Pepperl+Fuchs OHV1000-series Bedienungsanleitung

OHV1000-*

Handheld

FACTORY AUTOMATION

QUICK START GUIDE

With regard to the supply of products, the current issue of the following document is applicable: The

General Terms of Delivery for Products and Services of the Electrical Industry, published by the

Central Association of the Electrical Industry (Zentralverband Elektrotechnik und Elektroindustrie

(ZVEI) e.V.) in its most recent version as well as the supplementary clause: "Expanded reservation

of proprietorship"

OHV1000-*

Contents

2014-10

1 Introduction .......................................................................4

1.1 Purpose of this quick start guide ................................................................ 4

1.2 Intended Use.............................................................................................. 4

1.3 Operation, Maintenance, Repair................................................................. 5

1.4 Delivery, Transport, Disposal ...................................................................... 5

2 Product Description..........................................................6

2.1 Indicators and Operating Controls.............................................................. 6

2.2 Accessories................................................................................................ 7

3 Installation .........................................................................8

3.1 Installing/Removing the Cable.................................................................... 8

3.2 Establishing a USB Connection ................................................................. 9

3.3 Establishing an RS232 Connection ............................................................ 9

4 Operation .........................................................................11

4.1 Reading Codes ........................................................................................ 11

4.2 Keyboard Mode........................................................................................ 13

OHV1000-*

Introduction

2014-10

1Introduction

1.1 Purpose of this quick start guide

This quick start guide contains basic instructions for operating the device.

However, the manual takes priority over the quick start guide.

1.2 Intended Use

The handheld is used to identify 1-D and 2-D codes that have been applied

directly to the surface of a product. For example, the code may have been etched,

printed, or laser-engraved on a housing. The degree of flexibility offered when

decoding codes allows the handheld to be used in a number of industries.

Always operate the device as described in these instructions to ensure that the

device and connected systems function correctly. The protection of operating

personnel and plant is only guaranteed if the device is operated in accordance

with its intended use.

OHV1000-*

Introduction

2014-10

1.3 Operation, Maintenance, Repair

The handheld has bright LEDs to enable it to read 1-D and 2-D codes. The optical

light can be an irritant, especially in a dark environment. Do not point the handheld

at people. Do not look directly into the handheld's lens.

The device must not be repaired, changed or manipulated.

If there is a defect, the product must be returned to the manufacturer

Pepperl+Fuchs.

1.4 Delivery, Transport, Disposal

Check the packaging and contents for damage.

Check if you have received every item and if the items received are the ones you

ordered.

Keep the original packaging. Always store and transport the device in the original

packaging.

Store the device in a clean and dry environment. The permitted ambient

conditions (see datasheet) must be considered.

Disposing of device, packaging material, and possibly contained batteries must

be in compliance with the applicable laws and guidelines of the respective

country.

OHV1000-*

Product Description

2014-10

2 Product Description

2.1 Indicators and Operating Controls

1Mounting bracket

2Function indicator

310-pin connector socket

4Trigger button

5Optics

43 5

1 2

OHV1000-*

Product Description

2014-10

2.2 Accessories

Designation Description

ODZ-MAH-SUPPLY 5 VDC power supply, 1.2 A, short-circuit proof

V45-G-2M-PVC-ABG-USB-G Connection cable with USB plug, 4-pin, approx.

1.8 meters

V45-G-2M-PVC-SUBD9 Connection cable with D-sub plug and DC connector

socket, 6-pin, approx. 2.4 meters

Vision Configurator Configuration software for camera-based sensors

OHV1000-*

Installation

2014-10

3 Installation

3.1 Installing/Removing the Cable

Installing the Cable

1. Hold the end of the cable with the RJ50 plug and insert the plug into the RJ50

socket underneath the handle.

2. You must hear a click when the cable engages.

The cable is now securely connected to the handheld.

Removing the Cable

1. Insert a thin object such as a straightened paper clip into the hole at the bottom

of the handle.

2. Carefully pull the cable complete with RJ50 plug out of the handle.

The cable has now been detached from the handle.

OHV1000-*

Installation

2014-10

3.2 Establishing a USB Connection

Establishing a USB Connection

1. Insert the USB plug on the connection cable into a free USB port on the PC.

This step can be carried out even during operation.

2. To switch on the handheld, hold down the trigger button for approx. two

seconds.

3. When the handheld is successfully connected, an audible signal is emitted

and the handheld will vibrate.

The handheld is now ready.

3.3 Establishing an RS-232 Connection

Establishing an RS-232 Connection

1. Switch off the PC.

2. Insert the RS-232 plug on the connection cable into the RS-232 port on the

PC.

3. Insert the low-voltage plug on the power supply unit into the low-voltage

socket on the RS-232 connection cable.

4. Connect the mains power plug on the power supply unit to the mains.

OHV1000-*

Installation

2014-10

5. Switch on the PC.

Once you have switched on the PC, the handheld will switch itself on

automatically.

6. When the handheld is successfully connected, an audible signal is emitted

and the handheld will vibrate.

The handheld is now ready.

The handheld uses the following RS-232 factory settings:

■115,200 baud

■8 data bits

■No parity
