BOLYGUARD MG984G-36M 4G CAMERA

This camera is powered by 8 AA batteries. All types of

batteries (Lithium, Alkaline and Rechargeable (NiMH)

can be used in the cameras. For best performance, we

recommend using quality NiMH rechargeable batteries

or Energizer Ultimate Lithium batteries. The power port

can also be used to connect an external 6V battery

(cable not included).

POWER

SETTINGS INTERFACE & DISPLAY

Place the power switch to the TEST/SETUP position.

To navigate the menus, utilise the following built-in

buttons:

MENU: Enter the program menu in Preview Mode

: Move between menu options (OK to select)

OK / PLAY: Save parameter settings and play videos

DEL / : Delete an image/video when viewing them

SHOT / : Capture a photo or record a video manually

When the camera is in TEST/SETUP Mode, the screen will

activate and display the following:

Vodafone

SDcard icon Available space Battery level

Numberof image

36M

Indicates the SIM card is

recognised by the

camera.

Indicates the SIM card is not

recognised by the camera or the

SIM card is not working due to

connection/activation issues.

QUICK START

Your PerdixPro enabled camera is supplied with pre-

installed SIM and SD cards. To begin using your camera,

please follow these steps:

1. Setup your PerdixPro account to begin receiving

images. See PerdixPro Media Tool Setup for further

instructions.

2. Attach the aerial to the brass connector on top of

the camera.

3. Install 8 x AA batteries. We recommend using

Energizer Ultimate Lithium or high quality NiMH

batteries.

4. Turn the power switch to SETUP and wait for the

camera to connect to a network. This may take a

few minutes.

5. Once connected, turn the power switch to ON.

Images will start being taken (when PIR activated)

after the red LED on the front of the camera stops

ashing.

6. Images taken should now be shown in your

PerdixPro Portal and App.

NB: The camera is set to send low resolution photos by

default. This can be changed within the menu settings

but will reduce the number of images that can be

uploaded monthly.

Camera mode

Choose between capturing photo’s, video or both. When

set to Pic+Video, only the photo is sent to your PerdixPro

account. The video is saved to the SD card.

Photo size

Choose between 14, 25 or 36 megapixels. These original

sized images are stored on the SD card for along with a

lower resolution copy. The size of image sent to your

PerdixPro account is dependent on the Attachment Size

setting.

Photo burst

Choose between 1-3 photo’s to be taken per trigger

event. Only the rst photo is sent to your PerdixPro

account. Others are saved to SD card.

Video size

Choose between VGA, 720P or 1080P. When sending

video to your PerdixPro account, the setting should be

VGA. Video is sent in its original size and so uses

considerably more upload allowance than photos. Also

see Video Length settings below.

Video length

Choose a video length between 5 and 180 seconds.

When sending video to your PerdixPro account, the

video length should be set to no more than 10 seconds.

Video lengths above this create le sizes too large to be

sent.

CAMERA MODES

Picture Resolution 14/25/36MP

Video Resolution 1920x1080, 1280x720 or 640x480

Video Length 5 to 180 Sec

Detection Range 100Ft.

LED Type 940Nm

LED Number 44Pcs

Illumination Distance 90Ft.

Image Sensor 14MP Colour CMOS

Aperture ƒ/ 2.4

Field of View 60 Degrees

Trigger Time < 1.0 Sec

Memory Card 32GB Max

Display Screen Built-In 2.3" LCD

Sound Recording Yes

Operating Ambient

Temperature -20℃to + 60℃

Non-Operating

Temperature -30℃to + 70℃

Relative Humidity 5% to 90% Noncondensing

Dimensions 147x96x79 Mm

Unit Weight ~ 0.30Kg

Power Supply 8AA batteries or 6V,

2A external power supply

Standby Power

Consumption <0.3mA(<7mAh/Day)

Compliances FCC, CE, RoHS

PERDIX Wildlife Supplies.

Unit 1 Hatton Rock Business Park,

Hatton Rock, Stratford-Upon-Avon, CV37 0BX. UK

Tel: +44 (0)1789 336123

www.perdixwildlifesupplies.com

Clock

Set the cameras date and time. The date format is

month/day/year. But this can be changed. Date and

time stamp appears on photo’s and video.

Time-lapse

In time-lapse mode, the camera will activate at the set

time interval regardless of motion detection. Intervals

range from 5 minutes to 8 hours. Both PIR activation

and time-lapse can be on at the same time.

PIR trigger

In trigger mode, the camera will activate when motion is

detected. PIR sensitivity can be adjusted here. If PIR

trigger is OFF, the camera will not respond to any motion

within the camera’s trigger detection range. NOTE: If PIR

trigger and time-lapse options are both OFF, the camera

will not capture any photos or videos.

PIR interval

The PIR sensor can be disabled after each camera

triggering. During this time the PIR sensor will not react

to any detected motion or scheduled timer functions.

The PIR interval can be set between 0 and 60 seconds.

Work day

Choose specic days of the week when you want the

camera to be active. The camera works on all days by

default.

Work hour

Choose the hours of the day when you want the camera

to be active. The camera works at all hours by default.

Send mode

This should be set to instant to receive images directly

to your PerdixPro portal. The amount of images sent

daily can the limited. Default setting is unlimited.

SMS control

This should be ON if you wish to send SMS commands

from PerdixPro to the camera e.g. Take Snapshot. If not

required, turning OFF will improve battery life.

Attachment size

This is size of image sent to your PerdixPro account. The

default is Low and . When set to High, the original sized

image is sent. Please note: Changing attachment size

from Low will reduce the number images that can be

uploaded per month.

Select network

This should be kept on Auto to ensure best network

coverage. PerdixPro SIMs are 2, 3 and 4G enabled and

will roam across networks to nd best signal.

Automatic deletion

Select ON if your require images to be deleted from the

SD card after being sent. Images that cannot be sent

due to signal etc, will not be deleted.

ADDITIONAL SETTINGS

Additional settings can be found in the fourth menu

section. This includes setting up and PIN for the camera

and adding a name stamp to the images.

CAMERA MODES PERDIXPRO UPLOAD SETTINGS
