Familiarisation

Keyless Entry and Starting

This system allows you to unlock, lock

and start your vehicle while keeping

the key on your person and in the

defined zone.

39, 94

Parking space sensor

This system measures the size of a space and

advises whether parking is possible.

127

Exterior

Stop & Start

This system puts the engine temporarily into

standby during stops in the traffic (red lights, traffic

jams, etc...). The engine restarts automatically as

soon as you want to move off. The Stop & Start

system reduces fuel consumption and exhaust

emissions, and offers the comfort of complete

silence when stationary.

114

APp-W2_01_2010_anglais_cag_pdf_H4 4

03/11/2010 14:20:05

Familiarisation

Front and rear parking sensors

This system provides a warning when

manoeuvering forwards and backwards by

detecting obstacles located in front of or behind

the vehicle.

125

Motorised tailgate (SW)

This system provides motorised opening and

closing of the tailgate, by pressing a button.

Temporary puncture repair kit

This kit is a complete system consisting of a

compressor and a sealant cartridge, to allow

the temporary repair of a tyre.

170

Exterior

APp-W2_01_2010_anglais_cag_pdf_H5 5

03/11/2010 14:20:06

Familiarisation

Open

A. Unfolding/Folding the key.

B. Unlocking the vehicle.

Remote control key

1. Opening the fuel filler flap.

Fuel tank

Unlocking

With the electronic key on your person and in

the defined zone, pass your hand behind the

door handle to unlock the vehicle, then pull on

the handle to open the door.

Locking

With the electronic key in the defined zone,

press with a finger on the door handle (at the

markings) to lock the vehicle.

Keyless Entry and Starting

system

2. Opening and hooking the fuel filler cap.

Tank capacity: approximately 72 litres (or 55 litres

according to version).

Other functions...

C. Normal locking of the vehicle.

Vehicle location.

APp-W2_01_2010_anglais_cag_pdf_H6 6

03/11/2010 14:20:07

Familiarisation

Interior

Interior mood lighting

This subdued passenger compartment lighting

improves visibility inside the vehicle in low

lighting conditions.

Head-up display

This system projects speed and cruise control/

speed limiter information onto a lightly smoked

strip in the driver's field of vision, so that they

do not need to take their eyes off the road.

Digital air conditioning

After setting the desired level of comfort, the

system then automatically controls this level

according to the exterior climatic conditions.

Manual

Audio and communication

systems

These systems benefit from the latest

technology: MP3 compatible audio systems,

USB player, Bluetooth hands-free system,

satellite navigation system with colour screen,

auxiliary inputs, Hi-Fi audio system, ...

Satellite navigation system

145

118

285

231

Audio system

85, 87

Dual-zone

Quad-zone

If your 508 is fitted with a JBL

Hi-Fi audio system, this is

designed specifically for the

passenger compartment of your

vehicle.

APp-W2_01_2010_anglais_cag_pdf_H7 7

03/11/2010 14:20:09

Familiarisation

Lighting of the indicator lamp indicates the state

of the corresponding function.

Switch panels

Opening the boot.

Opening the fuel filler flap.

52, 53

Massage.

Alarm.

Programmable heating warning lamp.

Electric parking brake.

Starting/stopping using the

electronic key.

Deactivation of Stop & Start.

115

Head-up display (on/off, settings).

118

Deactivation of parking sensors.

126

Parking space sensor.

127

Electric child lock.

156

Deactivation of the ESP/ASR system.

160

Smartbeam.

135

APp-W2_01_2010_anglais_cag_pdf_H8 8

03/11/2010 14:20:10

Familiarisation

Sitting comfortably

Front seats

Manual adjustments

1. Head restraint height and angle

adjustment.

2. Backrest angle adjustment.

3. Seat cushion height adjustment.

4. Lumbar support adjustment.

5. Seat forwards-backwards adjustment.

6. Cushion adjustment.

Electrical adjustment

1. Angle, seat height and seat forwards-

backwards adjustment.

2. Backrest angle adjustment.

3. Lumbar support adjustment.

APp-W2_01_2010_anglais_cag_pdf_H9 9

03/11/2010 14:20:15

Familiarisation

9. Fusebox.

10. Front door window demisting/defrosting

vent.

11. Windscreen demisting/defrosting vent.

12. Steering lock and starting with the key.

13. Starting using the electronic key.

14. Audio equipment steering wheel controls.

15. Wiper/screenwash/trip computer stalk.

16. Central locking and hazard warning

buttons.

17. Multifunction screen.

Instruments and controls

1. Cruise control/speed limiter controls.

2. Headlamp height adjustment.

3. Lighting and direction indicator stalk.

4. Instrument panel.

5. Driver's airbag.

Horn.

6. Gear lever.

7. 12 V accessory socket

USB port/auxiliary socket.

8. Bonnet release lever.

18. Central adjustable air vents.

19. Passenger's airbag.

20. Side adjustable air vents.

21. Glove box/Passenger's airbag deactivation.

22. Electric parking brake.

23. Central armrest with storage.

24. Upper and lower storage.

25. Audio system.

26. Heating/air conditioning controls.

APp-W2_01_2010_anglais_cag_pdf_H10 10

03/11/2010 14:20:16

Familiarisation

APp-W2_01_2010_anglais_cag_pdf_H11 11

03/11/2010 14:20:16

Familiarisation

Sitting comfortably

Head restraint adjustment

1. Release the adjustment mechanism.

2. Adjust for height and reach.

3. Lock the adjustment mechanism.

Steering wheel adjustment

For reasons of safety, these operations

must only be carried out with the

vehicle stationary.

Heated seats control

0: off.

1: low.

2: medium.

3: high.

To lower it, press button A.

To raise it, guide the head restraint upwards to

the desired position.

To incline it, swivel the lower part backwards or

forwards.

APp-W2_01_2010_anglais_cag_pdf_H12 12
