Patek Philippe CALIBER 31-260 PS QL Bedienungsanleitung

CALIBER 31-260 PS QL

INLINEPERPETUAL

CALENDAR

CALIBER 31-260 PS QL

English ........................ 3

Français ...................... 19

Deutsch ..................... 35

Italiano ........................ 51

Español .......................67

...................... 83

................... 99

.................. 115

CALIBER

 PSQL

IN-LINE PERPETUAL CALENDAR

English

CALIBER

 PSQL

IN-LINE PERPETUAL CALENDAR

English

The first Patek Philippe wristwatch with a fully

in-line perpetual calendar, your Reference 5236 is

notable for its display of the day, date and month

in a single large aperture at 12 o’clock. To combine

originality with legibility and reliability, the man

facture’s engineers developed a new self-winding

movement with a platinum mini-rotor and a separate

perpetual calendar module, the latter the subject

of three patent applications. The in-line display

mechanism alone, with its four rotating disks (two

these for the date), required 118 additional parts

compared

with a conventional perpetual calendar

display. Two

small round apertures for the leap-year

cycle and the day/night indicator complete the infor-

mation. The small seconds counter is positioned at

6 o’clock, along with an aperture for the moon phase.

And an aperture for the moon phase complete the

information. A new grand complication timepiece

claims its place in the long and illustrious history

of the Patek Philippe calendar watches.

DISPLAYS

Hour hand

Minute hand

Subsidiary dial:

Small seconds

Apertures:

Day of the week

Date

Month

Moon phases

Leap-year cycle

Day/night indication

CROWN

1Manual winding

2Setting the time

CORRECTION

PUSHPIECES

Day-of-week correction

Date correction

Month and year correction

Moon-phase correction

MOVEMENT

• Caliber 31-260 PS QL

• Self-winding

• In-line perpetual calendar

• Diameter: 34 mm

• Height: 5.8 mm

• Number of parts: 503

• Number of jewels: 55

• Power reserve:

min. 38 hours – max. 48 hours

• Winding rotor:

oﬀ-center mini-rotor in platinum,

unidirectional winding

• Balance: Gyromax®

• Frequency:

28,800 semi-oscillations/hour (4 Hz)

• Balance spring: Spiromax®

• Patek Philippe Seal

INSTRUCTIONS

8 9

SETTINGTHETIME

To set the time, gently pull the crown all the way

out and move the hands in either direction. Once

you have set the correct time, push the crown home

again. The day/night indicator allows you to verify

whether the time displayed by your watch is between

6 a.m. and 6 p.m. (white) or between 6 p.m. and

6 a.m. (blue). When you turn the hands clockwise

beyond midnight, the calendar displays will advance

as well. We advise against turning the hands coun-

terclockwise across midnight because this would

desynchronize the calendar displays; however, it

would not damage the calendar mechanism.

PERPETUALCALENDAR

The perpetual calendar indicates the day of the

week, the date, and the month, automatically taking

into account months with 28, 29, 30, and 31 days. It

switches directly from September 30 to October 1

or from February 28 to March 1. In leap years, it

also displays February 29 and then jumps directly

to March 1 at midnight. In addition to the date,

day, and month, the watch also features a leap-year

display. The moon-phase display is highly accurate:

it deviates from the true lunar cycle by merely one

day every 122 years. If the watch is wound daily,

the perpetual calendar will not require any manual

corrections before February 28, 2100; this is a

secular year that by exception omits February 29.

WINDINGCROWN

The winding crown is used to manually wind the

watch (position 1) and to set the time (position 2).

WINDING

Your watch incorporates a self-winding movement.

The movements of your wrist set an oscillating

weight in motion; this tensions the mainspring,

which stores the energy. When you take off your

fully wound watch, it will continue to run for at

least 38 hours. When it has stopped after deplet-

ing the power reserve, it can be rewound by hand

(about 10 clockwise turns of the crown).

Your complicated self-winding wristwatch was

presented to you in a case with a winder. If you do

not intend to wear your watch for a long period of

time, please return it to the case where the constant

motion of the winder will keep it wound. By using

the winder, you can eliminate the need to reset the

calendar when you put on your watch again.

1110

PREPARATIONS

1. If your watch has stopped running, rewind it by

hand before performing any corrections or adjust-

ments (about 10 clockwise turns of the crown).

2. You can be sure that performing adjustments is

safe if you first set your watch to 6 a.m.; observe

the color of the day/night indicator (white).

3. Make sure to set the date to the first day

of the month with the correction push piece at

10 o’clock.

DATECORRECTION

To set the date , actuate the correction push piece

10 o’clock as many times as needed to display

the current date.

Please wind the watch and set the time

before

you put the watch on. This prevents

lateral pressure on the winding stem. Please

use your fingernails to pull the crown out

and turn it gently between two fingertips.

Never pull out the crown in a humid envi-

ronment or underwater: the water resist-

ance of your watch is assured only when

the crown is pushed home.

Correction push pieces should be actuated

exclusively with the correction stylus that

was delivered with the watch. The use of

any other tool may damage your timepiece.

Do not perform any calendar or moon-phase

corrections between 4 p.m. and 1 a.m.

The calendar corrections must be performed

strictly in the order described below:

Move the hands to 6 a.m.

Set the date to the first day of the month

Correct the month and the leap-year cycle

Correct the date

Correct the day of the week

Correct the moon phase

Set the time

CAUTION

1312

MOONPHASE

CORRECTION

Each time the correction push piece between 8 and

9 o’clock is actuated, the moon-phase disk will

advance by one day. To begin the correction proce-

dure, advance the moon-phase disk until a full moon

is displayed in the middle of the aperture. Consult

an almanac or visit www.patek.com and count the

number of days that have elapsed since the last full

moon (relative to the current date). To set the correct

moon phase, press the correction push piece as many

times as the number of days that have elapsed since

the last full moon.

MONTHANDLEAPYEAR

CYCLECORRECTION

To simultaneously set these two displays and ,

actuate the correction push piece at 2 o’clock as

many times as needed to display the current month

and the current year (4 = leap year; 1 = 1st year after

leap year; 2 = 2nd year after leap year; 3 = 3rd year

after leap year). Visit www.patek.com to find the

current leap-year cycle.

DAYOFWEEKCORRECTION

To set the day of the week , actuate the correction

push piece between 9 and 10 o’clock as many times

as needed to display the current day.

MAINTENANCE

14 15

QUALITYCONTROL

The movements and completely assembled watches

are subject to a series of technical tests and visual

inspections to verify their rate accuracy, winding

speed, power reserve, reliability, water resistance,

and overall appearance. Once assembled, your self-

winding watch will run for several weeks before

leaving the workshops; it fully complies with the

stringent criteria of the Patek Philippe Seal.

ACCURACY

The rate accuracy of Patek Philippe watches is ver-

ified in several phases of manufacturing, both with

uncased and fully cased movements. The final test

is performed with a wrist motion simulator and

the results must conform to the following Patek

Philippe precision benchmarks:

The rate accuracy of calibers with a diameter of 20 mm

or larger must range within -3 and +2 seconds per

24 hours.

The precision of a watch is determined by how accu-

rately it keeps the time. A watch that is fast or slow

is considered precise if the amount by which it is

fast or slow remains constant. Such a deviation can

be easily corrected. Consequently, the final test of

accuracy takes place on your wrist. Your move-

ments and the nature of your physical activities may

cause slight irregularities. Fluctuations in position,

temperature, or air pressure, the presence of mag-

netic fields (as produced by most electronic devices,

metal detectors, household appliances, etc.) as well

as vibrations and other factors may also affect its

accuracy. If you notice that your watch exhibits

CERTIFICATEOFORIGIN

Your watch is delivered with a certificate of origin

that indicates the movement and case numbers. The

certificate is valid only if it is dated, signed by an

Authorized Patek Philippe Retailer, and completed

with your name. It guarantees the authenticity of

your watch and validates your warranty privileges

for a period of two years after the date of sale. The

unique movement and case numbers of each watch

are transcribed into the Manufacture journals. With

this information, you may have yourself entered

the Patek Philippe Register of Owners and will

obtain the International Patek Philippe Magazine free

of charge.

PATEKPHILIPPESEAL

As an all-encompassing hallmark of quality,

the Patek Philippe Seal applies to the entire

watch, including the movement, case, dial,

hands, pushers, strap, and clasp as well as to all other

facets that contribute to the precision and aesthetic

perfection of the timepiece. It covers the technical,

functional, and aesthetic factors, but also rate accu-

racy, dependability, and customer service quality.

Additionally, it reflects the maker’s know-how and

all other assets needed for the development, produc-

tion, and long-term maintenance of an extraordinary

timekeeping instrument.

1716

SERVICE

We recommend that you have your watch serviced

every three to five years. With this in mind, we

suggest that you take or send your watch to an

Authorized Patek Philippe Retailer or an Author-

ized Service Center. This gives you the insurance

that your watch will be entrusted to the hands of

a qualified Patek Philippe watchmaker in Geneva

or at an Authorized Service Center.

The watchmaker will completely disassemble the

movement and then inspect, clean, and lubricate

all of the individual parts prior to reassembly. All

functions of the watch will also be tested in detail

and the escapement regulated if necessary. Finally,

its rate accuracy will be monitored and precision-

adjusted for a further period of two weeks. The

entire process may take several weeks because each

watch must undergo a complete series of tests to

fulfill the strict quality criteria of Patek Philippe.

If you have any questions regarding the maintenance

of your watch or need the address of your closest

Authorized Patek Philippe Service Center, contact our

International Customer Service Department in Geneva,

or visit www.patek.com.

such irregularities, please do not hesitate to take

it to an Authorized Patek Philippe Retailer or an

Authorized Service Center where no effort will be

spared to assure that it is adjusted to meet your

expectations.

WATERRESISTANCE

Your watch is fitted with different types of seals

to protect the movement against the ingress of

dust and moisture and to prevent damage if it is

immersed in water. Nonetheless, we recommend

that you prevent direct contact with water if your

watch has a leather strap.

It is advisable to have a water-resistance test car-

ried out every year on your watch. This is a simple

procedure that takes only a few minutes at a prop-

erly equipped point of sale.

CHANGINGTHECASEBACK

If your watch was delivered with two interchangea-

ble case backs, please note that only an Authorized

Patek Philippe Retailer or an Authorized Service

Center is qualified to exchange the case backs.

Inhaltsverzeichnis

Sprachen:

Andere Patek Philippe Betrachten Handbücher

Patek Philippe

Patek Philippe 5178G Bedienungsanleitung

Patek Philippe

Patek Philippe 5073 Caliber R 27 Q Bedienungsanleitung

Patek Philippe

Patek Philippe 7059 Bedienungsanleitung

Patek Philippe

Patek Philippe CALIBER 28-20 REC 8J PS IRM C J Bedienungsanleitung

Patek Philippe

Patek Philippe 240 Q Bedienungsanleitung

Patek Philippe

Patek Philippe 6301 Bedienungsanleitung

Patek Philippe

Patek Philippe 5374 Caliber R 27 Q Bedienungsanleitung

Patek Philippe

Patek Philippe World Time Chronograph Bedienungsanleitung

Patek Philippe

Patek Philippe 24H-HOUR DISPLAY TRAVEL TIME Bedienungsanleitung

Patek Philippe

Patek Philippe Grandmaster Chime 6300 Bedienungsanleitung

Patek Philippe

Patek Philippe 5178 Bedienungsanleitung

Patek Philippe

Patek Philippe CALIBER 324 S QA LU 24H/303 Bedienungsanleitung

Patek Philippe

Patek Philippe 5216 Bedienungsanleitung

Patek Philippe

Patek Philippe 324 S Q Bedienungsanleitung

Patek Philippe

Patek Philippe 5539 Bedienungsanleitung

Patek Philippe

Patek Philippe Reference 6102 Bedienungsanleitung

Patek Philippe

Patek Philippe ALIBER 324 S QA LU 24H Bedienungsanleitung

Patek Philippe

Patek Philippe 5520 Bedienungsanleitung

Patek Philippe

Patek Philippe 5531 Bedienungsanleitung

Patek Philippe

Patek Philippe Calatrava Pilot Travel Time Bedienungsanleitung

Patek Philippe

Patek Philippe CH 29-535 PS Q Bedienungsanleitung

Patek Philippe

Patek Philippe P2414 Bedienungsanleitung

Patek Philippe

Patek Philippe Sky Moon Tourbillon Bedienungsanleitung

Patek Philippe

Patek Philippe 5207 Bedienungsanleitung

Beliebte Betrachten Handbücher anderer Marken

Pandora

Pandora WATCH2 Bedienungsanleitung

Casio

Casio QW-4343 Bedienungsanleitung

Suunto

Suunto X6 Bedienungsanleitung

Seiko

Seiko N830 Bedienungsanleitung

MotionX

MotionX 365 Bedienungsanleitung

Garmin

Garmin VENU SQ 2 Bedienungsanleitung

QCY

QCY Watch GTC Bedienungsanleitung

Canyon

Canyon Cindy CNE-KW41WP Bedienungsanleitung

Esq

Esq Watches Installationsanleitung

Crane

Crane AA5-CDSM-3A Bedienungsanleitung

Timex

Timex W-214 Bedienungsanleitung

DETOMASO

DETOMASO MATERA Bedienungsanleitung

Geemarc

Geemarc Watch N Shake Bedienungsanleitung

LORUS

LORUS W590 Bedienungsanleitung

STENLILLE

STENLILLE Actío Bedienungsanleitung

Casio

Casio 5594 Bedienungsanleitung

Sinn

Sinn HUNTER'S WATCH 3. Edition Bedienungsanleitung

Slazenger

Slazenger SLZ800 Bedienungsanleitung
