PAJ GPS POWER Finder Bedienungsanleitung

POWER FINDER

USER MANUAL- PAJ GPS Finder WITH ONLINE-TRACKING

Thank you for purchasing a PAJ FINDER. Before using your

FINDER please read the instructions carefully. It will introduce

you to the handling and operation of the product. Please keep

the manual for future reference.

MANUAL DE INSTRUCCIONES - PAJ GPS Finder CON

LOCALIZACIÓN ONLINE

Muchas gracias comprar nuestro PAJ FINDER. Antes del

primer uso: Lea el manual de instrucciones atentamente antes

de utilizar el FINDER. Por favor guarde el manual para

consultas en el futuro.

This manual includes the languages

Este manual incluye los idiomas

1 English........................4

2 Spanish.....................20

POWER Finder 4G by PAJ GPS V.1.0 US
© PAJ GPS Inc.
4

Table of contents
1English
1.1 What's included ............................................. 5
1.2 Product graphics ........................................... 5
1.3 Loading.......................................................... 6
1.4 How do I activate the FINDER? ...................... 6
1.5 Turning on/off ............................................... 6
1.6 How do I track my vehicle with
the FINDER?................................................... 7
1.7 LED lights ...................................................... 8
1.8 Technical data............................................... 9
1.9 Safety instructions ...................................... 10
1.10 Note on the disposal of
used batteries.............................................. 17
1.11 Note on the disposal of
electric appliances ...................................... 18


POWER Finder 4G by PAJ GPS V.1.0 US

1.1 What's included

In the delivery:

POWER Finder 4G by PAJ

M2M SIM card (is already inserted/ do not replace)

USB charging cable

Adhesive magnet (attach the red adhesive strips to the

desired object - do not stick on the FINDER!)

The latest version of this manual always can be downloaded

for free at

www.paj-gps.us/finder

The PAJ-GPS team wishes you lots of fun with your PAJ GPS

FINDER!

1.2 Product graphics

LED signal

Battery terminal

Button for the

battery indicator

Battery indicator

POWER Finder 4G by PAJ GPS V.1.0 US

1.3 Loading

Before first using, the GPS Tracker should be charged for

approx. 8-12 hours. Connect the supplied charging cable to the

charging port of the GPS tracker. Then attach the USB port to

the socket adapter. As soon as none of the bars on the battery

display are flashing, the FINDER is charged.

The POWER Finder 4G offers you a running time of approx.

90 days without charging! However, it should be noted that

the duration depends on the load. The more PAJ's POWER

Finder 4G is moved and the more alerts are sent, the higher

the utilization.

1.4 How do I activate the FINDER?

In order to be able to use the PAJ GPS FINDER, it is necessary to

first activate the device online.

Note: To activate the device you need the ID of your FINDER.

These can be found on the barcode stuck on the device.

Please follow

www.finder-portal.us/go

for activation.

1.5 Turning on/off

Recommended first step: To receive the best GPS signal

place the POWER Finder 4G outside and make sure it is not

covered. Avoid garages, basements and similar.

If the activation has been carried out successfully, the FINDER

can be switched on. please follow these instructions:

POWER Finder 4G by PAJ GPS V.1.0 US

1) Open the housing cover

2) Remove the rubber cover

Please do not remove or change the SIM card!

3) Slide the slider to "ON"

4) Put the rubber cover

back into the device

5) Click the housing cover back

into the device

The button next to the charging socket is only used to

display the battery. Just press the button once!

How do I see if the FINDER is on?

Please briefly press the battery button once.

BEHAVIOR

STATUS

The red LED and battery

indicator light up for

approx. 20 seconds

FINDER is switched on

Red LED and battery indicator

remain switched off

FINDER is switched off

1.6 How do I track my vehicle with the FINDER?

Once the activation and connection processes have been

successful, and the FINDER already has sent its first data, you

can go ahead with tracking your protected vehicle. Use the app

POWER Finder 4G by PAJ GPS V.1.0 US

for IOs or Android, your tablet or computer. For online tracking

please visit:

www.finder-portal.us

The tracking service explains all functions online. Download

the app for free for IOS and Android here:

1.7 LED lights

Red LED

SIGNAL

MEANING

The red LED is off

Standby mode or FINDER is

switched off.

If the GPS tracker is not moved

(anymore), the GPS signal

switches off. As soon as the

GPS tracker is moved again,

the GPS signal automatically

switches on again.

The red LED flashes quickly

Reception available

The red LED flashes slowly

No signal available.

FINDER is looking for a signal.

Battery indicator

SIGNAL

MEANING

The battery indicator and the

red LED light up for approx. 10

seconds (if the FINDER is

connected to a cable)

FINDER is charging

POWER Finder 4G by PAJ GPS V.1.0 US

(briefly press the ON / OFF

button to display the battery)

All bars of the battery indicator

are displayed constantly

FINDER is fully charged

1.8 Technical data

Dimensions

4,33 x 2,76 x 0,47 inch (109 ×

61 × 30,5mm)

GPS accuracy

Up to 3 meters

Standby time

About 90 days

Battery

3,7V 10.000mAh Li-Polymer

Weight

302g

Time to start

Cold start: 40 seconds

In Operation: 1 second

Network/Band

LTE Cat-M1/NB2: B1/B2/

B3/B4/B5/B8/B12/B13/B18/

B19/B20/B26/B28/B66

EGPRS:

GSM 850 MHz (max. 2W)

GSM 900 MHz (max. 2W)

DCS 1800 MHz (max. 1W)

PCS 1900 MHz (max. 1W)

GPS chip

MTK high sensitivity chip

GSM-/LTE-/GPRS-Modul

SIM7600E

GPS reception

-165dBm

Charger

110-290V, AC 50 Hz input 5V,

DC output

Storage

temperature

from -20°C to +50°C

Operating environment

from -10°C to +70°C

Air humidity

10%-70%

POWER Finder 4G by PAJ GPS V.1.0 US

1.9 Safety instructions

Signal words

The following signal words are used in this manual:

WARNING! This classifies a hazard of medium risk level. Failure

to comply with the warning may result in serious injury.

Please note: This is a warning about possible damage to

property.

Proper use

Please read the safety instructions for this model, POWER Finder

4G, hereinafter only referred to as GPS tracker, carefully before

use in order to be able to deploy it properly. The intended use is

to employ the GPS tracker only as described in this manual to

locate a vehicle. Please bear in mind that it is a criminal offence

to monitor third parties using a GPS tracker without their

consent. If you use it in any other way, this is considered

improper use and can lead to damage to property or even

personal injury. Please note that the GPS tracker is not a toy for

children.

Please be aware in other countries and regions there are

different laws on digital positioning and localization of people,

animals and/or objects. PAJ GPS is not responsible if such laws

or regulations are violated, this is the sole responsibility of the

user.

Please note: Please note that changes or modifications not

expressly approved by the party responsible for compliance

could void the user's authority to operate the equipment.

Please note: The manufacturer and dealer accept no liability

for damage caused by improper or incorrect use.
