Pelonis HO-0203D Bedienungsanleitung

OWNER’S MANUAL

Convection

Oil Filled

Radiator

Heater

Model HO-0203D

PLEASE READ AND SAVE THESE INSTRUCTIONS

IMPORTANT INSTRUCTIONS

PLEASE READ AND SAVE THESE IMPORTANT SAFETY INSTRUCTIONS

When using electrical appliances, basic precautions should always be followed to reduce

the risk of fire, electric shock, and injury to persons, including the following:

1. Read all instructions before using this heater.

2. This heater is hot when in use

. To avoid burns, do not let bare skin touch hot surfaces.

If provided, use handles when moving this heater. Keep combustible materials, such

as furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9m) from

the front of the heater and keep them away from the sides and rear.

3. Extreme caution is necessary when any heater is used by or near children or invalids

and whenever the heater is left operating and unattended.

4. Always unplug heater when not in use.

5. Do not operate any heater with a damaged cord or plug or after the heater

malfunctions, has been dropped or damaged in any manner. Return heater to

authorized service facility for examination, electrical or mechanical adjustment, or

repair.

6. Do not use outdoors.

7. This heater is not intended for use in bathrooms, laundry areas and similar indoor

locations. Never locate heater where it may fall into bathtub or other water container.

8. Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar

coverings. Arrange cord away from traffic area and where it will not be tripped over.

9. To disconnect heater, first turn controls to off, then remove plug from outlet.

10. Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this

may cause an electric shock or fire, or damage the heater.

11. To prevent a possible fire, do not block air intakes or exhaust in any manner. Do not

use on soft surfaces, like a bed, where openings may become blocked.

12. A heater has hot and arcing or sparking parts inside. Do not use it in the areas where

gasoline, paint, or flammable liquids are used or stored.

13. Use this heater only as described in this manual. Any other use not recommended by

the manufacturer may cause fire, electric shock, or injury to persons.

14. Avoid the use of an extension cord because the extension cord may overheat and

cause a risk of fire. However, if you have to use an extension cord, the cord shall be

No. 14 AWG minimum size and rated no less than 1875 watts.

15. This heater draws 12.5 amps during operation. To prevent overloading a circuit, do

not plug the heater into a circuit that already has other appliances working.

16. It is normal for the plug to feel warm to the touch; however, a loose fit between the AC

outlet (receptacle) and plug may cause overheating and distortion of the plug. Contact

a qualified electrician to replace loose or worn outlet.

17. The output of this heater may vary and its temperature may become intense enough to

burn exposed skin. Use of this heater is not recommended for persons with reduced

sensitivity to heat or an inability to react to avoid burns.

18.“SAVE THESE INSTRUCTIONS”

Place the heater on a firm level surface free from obstructions, and at least 3 ft. away

from any wall and any other objects such as furniture, curtains, plants or combustible

material.

To program the functions of your electronic oil filled heater, refer to the control panel

in Fig. 2.

Press the “ POWER” button to turn the heater ON.

Select the power you desire by pressing the POWER button, the heater circularly in

sequence of LO – MED– HI. On LO, the heater operates at 600W. On MED, the heater

operates at 900W. On HI, the heater operates at 1500W.

There are 5 positions from MIN to MAX. Press the “ TEMP SETTING” button to select

the desired temperature, the heater circularly in sequence of 65 oF– 70 oF– 75 oF– 80 oF–

85oF.

Press the “ TIMER SETTING” button to select the desired temperature. There are 3

positions from 2H to 8H.

Timer setting: This heater has an 8 hours On/Off timer. You can set an “ On” timer when the

heater is standing by (plug in but not working) or you can set an “ Off” timer when the heater is

working. For example, you can plug in the heater and set the timer to turn the heater on after 2

hours, you can also set the timer to turn the heater off after 4 hours when the heater is working.

When each timer is set, the green light will remain on, indicating that the timers have been set.

During operation, when the heater operates in the Time Set mode, the green light will turn red,

indicating that the heater is operating during its set time.

UNPACKING AND SET-UP INSTRUCTIONS

Unpack your heater and remove the wheel assemblies from the package. Refer to Fig. 1

below:

1. Make sure the heater is unplugged and in

the “ OFF” position.

2. TURN THE HEATER UPSIDE DOWN.

3. Position the wheel base assemblies

between the end fins as shown.

4. Insert each U-shape screw into the holes

of each wheel holding plate.

5. Insert the butterfly nuts and screw them

tightly.

6. Turn the heater upright.

Your heater is now ready for use.

CAUTION: Risk of fire – Do not operate heater without wheel assemblies attached. Operate

heater in upright position only (wheels on bottom, controls on top). Any other position could

create a hazardous situation.

OPERATING INSTRUCTIONS

Fig. 2 - Control Panel View

IMPORTANT!

Your heater is equipped with a

polarized alternating current

line plug (a plug having one

blade wider than the other).

This plug will fit into the power

outlet only one way. This is a

safety feature. If you are

unable to insert the plug fully

into the outlet, try reversing the

plug. If the plug should still fail

to fit, contact your electrician to

replace your outlet. DO NOT

defeat the safety purpose of

the polarized plug.

Fig. 1

Upside down view

Wheel

holding

plate

shape

screw

Example for “ On” Timer:

1. When the heater is plugged in and not working, press “ Timer” button, the Indicator Light

will display. Press the “ Timer” button circularly in sequence of 2H – 4H– 8H to choose your

desired timer setting.

2. Press the “ Timer” button and the Indicator Light for 2H will display.

Now your heater is set to be turned on after 2 hours.

Example for “ Off” Timer:

1. When the heater is working, press “ Timer” button, the Indicator Light will display . Press

the “ Timer” button circularly in sequence of 2H – 4H– 8H to choose your desired timer

setting.

Press the “ Timer” button and the Indicator Light for 2H will display.

Now your heater is set to be turned off after 2 hours.

To disable the timer, adjust the set value of the POWER to OFF.

Note: Once the timer is set, the heater will work this way automatically unless you changed the

set value or shut it off.

CAUTION: This heater includes an Overheat Protection System that shuts the unit off if it

overheats due to abnormal conditions. At this time, the “C” Caution Indicator Light gets on. If this

occurs turn the heater “OFF”, unplug it, and inspect and remove any objects on or adjacent to the

heater. Allow it to cool for a few minutes, plug it back in, and resume normal operation.

ADDITIONAL FEATURES

This heater has additional features:

Convenient front Carry Handles and Heavy-Duty Caster Wheels - Allow for easy

maneuvering from room to room.

Cord Storage Compartment - Neatly stores power cord when the heater is not

used.

TROUBLESHOOTING

If your heater fails to operate, please follow these instructions:

Ensure that your circuit breaker or fuse is working properly.

Be sure the heater is plugged in and that the electrical outlet is working properly.

Check for any obstruction. If you find any obstruction, turn the heater “ OFF” .

Unplug the heater and wait a few minutes for it to cool down. Carefully remove the

obstruction. Plug the heater in and turn it on again by referring to the OPERATING

INSTRUCTIONS.

NOTE: IF YOU EXPERIENCE A PROBLEM WITH YOUR HEATER, PLEASE SEE THE

WARRANTY INFORMATION FOR INSTRUCTIONS. PLEASE DO NOT ATTEMPT TO

OPEN OR REPAIR THE HEATER YOURSELF. DOING SO MAY VOID THE WARRANTY

AND COULD CAUSE DAMAGE OR PERSONAL INJURY. IF THE PROBLEM STILL

PERSISTS, PLEASE CONTACT US BY REFERRING TO THE SERVICE & SUPPORT

INFORMATION ON THE FOLLOWING PAGE.

CLEANING AND STORAGE

It is recommended that the heater be cleaned at least one time during the operating

season in order to provide the optimum level of performance. ALWAYS TURN THE

POWER SWITCH OFF AND UNPLUG THE HEATER BEFORE CLEANING. Be sure

to save the box for off-season storage.

Turn the heater “ OFF” , unplug it and wait for the heater to cool down.

Use a dry cloth to clean only external surfaces of the heater.

Do not use any cleaning agents or detergents.

Never immerse the heater in water.

Pack the heater in the original carton and store it in a cool and dry place.

SPECIFICATIONS

Model No.: HO-0203D

Voltage: 120V, 60Hz

Current: Maximum continuous draw: 12.5 Amps.

Output: 5200 BTUs

Power: LOW = 600 Watts, MED = 900 Watts, HIGH = 1500 Watts

Tolerances on all specifications: Approximately +5%, -10%.

SERVICE & SUPPORT

In the event of a warranty claim or if service is required for this heater, please contact us at

the following:

Tel: 866-876-4332 (M-F 8:30am to 5:30pm CST)

Email us at: M[email protected]

For questions or comments, please write to:

PELONIS.

2617 North Great Southwest Parkway

Suite 100

Grand Prairie, TX 75050, USA

For your records, staple your sales receipt to this manual and record the following:

DATE OF PURCHASE: ________________________________

________________________________

PLACE OF PURCHASE: ________________________________

________________________________

SERIAL NUMBER:________________________________

________________________________

(STAPLE SALES RECEIPT HERE)

NOTE: PROOF OF PURCHASE IS REQUIRED FOR ALL WARRANTY

CLAIMS

ONE (1) YEAR LIMITED WARRANTY

Please read all instructions before attempting to use this product.

Please return the Warranty Registration card within fifteen (15) days from the date of

purchasing this product.

PELONIS warrants as limited herein to the original purchaser of retail that each new Pelonis Oil

Filled Radiator heater shall be free of defects in material and workmanship for a period of one

(1) year from the date of original purchase. This one (1) year warranty is limited to the heating

elements, motor, and electric control circuit board.

In the event of malfunctions or failure of your Pelonis Fan Forced heater, simply deliver or send

the heater, postage prepaid along with PROOF OF PURCHASE, within the warranty period of

one (1) year, to PELONIS. PELONIS reserves the right to inspect the claimed defective part or

parts to determine if the defect or malfunction complaint is covered by this warranty. PELONIS

shall, within sixty (60) days after receipt of the product, at its option, repair and/or replace the

defective part or parts free of charge. This warranty shall only cover defects arising from normal

usage. PELONIS assumes no responsibility whatsoever if the Fan Forced heater should fail

during the warranty period by reason of:

Misuse, negligence, physical damage or accidents.

Lack of maintenance (see instructions for proper maintenance).

Repair by any unauthorized party during the warranty period.

Damage caused by connection to an improper input voltage (see specification label on

your heater).

PELONIS makes no further warranties or representations, express or implied except those

contained herein. No representative or dealer is authorized to assume any other liability

regarding the Fan Forced heater. The duration of the implied warranty granted under State law,

including warranties of merchantability and fitness for particular purpose are limited in duration

should the duration of the express warranty grant it hereunder. PELONIS shall in no event be

liable for direct, indirect, special or consequential damages.

Some states do not allow limitations on how long an implied warranty lasts, and/or the above

limitations or exclusion may not apply to you. This warranty gives you specific legal rights and

you may have other rights which vary from state to state.

Andere Pelonis Heizung Handbücher

Pelonis

Pelonis PSH17PF2HDB Bedienungsanleitung

Pelonis

Pelonis PTH21S4BRB Bedienungsanleitung

Pelonis

Pelonis HC-451 Bedienungsanleitung

Pelonis

Pelonis Safe-T FURNACE HC-445 Bedienungsanleitung

Pelonis

Pelonis HC-0113 Bedienungsanleitung

Pelonis

Pelonis HC-0119A Bedienungsanleitung

Pelonis

Pelonis NTY15-16LA Bedienungsanleitung

Pelonis

Pelonis HC-0125D Bedienungsanleitung

Pelonis

Pelonis HC-1010 Bedienungsanleitung

Pelonis

Pelonis HO-158E Bedienungsanleitung

Pelonis

Pelonis HB-211 Bedienungsanleitung

Pelonis

Pelonis 1500W-II Bedienungsanleitung

Pelonis

Pelonis HB-215T Bedienungsanleitung

Pelonis

Pelonis PSH700S Bedienungsanleitung

Pelonis

Pelonis HO-0221 Bedienungsanleitung

Pelonis

Pelonis HF-0063 Bedienungsanleitung

Pelonis

Pelonis PHTPU1501 Bedienungsanleitung

Pelonis

Pelonis HC-461 Bedienungsanleitung

Pelonis

Pelonis PTH15A2BGB Bedienungsanleitung

Pelonis

Pelonis PSH700R Bedienungsanleitung

Pelonis

Pelonis HC-350 Bedienungsanleitung

Pelonis

Pelonis NY1507-14A Bedienungsanleitung

Pelonis

Pelonis HC-0155M Bedienungsanleitung

Pelonis

Pelonis HO-202C Bedienungsanleitung

Beliebte Heizung Handbücher anderer Marken

oventrop

oventrop Regucor Series Bedienungsanleitung

Blaze King

Blaze King CLARITY CL2118.IPI.1 Bedienungsanleitung

ELMEKO

ELMEKO ML 150 Bedienungsanleitung

BN Thermic

BN Thermic 830T Bedienungsanleitung

KING

KING K Series Leitfaden

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Kurzanleitung

Well Straler

Well Straler RC-16B Bedienungsanleitung

EUROM

EUROM 333299 Bedienungsanleitung

Heylo

Heylo K 170 Bedienungsanleitung

Eterna

Eterna TR70W Bedienungsanleitung

Clarke

Clarke GRH15 Bedienungsanleitung

IRSAP

IRSAP The Radiator Company Ovali Bedienungsanleitung

Empire Heating Systems

Empire Heating Systems WCC65 Bedienungsanleitung

Wetekom

Wetekom 92 86 43 Bedienungsanleitung

Desa

Desa SPC170-F Bedienungsanleitung

Watlow

Watlow Watrod Electric Tubular Heaters Bedienungsanleitung

Haverland

Haverland ECO-DRY GPS Series Stücklistenhandbuch

Stelpro

Stelpro ASILVC2060 Series Bedienungsanleitung
