Parkside PDSP 1000 A1 SANDBLASTER GUN Bedienungsanleitung

SANDBLASTER GUN PDSP 1000 A1

IAN 89572

SANDBLASTER GUN

Operation and Safety Notes

Translation of original operation manual

PAINEILMAKÄYTTÖINEN

HIEKKAPUHALLUSPISTOOLI

Käyttö- ja turvaohjeet

Alkuperäisen käyttöohjeen käännös

BLÄSTRINGSPISTOL, TRYCKLUFT

Bruksanvisning och säkerhetsanvisningar

Översättning av bruksanvisning i original

DRUCKLUFT-SANDSTRAHLPISTOLE

Bedienungs- und Sicherheitshinweise

Originalbetriebsanleitung

TRYKLUFT-SANDBLÆSERPISTOL

Brugs- og sikkerhedsanvisninger

Oversættelse af den originale driftsvejledning

GB/IE Operation and Safety Notes Page 5

FI Käyttö- ja turvaohjeet Sivu 15

SE Bruksanvisning och säkerhetsanvisningar Sidan 25

DK Brugs- og sikkerhedsanvisninger Side 35

DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 45

Before reading, unfold the page containing the illustrations and familiarise yourself with all

functions of the device.

Käännä ennen lukemista kuvallinen sivu esiin ja tutustu seuraavaksi laitteen kaikkiin toimintoihin.

Vik ut bildsidan och ha den till hands när du läser igenom anvisningarna och gör dig bekant

med apparatens/maskinens funktioner.

Før du læser, vend siden med billeder frem og bliv bekendt med alle apparatets funktioner.

Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend

mit allen Funktionen des Gerätes vertraut.

A EB

5GB/IE

Introduction

Proper use................................................................................ Page 6

Features and equipment......................................................... Page 6

Included items ......................................................................... Page 7

Technical data......................................................................... Page 7

Safety advice................................................................... Page 7

Operation

Connecting the compressed air source ................................. Page 9

Filling the blast medium container.......................................... Page 9

Using the sandblasting gun.................................................... Page 10

Cleaning ............................................................................... Page 11

Service................................................................................... Page 11

Warranty............................................................................. Page 11

Disposal................................................................................ Page 13

Declaration of Conformity/

Manufacturer................................................................... Page 13

Table of contents

6 GB/IE

Introduction

Sandblaster gun PDSP 1000 A1

Introduction

We congratulate you on the purchase of your new device. You have

chosen a high quality product. The instructions for use are part of the

product. They contain important information concerning safety, use and

disposal. Before using the product, please familiarise yourself with all

of the safety information and instructions for use. Only use the unit as

described and for the speciﬁed applications. If you pass the product

on to anyone else, please ensure that you also pass on all the docu-

mentation with it.

Proper use

This device is intended for the removal of rust and paint from metal

surfaces. Any other use or modiﬁcation to the device shall be considered

as improper use and could give rise to considerable risk of accident.

We will not accept liability for loss or damage arising from improper

use. The device is intended for private, domestic use only.

Features and equipment

1Sandblaster gun

2Trigger

3Plug-in nipple for compressed air connection

4Blast medium container

5Blast nozzle

Introduction/Safety advice

7GB/IE

Introduction

Introduction/Safety advice

Included items

1 Sandblaster gun PDSP 1000 A1

1 Operating instructions

Technical data

Max. Working pressure: 8bar

Recommended working air pressure: 3–5bar

Compressed air consumption: 130–260l/min

Nozzle ø: 2.8mm

Container capacity: 1000ml

Volume ﬂow rate: typically 200–220g/Min.

Required air quality: Cleaned and oil-free

Working settings: Working air pressure setting at

the pressure reducer max. 8bar.

Sound pressure level: 86dB(A)

Sound power level: 98dB(A)

Values determined in accordance with EN 14462 (EN1953/A1:2009).

Q Safety advice

Read all the safety advice

and instructions. Even minor failures to observe the

safety advice and instructions could lead to severe injury.

Keep all the safety advice and instructions in a safe

place for future reference.

8 GB/IE

Safety advice/Operation

Safety advice

Check the device for damage before bringing it into

use. Do not use the device if you discover any defects.

Keep children and other people away while you are

operating the sandblasting gun. Distractions can cause

you to lose control of the device.

RISK OF INJURY! IMPROPER USE! Never point the device

at people or animals.

For your own safety, wear suitable personal protec-

tive equipment.

Wear an approved dust mask/protective hood!

Wear protective glasses!

RISK OF EXPLOSION! Do not use the sandblasting gun 1in

environments containing gases, open flames, fires or gas-operated

water heaters.

NO SMOKING!

Work in adequately ventilated spaces only.

Never use oxygen or other combustible gas as the

energy source.

Never exceed the maximum working air pressure of 8bar.

RECOIL FORCES! High working pressures can

give rise to recoil forces that under certain conditions can result in

danger from continuous loading.

DANGER OF INJURY! Disconnect the device from the com

pressed

air source before carrying out any repairs or maintenance of the

device or moving it to another location.

DANGER OF INJURY! Disconnect the device from the com-

pressed air source before filling it with blast medium.

NOTE! Please observe the safety advice provided by the manu-

facturer of the blast medium.

Use only materials for the blast medium that are suit-

able for the sandblasting gun. Do not use quartz sand.

There is the danger of toxic silicon dust forming.

9GB/IE

Safety advice/Operation

Take precautions to ensure that other people are not

contaminated (dust generation).

Ensure that the spent blast medium is trapped and

collected so that it can be disposed of in an environ-

mentally compatible manner.

Do not remove rating plates or labels–they are safety-relevant

parts of the device.

If you are inexperienced in the use of this type of device, you should

seek out information or training to learn how to handle it safely.

Operation

Connecting the compressed air source

NOTE: Operate the sandblasting gun 1only with cleaned, conden-

sate- and oil-free compressed air and never exceed the maximum working

air pressure at the device of 8bar.

NOTE: The compressed air source must be ﬁtted with a (ﬁlter)/pressure

reducer so that the air pressure can be regulated.

Connect the sandblasting gun to a suitable compressed air source

by connecting the quick-release coupling of the air supply hose with

the plug-in nipple 3to the sandblasting gun 1. It locks itself in

place automatically.

Filling the blast medium container

Always use a suitable blast medium for your sand blasting work.

NOTE: We recommend using a silica-free blast medium

(e.g. ground blast furnace slag) with a grading of 0.2mm–0.8mm.

Safety advice

10 GB/IE

Operation/Cleaning/Service/Warranty

Operation

Ensure that the blast medium is completely dry and not too coarse.

NOTE: The maximum particle size is 0.8mm.

Turn the bayonet cap of the blast medium container 4to open it.

Pull the blast medium container 4oﬀ downwards.

Fill the blast medium container 4with the desired amount of

blast medium.

Ensure that the maximum capacity of the container (1000ml) is

not exceeded.

Screw the blast medium container 4back on and lock it in place

by inserting and turning it on to the container lid (see Figs. A).

Using the sandblasting gun

(see Figs. B, C)

Carefully prepare the workpiece before sand blasting it.

Clean it if necessary.

NOTE: Deposits of dust and grease can have a considerably

detrimental eﬀect on the result.

Carefully mask or tape oﬀ everything that is not to be sand blasted.

Ensure that there is always a minimum distance of 20cm between

the sandblasting gun 1and the surface being sand blasted.

Switching on:

Press the trigger 2to start operating the sandblasting gun 1.

Switching off:

Release the trigger 2to stop operating the sandblasting gun 1.

After you ﬁnish work, disconnect the device from the compressed

air source.

NOTE: First disconnect the hose from the compressed

air source and only then disconnect the compressed
