Philips VOIP1211S/01 Bedienungsanleitung

User manual

ESNO

3Contents

4 Important information

6 What’s in the box

7 Your telephone adapter

8 Install

10 Connect

13 Call

15 Troubleshooting

17 Information

Contents

For your safety

Before installing your USB adapter and software, carefully

read the following information:

Installation information

>In the Windows 2000 and Windows XP operating systems, you

must be logged in as a user with administration rights.

>Desactivate firewall (software / hardware) before installation.

Do not forget to reactivate it after the installation.

>If you have installed an old version IP Phone Center, we suggest

that you uninstall it before you install your USB adapter.

>During installation follow detailed descriptions on the screen.

>Voice quality may depend on the quality of your Internet

connection dial up or broadband.

>Voice quality may vary over time.

>Internet connection behind firewalls may not be supported,

depending on the IP softphone capabilities.

>One softphone only must be active at a given time. To avoid

any conflicts in the use of the adapter, disable the other

softphones than the one in use.

>Use of other softphone than Skype will impact installation &

use of this product.

Safety precautions for the USB adapter

>Only use the USB extension cable supplied.

>Do not connect or disconnect the USB adapter during a storm.

This brings a risk of electric shock.

Important information

Minimum PC requirements

Hardware

BM or 100% compatible PC , 400 MHz processor

8 MB RAM main memory

>30 MB or more free hard disk memory

>1 free USB port (USB1 or USB2 compatible)

>1 CD-ROM drive or 1 DVD drive

Software

>Operating system : Windows 2000 and Windows XP

>33,6 kbps or faster connection to the Internet. Broadband

connection recommended (from 256 kbit/s downlink,

128 kbit/s uplink)

Trademarks

>Windows 2000 and Windows XP are registered trademarks of

the Microsoft Corporation.

>Skype is a registered trademark of Skype Technologies SA.

Need help ?

More troubleshooting and FAQ’s :

Online help: www.p4c.philips.com

Troubleshooting : page 15

Important information

EN What’s in the box

USB adapter USB cable Line telephone cable

RJ11-RJ11

VOIP021

voice over IP telephone adapter

Installation CD

PHI

PC compatible

Version 1.00

Installation IP Phone Center

User manual

Bedienungsanleitung15

Moded’emploi

Bruksanvisning43

User manual

Your telephone adapter

Installation of Skype software

Download Skype software

1Switch on your PC

2Launch internet connection

Go to www.skype.com to download latest version of Skype

software

Install Skype software

Follow instructions displayed on your screen

1Create your Skype account

2Complete your new user profile

>Skype will send a confirmation email to the mail address declared in

your profile.

WARNING Download time is linked to

your speed connection

Installation involves various steps in which

you can select a number of options. After

each step confirm your selection with

Continue/Next to continue with the

installation procedure. Use Back to return

to your previous selection

Install

Create contacts in Skype

1Press + to add a contact

2Enter Skype name of your relation and follow instructions

3Go in tab Contacts, press mouse right key and select Assign

Speed-Dial

4Assign a number between 0 to 99 for this new contact to

directly call from your telephone

Repeat these 4 steps for each new contact.

This number will be the speed dial key of

your contact

Install

Install the adapter

Load CD Rom

Close all the programs (except Internet navigator)

running on your PC

1Insert the installation CD in your PC’s CD-ROM drive.

>The setup Wizard software is started automatically

2Follow instructions displayed on your screen

3Reboot system once installation finished

4After PC reboot, select your Skype name from the choice list

WARNING Do not connect adapter

before CD-ROM installation is completed.

If the Setup Wizard software does not start

automatically :

>Open Windows Explorer

>Select the CD-ROM drive

>Double-click Autorun.exe

Installation involves various steps in which

you can select a number of options. After

each step confirm your selection with

Continue/Next to continue with the

installation procedure. Use Back to return

to your previous selection

Connect
