Panasonic CF-VDM312U Bedienungsanleitung
E
D
F
J
Printed in Japan
HS0512-0
DFQW5658ZA
ENGLISH OPERATING INSTRUCTIONS
Introduction ....................................................5
Handling Precautions ....................................6
Using the Drive ..............................................8
Using the Software ......................................13
Troubleshooting ...........................................21
Specications ..............................................22
DEUTSCH BEDIENUNGSANLEITUNG
Einführung ...................................................24
Vorsichtsmaßnahmen zum Gebrauch .......25
Gebrauch des Laufwerks ............................27
Gebrauch von Software ..............................32
Störungsbehebung ......................................40
Technische Daten ........................................41
FRANÇAIS INSTRUCTIONS D’UTILISATION
Introduction ..................................................43
Précautions de manipulation .....................44
Utilisation du lecteur ...................................46
Utilisation du logiciel ..................................51
Dépannage ...................................................59
Spécications ..............................................60
保証書付き （日本国内向け）
61
62
63
65
70
78
79
80
• 取扱説明書をよくお読みのうえ、正しく安
全にお使いください。
62
• 保証書は「お買い上げ日・販売店名」など
の記入を確かめ、取扱説明書とともに大切
に保管してください。
DVD MULTI Drive Pack/DVD MULTI-Laufwerk-Pack/
Lecteur DVD MULTI/DVD MULTI
Model No./Modell-Nr./Numéro de modèle/ CF-VDM312U
DFQW5658ZA_CF-VDM312U_OI_EGFJ.indb 1 2012/05/23 13:21:51
2
CAUTION!
THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS, ADJUSTMENTS OR PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF.
REFER SERVICING TO QUALIFIED PERSONNEL.
12-E-1
WARNUNG!
DIESES PROUKT ERZEUGT LASERSTAHLUNG.
DURCHFÜHRUNG ANDERER VORGÄNGE ALS DER HIER ANGEGEBENEN
KANN ZU GEFÄHRLICHER STRAHLUNG FÜHREN.
REPARATUREN DÜRFEN NUR VON QUALIFIZIERTEM FACHPERSONAL
DURCHGEFÜHRT WERDEN.
12-G-1
AVERTISSEMENT!
CET APPAREIL UTILISE UN LASER.
L’UTILISATION DE COMMANDES OU DE RÉGLAGES OU L’EXÉCUTION DE
PROCÉDURES AUTRES QUE CELLES SPÉCIFIÉES ICI PEUVENT PROVOQUER
UNE EXPOSITION À DES RADIATIONS DANGEREUSES.
NE PAS OUVRIR LES COUVERCLES NI ESSAYER DE RÉPARER SOI-MÊME.
CONFIER TOUT TRAVAIL D’ENTRETIEN À UN PERSONNEL QUALIFIÉ.
12-F-1
CLASS 1 LASER PRODUCT
LASER KLASSE 1
DFQW5658ZA_CF-VDM312U_OI_EGFJ.indb 2 2012/05/23 13:21:51
3
For U.S.A.
Federal Communications Commission Radio Frequency Interference Statement
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equip-
ment generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communica-
tions. However, there is no guarantee that interference will not occur in a particular instal-
lation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiv-
er is connected.
Consult the Panasonic Service Center or an experienced radio/TV technician for help.
Warning
To assure continued compliance, use only shielded interface cables when connecting to a
computer or peripheral. Also, any changes or modications not expressly approved by the
party responsible for compliance could void the user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
This device is Class B verified to comply with Part 15 of FCC Rules when used with Pana-
sonic Notebook Computer.
Responsible Party: Panasonic Corporation of North America
One Panasonic Way
Secaucus, NJ 07094
Tel No:1-800-LAPTOP5 (1-800-527-8675)
6-M-1
DFQW5658ZA_CF-VDM312U_OI_EGFJ.indb 3 2012/05/23 13:21:51
4
<Read the “Notice for the products using LCD” in the Operating Instructions as follows.>
USA Only: This product has a uorescent lamp that contains mercury. Disposal may
be regulated in your community due to environmental considerations. For disposal
or recycling information, please visit Panasonic website: http://www.panasonic.com/
environmental or call 1-888-769-0149
65-M-1
<Other models>
USA Only: Disposal may be regulated in your community due to environmental
considerations. For disposal or recycling information, please visit Panasonic website:
http://www.panasonic.com/environmental or call 1-888-769-0149
65-M-2
For Canada
Canadian ICES-003
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
7-M-2
Models for Europe
Declaration of Conformity (DoC)
“Hereby, Panasonic declares that this DVD Multi Drive Pack is in
compliance with the essential requirements and other relevant provisions of
EU Council Directives.”
Authorised Representative:
Panasonic Testing Centre
Panasonic Marketing Europe GmbH
Winsbergring 15, 22525 Hamburg, Germany
18-E-0
Models for India
For the purpose of recycling to facilitate effective utilization of resources, please return
this product to a nearby authorized collection center, registered dismantler or recycler, or
Panasonic service center when disposing of this product.
Please see the Panasonic website for further information on collection centers, etc.
http://www.panasonic.co.in/wps/portal/home
DFQW5658ZA_CF-VDM312U_OI_EGFJ.indb 4 2012/05/23 13:21:51
5
E
Thank you for purchasing this Panasonic product*1.
This drive connects to the computer through the multimedia pocket.
Please read these instructions carefully before using this product, and save this manual for
future use.
*1 For information about the computer(s) for which the DVD MULTI Drive Pack can be used, refer
to the catalogs, etc.
Introduction
Microsoft® and Windows® are registered trademarks of Microsoft Corporation in the United States
and/or other countries.
Roxio Creator is a trademark or registered trademark of Corel Corporation in the United States and/
or other countries.
DVD MULTI Drive Pack ...............1 Operating Instructions
(This book) ................................... 1
DVD Drive Utility Disc*2 ...............1
NOTE
The DVD MULTI Drive Pack may also be referred to as the drive.
This manual explains the procedure for default settings. The procedure may differ
according to the settings.
: Page in these Operating Instructions or in the Reference Manual.
: Refers to the on-screen manuals.
*2
This contains the programs used to install “Roxio Creator
TM
LJB (hereafter, Roxio Creator LJB)”
and “PowerDVD
TM
(OEM Version) (hereafter, PowerDVD)”.
DFQW5658ZA_CF-VDM312U_OI_EGFJ.indb 5 2012/05/23 13:21:51
6
E
Handling Precautions
● Do not expose the drive to excessive smoke that may leave a residue, e.g., oil smoke, or
tobacco smoke. Doing so can shorten the life of the drive lens.
● We recommend cleaning the drive lens with an air puffer used for camera lenses.
(Do not use any spray-type of lens cleaning products.)
When opening/closing the tray
● When the computer is on, use the eject button ( page 8) or eject through Windows.
● When inserting or removing a disc, be careful not to touch the lens and other parts of the
laser pickup.
● Do not leave the tray open and do not touch the lens and other parts of the laser pickup.
The laser pickup and disc can become dusty in some conditions. It may cause
malfunction in reading or writing.
● Do not apply excessive force to the tray in the open position.
● Never insert a foreign object such as a paper clip into the drive.
Doing so may cause malfunction.
● Do not place items other than discs on the tray.
While the drive is being accessed
● Do not open the tray or move the computer while the drive is being accessed.
Doing so could cause the disc to shift position and this may damage the disc, or cause
the drive to malfunction.
In addition, after running an application involving access to a disc, close the application
before opening the tray or removing the disc.
Drive Handling Care
Do Not Look Into the Drive
Looking directly at the internal laser light source may result in damage to eyesight.
Do Not Use Discs That Are Cracked or Deformed
Because the discs rotate at high speeds, damaged discs may break apart causing injury.
● Discs that are not round and discs that have been repaired using adhesives are similarly
dangerous, and so should not be used.
DFQW5658ZA_CF-VDM312U_OI_EGFJ.indb 6 2012/05/23 13:21:51
7
E
● Before using a disc, carefully read the operating/handling instructions and package of
the disc.
● If the discs are not handled appropriately, they may become dirty or scratched.
Furthermore the writing speed may get slower and the data may not be correctly written
on or read from the disc. Other damage may cause a drive failure.
● Note the following precautions.
• Do not touch the disc surface (the side with no printing).
• Keep the disc surface clean and free from dirt, dust, ngerprints and scratches.
• Do not write on the surface of the disc with a ballpoint pen or other writing instrument.
• Do not attach stickers to discs.
• Do not drop, bend, or place heavy objects on top of discs.
• Do not place or store discs in locations exposed to heat, direct sunlight, humidity or dust.
• If a disc is brought from a cold to a warm location, condensation may form on the disc.
For read-only discs, wipe off the condensation using a soft, dry, lint-free cloth before
using the disc. For recordable/rewritable discs, wait until the condensation dries.
• When not using discs, keep them in their protective cases or cartridges.
To clean discs
How to hold a disc
<For read-only discs>
Wipe discs with a dry, soft cloth from
the center toward the edge.
If discs get very dirty, wipe with a
moist, soft cloth from the center toward the edge, then wipe again with a dry cloth to
take up remaining moisture.
<For recordable/rewritable discs>
Use the recordable/rewritable disc cleaner to clean these discs.
Do not use a cloth, CD cleaners or any other such cleaners under any circumstances.
Disc Handling Care
DFQW5658ZA_CF-VDM312U_OI_EGFJ.indb 7 2012/05/23 13:21:52
8
E
Using the Drive
For details on how to insert and remove the drive, refer to “Multimedia Pocket” in the
Reference Manual included with your computer.
Inserting/Removing the Drive
1 Turn on the computer.
2 Slide the latch (A) and open the cover.
3 Press the eject button (B) and slowly
pull out the tray.
4 Insert/Remove the disc.
To insert
Set the disc with the label side up and press the
center of the disc until it clicks in place.
To remove
Press on the center spindle (C) and carefully lift
up the edge of the disc.
5 Close the tray and the cover.
Do not press the eject button.
Setting a Disc
NOTE
To remove a disc when the computer is powered off, insert a pointed object (e.g.,
the bent-out tip of a paper clip) into the emergency hole (D). Pushing it to the end
allows the tray to come out.
If the vibration of the drive is excessive, check the disc.
For AutoPlay CD/DVD:
• If an AutoPlay CD
/DVD
does not start after the computer resumes from sleep
or hibernation, remove the disc from the drive and then reinsert it after waiting 15
seconds.
• An AutoPlay CD/DVD may start during le access depending on the status of the
disc.
When playing back video from a disc, playback may not be smooth in some conditions.
DFQW5658ZA_CF-VDM312U_OI_EGFJ.indb 8 2012/05/23 13:21:52
9
E
Power-saving Mode
If the drive is not accessed for 30 seconds, the drive motor will automatically be shut
down to reduce the power consumption. When the drive is accessed again, the drive motor
is turned on. In this case, reading of the disc data will take approximately 30 seconds.
DFQW5658ZA_CF-VDM312U_OI_EGFJ.indb 9 2012/05/23 13:21:52
10
E
Using the Drive
Information
NOTE
[Conrm Region] appears when the DVD-Video has only one region code and the
drive is set for another region code.
([Conrm Region] may not appear with some DVD-Video discs. To check the
current region code and the number of remaining times of changing the code, right-
click on the [CyberLink PowerDVD] screen and click [Settings...] - [Information].)
You can change the region code setting up to ve times including the initial setting.
Be extremely careful because you cannot change the region code anymore after the
fth change, even if you reinstalled the operating system.
Any problem resulting from illegal changing or altering of the region code is the
user’s responsibility.
CAUTION
To play DVD-Video or MPEG2 les, install the DVD playback software using “DVD
Drive Utility Disc” (included).
For information on how to install the software, refer to page 17.
Region Code Setting
DVD-Videos are allocated to region codes according to where they are sold. To play a
DVD-Video, the player’s software and the drive must have the corresponding region code.
e.g.,
For U.S.A. and Canada: “1”
For Europe: “2”
The region code of the drive is not set at purchase. The operation depends on the DVD-
Video that is rst played.
• DVD-Video with a specic region code:
The drive will automatically be set at the same region code as the DVD-Video.
• DVD-Video with multiple region codes:
[Conrm Region] appears. Select the region code and click [OK]. Play now begins.
DFQW5658ZA_CF-VDM312U_OI_EGFJ.indb 10 2012/05/23 13:21:52
Inhaltsverzeichnis
Sprachen:
Andere Panasonic DVD-Laufwerk Handbücher
Panasonic
Panasonic LF-D103E Bedienungsanleitung
Panasonic
Panasonic FZ-VDR551 Series Bedienungsanleitung
Panasonic
Panasonic LF-D102U Bedienungsanleitung
Panasonic
Panasonic CF-VDD711W Bedienungsanleitung
Panasonic
Panasonic SR-8588-B Bedienungsanleitung
Panasonic
Panasonic VW-BN1 - DVD-RW / DVD-RAM Drive Bedienungsanleitung
Panasonic
Panasonic CF-VDD272 Bedienungsanleitung
Panasonic
Panasonic CF-VDM311U Bedienungsanleitung
Panasonic
Panasonic CF-VDD372M Bedienungsanleitung
Panasonic
Panasonic CF-VDR301U Bedienungsanleitung
Panasonic
Panasonic SR-8587-B Bedienungsanleitung
Panasonic
Panasonic FZ-VDM551 Series Bedienungsanleitung
Panasonic
Panasonic CF-VDD271W Bedienungsanleitung
Panasonic
Panasonic CF-VDD285 Bedienungsanleitung
Panasonic
Panasonic CF-VDM302AT Bedienungsanleitung
Panasonic
Panasonic CF-VDR301U Bedienungsanleitung
Panasonic
Panasonic CF-VDD371M Bedienungsanleitung
Panasonic
Panasonic CF-VDM Series Bedienungsanleitung
Panasonic
Panasonic CF-VDD283 Bedienungsanleitung
Panasonic
Panasonic CF-VDRRT3W Bedienungsanleitung
