3: Mounting the monitor
Mount the base to your table top. If the default clamp size is
not suitable for you, it can be made larger or smaller by
adjusting its bottom plate.
Method 1: Installing on the open edge of the
table top
Method 2: Installing through a grommet hole
Detach the bottom clamp before
installing the base stem
Once the arm is put in place,
secure it in place by
tightening the screw.
Install the VESA plate to the back of your monitor. Make
sure you install the clip facing upwards. Our VESA plate
is compatible with both 75x75mm and 100x100mm
mounts.
You can easily slide down the monitor with VESA plate
into the arm bracket.
To remo e, press the clip at the top while pulling the
monitor up.
Cable Management
Use the built-in cable management to tidy up your cables.
Remo ing the co er plate may need some force, be careful
not to damage it while doing so.
Adjustments
The default adjustments work for most use cases. You may
look into these ner adjustments to make them suit your
needs.
Adjusts the tightness of erticle
tilt
Adjusts the tightness of horizontal tilt
If your monitor seems too hea y or too light to easily adjust
its height, tightening the weight screw may help.
Important: Unlike other screws, turning this screw anti-
clockwise will make it tighter, requiring more weight to
mo e the monitor up or down.
