Peavey 22 Bedienungsanleitung

Diaphragm type:

Diamond coated

Element type:

Dynamic

Magnet composition:

Neodymium iron boron

Pick up pattern:

Cardioid

Front-to-back rejection:

20 dB (typical)

Impedance:

400 ohms, balanced

Frequency response:

50 Hz to 16 kHz

Sensitivity (at 1 kHz open

circuit voltage):

-48 dBV/Pa (1 Pa = 94 dB SPL)

Maximum:

SPL 140 dB

Case (housing):

Die-cast zinc

Finish:

Black rubberized paint

Pop filter:

Dual, integral, open-cell foam

Phasing:

Positive (inward) pressure on

diaphragm produces positive

voltage at Pin #2

Weight:

9.92 oz. (281 g)

Features:

• Diamond-coated

diaphragm

• Cardioid polar response

• Neodymium magnetic

• Smooth, accurate

frequency response

• Ultra-high sensitivity

Description

Thank you for choosing the

Peavey PVM 22 diamond-

coated microphone. The PVM

22 is dynamic cardioid and

incorporates a neodymium

magnet—which has more

than twice the sensitivity of

conventional microphones—

and our diamond-coated

diaphragm for flawless

transient and frequency

response. The cardioid

polar response is one of the

most popular patterns in

the industry, giving the user

the freedom of movement

within the frontal lobe while

maintaining a relatively

consistent sound. The rear

rejection of the PVM 22 is

typically 20 dB less sensitive

than the on-axis response. This

helps reduce feedback from

stage monitors and background

noise. The cardioid pattern

also works well when trying to

get a good sound on acoustic

instruments.

The Amorphous Diamond-

Coated Diaphragm is a

patented technology that coats

the diaphragm with a super-

thin layer of diamond, which

offers many advantages over

conventional laminating or

other coating materials. Mainly,

it improves the stiffness of the

large diaphragm. In return, it

keeps the diaphragm super stiff

but ultra light, which is needed

for extended high-frequency

response and sharp, crisp

highs.

SPECIFICATIONS PVM™22

The most significant advances in the microphone

industry have been made through the utilization of high-

tech polymers. We are proud to say that we are always

at the forefront of this technology by utilizing the latest

designs. By doing so, we have developed a new shock

mounting system that reduces handling noise, cable

noise and noise picked up by the mic stand.

By combining the latest in technologies, performance,

styling and durability, the Peavey PVM 22 microphone

is the professionals choice for the sound reinforcement

industry.

ARCHITECTURAL & ENGINEERING

SPECIFICATIONS

The microphone shall be a moving-coil dynamic

with a frequency response of 50 Hz to 16 kHz. The

microphone shall have a cardioid characteristic

typically 20 dB down from the front response. The

microphone shall have an output of -48 dBV per

Pascal where 1 Pascal = 94 dB of SPL with no load

(open circuit).

The microphone shall have a black rubberized

finish that can withstand the toughest conditions.

The microphone uses a standard mic clip for stand

mounting. The connector shall be a three-pin XLR

equivalent audio type.

PROXIMITY

Proximity effect is a naturally occurring phenomenon in

unidirectional microphones. The effect is to accentuate

or boost the low frequency response. This effect is a

function of distance from the diaphragm to the source

and increases as the diaphragm is moved closer to the

source.

2-YEAR LIMITED WARRANTY

NOTE: For details, refer to the warranty statement. For

copies of this statement, contact Peavey Electronics

Corporation, at P.O. Box 2898, Meridian, Mississippi

39301-2898, or go online to www.peavey.com.

Frequency Response

13/16"

2 1/4"

6 3/8"

SPECIFICATIONS PVM™22

Pickup Patterns

(5 dB per division)

Features and specifications subject to change without notice.

Peavey Electronics Corporation • 5022 Hartley Peavey Drive • Meridian, MS 39305 • (601) 483-5365 • FAX (601) 486-1278

Logo referenced in Directive 2002/96/EC Annex IV

(OJ(L)37/38,13.02.03 and defined in EN 50419: 2005

The bar is the symbol for marking of new waste and

is applied only to equipment manufactured after

13 August 2005
