Instruction Manual

chs

PBU1153 A

Please read this user manual first!

Dear Customer,

We hope that your product, which has been produced in modern plants and

checked under the most meticulous quality control procedures, will provide you

an effective service.

Therefore, read this entire user manual carefully before using the product and

keep it as a reference. If you handover the product to someone else, give the user

manual as well.

The user manual will help you use the product in a fast and safe way.

• Read the manual before installing and operating the product.

• Make sure you read the safety instructions.

• Keep the manual in an easily accessible place as you may need it later.

• Read the other documents given with the product.

Remember that this user manual is also applicable for several other models.

Differences between models will be identified in the manual.

Explanation of symbols

Throughout this user manual the following symbols are used:

CImportant information or useful tips.

AWarning against dangerous conditions for life and property.

BWarning against electric voltage.

1 Your refrigerator 4

2 Important Safety

Warnings 5

Intended use .....................................5

General safety ...................................6

For products with a ........................10

water dispenser;..............................10

Child safety......................................10

Compliance with WEEE Directive and

Disposing of the Waste Product: .....11

Package information........................11

HC warning .....................................11

Things to be done for energy saving 12

3 Installation 13

Points to be paid attention to when the

relocation of the refrigerator .............13

Electrical connection........................13

Disposing of the packaging .............14

Disposing of your old refrigerator .....14

Placing and Installation ....................14

Changing the illumination lamp .......15

Reversing the doors ........................16

4Preparation 17

5 Using your refrigerator 18

Thermostat setting button................18

Cooling............................................19

Freezing...........................................19

Defrost ............................................19

Stopping your product.....................20

6 Maintenance and

cleaning 21

Protection of plastic surfaces ..........21

7 Troubleshooting 22

CONTENTS

4EN

C Figures that take place in this instruction manual are schematic and may not

correspond exactly with your product. If the subject parts are not included in the

product you have purchased, then it is valid for other models.

1. To freeze fresh food, frozen food, rapid

cooling of beverages, making ice cubes.

2. Baked, chilled cooked food, dairy

products.

3. Meat, sausages, cold cuts, cans.

4. Fruit, vegetables, salads.

5. Tubes, small bottles and cans.

6. Egg tray.

7. Beverages, large bottles.

1Your refrigerator

This section provides the safety

instructions necessary to prevent the

risk of injury and material damage.

Failure to observe these instructions will

invalidate all types of product warranty.

Intended use

WARNING:

Keep ventilation openings,

in the appliance enclosure or

in the built-instructure, clear

of obstruction.

WARNING:

Do not use mechanical

devices or other

means to accelerate the

defrostingprocess, other than

those recommended by the

manufacturer.

WARNING:

Do not damage the

refrigerant circuit.

WARNING:

Do not use electrical

appliances inside the food

storage compartments of the

appliance, unless they are of

the type recommended by

the manufacturer.

WARNING:

Do not store explosive

substances such as aerosol

cans with a flammable

propellant in this appliance.

This appliance is intended to be used

in household and similar applications

such as

– staff kitchen areas in shops, offices

and other working environments;

– farm houses and by clients in hotels,

motels and other residential type

environments;

–bed andbreakfasttype environments;

– catering and similar non-retail

applications.

General Safety

• This product should not be used by

persons with physical, sensory and

mental disabilities, without sufficient

knowledge and experience or by

children. The device can only be used

by such persons under supervision

and instruction of a person

responsible for their safety. Children

should not be allowed to play with this

device.

• In case of malfunction, unplug the

device.

• After unplugging, wait at least 5

minutes before plugging in again.

• Unplug the product when not in use.

• Do not touch the plug with wet

hands! Do not pull the cable to plug

off, always hold the plug.

• Do not plug in the refrigerator if the

socket is loose.

• Unplug the product during installation,

maintenance, cleaning and repair.

• If the product will not be used for a

while, unplug the product and remove

any food inside.

• Do not use the product when the

compartment with circuit cards

located on the upper back part of the

product (electrical card box cover) (1)

is open.

2Safety and Environment Instructions

6EN

• Do not use steam or steamed

cleaning materials for cleaning the

refrigerator and melting the ice inside.

Steam may contact the electrified

areas and cause short circuit or

electric shock!

• Do not wash the product by spraying

or pouring water on it! Danger of

electric shock!

• In case of malfunction, do not use

the product, as it may cause electric

shock. Contact the authorized service

before doing anything.

• Plug the product into an earthed

socket. Earthing must be done by a

qualified electrician.

• If the product has LED type lighting,

contact the authorized service for

replacing or in case of any problem.

• Do not touch frozen food with wet

hands! It may adhere to your hands!

• Do not place liquids in bottles and

cans into the freezer compartment.

They may burst out!

• Place liquids in upright position after

tightly closing the lid.

• Do not spray flammable substances

near the product, as it may burn or

explode.

• Do not keep flammable materials and

products with flammable gas (sprays,

etc.) in the refrigerator.

• Do not place containers holding

liquids on top of the product.

Splashing water on an electrified part

may cause electric shock and risk of

fire.

• Exposing the product to rain, snow,

sunlight and wind will cause electrical

danger. When relocating the product,

do not pull by holding the door

handle. The handle may come off.

• Take care to avoid trapping any part

of your hands or body in any of the

moving parts inside the product.

• Do not step or lean on the door,

drawers and similar parts of the

refrigerator. This will cause the product

to fall down and cause damage to the

parts.

• Take care not to trap the power cable.

• When positioning the appliance,

ensure the supply cord is not trapped

or damaged.

• Do not locate multiple portable

socket-outlets or portable power

supplies at the rear of the appliance.

• Children aged from 3 to 8 years

are allowed to load and unload

refrigerating appliances.

• To avoid contamination of food,

please respect the following

instructions:

• – Opening the door for long periods

can cause a significant increase of the

temperature in the compartments of

the appliance.

• – Clean regularly surfaces that can

come in contact with food and

accessible drainage systems.

• – Clean water tanks if they have not

been used for 48 h; flush the water

system connected to a water supply if

water has not been drawn for 5 days.

• – Store raw meat and fish in suitable

containers in the refrigerator, so that

it is not in contact with or drip onto

other food.

• – Two-star frozen-food compartments

are suitable for storing pre-frozen

food, storing or making icecream and

making ice cubes.

• – One-, two- and three-star

compartments are not suitable for the

freezing of fresh food.

• – If the refrigerating appliance is left

empty for long periods, switch off,

defrost, clean, dry, and leave the door

open to prevent mould developing

within the appliance.

1.1.1 HC Warning

If the product comprises a cooling

system using R600a gas, take care

to avoid damaging the cooling system

and its pipe while using and moving the

product. This gas is flammable. If the

cooling system is damaged, keep the

product away from sources of fire and

ventilate the room immediately.

The label on the inner left

side indicates the type of gas

used in the product.

1.1.2 For Models with

Water Dispenser

• Pressure for cold water inlet shall

be maximum 90 psi (6.2 bar). If

your water pressure exceeds 80

psi (5.5 bar), use a pressure limiting

valve in your mains system. If you

do not know how to check your

water pressure, ask for the help of a

professional plumber.

• If there is risk of water hammer effect

in your installation, always use a water

hammer prevention equipment in

your installation. Consult Professional

plumbers if you are not sure that there

is no water hammer effect in your

installation.

• Do not install on the hot water inlet.

Take precautions against of the

risk of freezing of the hoses. Water

temperature operating interval shall

be 33°F (0.6°C) minimum and 100°F

(38°C) maximum.

• Use drinking water only.

Intended Use

• This product is designed for home

use. It is not intended for commercial

use.

• The product should be used to store

food and beverages only.

• Do not keep sensitive products

requiring controlled temperatures

(vaccines, heat sensitive medication,

medical supplies, etc.) in the

refrigerator.

8EN

• The manufacturer assumes no

responsibility for any damage due to

misuse or mishandling.

• Original spare parts will be provided

for 10 years, following the product

purchasing date.

Child Safety

• Keep packaging materials out of

children’s reach.

• Do not allow the children to play with

the product.

• If the product’s door comprises a

lock, keep the key out of children’s

reach.

Compliance with WEEE

Directive and Disposing of

the Waste Product

This product complies with

EU WEEE Directive (2012/19/EU). This

product bears a classification symbol

for waste electrical and electronic

equipment (WEEE).

This product has been

manufactured with high

quality parts and materials

which can be reused and

are suitable for recycling.

Do not dispose of the

waste product with normal

domestic and other wastes at the end

of its service life. Take it to the collection

center for the recycling of electrical and

electronic equipment. Please consult

your local authorities to learn about

these collection centers.

Compliance with RoHS

Directive

• This product complies with EU

WEEE Directive (2011/65/EU). It does

not contain harmful and prohibited

materials specified in the Directive.

Package Information

Packaging materials of the product

are manufactured from recyclable

materials in accordance with our

National Environment Regulations. Do

not dispose of the packaging materials

together with the domestic or other

wastes. Take them to the packaging

material collection points designated

by the local authorities.

3Installation

BIn case the information which are

given in the user manual are not taken

into account, manufacturer will not

assume any liability for this.

Points to be paid attention

to when the relocation of the

refrigerator

1. Your refrigerator should be

unplugged.Before transportation of

your refrigerator, it should be emptied

and cleaned.

2. Before it is re-packaged,

shelves, accessories, crisper, etc.

inside your refrigerator should be

fixed with adhesive tape and secured

against impacts. Package should

be bound with a thick tape or sound

ropes and the transportation rules

on the package should be strictly

observed.

3. Original packaging and foam

materials should be kept for future

transportations or moving.

Before you start the refrigerator,

Check the following before you

start to use your refrigerator:

1. Attach 2 plastic wedges as

illustrated below. Plastic wedges are

intended to keep the distance which

will ensure the air circulation between

your refrigerator and the wall. (The

picture is drawn up as a representation

and it is not identical with your

product.)

2. Clean the interior of the

refrigerator as recommended in the

“Maintenance and cleaning” section.

3. Connect the plug of the

refrigerator to the wall socket. When

the fridge door is opened, fridge

internal lamp will turn on.

4. When the compressor starts to

operate, a sound will be heard. The

liquid and gases sealed within the

refrigeration system may also give rise

to noise, even if the compressor is not

running and this is quite normal.

5. Front edges of the refrigerator

may feel warm. This is normal. These

areas are designed to be warm to

avoid condensation.

Electrical connection

Connect your product to a grounded

socket which is being protected by a

fuse with the appropriate capacity.

Important:

The connection must be in compliance

with national regulations.

• The power plug must be easily

accessible after installation.

• Electrical safety of your refrigerator

shall be guaranteed only if the earth

system in your house complies with

standards.

• The voltage stated on the label

located at left inner side of your

product should be equal to your

network voltage.

• Extension cables and multi plugs

must not be used for connection.

BA damaged power cable must be

replaced by a qualified electrician.

BProduct must not be operated before

it is repaired! There is the risk of

electric shock!

10 EN

Disposing of the packaging

The packing materials may be

dangerous for children. Keep the

packing materials out of the reach

of children or dispose of them by

classifying them in accordance with the

waste instructions stated by your local

authorities. Do not throw away with

regular house waste, throw away on

packaging pick up spots designated by

the local authorities.

The packing of your refrigerator is

produced from recyclable materials.

Disposing of your old

refrigerator

Dispose of your old refrigerator without

giving any harm to the environment.

• You may consult your authorized

dealer or waste collection center of

your municipality about the disposal of

your refrigerator.

Before disposing of your refrigerator,

cut out the electric plug and, if there

are any locks on the door, make them

inoperable in order to protect children

against any danger.

Placing and Installation

AIf the entrance door of the room

where the refrigerator will be installed is

not wide enough for the refrigerator to

pass through, then call the authorized

service to have them remove the doors

of your refrigerator and pass it sideways

through the door.

1. Install your refrigerator to a

place that allows ease of use.

2. Keep your refrigerator away

from heat sources, humid places and

direct sunlight.

3. There must be appropriate air

ventilation around your refrigerator in

order to achieve an efficient operation.

If the refrigerator is to be placed in a

recess in the wall, there must be at

least 5 cm distance with the ceiling

and at least 5 cm with the wall. Do not

place your product on the materials

such as rug or carpet.

4. Place your refrigerator on an

even floor surface to prevent jolts.

Andere Handbücher für PBU1153A

Inhaltsverzeichnis

Andere Philco Kühlschrank Handbücher

Philco

Philco PRD-95W Bedienungsanleitung

Philco

Philco PTB 117 D Bedienungsanleitung

Philco

Philco PCN 17732 EBI Bedienungsanleitung

Philco

Philco PTB 1132 Bedienungsanleitung

Philco

Philco PRD-100/4A+ Bedienungsanleitung

Philco

Philco PCE 3181HN/N Bedienungsanleitung

Philco

Philco PX 5261 Bedienungsanleitung

Philco

Philco PSB 401 X Cube Bedienungsanleitung

Philco

Philco PC 1801 Bedienungsanleitung

Philco

Philco PTL 3602 NX Bedienungsanleitung

Philco

Philco PTL 1302 W Bedienungsanleitung

Philco

Philco PT 569 Maestro Bedienungsanleitung

Philco

Philco PCS 2001 Bedienungsanleitung

Philco

Philco PCD 3602 ENF Bedienungsanleitung

Philco

Philco PTL 1302 Bedienungsanleitung

Philco

Philco PTL 3602 NX Bedienungsanleitung

Philco

Philco PHK15BM Einrichtungshandbuch

Philco

Philco PTB 1183 Bedienungsanleitung

Philco

Philco PTB 80 F Bedienungsanleitung

Philco

Philco PT 204 E Bedienungsanleitung

Philco

Philco PCS 2531 F Bedienungsanleitung

Philco

Philco Philco PRD-227W Bedienungsanleitung

Philco

Philco PX 502 Iceberg Bedienungsanleitung

Philco

Philco PC 1721 BI Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
