Programming Guide

32-Zone Wireless Transceiver Security Systems

MG5000 V3.2

MG5050 V3.2

5- to 32-Zone Expandable Security Systems

SP5500 V3.2

SP6000 V3.2

SP7000 V3.2

Always Armed,

Never Disarmed

1Programming Guide

MG5000 PCB Layout

Refer to Single Zone

Inputs on page 59

Refer to AC Power

& Backup Battery

Connections on

page 61.

For the keypad’s zone

configurations, refer to

the Installer Quick

Menu.IfEOLisenabled:

see section [706] option

[2]. Also refer to Keypad

Zone Connections on

page 59.

AUX Power

Refer to transformer requirements on page 61 for Aux.

Power Output. To connect additional wiring to auxiliary

power, use the red (+) and black (-) keypad connectors.

Auxiliary power will shut down ifcurrent exceeds 1.1A. If the

auxiliary output is overloaded and is shut down, you must

disconnect all loads from the output for at least 10 seconds

before reconnecting any load back to the auxiliary output.

To provide maximum lightning protection

we strongly recommend having separate

earth connections for the dialer and zone

ground terminals.

To metallic

enclosure

Ground

clamp

AWG#14 single

conductor solid

copper wire

Cold water

pipe

grounding

The "BELL" output will shutdown if

the current exceeds 3A.

Disconnect telephone

line before servicing.

Four pin connector

can be used for

quickinstallationofa

keypad.

Do not cut, bend or alter

the antennas and ensure

that electrical wires do

not cross over the

antennae, as this may

affect signal reception.

Paradox Memory Key

(PMC-4 PMC-5)

Antennas

"RX" & “TX” LED:

Flashes quickly when

receiving or transmitting RF signals

from wireless devices.

"STATUS" LED:

Flash once every second = Normal

Flashes ON 1 second and OFF 1 second =

Any trouble

Always ON = Panel is using phone line

Fast flash 6 seconds after power up = Installer

lock enabled

This equipment must be installed and maintained

by qualified service personnel only.

For UL and C-UL warnings, refer to the UL and

C-UL Warnings section at the back of the

Reference & Installation Manual.

Used for In-Field Firmware upgrade

through a 307USB Direct Connect

Interface. See Connecting to

WinLoad on page 62 for details.

EBUS and Dialer used with:

VDMP3 plug-in voice module for voice reporting

PCS100 GSM communicator module

Press and hold the RESET

button for five seconds. The

STATUS LED will start

flashing. Within 2 seconds

of this flashing, press the

reset switch again. The

panel will reset to default

and restart.

The sum of the

current drawn

from the BELL

and AUX must be

limited to 1.3A (40VA

transformer strongly

recommended).

Exceeding this limitwill

overload the panel

power supply and lead

to complete system

shutdown.

Connection for Self-Contained Bell/Siren

Max. amount of keypads = 15 keypads

Max. aux. current = 700 mA

Max. distance of keypad from panel = 76m (250 feet)

Max. total run of wire = 230m (750 feet)

Charge LED:

Charging and Battery test LED

* If EOL is enabled: see section

[706] option [2]. For the keypad’s

zone configurations, refer to

Installer Quick Menu on page 65.

Also refer to keypad zone

connections on page 59.

Magellan / Spectra SP 2

MG5050 PCB Layout

Used for In-Field Firmware upgrade

through a 307USB Direct Connect

Interface. See Connecting to

WinLoad on page 62 for details.

Antennas

Do not cut, bend or

alter the antennas and

ensure that electrical

wires do not cross

over the antennae, as

this may affect signal

reception.

Four pin connector can

be used for quick

installation of a keypad.

Refer to AC Power

& Backup Battery

Connections on

page 61.

Paradox Memory Key

(PMC-4, PMC-5)

LEDs

Charge LED:

Charging and battery test

LED

Status LED:

• Flash once everysecond=

Normal

• Flashes ON 1 second and

OFF 1 second = Any trou-

ble

• Always ON = Panel is

using phone line

• Fast flash 6 seconds after

power up = Installer lock

enabled

"RX" & “TX” LED:

Flashes quickly when

receiving or transmitting RF

signals from wireless

devices.

To metallic

enclosure

Ground

clamp

AWG#14 single

conductor solid

copper wire

Cold water

pipe

grounding

To provide maximum lightning

protection we strongly recommend

having separate earth connections

for the dialer and zone ground

terminals.

The "BELL" output will

shutdown if the current

exceeds 3A.

Refer to Single Zone

Inputs on page 59

Max. amount of keypads = 15 keypads

Max. aux. current = 700 mA

Max. distance of keypad from panel = 76m (250 feet)

Max. total run of wire = 230m (750 feet)

Disconnecttelephone

line before servicing.

AUX Power

Refer to transformer requirements on page 61 for Aux.

Power Output. To connect additional wiring to auxiliary

power, use the red (+) and black (-) keypad connectors.

Auxiliary power will shut down if currentexceeds 1.1A. If the

auxiliary output is overloaded and is shut down, you must

disconnect all loads from the output for at least 10 seconds

before reconnecting any load back to the auxiliary output.

This equipment must be installed and

maintained by qualified service personnel only.

For UL and C-UL warnings, refer to the UL and

C-UL Warnings section at the back of the

Reference & Installation Manual.

The sum of the

current drawn

from the BELL and AUX

must be limited to 1.3A

(40VA transformer

strongly recommended).

Exceeding this limit will

overload the panel power

supply and lead to

complete system

shutdown.

Connection for Self-Contained Bell/Siren

For the keypad’s zone

configurations, refer to

the Installer Quick

Menu. If EOL is

enabled: see section

[706] option [2]. Also

refer to Keypad Zone

Connections on

page 59.

Press and hold the

RESET button for five

seconds. The STATUS

LED will start flashing.

Within 2 seconds of

this flashing, press the

reset switch again. The

panel will reset to

default and restart.

* If EOL is enabled: see section

[706] option [2]. For the

keypad’s zone configurations,

refer to Installer Quick Menu on

page 65. Also refer to keypad

zone connections on page 59.

Solid-state PGM

(+/- trigger on

PGM4 only.

J3 and J4 used with:

VDMP3 plug-in voice module for

voice reporting

PCS100 GSM communicator

module

3Programming Guide

SP5500 PCB Layout

Four pin connector can be used

for quick installation of a SP5500

keypad.

Used for In-Field Firmware

upgrade through a 307USB Direct

Connect Interface. See Connecting

to WinLoad on page 62 for details.

Paradox Memory Key

(PMC-4, PMC5)

Refer to AC Power

& Backup Battery

Connections on

page 61.

The "BELL" output will

shutdown if the current

exceeds 3A.

AUX Power

Refer to transformer requirements on page 61 for

Aux. Power Output. To connect additional wiring to

auxiliary power, use the red (+) and black (-)

keypad connectors. Auxiliary power will shut down

if current exceeds 1.1A. If the auxiliary output is

overloaded and is shut down, you must

disconnect all loads from the output for at least 10

seconds before reconnecting any load back to the

auxiliary output.

This equipment must be installed and

maintained by qualified service

personnel only.

For UL and C-UL warnings, refer to

the UL and C-UL Warnings section at

the back of the Reference &

Installation Manual.

The sum of the current drawn

from the BELL and AUX must be

limited to 1.3A (40VA transformer

strongly recommended).

Exceeding this limit will overload

the panel power supply and lead

to complete system shutdown.

Connection for Self-Contained Bell/Siren

To provide maximum lightning

protection we strongly recommend

having separate earth connections

for the dialer and zone ground

terminals.

Max. amount of keypads = 15 keypads

Max. aux. current = 700 mA

Max. distance of keypad from panel = 76m (250 feet)

Max. total run of wire = 230m (750 feet)

Disconnecttelephone

line before servicing.

To metallic

enclosure Ground

clamp

AWG#14 single

conductor solid

copper wire

Cold water

pipe

grounding

For the keypad’s zone

configurations, refer to the

Installer Quick Menu. If EOL

is enabled: see section [706]

option [2]. Also refer to Keypad

Zone Connections on page 59.

Refer to Single Zone

Inputs on page 59

PGM +/- trigger not

supported by the

SP5500

Press and hold the RESET button

for five seconds. The STATUS LED

will start flashing. Within 2 seconds

of this flashing, press the reset

switch again. The panel will reset to

default and restart.

Charge LED:

Charging and battery test LED Status LED:

• Flash once every second = Normal

• Flashes ON 1 second and OFF 1 second = Any trouble

• Always ON = Panel is using phone line

• Fast flash 6 seconds after power up = Installer lock enabled

EBUS and Dialer used with:

VDMP3 plug-in voice module for voice reporting

PCS100 GSM communicator module

* If EOL is enabled: see

section [706] option [2].

For the keypad’s zone

configurations, refer to

Installer Quick Menu on

page 65. Also refer to

keypad zone

connections on page 59.

Magellan / Spectra SP 4

SP6000 PCB Layout

LEDs

Charge LED:

Charging and battery test LED

Status LED:

• Flash once every second = Normal

• Flashes ON 1 second and OFF 1 second = Any trouble

• Always ON = Panel is using phone line

• Fast flash 6 seconds after power up = Installer lock enabled Four pin connector can

be used for quick

installation of a keypad.

Used for In-Field Firmware

upgrade through a 307USB

Direct Connect Interface. See

Connecting to WinLoad on

page 62 for details.

Paradox Memory Key

(PMC-4, PMC-5)

Refer to AC Power

& Backup Battery

Connections on

page 61.

The "BELL" output will

shutdown if the current

exceeds 3A.

AUX Power

Refer to transformer requirements on page 61 for

Aux. Power Output. To connect additional wiring to

auxiliary power, use the red (+) and black (-)

keypad connectors. Auxiliary power will shut down

if current exceeds 1.1A. If the auxiliary output is

overloaded and is shut down, you must

disconnect all loads from the output for at least 10

seconds before reconnecting any load back to the

auxiliary output.

This equipment must be installed and

maintained by qualified service

personnel only.

For UL and C-UL warnings, refer to the

UL and C-UL Warnings section at the

back of the Reference & Installation

Manual.

The sum of the current drawn

from the BELL and AUX must be

limited to 1.3A (40VA transformer

strongly recommended).

Exceeding this limit will overload

the panel power supply and lead

to complete system shutdown.

Connection for Self-Contained Bell/Siren

To provide maximum lightning

protection we strongly recommend

having separate earth connections

for the dialer and zone ground

terminals.

Max. amount of keypads = 15 keypads

Max. aux. current = 700 mA

Max. distance of keypad from panel = 76m (250 feet)

Max. total run of wire = 230m (750 feet)

Disconnecttelephone

line before servicing.

To metallic

enclosure

Ground

clamp

AWG#14 single

conductor solid

copper wire

Cold water

pipe

grounding

For the keypad’s zone configurations, refer to the

Installer Quick Menu. If EOL is enabled: see

section [706] option [2]. Also refer to Keypad Zone

Connections on page 59.

Refer to Single Zone

Inputs on page 59

PGM Trigger: This

jumper allows you to

choose whether the solid

state relay PGMs are

grounded (-), or give out

12V (+).

Press and hold the

RESET button for five

seconds. The STATUS

LED will start flashing.

Within 2 seconds of

this flashing, press the

reset switch again. The

panel will reset to

default and restart.

When using an SP6000 panel in

conjunction with an RTX3, all K32

and K10V/H keypads must be

versions 2.0 or higher.

* If EOL is enabled: see

section [706] option [2].

For the keypad’s zone

configurations, refer to

Installer Quick Menu on

page 65. Also refer to

keypad zone

connections on page 59.

EBUS and Dialer used with:

VDMP3 plug-in voice module for voice reporting

PCS100 GSM communicator module

5Programming Guide

SP7000 PCB Layout

LEDs

Charge LED:

Charging and battery test LED

Status LED:

• Flash once every second = Normal

• Flashes ON 1 second and OFF 1 second = Any trouble

• Always ON = Panel is using phone line

• Fast flash 6 seconds after power up = Installer lock enabled Four pin connector can

be used for quick

installation of a keypad.

Used for In-Field Firmware

upgrade through a 307USB

Direct Connect Interface. See

Connecting to WinLoad on

page 62 for details.

Paradox Memory Key

(PMC-4, PMC-5)

Refer to AC Power

& Backup Battery

Connections on

page 61.

The "BELL" output will

shutdown if the current

exceeds 3A.

AUX Power

Refer to transformer requirements on page 61

for Aux. Power Output. To connect additional

wiring to auxiliary power, use the red (+) and

black (-) keypad connectors. Auxiliary power

will shut down if current exceeds 1.1A. If the

auxiliary output is overloaded and is shut down,

you must disconnect all loads from the output

for at least 10 seconds before reconnecting any

load back to the auxiliary output.

This equipment must be installed and

maintained by qualified service

personnel only.

For UL and C-UL warnings, refer to the

UL and C-UL Warnings section at the

back of the Reference & Installation

Manual.

The sum of the current drawn from

the BELL and AUX must be limited

to 1.3A (40VA transformer strongly

recommended). Exceeding this

limit will overload the panel power

supply and lead to complete

system shutdown.

Connection for Self-Contained Bell/Siren

To provide maximum lightning

protection we strongly recommend

having separate earth connections

for the dialer and zone ground

terminals.

Max. amount of keypads = 15 keypads

Max. aux. current = 700 mA

Max. distance of keypad from panel = 76m (250 feet)

Max. total run of wire = 230m (750 feet)

Disconnecttelephone

line before servicing.

To metallic

enclosure

Ground

clamp

AWG#14 single

conductor solid

copper wire

Cold water

pipe

grounding

For the keypad’s zone configurations, refer to the

Installer Quick Menu. If EOL is enabled: see

section [706] option [2]. Also refer to Keypad Zone

Connections on page 59.

Refer to Single Zone

Inputs on page 59

PGM Trigger: This jumper allows you

to choose whether the solid state

relay PGMs are grounded (-), or give

out 12V (+). Upper Inputs = Zones 9 to 16

Lower Inputs = Zones 1 to 8

Press and hold the RESET button for five seconds. The

STATUS LED will start flashing. Within 2 seconds of this

flashing, press the reset switch again. The panel will

reset to default and restart.

* If EOL is enabled: see

section [706] option [2].

For the keypad’s zone

configurations, refer to

Installer Quick Menu on

page 65. Also refer to

keypad zone

connections on page 59.

Z1 Z2 Z3 Z4 C Z5 Z6 Z7 Z8 C

Z9 Z10 Z11 Z12 C Z13 Z14 Z15 Z16 C

EBUS and Dialer used with:

VDMP3 plug-in voice module

for voice reporting

PCS100 GSM communicator

module

May be labeled

ADM2 on some

panels

Magellan / Spectra SP 6

Table of Contents

More detailed information can be found in the Reference & Installation Manual, which can be downloaded from our website

at paradox.com.

Renamed Products

Conventions

Entering Programming Mode

IMPORTANT: StayD Mode must be deactivated in order to enter programming mode. Press [OFF] + [CODE] + [OFF] to

deactivate StayD.

1. Press [ENTER].

2. Enter your [INSTALLER CODE](default: 000000) or [MAINTENANCE CODE](no default). [ARM] and [STAY] lights flash.

To modify codes, see System Codes on page 8.

3. Enter 3-digit [SECTION]you wish to program. [ARM] and [STAY] lights are ON.

4. Enter required [DATA].

New Product Codes Previous Product Codes New Product Codes Previous Product Codes

Keypads Door Contacts

K32RF MG32LRF DCT10 MG-DCT10

K32LCD MG32LCD DCTXP2 MG-DCTXP2

K32I MG32I DCT2 MG-DCT2

K32 MG32LED

K10V MG10LEDV Accessories

K10H MG10LEDH 2WPGM MG-2WPGM

RPT1 MG-RPT1

Remotes RTX3 MG-RTX3

REM2 / RAC2 MG-REM2 / MG-RAC2 PX8 MG-PX8

REM1 MG-REM1 ZX8SP SP-ZX8

RAC1 MG-RAC1 ZX8 APR-ZX8

PGM4 APR3-PGM4

Motion Detectors HUB2 APR3-HUB2

PMD1P MG-PMD1P

PMD75 MG-PMD75

PMD85 MG-PMD85

Warning or important information. Suggestion or reminder. Quick Menu (see page 65)

Table of Contents .......................................................... 6

Entering Programming Mode ........................................ 6

Codes and Panel Reset ................................................ 7

System Overview .......................................................... 7

User Programming ........................................................ 8

System Planning ......................................................... 13

Wireless Keypad Planning .......................................... 14

Wireless System Planning ........................................... 15

Daylight Savings Programming ................................... 21

Keypad Programming .................................................. 22

System Programming .................................................. 23

Other Settings and Modes ........................................... 25

Partition Programming ................................................. 25

Timers ......................................................................... 26

Communication Programming ..................................... 28

Programmable Output Programming .......................... 31

WinLoad and PCS100 Programming .......................... 39

Report Codes ...............................................................40

Ademco Contact ID Report Codes ..............................43

Automatic Report Code List .........................................45

Data Entry & Display ....................................................47

Trouble Display ............................................................48

Installer Function Keys .................................................48

Wireless Repeater Programming (RPT1) ....................49

Wireless Keypad Programming (K32RF / K32IRF) ......52

LCD Keypad Labels (K32LCD) ....................................54

Labels ..........................................................................57

Hardware Connections ................................................59

Connecting to WinLoad ................................................62

Updating Firmware Using WinLoad .............................62

Metal Box Installation ...................................................63

Installer Quick Menu ....................................................65

Index ............................................................................68

Default Settings: Options which are bold signify the default value:

e.g. Access code length: N6 digits 4 digits (4 digits is the default value).

7Programming Guide

Codes and Panel Reset

IMPORTANT: When using an SP Series panel, all wireless sections and options do not apply unless an RTX3 is used in

conjunction with the panel.

IMPORTANT: When using an SP6000 panel in conjunction with an RTX3, all K32 and K10V/H keypads must be versions

2.0 or higher.

IMPORTANT: The K32I Fixed LCD keypad module is only compatible with MG/SP panel version 2.30 and higher.

System Overview

Viewing Version Numbers

Installer Code (Default: 0000 / 000000) The Installer code is used to enter programming mode, which allows you to program everything

except user codes. To change the default code, go to section [397] on page 8 and refer to sec-

tion [701] option [1] on page 23.

Maintenance Code (No Default) The Maintenance code is used to enter programming mode, which allows you to

program everything except for user codes and communication settings (sections [395], [397],

[398], [815], [816], [817], [910], [911], [970], and [975]). To set the default code, go to section

[398] on page 8 and refer to section [701] option [1] on page 23.

System Master Code (Default: 1234 / 123456) The System Master code can use any arming method and can program user codes. To change

the default code, go to section [399] on page 8 and refer to section [701] option [1] on page 23.

Panel Reset Press and hold the RESET switch for five seconds. When the STATUS LED flashes, press the

RESET switch within 2 seconds. However, this will not clear a bus module trouble (see section

[955]). To reset the panel to default using section programming (see section [950]).

Module Description Maximum num-

ber per system Current

Consumption

K32RF, K32IRF 32-Zone Wireless Keypad Modules 8 total Wireless

K10V/H, K32,

K32LCD,

K32I,

K636

10 and 32-Zone Hardwired Keypad Module

15totalincluding

ZX8

and RTX3

K10V/H: Min. = 44mA / Max. = 72mA

K32: Min. = 49mA / Max. = 148mA

K32LCD: Min. = 43mA / Max. = 86mA

K32I: Min. = 30mA / Max. = 70mA

K636: Min. = 28mA / Max. = 33mA

ZX8

ZX8SP 8-Zone Expansion Module 3 Min. = 29mA / Max. = 31mA

RPT1 Magellan Wireless Repeater Module 2 Average = 57mA

VDMP3 Plug-In Voice Dialer 1 Min. = 28mA / Max. = 28mA

IP100 Internet Module 1 Min. = 90mA / Max. = 120mA

RTX3 Wireless Expansion Module (Spectra SP only) 1 Min. = 61mA / Max. = 143mA

PCS100 GSM Communicator Module 1 Min. = 400mA / Max. = 1A

Example: Version 01.42.

Digits 1-4

Step Action Details When Viewing Keypad Version

1 Enter Viewing Mode:

-For panel version, Enter section [980].

-For keypad version, Enter Installer Programming,

then press and hold [ARM].

The first digit is displayed

(usually “0”) Digit 1 D[ARM]is illuminated

2 Press [ENTER]The second digit is displayed. Digit 2 D[SLEEP]is illuminated

3 Press [ENTER]The third digit is displayed. Digit 3 D[STAY]is illuminated

4 Press [ENTER]The fourth digit is displayed. Digit 4 D[OFF]is illuminated

NOTE: K10V/H / K636 keypad version numbers cannot be viewed.

Andere Handbücher für MG5050

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Paradox Sicherheitssystem Handbücher

Paradox

Paradox Digiplex EVO Bedienungsanleitung

Paradox

Paradox MG5050+ Betriebsanleitung

Paradox

Paradox Esprit 727 Bedienungsanleitung

Paradox

Paradox SP5500 Bedienungsanleitung

Paradox

Paradox Esprit 738 EXPRESS Bedienungsanleitung

Paradox

Paradox Digiplex EVO DGP2-640 Bedienungsanleitung

Paradox

Paradox Magellan K636 Bedienungsanleitung

Paradox

Paradox 1686V Bedienungsanleitung

Paradox

Paradox K07C Bedienungsanleitung

Paradox

Paradox Magellan MG5050 EN Bedienungsanleitung

Paradox

Paradox MG5000 Bedienungsanleitung

Paradox

Paradox Digiplex EVO EVO48 Bedienungsanleitung

Paradox

Paradox Esprit 748ES Betriebsanleitung

Paradox

Paradox Esprit 748 Express Betriebsanleitung

Paradox

Paradox Magellan DCT2 Bedienungsanleitung

Paradox

Paradox 1686V Bedienungsanleitung

Paradox

Paradox SP5500+ Betriebsanleitung

Paradox

Paradox K656 Touch Sense Bedienungsanleitung

Paradox

Paradox SR120 Bedienungsanleitung

Paradox

Paradox STAY D MG5000 Bedienungsanleitung

Paradox

Paradox Marine Magel 6130 Bedienungsanleitung

Paradox

Paradox Paradox Bedienungsanleitung

Paradox

Paradox Digiplex NE DGP-NE96 Betriebsanleitung

Paradox

Paradox MG5000+ Bedienungsanleitung

Beliebte Sicherheitssystem Handbücher anderer Marken

Inner Range

Inner Range Concept 2000 Bedienungsanleitung

Climax

Climax Mobile Lite R32 Montageanleitung

CADDX

CADDX NX-6 Bedienungsanleitung

FBII

FBII XL-31 Series Bedienungsanleitung

Johnson Controls

Johnson Controls PENN Connected PC10 Bedienungsanleitung

Aeotec

Aeotec Siren Gen5 Bedienungsanleitung

Blaupunkt

Blaupunkt SA 2700 Bedienungsanleitung

IDEAL

IDEAL Accenta Betriebsanleitung

AJAX

AJAX DoubleButton Bedienungsanleitung

Swann

Swann SW-P-MC2 Bedienungsanleitung

Ecolink

Ecolink Siren+Chime Bedienungsanleitung

Digital Monitoring Products

Digital Monitoring Products XR150 Bedienungsanleitung

EDM

EDM Solution 6+6 Wireless-AE Bedienungsanleitung

Highway Safety Group

Highway Safety Group EA401 Bedienungsanleitung

Siren

Siren LED GSM Bedienungsanleitung

Detection Systems

Detection Systems 7090i Montageanleitung

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Bedienungsanleitung

Siemens

Siemens FDM273 Bedienungsanleitung
