Service Manual

TOP NEXT

OrderNo.MTV0308268C3

Colour Television

lTX-29PS62Z

GP3Chassis

Specification

PowerSourceACAuto110-240 V, 50/60 Hz

PowerConsumption129 W

Standby condition :2W

AerialTerminalImpedance :75 ,Coaxial type

TuningSystem FrequencySynthesizer

AutoSearchTuning

Pos:100 Positions

ReceivingSystem17Systems

Receiving ChannelsRegularTV

VHF BAND 2-12(PAL/SECAM B,K1)

0-12(PALBAUST.)

1-9(PALBN.Z.)

1-12(PAL/SECAM D)

1-12(NTSCMJapan)

2-13(NTSCMU.S.A)

UHF BAND 21-69(PALG,H,I/SECAM G,K,K1)

28-69(PALBAUST.)

13-57(PALD,K)

13-62(NTSCMJapan)

14-69(NTSCMU.S.A.)

CATVS1-S20(OSCAR)

1-125 (U.S.A.CATV)

C13-C49 (JAPAN)

S21-S41(HYPER)

Z1-Z37(CHINA)

Intermediate Frequency38.0MHz

Video31.5MHz(D,K)/32.5MHz(B,G)

32.0MHz(I)/32.5MHz(M)

Sound33.57MHz(PAL)/

Colour33.6MHz(SECAM)

34.42MHz(NTSC)/

33.75MHz(SECAM)

Receiving StereoSound SystemAVSTEREO

Video/Audio/TerminalsINS-VideoY:1.0Vp-p 75

AV1, 2, 3, 4DVD INS-VideoC:0.3Vp-p 75

Y/PB/PR(PhoneType)Y:1.0Vp-p75 PB,

PR:0.7Vp-p 75 Video1.0Vp-p

75 AudioApprox.400mV47K

Video1.0Vp-p 75

Monitor OutAudioApprox.400mV47K

High Voltage31.0±1.0Vat zero

beamcurrent

PictureTubeA68QCP83XA Type29 (68cm)

Measureddiagonally,

104°deflection

AudioOutput16Wspeaker

Dimensions(WxDxH)820 mm x500mmx566 mm

Weight(Mass)43.5kg(Net)

Note:

Specificationsaresubject tochangewithoutnotice.Mass and dimensionsshownareapproximate.

http://servis-manual.com/

4MarketModeFunction

TOP PREVIOUS NEXT

Outline:

MPUcontrolsthefunctionsswitchingforeachICsthroughIICbusinthischassis.Thefollowing

settingand adjustmentcanbeadjustedby remotecontrolinMarketMode.

1.Selection ofMarketMode

AdjusttheVOLUME“zero”and setOFF TIMERButton to30 min. Then,simultaneously

presstheRECALLButton on theremotecontroland theVOLUMEDOWNbutton -theTV

set.

2.Selection ofCHK Mode

CursormoveseachCHKModeby pressing“1”or“2”of10 keybutton on theremotecontrol.

3.PressSelf-CheckButton

Pressthevol.downbutton on frontpaneltogetherpresstheoff timerbutton on remote.

TOP PREVIOUS NEXT

9.6.2004file://C:\Documents%20and%20Settings\Admin\Plocha\TX-29PS62Z\s0400000000x.h...

http://servis-manual.com/

5.1BVOLTAGE

TOP PREVIOUS NEXT

Item/PreparationAdjustmentProcedure

1.OperatetheTVset.

2.Setcontrols:(MARKETMODECHK 2)

Bright............. Minimum

Contrast......... Minimum

Volume............. Minimum

1.Confirmthat theindicatedtestpointsfor thespecifiedvoltage:

TPA10:141 ±1.50V

TPA8:8±1.0V

TPA9:5±1.0V

TPA21:215 ±15V

9.6.2004file://C:\Documents%20and%20Settings\Admin\Plocha\TX-29PS62Z\s0501000000.htm

http://servis-manual.com/

5.2RF AGC

TOP PREVIOUS NEXT

Item/PreparationAdjustmentProcedure

1.Receiveacolourbarpattern.

2.Settheinputlevelto69(+1.2) db.

(75 opened)

3.SetRFAGCinCHK2.

1.SetRFAGCControlsuchastoprocedureasnowypicture.

2.SetRFAGCControlat thepointjustbeforethevoltageat AGC:TPA15beginstodrop.

3.Increasetheinputlevelby2dbandconfirmthatthevoltagechanges.

9.6.2004file://C:\Documents%20and%20Settings\Admin\Plocha\TX-29PS62Z\s0502000000.htm

http://servis-manual.com/

5.3HIGH VOLTAGE

TOP PREVIOUS NEXT

Item/PreparationAdjustmentProcedure

1.OperatetheTVset.

2.Receivethecrosshatchpattern.

3.Setto0Beam

(ScreenControl:min.CONTRAST:min)

1.Connect aDCvoltagemetertoD850 cathodeandconfirmthevoltageis141.0±2.0V.

2.Connect ahighvoltagemeter(ElectrostaticType)toananodeofthepicturetube.

3.Confirmthat thehighvoltageiswithintherangeof31.0±1.0V.

9.6.2004file://C:\Documents%20and%20Settings\Admin\Plocha\TX-29PS62Z\s0503000000.htm

http://servis-manual.com/

5.4SUBTINT

TOP PREVIOUS NEXT

Item/PreparationAdjustmentProcedure

1.Receivea3.58 MHzNTSCrainbowpattern

2.Connect oscilloscopetoA21pin6.

3.Setcontrols:

BRT................CENTER

COLOUR........CENTER

CONTRAST....MAX

NTSCTINT.....CENTER

AI....................OFF

1.AdjustSubNTSCTintsothat thepeakoflevel ofwaveformissimilartoFig.3

2.ReceivetheRainbowpattern (3.58MHzNTSC)on bothofMainandSubpictures.

3.AdjustSubNTSCTint2sothatthepeakoflevelof1.3±0.5V

9.6.2004file://C:\Documents%20and%20Settings\Admin\Plocha\TX-29PS62Z\s0504000000.htm

http://servis-manual.com/

5.5SUBCONTRAST

TOP PREVIOUS NEXT

Item/PreparationAdjustmentProcedure

1.Receiveacolourbarpattern.

2.Connect anoscilloscopetoTPA37or TPL2(GOUT).

3.Connect ashortjumpertoFBTpin3orTPA34andTPA5..

4.Setcontrols:

Picturemenu........ Dynamic Normal

AI............................. off

1.AdjustBrightColour:

Y=1.0±0.4Vp-p

2.AdjustSubContrastColour:

b=2.7±0.1Vp-p

9.6.2004file://C:\Documents%20and%20Settings\Admin\Plocha\TX-29PS62Z\s0505000000.htm

http://servis-manual.com/

5.6PALCOLOUR OUTPUT

TOP PREVIOUS NEXT

Item/PreparationAdjustmentProcedure

1.ReceivePALcolour barpattern.

2.Connect anoscilloscopeprobetoTPL2(GOUT).

3.Connect ashortjumpertoFBTpin3or TPA34andTPA5.

4.Setcontrol:

Picturemenu.....................DYNAMIC NORMAL

AI......................................off

1.AdjustBrightControl.

a=2.3±0.5Vp-p

2.AdjustSubColour control.

3.Connect theoscilloscopeprobetoTPA40.

4.Connect thewaveform.

b=2.4±0.5Vp-p

9.6.2004file://C:\Documents%20and%20Settings\Admin\Plocha\TX-29PS62Z\s0506000000.htm

http://servis-manual.com/

5.7NTSCCOLOUR OUTPUT

TOP PREVIOUS NEXT

Item/PreparationAdjustmentProcedure

1.Apply3.58MHzNTSCRainbowpattern.

2.Connect anoscilloscopetoTPA36or TPL1(ROUT).

3.CHK2andpressdigitkey“5”(AKBOFF).

4.Connect ashortjumpertoFBTpin3or TPA34andTPA5.

5.Setcontrol:

Picturemenu.......................DYNAMICCONTROL

Channel Colour Set...........STD

1.AdjustBrightControl.

a=2.3±0.2Vp-p

2.Connect thewaveform.

b=1.3±0.5Vp-p

BeforeColour Purity,Convergence andWhiteBalance adjustmentsareattempted,V.Center,V.Height,H.Width,H. CenterandFocusadjustmentsmustbe

completed.

9.6.2004file://C:\Documents%20and%20Settings\Admin\Plocha\TX-29PS62Z\s0507000000.htm

http://servis-manual.com/

5.8COLOUR PURITY

TOP PREVIOUS NEXT

1.SetBrightand Contrastcontrolstotheirmaximumpositions.

2.OperatetheTVsetover60 minutes.

3.Full degaussthepicturetubeby usinganexternaldegaussingcoil.ByrotatingR-Bstatic

convergencemagnet.

4.Applyacrosshatchpatternsignaland adjustroughlythestaticconvergencemagnets.

5.Applyagreenpatternsignal.

6.LoosenaclampscrewfortheDeflection Yokeand movetheDeflection Yokeasclosetothe

puritymagnetaspossible.

7.Adjustthepuritymagnetsothataverticalgreenfieldisobtainedatthecenterofthescreen.

8.SlowlypresstheDeflection Yokeand setit whereauniformgreenfieldisobtained.

9.AdjustroughlytheLowLightcontrolsand makesurethatauniformwhitefieldisobtained.

10.Tightentheclampscrew.

9.6.2004file://C:\Documents%20and%20Settings\Admin\Plocha\TX-29PS62Z\s0508000000.htm
