Philips HP4640/00 Bedienungsanleitung

Satin curl aqua

HP4640

/01

1234

5678

910 11

ENGLISH 6

BAHASA MELAYU 10

BAHASA INDONESIA 14

TI”NG VI◊T 18

 22

HP4640

Introduction

This new Philips Satin curl aqua has been specially designed to give

beautiful styling results in a quick and easy way. Its steam function allows

you to make healthy and shiny curls or waves at any time.

Important

Read these instructions for use carefully before using the appliance and

save them for future reference.

◗Check if the voltage indicated on the appliance corresponds to

the local mains voltage before you connect the appliance.

◗Check the condition of the mains cord regularly. Do not use the

appliance if the plug, the cord or the appliance itself is damaged.

◗If the mains cord is damaged, it must be replaced by Philips, a

service centre authorised by Philips or similarly qualified persons

in order to avoid a hazard.

◗Keep this appliance away from water! Do not use this product

near or over water contained in baths, washbasins, sinks etc. If

you use it in a bathroom, unplug the appliance after use, since the

proximity of water presents a risk.

◗For additional protection we advise you to install a residual

current device (RCD) with a rated residual operating current

not exceeding 30mA in the electrical circuit supplying the

bathroom.Ask your installer for advice.

◗Keep the appliance out of the reach of children.

◗Only use the appliance on dry or damp hair.

◗The barrel of the brush becomes hot during use. Prevent contact

with the skin.

◗If the appliance falls into water, unplug it immediately and never

use it again.

◗Wait until the appliance has cooled down before storing it.

◗Always unplug the appliance after use.

◗Do not wind the mains cord round the appliance.

ENGLISH6

Preparing for use

1Unscrew the Cool Tip water reservoir from the brush (fig. 1).

2Fill the reservoir with water to the maximum level indication

under a gently running tap (fig. 2).

3Hold the appliance vertically with the brush end pointing

downwards, and screw the reservoir back onto the brush (fig. 3).

4Unscrew the reservoir a quarter turn and tighten it again to

ensure proper fastening and to prevent leakage.

Using the appliance

BBefore styling, comb or brush your hair so that it is completely

untangled and smooth.

BWe advise you to perform a curl test to determine how long the brush

should be held in your hair to achieve a good result. Start with 8 to 10

seconds.You may have to hold the brush in your hair longer for tighter

curls. Less tight curls will require less than 8 seconds.

1Insert the mains plug into the wall socket (fig. 4).

The pilot light goes on and the appliance starts heating up.

◗The appliance is ready for use after approx. 15 minutes.

2Start styling when the ready dot on the attachment changes

colour (fig. 5).

3Take a lock of hair and wind it round the brush. Make sure the

end of the lock is wound in the required direction (fig. 6).

Do not wind too much hair round the barrel at a time.

The thinner the lock of hair, the tigher the curl will be.

Do not wind a lock of hair more than twice round the brush.

Make sure the lock of hair is in contact with the barrel of the brush.

4Activate the steam function by pushing the Cool Tip water

reservoir into the barrel. Keep it pressed in for up to 3 seconds

before releasing it (fig. 7).

ENGLISH 7

One push will suffice to set one curl or wave.

5Hold the brush in place as long as required (normally 8 to

10 seconds) (fig. 8).

6To remove the brush from your hair, push the button and slide

the brush out of your hair (fig. 9).

Make sure you keep the brush away from the underlying hair when

you remove it.

7Let the curls cool down before combing, brushing or finger-

combing the hair to finish your style (fig. 10).

Cleaning

Always unplug the appliance before cleaning it.

Never rinse the appliance with water.

1Clean the appliance with a small brush or a dry cloth.

2To prevent the build-up of scale, put 3-4 drops of vinegar in the

Cool Tip water reservoir, top it up with water and plug in the

appliance.After a few minutes, i.e. when the ready dot has turned

black, activate the steam function for 3 seconds.Activate the

steam function 10 more times, then unplug the appliance and

rinse the Cool Tip water reservoir with fresh water.

Storage

Always unplug the appliance before storing it.

◗Unscrew the Cool Tip water reservoir and pour out the

remaining water (fig. 11).

◗Put the appliance in a safe place and let it cool down before

storing it.

◗Do not wind the mains cord round the appliance.

ENGLISH8

Guarantee & service

If you need information or if you have a problem, please visit the Philips

website at www.philips.com or contact the Philips Customer Care

Centre in your country (you will find its phone number in the

worldwide guarantee leaflet). If there is no Customer Care Centre in

your country, turn to your local Philips dealer or contact the Service

Department of Philips Domestic Appliances and Personal Care BV.

ENGLISH 9

Pendahuluan

Akua ikal Philips Satin baru ini telah direka bentuk khusus untuk

menghasilkan gaya yang menawan dengan pantas dan mudah. Fungsi

wapnya membolehkan anda membuat ikal atau keriting yang sihat dan

bersinar pada bila-bila masa.

Penting

Baca arahan penggunaan ini dengan teliti sebelum menggunakan

perkakas dan simpankannya sebagai rujukan masa depan.

◗Periksa sama ada voltan yang dinyatakan pada perkakas sepadan

dengan voltan sesalur tempatan sebelum anda menyambungkan

perkakas.

◗Periksa keadaan kord sesalur dengan kerap. Jangan gunakan

perkakas jika plag, kord atau perkakas itu sendiri rosak.

◗Jika kord sesalur rosak, ia mesti digantikan oleh Philips, atau pusat

servis yang disahkan oleh Philips, atau orang dengan kelayakan

seumpamanya, untuk mengelakkan bahaya.

◗Jauhkan peralatan ini dari air! Jangan gunakan produk ini

berhampiran atau di atas air yang bertakung dalam tab mandi,

besin air, sinki dsb. Jika anda menggunakannya di dalam bilik air,

cabut peralatan selepas digunakan, kerana adanya air berdekatan

mendatangkan risiko.

◗Sebagai perlindungan tambahan lebih baik untuk melindungi litar

elektrik yang membekalkan bilik mandi dengan suis penutup litar

elektrik yang menghentikan arus lebih dari 30 mA. Menanyai

nasihat pemasang.

◗Jauhkan perkakas daripada capaian kanak-kanak.

◗Gunakan perkakas hanya pada rambut yang kering atau lembap.

◗Laras berus menjadi panas semasa digunakan. Elakkan terkena

pada kulit.

◗Jika peralatan terjatuh ke dalam air, cabutnya serta-merta dan

jangan sekali-kali digunakan lagi.

◗Tunggu sehingga perkakas sejuk sebelum menyimpannya.

◗Cabutkan plag perkakas setiap kali selepas menggunakannya.

◗Jangan lilitkan kord sesalur di sekeliling perkakas.

BAHASA MELAYU10
