Facsimile

Operating Instructions

(For User Authentication)

Before operating this machine, please carefully read this manual, and keep this

documentation in a safe place for future reference.

English

Model No. UF-7950

UF-6950

General Description

Using Machine (for User)

Setting Machine

Appendix

The following trademarks and registered trademarks are used throughout this manual:

Microsoft, MS-DOS, Windows , Windows NT and Windows Server are either registered trademarks

or trademarks of Microsoft Corporation in the USA and other countries.

Microsoft product screen shot(s) reprinted with permission from Microsoft Corporation.

Adobe, Acrobat, Adobe Reader, PostScript and PostScript 3 are either registered trademarks or

trademarks of Adobe Systems Incorporated in the United States and/or other countries.

Captaris and RightFax are trademarks of Captaris, Inc.

All other product/brand names, trademarks or registered trademarks identied herein are the property

of their respective owners.

Unauthorized copying and distribution is a violation of law.

Published in Japan.

The contents of these Operating Instructions are subject to change without notice.

Table of Contents

General Description .......................................... 4

User Authentication .................................................................................... 4

Job Tracking............................................................................................... 5

RightFax Server ......................................................................................... 6

Using Machine (for User) .................................. 8

Sending a Document via RightFax............................................................. 10

Setting Machine ................................................ 12

Access Code Setting .................................................................................. 12

Authentication Setting ................................................................................ 13

Registration of Domain Name .................................................................... 16

ID Timeout Setting...................................................................................... 17

Auto Reset Time Setting ............................................................................ 18

Logon Attempts Setting .............................................................................. 19

Lockout Time Setting.................................................................................. 20

Authentication Method Setting ................................................................... 21

Job Tracking Setting................................................................................... 22

RightFax Server Setting ............................................................................. 24

Appendix............................................................ 26

Administrator Login .................................................................................... 26

Administrator Name & Password ............................................................... 27

Description of Job Tracking Notice............................................................. 28

General Description

User Authentication

The User Authentication works for the devices under the management of the Windows Server. As a result,

users must be authenticated before they can use the functions of the machine (copying, faxing, scanning, and

printing). The supported authentication protocol is NTLM v2.

Windows Server

Panasonic Device

User Name/Password

Authentication LAN

- Windows 2000 Server

- Windows Server 2003

- Windows NT Server 4.0 + Exchange Server 5.5 or late

Users

System administrator

The system administrator can manage user accounts by using the Windows Server.

User authentication can be set independently for each function (copying, faxing, scanning, and printing).

Users login to the Panasonic machine using their Windows account (user name and password).

NOTE

1. NTLM authentication is a user authentication protocol used in the Windows NT family of operating

systems.

NTLM uses a challenge/response method, and operates in such a way that the password is not

sent across the network in clear text. In Windows 2000, this protocol can also be used to maintain

compatibility between client and server.

2. This feature is available if the optional Network Scanner/Email/Internet Fax module (UE-404090)

is installed.

General Description

Windows

Server

System

Administrator

Panasonic Device

PSTN

LAN

Usage Log, and

Send-Receive Log

Job Tracking

While using User Authentication, it is also possible to use the Job Tracking function as well. The Job Tracking

function allows the system administrator to receive a machine usage log, and send/receive log via Email.

The Email to the administrator includes the name of the machine user, destination, and communication time,

together with the image of the document that was sent or received.

The following jobs are only tracked with this function.

1. Fax Transmission and Reception via PSTN.

2. Email Transmission to an Internet Fax, or a PC.

3. Reception from an Internet Fax, or a PC.

NOTE

1. When the Job Tracking function is enabled, the following functions are not available.

Manual Reception

On-Hook Dialing

Fax Forward (Fax Parameter No. 54)

For details, refer to the Operating Instructions for Facsimile and Copy Functions.

2. This feature is available if the optional Network Scanner/Email/Internet Fax module

(UE-404090) is installed.

(See page 28)

General Description

RightFax Server

By enabling the RightFax Server function, all the faxes will be sent via the RightFax Server. All the fax logs can

be easily be managed by a single server.

When using it with the User Authentication function, it will increase the security by controlling the usage and

identifying the users.

Windows Server Mail Server RightFax Server

Panasonic Device

Send image data with the Fax Number

POP receives

Fax content

PSTN

Send image data via PSTN

LAN

Check Fax logs

G3 Fax

Authenticate

When using User Authentications

The fax document to be sent is passed to the RightFax server via Email.

A user who sends a fax from a Panasonic machine can receive a send conrmation report on the PC from the

RightFax server.

NOTE

1. When the RightFax function is enabled, the following functions are not available.

Deferred Polling

Sub-Address Transmission

LAN Relay Transmission

Polling

Fax Cover Sheet

Direct Transmission

2. Requires RightFax Ver. 8.0 or later.

The document(s) is always stored into memory when sending the document(s).

For details, refer to the Operating Instructions for Facsimile and Copy Functions.

3. This feature is available if the optional Network Scanner/Email/Internet Fax module (UE-404090)

is installed.

General Description

Memo

Using Machine (for User)

Users must enter the login name and the password before using any device which has the User Authentication

function enabled. Authentication is performed using the user's Windows account.

A login prompt appears if user authentication is enabled. ENTER LOGIN NAME

MMM-DD-YYYY 16:30

00%

Standby Message

Note:

User authentication can be set independently for each function (copying,

faxing, scanning, and printing).

If user authentication is disabled for the fax function, the control panel displays

the standby message, and the login prompt only appears when a function that

requires authentication is selected.

Enter your user name, and then press

SET

. (Up to 40 characters)

The user name is NOT case-sensitive.

Ex: panasonic

Note:

Accepts following characters.

, & ( ) : ! / _ . - + % = ' " $ ; < > ? [ ] ^ ` { | } * # and alphanumeric characters

ENTER LOGIN NAME

panasonic

Note:

Accepts following characters.

, \ & ( ) : ! / _ . - + % = ' " $ ; < > ? [ ] ^ ` { | } * # and alphanumeric characters

Enter your password, and then press

SET

. (Up to 40 characters)

The password is case-sensitive.

Ex: pana

ENTER PASSWORD

***a

Press or to select the domain, and then press

SET

Ex: PANA01

SELECT DOMAIN

PANA01

Using Machine (for User)

MMM-DD-YYYY 16:30

00%

Note:

If the authentication fails, one of the following messages may appear.

This completes the authentication.

After completing the authentication, you can use the selected function

(copying, faxing, scanning, or printing) .

Message Explanation

Check your user name and password.

Check whether the Date and Time is set properly.

LOGON ATTEMPTS EXCEEDED The system has been locked because the permitted number of login

attempts has been exceeded. Please contact the system administrator.

CONNECTION FAILED Unable to connect to the authentication server. Please contact the system

administrator.

PROTOCOL ERROR Unable to connect to the authentication server. Please contact the system

administrator.

SERVER NOT FOUND Unable to locate the authentication server.

Check whether the DNS Domain Name is set properly (see page 16).

Check whether the Internet Parameters are set properly.

IP Address

Subnet Mask

Default Gateway IP Address

DNS Server Addresses

Authentication is cancelled if no operation is performed on the machine within a certain period of time after

authentication is completed. In this case, you need to perform user authentication again before you can use the

machine. The system administrator can specify the ID Timeout Period. See "ID Timeout Setting" on page 17 for

details.

The system administrator can specify whether authentication is required independently for each machine function

(copying, faxing, scanning, and printing). See "Authentication Setting" on page 13 for details.

Sending a Document via RightFax

When the RightFax server is used to send a fax, the following details are entered in the recipient (TO) eld, and

sender (FROM) eld.

Field Content

Recipient Station Name registered for One-Touch or ABBR. dialing. If manual number dialing is used, you

can enter the user name from the control panel.

Sender When the user authentication is not enabled

Logo and Email Address of this device.

Name and Email Address selected with the Sender Selection function.

When the user authentication is enabled

Name of the authenticated user registered with the Windows Server.

THEN PRESS START 00%

Note:

If you need to login, see "Login Procedure" on page 8 for details.

Specify the recipient.

Ex: 5551234

TEL. NO.

5551234

Note:

Quick Name Search dialing, One- Touch/ABBR. dialing, and Directory Search

dialing can be used to specify the recipient. For details, refer to the Operating

Instructions for Facsimile and Copy Functions.

Press

START

to starts scanning, and then sending the document. *STORE* NO. 001

PAGES=001 01%

When using manual number dialing, press

SET

instead of

START

to enter the recipient's name. (Up to 15 characters)

ENTER NAME

Enter the name, and then press

SET

. 1 STN(S) ARE SET

ADD MORE OR START

When you press

START

, the machine starts scanning, and then

sending the document.

*STORE* NO. 001

PAGES=001 01%

Using Machine (for User)

Andere Handbücher für UF-6950 - Panafax - Multifunction

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Panasonic Faxgerät Handbücher

Panasonic

Panasonic Panafax DX-800 Bedienungsanleitung

Panasonic

Panasonic KX-FLB756AL Bedienungsanleitung

Panasonic

Panasonic KX-FLM652CX Bedienungsanleitung

Panasonic

Panasonic KX-FLB851E Bedienungsanleitung

Panasonic

Panasonic KX-FM205 Bedienungsanleitung

Panasonic

Panasonic KX-FLM551 Bedienungsanleitung

Panasonic

Panasonic Panafax UF-140 Bedienungsanleitung

Panasonic

Panasonic KX-FT981CX-B Bedienungsanleitung

Panasonic

Panasonic KX-FP205AL Bedienungsanleitung

Panasonic

Panasonic KX-FM131AL Bedienungsanleitung

Panasonic

Panasonic KX-FPC141 Bedienungsanleitung

Panasonic

Panasonic KX-PW508DL Bedienungsanleitung

Panasonic

Panasonic Panafax UF-585 Bedienungsanleitung

Panasonic

Panasonic KX-FP300E Bedienungsanleitung

Panasonic

Panasonic KX-FP701LA Bedienungsanleitung

Panasonic

Panasonic KX-FL611BL Bedienungsanleitung

Panasonic

Panasonic Panafax UF-322 Bedienungsanleitung

Panasonic

Panasonic KX-FP205 Bedienungsanleitung

Panasonic

Panasonic KX-FL511 Bedienungsanleitung

Panasonic

Panasonic KXF160 - CONSUMER FACSIMILE Bedienungsanleitung

Panasonic

Panasonic KX-FC971CX-S Bedienungsanleitung

Panasonic

Panasonic KX-PW820DL Bedienungsanleitung

Panasonic

Panasonic KX-FP181E Bedienungsanleitung

Panasonic

Panasonic KX-PW301DL Bedienungsanleitung

Beliebte Faxgerät Handbücher anderer Marken

Samsung

Samsung SF-515 Bedienungsanleitung

Radio Shack

Radio Shack TFX-1031 Bedienungsanleitung

imagistics

imagistics 2030 Handbuch

Furuno

Furuno FAX-30 Bedienungsanleitung

Savin

Savin 3740 Handbuch

Sharp

Sharp FO-51 Bedienungsanleitung

Muratec

Muratec MFX-C3035 Bedienungsanleitung

Canon

Canon FAX-L400 Bedienungsanleitung

Ricoh

Ricoh 1000L Kurzanleitung

Sharp

Sharp FO-3150 Bedienungsanleitung

Kyocera

Kyocera KM-F1060 Bedienungsanleitung

Sharp

Sharp FO-2970M Bedienungsanleitung

Canon

Canon JX510P Bedienungsanleitung

Mita

Mita LDC-870 Handbuch

Brother

Brother MFC 640CW - Color Inkjet - All-in-One Bedienungsanleitung

Samsung

Samsung FX100 Handbuch

Sharp

Sharp MX-FXX1 Bedienungsanleitung

Develop

Develop ineo 25e Bedienungsanleitung
