Peak Brado Bedienungsanleitung

1. Ergonomic Grips

2. Brake Lever

3. Seating area with drawstring

4. Hook for bag

5. Locking screw for Height Adjustment

6. Kerb Climbing Assistance

7. Brakes

8. Wheel

Brado Rollator Parts

The Brado –simple and user-friendly

Up / unfold 1. rollator

Place the rollator in the direction of travel and actuate the parking break.

Print with both hands the side tubes of the seat surface left and right

down to the folding mechanism locks into place.

Only then mesh pocket, bag or basket in the throw holder provided

hang.

2. Adjust handle Height

Solve urn set screw 5-6 turns (the screw must not be out completely)

and set the desired height by pushing in or pulling the push handles.

The push handles latch into increments of 25 mm.

Turn the locking screw again. The locking screw must not be

tightened between the predetermined locking positions. After

tightening, the screw can be accommodated by pulling in a

vertical position, thereby interfering less.

between the predetermined locking positions. After tightening the

3. Brake

Service Brake (when pushing): Pull the lever up.

Fasten the break (for parking): You push the lever down.

4. Brake Adjustment

The brake is correctly adjusted, even if the brake levers like those

Bowden cables a play do not exhibit themselves and the wheels without

sharpening noises to turn leave.

The braking action can be set using the adjusting screw of the

Bowden cable to the brake pads the rear wheels.

5. Climbing

Raising the steering wheels is relieved by applying pressure with the toe

the prolonged so frame.

The Brado –simple and user-friendly

6. Fold Walker

Take the mesh pocket or bag on the frame.

Pull the locking band in the center of the seating surface upward -

the rollator folds together.

Safety

Do not hang Pockets on the handles - Tipping!

Use on downhill because the service brake (Pull the lever up).

Use the rollator on firm, level ground.

If too much lean on the handles of the walker from tipping

backwards.

When folding the walker clothing and body parts can be clamped.

Please note that padded parts that are exposed to direct

sunlight, heat up and can cause skin injuries in tubing.

Therefore, cover these parts or protect the rollator from

sunlight.

Cleaning / maintenance / re-use

Maintenance

The walker brado is maintenance free. If you notice a decrease in

the brakes, the wheels binding or other functional limitations, then

bring the walker to be serviced by your local dealer.

Re-use

Please keep in mind when passing the walker to the new user,

necessary for safe handling technical documentation to upper

Enter. The rollator must by retailers - as above - checked, cleaned

and re-use for in perfect condition be added.

Cleaning

Cleaning and disinfection must in regular distances traveled by.

Use soapy water without abrasive additives.

The disinfection You can drove through with commercial

means. Use no Steam jet devices and abrasive or caustic

cleaning agents.

Technical Data

Type S / M

Type S

Type M

High:

67-82 cm

78-102 cm

High folded:

67 cm

78 cm

Seat height:

52.5 cm

62.5 cm

Height adjustment of the push

handles in 25 mm steps:

0-15 cm

0-24 cm

Frame High adjustable:

8 times

10 times

Lange:

66 cm

Width:

60 cm

Width folded:

22 cm

. Max user weight:

150 kg

Max. Load net / bag:

5 kg

Net weight:

7.1 kg

Tires (puncture proof):

20 x 3 cm

Type S / M

Type S

Type M

High:

67-82 cm

78-102 cm

High folded:

67 cm

78 cm

Seat height:

52.5 cm

62.5 cm

Height adjustment of the push

handles in 25 mm steps:

0-15 cm

0-24 cm

Frame High adjustable:

8 times

10 times

Lange:

66 cm

Width:

60 cm

Width folded:

22 cm

. Max user weight:

150 kg

Max. Load net / bag:

5 kg

Net weight:

7.1 kg

Tires (puncture proof):

20 x 3 cm

3/10

The Brado –simple and user-friendly

Scope of Delivery

- Rollatorbrado

- Mesh pocket

- Instruction Warranty

- Card

Guarantee

The warranty period is 5 years on the aluminum frame, for all

remaining portions 24 months.

Worn parts are excluded from the Guarantee.

General

For the here described Rollator is the conformity according to

the EC Directive 93/42 for medical devices explained.

This manual is part of the delivery. They must be ready for the user

and will continue to pass the product with the product.

Changes due to technical advancements against over the in this

Instructions versions described above, we reserve ourselves.

Reproduction, translation and reproduction in any Form, even in

part, require the written consent of the manufacturer.

These instructions can be no changes approximation service. For

current information, please check with us.

Indications and Usage

The hinged under the seat surface mesh pocket is provided for

transporting objects and goods. Please do not rely on the mesh

pocket.

The walker brado may only be used on firm, level ground. The use for

other purposes, especially the use as Uphill or Transporting heavy loads

is improper and dangerous!

The walker brado serves limited mobility people with max.150 kg

body weight as a walking aid and limited Seating for of transient

resting.

3/10 Tannery St

Unanderra NSW 2625

Australia

Tel: +61 2 4272 2688. Fax: +61 2 4272 2699

www.peak-care.com.au
