Pfaff 300 e Bedienungsanleitung

300e

USER’S GUIDE

This houshold sewing machine is designed to comply with IEC/EN 60335-2-28 and UL1594

IMPORTANT SAFETY INSTRUCTIONS

When using an electrical appliance, basic safety precautions should always be followed, including the

following:

Read all instructions before using this household Sewing machine.

DANGER – To reduce the risk of electric shock:

• A sewing machine should never be left unattended when plugged in. Always unplug this sewing

machine from the electric outlet immediately after using and before cleaning.

• Always unplug before relamping. Replace bulb with same type rated 5 Watt.

WARNING – To reduce the risk of burns, ﬁre,

electric shock, or injury to person:

• Do not allow to be used as a toy. Close attention is necessary when this sewing machine is used by or

near children or inﬁrm persons.

• Use this sewing machine only for its intended use as described in this manual. Use only attachments

recommended by the manufacturer as contained in this manual.

• Never operate this sewing machine if it has a damaged cord or plug, if it is not working properly, if it has

been dropped or damaged, or dropped into water. Return the sewing machine to the nearest authorized

dealer or service center for examination, repair, electrical or mechanical adjustment.

• Never operate the sewing machine with any air openings blocked. Keep ventilation openings of the

Sewing machine and foot controller free from the accumulation of lint, dust, and loose cloth.

• Keep ﬁngers away from all moving parts. Special care is required around the Sewing machine needle.

• Always use the proper needle plate. The wrong plate can cause the needle to break.

• Do not use bent needles.

• Do not pull or push fabric while stitching. It may deﬂect the needle causing it to break.

• Switch the Sewing machine off (“0”) when making any adjustment in the needle area, such as threading

needle, changing needle, threading bobbin, or changing presser foot, etc.

• Always unplug Sewing machine from the electrical outlet when removing covers, lubricating, or when

making any other user servicing adjustments mentioned in the instruction manual.

• Never drop or insert any object into any opening.

• Do not use outdoors.

• Do not operate where aerosol (spray) products are being used or where oxygen is being administrated.

• To disconnect, turn all controls to the off (“0”) position, then remove plug from outlet.

• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.

• Hold plug when rewinding into cord reel. Do not allow plug to whip when rewinding.

• This sewing machine is provided with double insulation. Use only identical replacement parts.

See instructions for Servicing of Double-Insulated Appliances.

SAVE THESE INSTRUCTIONS

SERVICING OF DOUBLE INSULATED

PRODUCTS

In a double-insulated product, two systems of insulation are provided instead of grounding. No ground means is

provided on a double-insulated product, nor should a means for grounding be added to the product. Servicing

of a double-insulated product requires extreme care and knowledge of the system, and should be done only

by qualiﬁed service personnel. Replacement parts for a double-insulated product must be identical to those

parts in the product. A double-insulated product is marked with the words ‘DOUBLE INSULATION’ or ‘DOUBLE

INSULATED’.

INTRODUCTION

CONGRATULATIONS ON CHOOSING

YOUR NEW MACHINE

Your new machine is an advanced computerized

household embroidery machine. To fully enjoy all the

features, we suggest that you study this user’s guide

before using the machine.

To make sure that you are always provided with the latest

sewing capabilities, we reserve the right to change the

machine equipment and the assortment of accessories

without prior notice, or make modiﬁcations to the

performance or design.

Such modiﬁcations, however, will always be to the beneﬁt

of the user and the product.

Table of contents

INTRODUCTION 2

Overview 4

Accessories 5

Power Switch and

Power Connections 6

Connecting the machine 7

Turning the Machine On 7

Turning the Machine Off 7

GET READY TO EMBROIDER 9

Operating the Machine 10

Winding the Bobbin 11

Place Bobbin in Machine 13

Top Threading 14

Needle Threader 15

Top Tension 16

Vertical Spool Pin 17

Needle change 18

Replace the Needle 19

Start/Stop Button 20

Presser foot Lift 20

Control Panel 21

Design perimeter button 22

Mirror horizontally 22

Mirror vertically 22

Rotate 90° 22

Center design button 22

Select design button 22

Machine Mode Indicators 23

Directional buttons 24

CONNECTIVITY TO YOUR

COMPUTER 25

How to transfer designs to the

machine 26

Send 27

Using the machine without being

connecting to the computer 28

Navigator module 29

Navigator software 29

Transfer a design from the

computer via the USB 29

Navigator tools 31

Help Messages 33

Hooping 35

Attach the Hoop 37

Remove the Hoop 37

Move To Stitch 38

Stitching a Design 39

Changing the light bulb 41

Cleaning 42

Lubrication 43

Troubleshooting Guide 44

User’s Guide

Overview

Familiarize yourself with the names of

the parts of your machine. This will help

you in learning its operation.

1. Bobbin winder

2. Handwheel

3. Main power switch

and connectors

4. USB connection

5. Control Panel

6. Embroidery hoop

holder

7. Needle plate

8. Bobbin cover

9. Presser foot

10.Needle threader

11. Start/Stop button

12.Presser foot lever

13.Bobbin winding

guide

14.Upper thread

tension

15.Spool cap

16.Spool felt

2. 3.

9.8.7. 10.

INTRODUCTION

Accessories

These are standard

accessories included with your

embroidery machine.

1. Needles

2. Seam Ripper

3. Thread Snips

4. Screwdriver tool

5. Hoop

6. Vertical spool pin

7. Large spool cap

8. Small spool cap

9. Oiler

10.Bobbins

11. Brush (not in picture)

12.USB cable (not in

picture)

13.Accessory storage

envelope (not in

picture)

Your machine

comes with clear

sewing machine

oil that should be

used to keep your

machine lubricated.

User’s Guide

Main switch

When the main switch (A) is turned on, the sewing light bulb. The sewing machine is

now ready to use.

For USA and Canada

This appliance has a polarized plug (one blade is wider than the other).

To reduce the risk of electric shock, this plug is intended to ﬁt in a

polarized outlet only one way. If it does not ﬁt fully in the outlet, reverse

the plug. If it still does not ﬁt, contact a qualiﬁed electrician to install the

proper outlet. Do not modify the plug in any way.

A - On/Off switch

1 - on 2 - off

B - USB Connection

Power Switch and Power Connections

Turn switch to OFF

position before

unplugging cord

from power source.

OFF

INTRODUCTION

Connecting the machine

Turning the Machine On

Make sure that the machine is turned off (the main power

switch is set to “O”) and then insert the power supply cord

into the power supply jack on the right side of the machine.

1. Insert the plug of the power supply cord into a household

electrical outlet.

2. Set the main power switch on the right side of the machine to

on (set it to “I”).

Turning the Machine Off

Make sure that the machine is not sewing.

1. Press the bottom of the main power switch on the right side

of the machine to “O”. The sewing light goes off when the

machine is turned off.

2. Unplug the power supply cord from the electrical outlet by

grasping the plug.

3. Unplug the power supply cord from the power supply jack.

User’s Guide
