Pela tools LD-E04200 Bedienungsanleitung

Engine load leveler

Lyftok till motorlyft

Item No:

68244

Kontaktinformation

Verktygsboden Erlux AB

Källbäcksrydsgatan 1

SE-507 42 Borås

Telefon: 033-202650

Mejl: [email protected]

Miljöskydd/Skrotning

Återvinn oönskat material, släng

det inte bland hushållssoporna. Alla

maskiner, tillbehör och förpackningar

skall sorteras och lämnas till en

återvinningscentral och där kasseras

på ett miljövänligt sätt.

Viktigt

Ha kvar bruksanvisningen och kvittot på en säker

och torr plats för framtida referens.

Maximal belastning: 680 KG

Nr Beskrivning Antal

1 Tvärstång 1

2Fjädrar 2

3 Bult M10x30 4

4Nylon mutter M10 4

5Gängad stång 1

6 Mutter 2

7Spärrstift 2

8Justeringsmutter 1

9Bricka 1

10 Bult M12x45 1

Nr Beskrivning Antal

11 Upphängningsplatta 2

12 Ytterhylsa 1

13 Inrehylsa 1

14 Nylon mutter M12 2

15 Bult M12x40 1

16 Bricka 1

17 Kedja 1

18 Fäste 1

19 Fäste 1

20 Kedjesamling 4

Sprängskiss

Environmental protection/

Scrapping

Recycle any unwanted material,

do not throw it in the household

rubbish. All machines, accessories

and packaging must be sorted and left

at a recycling center and disposed

of in an environmentally friendly

manner.

Contact

PELA Tools

Solängsvägen 13

SE-513 70 Borås

Phone: 033-202650

E-mail: [email protected]

Important

Keep the instructions manual in a safe place for

future reference.

Maximum load: 680 KG

Part no. Description OTY

1 Cross bar 1

2Spring hanger 2

3 Bolt M10x30 4

4Nylon Nut M10 4

5Threaded Rod 1

6 Nut 2

7Cotter pin 2

8Adjustment nut 1

9Spacer 1

10 Bolt M12x45 1

Part no. Description OTY

11 Hangning plate 2

12 Outer sleeve 1

13 Inner sleeve 1

14 Nylon nut M12 2

15 Bolt M12x40 1

16 Spacer 1

17 Chain 1

18 Rigging 1

19 Rigging 1

20 Chain assembly 4

Exploded view

EU Declaration of Conformity

2006/42/EC (MD)

ORIGINAL Declaration of conformity

We, the manufacturer

Company: Verktygsboden Erfilux AB

Address: Källbäcksrydsgatan 1, SE-507 42 Borås, Sweden

Telephone number: +46-33-2026 53

Declare under our sole responsibility that the product

Machine: 2000Lb load Leveler

Type designation: LD-E04200

Item number: 68244

fulfils all relevant provisions of the 2006/42/EC (MD).

To show compliance with the above Directives the following harmonized standards have been

applied:

Standards:

EN 1494:2000+A1:2008 EN ISO 12100:2010

Notified body: Alberka QA Uluslararasi Teknik

Certificate number: QA-AC-3231/17

This product was CE marked year: 2020

Person authorized to compile the technical file:

Namn: Lars Edwardsson

Adress: Källbäcksrydsgatan 1, SE-507 42 Borås, Sweden

This declaration relates to the machinery in the state in which it was placed on the market, and

excludes components which are added and/or operations carried out subsequently by the final user.

City and Country: Borås, Sverige Date: 31/08/2020

……………………………………………………………………

Name: Ted Berglund

Position: Purchasing coordinator

Verktygsboden Erlux AB Källbäcksrydsgatan 1, SE-507 42 Borås
